QwF1TDContainer Class Reference

F1TDCs configuration and reference siganls container. More...

#include <QwF1TDContainer.h>

Inherits TObject.

Collaboration diagram for QwF1TDContainer:

Public Member Functions
	QwF1TDContainer ()
virtual	~QwF1TDContainer ()
void	SetSystemName (const TString name)
const TString	GetSystemName () const
void	AddQwF1TDC (QwF1TDC *in)
void	Print (const Option_t *options=0) const
Int_t	GetSize () const
Int_t	Size () const
Int_t	HowManyF1TDCs () const
EQwDetectorType	GetDetectorType () const
EQwRegionID	GetRegion () const
QwF1TDC *	GetF1TDC (Int_t roc, Int_t slot)
QwF1TDC *	GetF1TDCwithIndex (Int_t tdc_index)
QwF1TDC *	GetF1TDCwithBankIndexSLOT (Int_t bank_index, Int_t slot)
Double_t	GetF1TDCOneResolution () const
Double_t	DoneF1TDCsConfiguration ()
Double_t	ReturnTimeCalibration (Double_t time_arb_unit)
Int_t	GetF1TDCChannelNumber ()
	Double_t GetF1TDCResolution();. More...
const TH2F *	GetF1TDCErrorHist ()
void	AddSYN (Int_t roc, Int_t slot, Int_t channel)
void	AddEMM (Int_t roc, Int_t slot, Int_t channel)
void	AddSEU (Int_t roc, Int_t slot, Int_t channel)
void	AddTFO (Int_t roc, Int_t slot, Int_t channel)
void	AddRLF (Int_t roc, Int_t slot, Int_t channel)
void	AddHFO (Int_t roc, Int_t slot, Int_t channel)
void	AddOFO (Int_t roc, Int_t slot, Int_t channel)
void	AddFDF (Int_t roc, Int_t slot, Int_t channel)
void	AddS30 (Int_t roc, Int_t slot, Int_t channel)
Bool_t	CheckDataIntegrity (const UInt_t roc_id, UInt_t *buffer, UInt_t num_words)
const MQwF1TDC	GetF1TDCDecoder () const
Double_t	ReferenceSignalCorrection (Double_t raw_time, Double_t ref_time, Int_t bank_index, Int_t slot)
void	PrintErrorSummary ()
void	WriteErrorSummary (Bool_t hist_flag=true)

Data Fields
Int_t	fNQwF1TDCs
TObjArray *	fQwF1TDCList
EQwDetectorType	fDetectorType
EQwRegionID	fRegion
TString	fSystemName
TH2F *	fError2DHist

Private Member Functions
Double_t	GetF1TDCsResolution ()
TList *	GetErrorSummary ()
TString	PrintNoF1TDC (Int_t roc, Int_t slot)
TString	PrintNoF1TDC (Int_t tdc_index)
Bool_t	CheckRegisteredF1 (Int_t roc, Int_t slot)
Double_t	GetF1TDCTriggerRollover ()
void	SetErrorHistOptions ()
Bool_t	CheckSlot20Chan30 (Int_t slot, Int_t chan)
	ClassDef (QwF1TDContainer, 1)

Private Attributes
MQwF1TDC	fF1TDCDecoder
Bool_t	fLocalF1RawDecodeDebug
Bool_t	fLocalF1DecodeDebug
Bool_t	fLocalDebug
Bool_t	fLocalF1ErrorDebug
Double_t	fF1TDCOneResolutionNS
Double_t	fF1TDCTriggerRollover

Detailed Description

F1TDCs configuration and reference siganls container.

This would be used to be a configuration and reference signal(s) container for F1TDCs which are used in one subsystem. The subsystem has one QwF1TDContaier that have DetectorType, Region, and QwF1TDC(s)

Definition at line 266 of file QwF1TDContainer.h.

Constructor & Destructor Documentation

QwF1TDContainer::QwF1TDContainer

(

)

Definition at line 770 of file QwF1TDContainer.cc.

References fDetectorType, fError2DHist, fLocalDebug, fLocalF1DecodeDebug, fLocalF1ErrorDebug, fLocalF1RawDecodeDebug, fNQwF1TDCs, fQwF1TDCList, fRegion, kRegionIDNull, and kTypeNull.

{
  fQwF1TDCList = new TObjArray();

  fQwF1TDCList -> Clear();
  fQwF1TDCList -> SetOwner(kTRUE);

  fError2DHist = new TH2F;
  fError2DHist -> SetBins(3,0,3,2,0,2);

  // kCanRebin removed in ROOT 6
  // Ref: https://root.cern.ch/content/main-histogram-changes-root-6
#if ROOT_VERSION_CODE < ROOT_VERSION(5,90,0)
  fError2DHist -> SetBit(TH1::kCanRebin);
#else
  fError2DHist -> SetCanExtend(TH1::kAllAxes);
#endif
  fError2DHist -> SetStats(0);

  fNQwF1TDCs = 0;
  fDetectorType = kTypeNull;
  fRegion       = kRegionIDNull;


  fLocalF1RawDecodeDebug = false; // Before checking "subsystem"
  fLocalF1DecodeDebug    = false; //  After cheking "subsystem"
  //level 0

  fLocalDebug        = false; // level 1 // not well defined...
  fLocalF1ErrorDebug = false; // Error logs

}

QwF1TDContainer::~QwF1TDContainer ( )

virtual

Definition at line 804 of file QwF1TDContainer.cc.

References fError2DHist, and fQwF1TDCList.

{
  if(fQwF1TDCList) delete fQwF1TDCList; fQwF1TDCList = NULL;
  if(fError2DHist) delete fError2DHist; fError2DHist = NULL;
}

Member Function Documentation

void QwF1TDContainer::AddEMM	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 932 of file QwF1TDContainer.cc.

References QwF1TDC::AddEMM(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddEMM(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddEMM : " << PrintNoF1TDC(roc,slot)  << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddFDF	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 1033 of file QwF1TDContainer.cc.

References QwF1TDC::AddFDF(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddFDF(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddFDF : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddHFO	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 1000 of file QwF1TDContainer.cc.

References QwF1TDC::AddHFO(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddHFO(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddHFO : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddOFO	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 1016 of file QwF1TDContainer.cc.

References QwF1TDC::AddOFO(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddOFO(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddOFO : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddQwF1TDC

(

QwF1TDC *

in

)

Definition at line 813 of file QwF1TDContainer.cc.

References fLocalDebug, fNQwF1TDCs, and fQwF1TDCList.

Referenced by QwTriggerScintillator::ProcessConfigurationBuffer(), QwSciFiDetector::ProcessConfigurationBuffer(), QwMainDetector::ProcessConfigurationBuffer(), QwDriftChamber::ProcessConfigurationBuffer(), and QwScanner::ProcessConfigurationBuffer().

{
  Int_t pos = 0;

  pos = fQwF1TDCList -> AddAtFree(in);
  if(fLocalDebug) {
    printf("AddQwF1TDC at pos %d\n", pos);
  }

  fNQwF1TDCs++;
  return;
}

Here is the caller graph for this function:

void QwF1TDContainer::AddRLF	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 983 of file QwF1TDContainer.cc.

References QwF1TDC::AddRLF(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddRLF(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddRLF : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddS30	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 1051 of file QwF1TDContainer.cc.

References QwF1TDC::AddS30(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);
  if(F1) {
    F1->AddS30(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddS30 : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

void QwF1TDContainer::AddSEU	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 949 of file QwF1TDContainer.cc.

References QwF1TDC::AddSEU(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddSEU(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddSEU : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddSYN	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 916 of file QwF1TDContainer.cc.

References QwF1TDC::AddSYN(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddSYN(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddSYN : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::AddTFO	(	Int_t	roc,
		Int_t	slot,
		Int_t	channel
	)

Definition at line 966 of file QwF1TDContainer.cc.

References QwF1TDC::AddTFO(), fLocalF1ErrorDebug, GetF1TDC(), QwF1TDC::PrintChannelErrorCounter(), and PrintNoF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) {
    F1->AddTFO(channel);
    if(fLocalF1ErrorDebug) F1->PrintChannelErrorCounter(channel);
  }
  else {
    if(fLocalF1ErrorDebug) std::cout << "QwF1TDContainer::AddTFO : " << PrintNoF1TDC(roc,slot) << std::endl;
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t QwF1TDContainer::CheckDataIntegrity	(	const UInt_t	roc_id,
		UInt_t *	buffer,
		UInt_t	num_words
	)

Definition at line 1405 of file QwF1TDContainer.cc.

References AddEMM(), AddFDF(), AddHFO(), AddOFO(), AddRLF(), AddSEU(), AddSYN(), AddTFO(), CheckRegisteredF1(), CheckSlot20Chan30(), MQwF1TDC::DecodeTDCWord(), QwLog::endl(), fError2DHist, fF1TDCDecoder, fLocalDebug, fLocalF1DecodeDebug, fLocalF1RawDecodeDebug, GetF1TDCTriggerRollover(), GetSystemName(), MQwF1TDC::GetTDCChannelAddress(), MQwF1TDC::GetTDCChannelNumber(), MQwF1TDC::GetTDCChipAddress(), MQwF1TDC::GetTDCEventNumber(), MQwF1TDC::GetTDCHeaderEventNumber(), MQwF1TDC::GetTDCHeaderTriggerTime(), MQwF1TDC::GetTDCSlotNumber(), MQwF1TDC::GetTDCTriggerTime(), MQwF1TDC::IsFakeData(), MQwF1TDC::IsHeaderword(), MQwF1TDC::IsHeaderXorSetup(), MQwF1TDC::IsHitFIFOOverFlow(), MQwF1TDC::IsNotHeaderTrigFIFO(), MQwF1TDC::IsOutputFIFOOverFlow(), MQwF1TDC::IsResolutionLock(), MQwF1TDC::IsValidDataSlot(), and QwMessage.

Referenced by QwSciFiDetector::ProcessEvBuffer(), QwTriggerScintillator::ProcessEvBuffer(), QwDriftChamber::ProcessEvBuffer(), QwMainDetector::ProcessEvBuffer(), and QwScanner::ProcessEvBuffer().

{



  // three counter flags
  Bool_t hit_fifo_overflow_flag    = kFALSE;
  Bool_t output_fifo_overflow_flag = kFALSE;
  Bool_t chip_resolution_lock_flag = kTRUE;

  // real DataIntegrity Check
  Bool_t event_ok_flag              = kFALSE;
  Bool_t trig_time_ok_flag          = kFALSE;
  Bool_t trig_fifo_ok_flag          = kFALSE;

  // data integrity flags
  Bool_t data_integrity_flag        = kFALSE;
  Bool_t data_integrity_unlock_flag = kTRUE; // unlock first


  // SEU
  Bool_t xor_setup_flag     = kFALSE;
  Bool_t fake_data_flag     = kFALSE;


  UInt_t  slot_number         = 0;
  UInt_t  channel_number      = 0;
  UInt_t  chip_address        = 0;
  UInt_t  channel_address     = 0;

  UInt_t reference_trig_time = 0;
  UInt_t reference_event_num = 0;


  Double_t trigger_rollover = 0.0;
  Int_t    rounded_trigger_rollover = 0;
  Int_t    diff_trigger_time = 0;

  trigger_rollover         = GetF1TDCTriggerRollover();
  rounded_trigger_rollover = (Int_t) trigger_rollover;

  //  fLocalDebug = true;
  if(fLocalDebug) printf("roc_id %d trigger rollover %f, %d\n", roc_id, trigger_rollover, rounded_trigger_rollover);


  const Int_t valid_trigger_time_offset[3] = {0, 1, rounded_trigger_rollover};


  if(fLocalF1DecodeDebug) {
    QwMessage << "\n\n" << QwLog::endl;
    QwMessage << GetSystemName()
              << " ROC " << roc_id
              << " num_words (buffer size) " << num_words
              << QwLog::endl;
  }

  Int_t subsystem_cnt = 0;
  TString roc_idx;

  if(fLocalF1RawDecodeDebug) {
    printf("%s at %s nwrds %d\n",
     __PRETTY_FUNCTION__, GetSystemName().Data(), num_words);
  }

  for (UInt_t i=0; i<num_words ; i++)
    {
      fF1TDCDecoder.DecodeTDCWord(buffer[i], roc_id);
      // without any further process
      // check the decoding....

      if(fLocalF1RawDecodeDebug) {
  std::cout << "[" << std::setw(3) << i
      << "," << std::setw(3) << i
      << "] "
      << fF1TDCDecoder << std::endl;
      }


      slot_number     = fF1TDCDecoder.GetTDCSlotNumber();

      if(fF1TDCDecoder.IsValidDataSlot()) {
  // Check F1TDC slot, provided by buffer[i], is valid (1<=slot<=21)
  //, because sometimes, slot 30 data (junk) is placed in the first one
  // or two buffers.

  chip_address    = fF1TDCDecoder.GetTDCChipAddress();
  channel_address = fF1TDCDecoder.GetTDCChannelAddress();
  channel_number  = fF1TDCDecoder.GetTDCChannelNumber();


  // if(fLocalDebug) {
  //   // this is for tracking down missing wires in Region 2
  //   // a quick and dirty way to check
  //   // Monday, December 20 10:38:38 EST 2010, jhlee
  //      it turned out "loosing cabling....
  //      Saturday, January  8 01:54:02 EST 2011, jhlee

  //   if( (slot_number==10) and (roc_id==3) ) {
  //     if( (channel_number == 19) ||  (channel_number == 21) || (channel_number == 23) || (channel_number == 25)
  //  || (channel_number == 27) ||  (channel_number == 29) || (channel_number == 31) || (channel_number == 17)
  //  )
  //       {
  //  printf("Roc %2d Slot%2d Ch %2d \n", roc_id, slot_number, channel_number);
  //       }
  //   }
  // }

  roc_idx = Form("R%2d-S%2d", roc_id, slot_number);

  // We use the multiblock data transfer for F1TDC, thus
  // we must get the event number and the trigger time from the first buffer
  // (buffer[0]), and these valuse can be used to check "data" integrity
  // over all F1TDCs.
  // Each Subsystem uses the same buffer[0] even if their interesting F1
  // is not in the SLOT 4

  if ( i ==0 ) {
    if ( fF1TDCDecoder.IsHeaderword() ) {
      reference_event_num = fF1TDCDecoder.GetTDCEventNumber();
      reference_trig_time = fF1TDCDecoder.GetTDCTriggerTime();

      trig_fifo_ok_flag = fF1TDCDecoder.IsNotHeaderTrigFIFO();
      if(not trig_fifo_ok_flag) {
        // temp solution ....
        if(not CheckSlot20Chan30(slot_number, channel_number)) {
    this -> AddTFO(roc_id, slot_number, channel_number);
      fError2DHist -> Fill(roc_idx.Data(), "TFO",1);
    }
      }

    }
    else {
      printf("The first word of F1TDC must be header word. Check CODA stream and QwF1TDContainer::CheckDataIntegrity fucntion.\n");
      return false;
    }
  }

  // Check F1TDC status is inside a subsystem

  if( CheckRegisteredF1(roc_id, slot_number) ) {

    // Check F1TDC data, provided by buffer[i], is valid in each subsystem
    //    subsystem_cnt = 0;

    if(fLocalF1DecodeDebug) {

      std::cout << "[" << std::setw(3) << i
          << "," << std::setw(3) << subsystem_cnt
          << "] "
          << fF1TDCDecoder << std::endl;
    }
    subsystem_cnt++;
    // Both header and data words have HFO, OFO, and RLF
    hit_fifo_overflow_flag    = fF1TDCDecoder.IsHitFIFOOverFlow();
    output_fifo_overflow_flag = fF1TDCDecoder.IsOutputFIFOOverFlow();
    chip_resolution_lock_flag = fF1TDCDecoder.IsResolutionLock();


    if(hit_fifo_overflow_flag) {
      if(not CheckSlot20Chan30(slot_number, channel_number)) {
    this->AddHFO(roc_id, slot_number, channel_number);
    // one event creates the maximum 9 HFOs
    // but the number is within the range of 1 - 9

    fError2DHist -> Fill(roc_idx.Data(), "HFO",1);

    if(fLocalDebug) {
      std::cout << "There is the Hit FIFO Overflow on the F1TDC board at"
          << " ROC "  << roc_id
          << " Slot " << slot_number
          << " Ch " << std::setw(3) << channel_number
          << "[" << chip_address
          << "," << channel_address
          << "]\n";
    }
        }
    }

    if(output_fifo_overflow_flag)  {
      if(not CheckSlot20Chan30(slot_number, channel_number)) {
        this->AddOFO(roc_id, slot_number, channel_number);
        fError2DHist -> Fill(roc_idx.Data(), "OFO",1);
        if(fLocalDebug) {
    std::cout << "There is the Output FIFO Overflow on the F1TDC board at"
        << " ROC "  << roc_id
        << " Slot " << slot_number
        << " Ch " << std::setw(3) << channel_number
        << "[" << chip_address
        << "," << channel_address
        << "]\n";

        }
      }
    }

    if(not chip_resolution_lock_flag) {
      if(not CheckSlot20Chan30(slot_number, channel_number)) {
        this->AddRLF(roc_id, slot_number, channel_number);
        fError2DHist -> Fill(roc_idx.Data(), "RLF",1);
        if(fLocalDebug) {
    std::cout << "There is the Resolution Lock Failed on the F1TDC board at"
        << " ROC "  << roc_id
        << " Slot " << slot_number
        << " Ch " << std::setw(3) << channel_number
        << "[" << chip_address
        << "," << channel_address
        << "]\n";
        }
      }
    }

    // check only header word

    if ( fF1TDCDecoder.IsHeaderword() ) {


      xor_setup_flag    = fF1TDCDecoder.IsHeaderXorSetup();
      trig_fifo_ok_flag = fF1TDCDecoder.IsNotHeaderTrigFIFO();
      event_ok_flag     = ( reference_event_num==fF1TDCDecoder.GetTDCHeaderEventNumber() );
      diff_trigger_time = abs( int(reference_trig_time)-int(fF1TDCDecoder.GetTDCHeaderTriggerTime()) );

      trig_time_ok_flag =
        (diff_trigger_time == valid_trigger_time_offset[0])
        ||
        (diff_trigger_time == valid_trigger_time_offset[1])
        ||
        (diff_trigger_time == valid_trigger_time_offset[2]);

      // trig_time_ok_flag = abs( reference_trig_time-fF1TDCDecoder.GetTDCHeaderTriggerTime() ) <= valid_trigger_time_offset;

      // if no SEU, check Trigger FIFO Overflow, Trigger Time, and Event Number

      if (xor_setup_flag) {

        if(not trig_fifo_ok_flag) {
    if(not CheckSlot20Chan30(slot_number, channel_number)) {
      this -> AddTFO(roc_id, slot_number, channel_number);
      fError2DHist -> Fill(roc_idx.Data(), "TFO",1);
      if(fLocalDebug) {
        std::cout << "There is the Trigger FIFO overflow at"
            << " ROC "  << roc_id
            << " Slot " << slot_number
            << " Ch " << std::setw(3) << channel_number
            << "[" << chip_address
            << "," << channel_address
            << "]\n";

      }
    }
        }

        // Trigger Time difference of up to 1 count among the chips is acceptable
        // For the Trigger Time, this assumes that an external SYNC_RESET signal has
        // been successfully applied at the start of the run

        if (not trig_time_ok_flag) {
    if(not CheckSlot20Chan30(slot_number, channel_number)) {
      this->AddSYN(roc_id, slot_number, channel_number);
      fError2DHist -> Fill(roc_idx.Data(), "SYN",1);
      if(fLocalDebug) {
        std::cout << "There is the Trigger Time Mismatch on the F1TDC board at"
            << " ROC "  << roc_id
            << " Slot " << slot_number
            << " Ch " << std::setw(3) << channel_number
            << "[" << chip_address
            << "," << channel_address
            << "]\n";
      }
    }

        }
        // Any difference in the Event Number among the chips indicates a serious error
        // that requires a reset of the board.

        if (not event_ok_flag) {
    if(not CheckSlot20Chan30(slot_number, channel_number)) {
      this->AddEMM(roc_id, slot_number, channel_number);
      fError2DHist -> Fill(roc_idx.Data(), "EMM",1);
      if(fLocalDebug) {
        std::cout << "There is the Event Number Mismatch issue on the F1TDC board at"
            << " ROC "  << roc_id
            << " Slot " << slot_number
            << " Ch " << std::setw(3) << channel_number
            << "[" << chip_address
            << "," << channel_address
            << "]\n";
      }
    }
        }


        if(data_integrity_unlock_flag) {
    // check data_integrity_flag = false once (not initial value),
    // if so, we skip the further process to check
    // data integrity, because it is alreay invalid
    // data we have.

    data_integrity_flag = (event_ok_flag) && (trig_time_ok_flag) && (trig_fifo_ok_flag) ;
    if(data_integrity_flag) data_integrity_unlock_flag = true;    // true  -> not lock -> check it again
    else                    data_integrity_unlock_flag = false;   // false -> lock  -> no check it again -> return false;
        }
      } // if(xor_setup_flag) {


      // ignore SEU first, then we count them how frequently they are,
      // because there is no way to seperate SEU and the data integrity.
      // data integrity is valid within all buffer, but SEU is valid
      // for only when it is (header and dataword)

      else {
        if(not CheckSlot20Chan30(slot_number, channel_number)) {
    this->AddSEU(roc_id, slot_number, channel_number);
    fError2DHist -> Fill(roc_idx.Data(), "SEU",1);
    if (fLocalDebug) {
      std::cout << "There is the Single Event Upset (SEU) on the F1TDC board at"
          << " ROC "  << roc_id
          << " Slot " << slot_number
          << " Ch " << std::setw(3) << channel_number
          << "[" << chip_address
          << "," << channel_address
          << "]\n";
    }
        }
      }
    } //   if ( fF1TDCDecoder.IsHeaderword() ) {
    else {
      //      fF1TDCDecoder.Print(true);
      fake_data_flag = fF1TDCDecoder.IsFakeData();
      if(fake_data_flag) {
        if(not CheckSlot20Chan30(slot_number, channel_number)) {
    this->AddFDF(roc_id, slot_number, channel_number);
    fError2DHist -> Fill(roc_idx.Data(), "FDF",1);
    if(fLocalDebug) {
      std::cout << "There is the Fake Data on the F1TDC board at"
          << " ROC "  << roc_id
          << " Slot " << slot_number
          << " Ch " << std::setw(3) << channel_number
          << "[" << chip_address
          << "," << channel_address
          << "]\n";
    }
        }
      }

      // dataword

      //      if(!fF1TDCDecoder.IsOverFlowEntry()) fF1TDCDecoder.PrintTDCData(fLocalDebug);
    }//;;

  } // if( CheckRegisteredF1(roc_id, slot_number) ) {




      }//if(fF1TDCDecoder.IsValidDataSlot()) {
      else {

  //  slot_number = fF1TDCDecoder.GetTDCSlotNumber();
  if( slot_number == 0 ) {
    if(fLocalDebug)  {
      std::cout << "Slot " << slot_number << " is a filler word,"
          << " then we ignore it." << std::endl;
    }
  }
  else if( slot_number == 30 ) {
    // Slot 30 is not in the list of F1TDCs in a subsystem.
    // we cannot add this counter into QwF1TDC.
    // Now just leave what I wrote for a possible future release.
    // Tuesday, September 21 15:19:34 EDT 2010, jhlee
    // this->AddS30(roc_id, slot_number);
    if(fLocalDebug)  {
      std::cout << "Slot " << slot_number << " is a junk  word,"
          << " then we ignore it." << std::endl;
    }
  }
  else {
    std::cout << "Slot " << slot_number << " is not in the reasonable slot,"
        << " then we ignore it, but it is better to check what it is going on CODA stream." << std::endl;
  }
      }



    }//for (UInt_t i=0; i<num_words ; i++) {

  if(fLocalF1RawDecodeDebug) printf("\n");
  return (data_integrity_flag);
}

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t QwF1TDContainer::CheckRegisteredF1 ( Int_t  roc, Int_t  slot  )

private

Definition at line 1887 of file QwF1TDContainer.cc.

References GetF1TDC().

Referenced by CheckDataIntegrity().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDC(roc, slot);

  if(F1) return true;
  else   return false;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Bool_t QwF1TDContainer::CheckSlot20Chan30 ( Int_t  slot, Int_t  chan  )

private

Definition at line 1898 of file QwF1TDContainer.cc.

Referenced by CheckDataIntegrity().

{
  return ( (slot==20) and (chan==30) );
}

Here is the caller graph for this function:

QwF1TDContainer::ClassDef ( QwF1TDContainer  , 1    )

private

Double_t QwF1TDContainer::DoneF1TDCsConfiguration

(

)

Definition at line 1907 of file QwF1TDContainer.cc.

References fF1TDCOneResolutionNS, and GetF1TDCsResolution().

Referenced by QwTriggerScintillator::ProcessConfigurationBuffer(), QwSciFiDetector::ProcessConfigurationBuffer(), QwMainDetector::ProcessConfigurationBuffer(), QwDriftChamber::ProcessConfigurationBuffer(), and QwScanner::ProcessConfigurationBuffer().

{
  //
  // reduce call "GetF1TDCsResolution" inside subsystem...
  //
  fF1TDCOneResolutionNS = this->GetF1TDCsResolution();
  return fF1TDCOneResolutionNS;
}

Here is the call graph for this function:

Here is the caller graph for this function:

EQwDetectorType QwF1TDContainer::GetDetectorType ( ) const

inline

Definition at line 288 of file QwF1TDContainer.h.

References fDetectorType.

Referenced by Print().

{return fDetectorType;}

Here is the caller graph for this function:

TList * QwF1TDContainer::GetErrorSummary ( )

private

Definition at line 1368 of file QwF1TDContainer.cc.

References fQwF1TDCList, and QwF1TDC::GetErrorCounter().

Referenced by WriteErrorSummary().

{

  TList *error_list = new TList;
  error_list->SetOwner(true);

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;

  while ( (obj = next()) )
    {
      QwF1TDC* F1 = (QwF1TDC*) obj;
      TString error = F1->GetErrorCounter();
      error_list -> Add(new TObjString(error));
    }

  return error_list;
}

Here is the call graph for this function:

Here is the caller graph for this function:

QwF1TDC * QwF1TDContainer::GetF1TDC	(	Int_t	roc,
		Int_t	slot
	)

Definition at line 828 of file QwF1TDContainer.cc.

References fQwF1TDCList, QwF1TDC::GetROCNumber(), and QwF1TDC::GetSlotNumber().

Referenced by AddEMM(), AddFDF(), AddHFO(), AddOFO(), AddRLF(), AddS30(), AddSEU(), AddSYN(), AddTFO(), and CheckRegisteredF1().

{
  Int_t roc_num  = 0;
  Int_t slot_num = 0;

  //  Int_t unique_id = 0;


  QwF1TDC* F1 = NULL;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;


  while ( (obj = next()) )
    {

      F1 = (QwF1TDC*) obj;
      //      unique_id = F1->GetUniqueID();
      roc_num  = F1->GetROCNumber();
      slot_num = F1->GetSlotNumber();
      if((roc_num == roc) && (slot_num == slot) ) {
  //  if(fLocalDebug) {
  //    std::cout << "System " << F1->GetF1SystemName()
  //        << " QwF1TDContainer::GetF1TDC F1TDC address at" << F1 << std::endl;
  //  }
  return F1;
      }
    }

  return NULL;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Int_t QwF1TDContainer::GetF1TDCChannelNumber

(

)

Double_t GetF1TDCResolution();.

Definition at line 1310 of file QwF1TDContainer.cc.

References fQwF1TDCList, QwF1TDC::GetChannelNumber(), GetSystemName(), QwF1TDC::PrintContact(), and QwF1TDC::PrintF1TDCConfigure().

{

  // F1TDC max channel number must be the same
  // among VME crates and among F1TDC boards
  // We cannot change it on each F1TDC board.
  // Thus, this function return one value of them. (32 or 64)
  // Friday, September  3 13:09:01 EDT 2010, jhlee

  Int_t old_c = 0;
  Int_t new_c = 0;
  Int_t cnt   = 0;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;

  while ( (obj = next()) )
    {
      QwF1TDC* F1 = (QwF1TDC*) obj;
      new_c = F1->GetChannelNumber();
      //  printf("QwF1TDContainer::GetF1TDCChannelNumber() cnt %d, new %d , old %d\n", cnt, new_c, old_c);
      if(cnt not_eq 0) {
  if(old_c not_eq new_c) {
    F1->PrintContact();
    printf("%s : QwF1TDContainer::GetF1TDCChannelNumber(): F1TDC configurations are corrupted!\n",
     GetSystemName().Data());
    F1->PrintF1TDCConfigure();
    return 0;
  }

      }
      old_c = new_c;
      cnt++;
    }

  return old_c;
}

Here is the call graph for this function:

const MQwF1TDC QwF1TDContainer::GetF1TDCDecoder ( ) const

inline

Definition at line 326 of file QwF1TDContainer.h.

References fF1TDCDecoder.

Referenced by QwDriftChamber::QwDriftChamber(), QwMainDetector::QwMainDetector(), QwScanner::QwScanner(), QwSciFiDetector::QwSciFiDetector(), and QwTriggerScintillator::QwTriggerScintillator().

{return fF1TDCDecoder;};

Here is the caller graph for this function:

const TH2F * QwF1TDContainer::GetF1TDCErrorHist

(

)

Definition at line 1811 of file QwF1TDContainer.cc.

References fError2DHist, and SetErrorHistOptions().

{
  this->SetErrorHistOptions();
  return fError2DHist;
}

Here is the call graph for this function:

Double_t QwF1TDContainer::GetF1TDCOneResolution ( ) const

inline

Definition at line 295 of file QwF1TDContainer.h.

References fF1TDCOneResolutionNS.

{return fF1TDCOneResolutionNS;};

Double_t QwF1TDContainer::GetF1TDCsResolution ( )

private

Definition at line 1231 of file QwF1TDContainer.cc.

References fQwF1TDCList, QwF1TDC::GetF1TDC_resolution(), GetSystemName(), QwF1TDC::PrintContact(), and QwF1TDC::PrintF1TDCConfigure().

Referenced by DoneF1TDCsConfiguration().

{

  // F1TDC resolution must be the same
  // among VME crates and among F1TDC boards
  // We cannot change it on each F1TDC board.QwF1TDContainer::GetF1TDCResolution()
  // Thus, this function return one value of them.
  // Wednesday, September  1 16:52:05 EDT 2010, jhlee

  Double_t old_r = 0.0;
  Double_t new_r = 0.0;
  Int_t cnt      = 0;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;

  while ( (obj = next()) )
    {
      QwF1TDC* F1 = (QwF1TDC*) obj;
      new_r = F1->GetF1TDC_resolution();
      if(cnt not_eq 0) {
  if(old_r not_eq new_r) {
    F1->PrintContact();
    printf("%s : QwF1TDContainer::GetF1TDCResolution(): F1TDC configurations are corrupted!\n",
     GetSystemName().Data());
    F1->PrintF1TDCConfigure();

    return 0.0;
  }

      }
      old_r = new_r;
      cnt++;
    }

  return old_r;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Double_t QwF1TDContainer::GetF1TDCTriggerRollover ( )

private

Definition at line 1272 of file QwF1TDContainer.cc.

References fLocalDebug, fQwF1TDCList, QwF1TDC::GetF1TDC_trig_t_offset(), GetSystemName(), QwF1TDC::PrintContact(), and QwF1TDC::PrintF1TDCConfigure().

Referenced by CheckDataIntegrity().

{

  Double_t old_r = 0.0;
  Double_t new_r = 0.0;
  Int_t cnt      = 0;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;

  if(fLocalDebug) printf("\nHow many F1TDC in %s : %d\n", GetSystemName().Data(), fQwF1TDCList->GetEntriesFast());

  while ( (obj = next()) )
    {
      QwF1TDC* F1 = (QwF1TDC*) obj;
      new_r = F1->GetF1TDC_trig_t_offset();
      //      printf("QwF1TDContainer::GetF1TDCTriggerRollover():: cnt %d, new %f , old %f\n", cnt, new_r, old_r);
      if(cnt not_eq 0) {
        if(old_r not_eq new_r) {
    F1->PrintContact();
    printf("%s : QwF1TDContainer::GetF1TDCTriggerRollover(): F1TDC configurations are corrupted!\n",
     GetSystemName().Data());
    F1->PrintF1TDCConfigure();
    return 0.0;
        }

      }
      old_r = new_r;
      cnt++;
    }

  return old_r;
}

Here is the call graph for this function:

Here is the caller graph for this function:

QwF1TDC * QwF1TDContainer::GetF1TDCwithBankIndexSLOT	(	Int_t	bank_index,
		Int_t	slot
	)

Definition at line 888 of file QwF1TDContainer.cc.

References fQwF1TDCList, QwF1TDC::GetF1BankIndex(), and QwF1TDC::GetSlotNumber().

Referenced by ReferenceSignalCorrection().

{
  Int_t bank_idx = 0;
  Int_t slot_num = 0;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;
  QwF1TDC* F1  = NULL;

  while ( (obj = next()) )
    {
      F1       = (QwF1TDC*) obj;
      bank_idx = F1->GetF1BankIndex();
      slot_num = F1->GetSlotNumber();
      if((bank_idx == bank_index) && (slot_num == slot) ) {
  // if(fLocalDebug) {
  //   std::cout << "System " << F1->GetF1SystemName()
  //      << " QwF1TDContainer::GetF1TDC F1TDC address at" << F1 << std::endl;
  // }
  return F1;
      }
    }

  return NULL;
}

Here is the call graph for this function:

Here is the caller graph for this function:

QwF1TDC * QwF1TDContainer::GetF1TDCwithIndex

(

Int_t

tdc_index

)

Definition at line 863 of file QwF1TDContainer.cc.

References fQwF1TDCList, and QwF1TDC::GetF1TDCIndex().

{
  Int_t f1_idx = 0;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;
  QwF1TDC* F1  = NULL;

  while ( (obj = next()) )
    {
      F1     = (QwF1TDC*) obj;
      f1_idx = F1->GetF1TDCIndex();
      if( f1_idx == tdc_index ) {
  // if(fLocalDebug) {
  //   std::cout << "System " << F1->GetF1SystemName()
  //      << " QwF1TDContainer::GetF1TDCIndex F1TDC address at" << F1 << std::endl;
  // }
  return F1;
      }
    }

  return NULL;
}

Here is the call graph for this function:

EQwRegionID QwF1TDContainer::GetRegion ( ) const

inline

Definition at line 289 of file QwF1TDContainer.h.

References fRegion.

Referenced by Print().

{return fRegion;};

Here is the caller graph for this function:

Int_t QwF1TDContainer::GetSize ( ) const

inline

Definition at line 285 of file QwF1TDContainer.h.

References fNQwF1TDCs.

Referenced by Print().

{return fNQwF1TDCs;};

Here is the caller graph for this function:

const TString QwF1TDContainer::GetSystemName ( ) const

inline

Definition at line 280 of file QwF1TDContainer.h.

References fSystemName.

Referenced by CheckDataIntegrity(), GetF1TDCChannelNumber(), GetF1TDCsResolution(), GetF1TDCTriggerRollover(), Print(), PrintNoF1TDC(), and WriteErrorSummary().

{return fSystemName;};

Here is the caller graph for this function:

Int_t QwF1TDContainer::HowManyF1TDCs ( ) const

inline

Definition at line 287 of file QwF1TDContainer.h.

References fNQwF1TDCs.

{return fNQwF1TDCs;};

void QwF1TDContainer::Print

(

const Option_t *

options = 0

)

const

Definition at line 1139 of file QwF1TDContainer.cc.

References QwLog::endl(), fQwF1TDCList, GetDetectorType(), GetRegion(), GetSize(), GetSystemName(), and QwMessage.

Referenced by QwTriggerScintillator::ProcessConfigurationBuffer(), QwSciFiDetector::ProcessConfigurationBuffer(), QwMainDetector::ProcessConfigurationBuffer(), QwDriftChamber::ProcessConfigurationBuffer(), and QwScanner::ProcessConfigurationBuffer().

{

  Int_t size = 0;
  size = this->GetSize();

  QwMessage << "\nQwF1TDContainer::Print() "
            << " QwF1TDContainer in System : "
            << this->GetSystemName()
            << ", DetectorType "
      << this->GetDetectorType()
      << ", RegionType "
            << this->GetRegion()
            << ", How many F1TDCs are : "
            << size
            << QwLog::endl;

  TObjArrayIter next(fQwF1TDCList);
  TObject* obj;
  while ( (obj = next()) )
    {
      QwF1TDC* F1 = (QwF1TDC*) obj;
      QwMessage << "F1TDC object " << F1 << QwLog::endl;
      F1 -> PrintF1TDCBuffer();
      F1 -> PrintF1TDCConfigure();
    }

  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QwF1TDContainer::PrintErrorSummary

(

)

Definition at line 1351 of file QwF1TDContainer.cc.

References fQwF1TDCList.

Referenced by QwScanner::FillHardwareErrorSummary().

{
  printf("-----------------------\n");
  TObjArrayIter next(fQwF1TDCList);
  TObject* obj = NULL;
  while ( (obj = next()) )
    {
      QwF1TDC* F1 = (QwF1TDC*) obj;

      F1 -> PrintTotalErrorCounter();
    }
  printf("-----------------------\n");
  return;
}

Here is the caller graph for this function:

TString QwF1TDContainer::PrintNoF1TDC ( Int_t  roc, Int_t  slot  )

private

Definition at line 1171 of file QwF1TDContainer.cc.

References GetSystemName().

Referenced by AddEMM(), AddFDF(), AddHFO(), AddOFO(), AddRLF(), AddS30(), AddSEU(), AddSYN(), and AddTFO().

{
  TString tmp = Form("There is no F1TDC with ROC%2d and SLOT%2d in System %s\n",
         roc, slot, GetSystemName().Data());
  return tmp;

}

Here is the call graph for this function:

Here is the caller graph for this function:

TString QwF1TDContainer::PrintNoF1TDC ( Int_t  tdc_index )

private

Definition at line 1180 of file QwF1TDContainer.cc.

References GetSystemName().

{
  TString tmp = Form("There is no F1TDC with TDCINDEX%2d in System %s\n",
         tdc_index, GetSystemName().Data());

  return tmp;
}

Here is the call graph for this function:

Double_t QwF1TDContainer::ReferenceSignalCorrection	(	Double_t	raw_time,
		Double_t	ref_time,
		Int_t	bank_index,
		Int_t	slot
	)

Definition at line 1068 of file QwF1TDContainer.cc.

References GetF1TDCwithBankIndexSLOT(), and QwF1TDC::ReferenceSignalCorrection().

Referenced by QwTriggerScintillator::ProcessEvent(), QwMainDetector::ProcessEvent(), QwScanner::ProcessEvent(), QwDriftChamberHDC::SubtractReferenceTimes(), QwDriftChamberVDC::SubtractReferenceTimes(), QwSciFiDetector::SubtractReferenceTimes(), QwMainDetector::SubtractReferenceTimes(), QwTriggerScintillator::SubtractReferenceTimes(), and QwScanner::SubtractReferenceTimes().

{
  QwF1TDC* F1 = NULL;
  F1 = this->GetF1TDCwithBankIndexSLOT(bank_index, slot_num);

  if(F1) {
    return F1->ReferenceSignalCorrection(raw_time, ref_time);
  }
  else {
    //   printf("There is no F1TDC with Bank index %2d slot %2d\n", bank_index, slot_num);
    return -1.0;
  }
}

Here is the call graph for this function:

Here is the caller graph for this function:

Double_t QwF1TDContainer::ReturnTimeCalibration ( Double_t  time_arb_unit )

inline

Definition at line 298 of file QwF1TDContainer.h.

References fF1TDCOneResolutionNS.

Referenced by QwTriggerScintillator::ProcessEvent(), QwMainDetector::ProcessEvent(), and QwScanner::ProcessEvent().

{return fF1TDCOneResolutionNS*time_arb_unit;};

Here is the caller graph for this function:

void QwF1TDContainer::SetErrorHistOptions ( )

private

Definition at line 1795 of file QwF1TDContainer.cc.

References fError2DHist.

Referenced by GetF1TDCErrorHist(), and WriteErrorSummary().

{
  const char* opt = "TEXT";
  fError2DHist->SetMarkerSize(1.4);
  fError2DHist->SetOption(opt);
  fError2DHist->LabelsDeflate("X");
  fError2DHist->LabelsDeflate("Y");
  fError2DHist->LabelsOption("a", "X");
  fError2DHist->LabelsOption("a", "Y");
  return;
}

Here is the caller graph for this function:

void QwF1TDContainer::SetSystemName

(

const TString

name

)

Definition at line 1089 of file QwF1TDContainer.cc.

References QwLog::endl(), fDetectorType, fError2DHist, fRegion, fSystemName, kRegionID1, kRegionID2, kRegionID3, kRegionIDCer, kRegionIDNull, kRegionIDScanner, kRegionIDTrig, kTypeCerenkov, kTypeDriftHDC, kTypeDriftVDC, kTypeNull, kTypeScanner, kTypeSciFiber, kTypeTrigscint, and QwWarning.

{
  // Types are defined in QwType.h
  if(fSystemName.IsNull()) {
    fSystemName = name;
    if(fSystemName == "R1") {
      fDetectorType = kTypeSciFiber;
      fRegion       = kRegionID1;
    }
    else if(fSystemName == "R2") {
      fDetectorType = kTypeDriftHDC;
      fRegion       = kRegionID2;
    }
    else if(fSystemName == "R3") {
      fDetectorType = kTypeDriftVDC;
      fRegion       = kRegionID3;
    }

    else if(fSystemName == "MD" ) {
      fDetectorType = kTypeCerenkov;
      fRegion       = kRegionIDCer;
    }
    else if(fSystemName == "TS" ) {
      fDetectorType = kTypeTrigscint;
      fRegion       = kRegionIDTrig;
    }
    else if(fSystemName == "FPS") {
      fDetectorType = kTypeScanner;
      fRegion       = kRegionIDScanner;
    }
    else {
      fDetectorType = kTypeNull;
      fRegion       = kRegionIDNull;
    }
  }
  else {
    QwWarning << "QwF1TDContainer::SetSystemName "
              << fSystemName
              << " is already registered."
              << QwLog::endl;
  }

  fError2DHist -> SetNameTitle(
             Form("%s_F1ErrorHist",fSystemName.Data()),
             Form("%s F1TDC Board Error Status Histogram", fSystemName.Data())
             );
  return;
}

Here is the call graph for this function:

Int_t QwF1TDContainer::Size ( ) const

inline

Definition at line 286 of file QwF1TDContainer.h.

References fNQwF1TDCs.

{return fNQwF1TDCs;};

void QwF1TDContainer::WriteErrorSummary

(

Bool_t

hist_flag = true

)

Definition at line 1821 of file QwF1TDContainer.cc.

References fError2DHist, fLocalDebug, GetErrorSummary(), GetSystemName(), and SetErrorHistOptions().

Referenced by QwScanner::FillHardwareErrorSummary().

{
  if (fError2DHist->GetEntries() not_eq 0) {

    TSeqCollection *file_list = gROOT->GetListOfFiles();

    if (file_list) {

      Int_t size = file_list->GetSize();

      TString error_summary_name = this-> GetSystemName();
      error_summary_name += "_F1TDCs_Status";

      for (Int_t i=0; i<size; i++)
  {
    TFile *file = (TFile*) file_list->At(i);
    if(hist_flag) {
      TString hist_name = fError2DHist->GetName();
      TH2F *error_hist = (TH2F*) file->FindObjectAny(hist_name);
      if (not error_hist)  {
        this->SetErrorHistOptions();
        file->WriteObject(fError2DHist, hist_name);
      }
    }
    else {
      TList *error_summary = (TList*) file->FindObjectAny(error_summary_name);
      if (not error_summary) {
        file->WriteObject(this->GetErrorSummary(), error_summary_name);
      }
    }
    if(fLocalDebug) {
      std::cout << "i " << i
          << " size " << size
          << " error_summary_name " << error_summary_name
          << std::endl;
    }
  }
    }
  }
  return;
}

Here is the call graph for this function:

Here is the caller graph for this function:

Field Documentation

EQwDetectorType QwF1TDContainer::fDetectorType

Definition at line 338 of file QwF1TDContainer.h.

Referenced by GetDetectorType(), QwF1TDContainer(), and SetSystemName().

TH2F* QwF1TDContainer::fError2DHist

Definition at line 342 of file QwF1TDContainer.h.

Referenced by CheckDataIntegrity(), GetF1TDCErrorHist(), QwF1TDContainer(), SetErrorHistOptions(), SetSystemName(), WriteErrorSummary(), and ~QwF1TDContainer().

MQwF1TDC QwF1TDContainer::fF1TDCDecoder

private

Definition at line 347 of file QwF1TDContainer.h.

Referenced by CheckDataIntegrity(), and GetF1TDCDecoder().

Double_t QwF1TDContainer::fF1TDCOneResolutionNS

private

Definition at line 355 of file QwF1TDContainer.h.

Referenced by DoneF1TDCsConfiguration(), GetF1TDCOneResolution(), and ReturnTimeCalibration().

Double_t QwF1TDContainer::fF1TDCTriggerRollover

private

Definition at line 366 of file QwF1TDContainer.h.

Bool_t QwF1TDContainer::fLocalDebug

private

Definition at line 352 of file QwF1TDContainer.h.

Referenced by AddQwF1TDC(), CheckDataIntegrity(), GetF1TDCTriggerRollover(), QwF1TDContainer(), and WriteErrorSummary().

Bool_t QwF1TDContainer::fLocalF1DecodeDebug

private

Definition at line 350 of file QwF1TDContainer.h.

Referenced by CheckDataIntegrity(), and QwF1TDContainer().

Bool_t QwF1TDContainer::fLocalF1ErrorDebug

private

Definition at line 353 of file QwF1TDContainer.h.

Referenced by AddEMM(), AddFDF(), AddHFO(), AddOFO(), AddRLF(), AddS30(), AddSEU(), AddSYN(), AddTFO(), and QwF1TDContainer().

Bool_t QwF1TDContainer::fLocalF1RawDecodeDebug

private

Definition at line 349 of file QwF1TDContainer.h.

Referenced by CheckDataIntegrity(), and QwF1TDContainer().

Int_t QwF1TDContainer::fNQwF1TDCs

Definition at line 270 of file QwF1TDContainer.h.

Referenced by AddQwF1TDC(), GetSize(), HowManyF1TDCs(), QwF1TDContainer(), and Size().

TObjArray* QwF1TDContainer::fQwF1TDCList

Definition at line 271 of file QwF1TDContainer.h.

Referenced by AddQwF1TDC(), GetErrorSummary(), GetF1TDC(), GetF1TDCChannelNumber(), GetF1TDCsResolution(), GetF1TDCTriggerRollover(), GetF1TDCwithBankIndexSLOT(), GetF1TDCwithIndex(), Print(), PrintErrorSummary(), QwF1TDContainer(), and ~QwF1TDContainer().

EQwRegionID QwF1TDContainer::fRegion

Definition at line 339 of file QwF1TDContainer.h.

Referenced by GetRegion(), QwF1TDContainer(), and SetSystemName().

TString QwF1TDContainer::fSystemName

Definition at line 340 of file QwF1TDContainer.h.

Referenced by GetSystemName(), and SetSystemName().

---

The documentation for this class was generated from the following files:

• QwF1TDContainer.h
• QwF1TDContainer.cc
