QwGeant4
QweakSimVDCRotator Class Reference

Definition of the Support/Shielding of the Collimators. More...

#include <QweakSimVDCRotator.hh>

+ Collaboration diagram for QweakSimVDCRotator:

Public Member Functions

 QweakSimVDCRotator ()
 Constructor. More...

 ~QweakSimVDCRotator ()
 Destructor. More...

void SetMotherVolume (G4VPhysicalVolume *mv)

void ConstructRotatorMasterContainer ()

void ConstructRings ()

void ConstructRails ()

void ConstructMount ()

void ConstructSliderSupport ()

void PlacePVSliderSupport (int pkg)

void PlacePVRails ()

void PlacePVMount ()

void SetRingMaterial (G4String)

void SetRotationAngleInPhi (G4double vdc_phiangle)

G4LogicalVolume * GetUpstreamRing_LogicalVolume ()

G4VPhysicalVolume * GetUpstreamRing_PhysicalVolume ()


Private Attributes

QweakSimMaterialpMaterial

QweakSimVDCDualVDC

G4double kAngle_GlobalRotation

G4VPhysicalVolume * theMotherVolume

G4VPhysicalVolume * RotatorMasterContainer_Physical

G4double kRing_RadiusMin

G4double kRing_RadiusMax

G4double kRing_FullThickness

G4double kRing_PhiAngleStart

G4double kRing_PhiAngleEnd

G4LogicalVolume * UpstreamRing_Logical

G4VPhysicalVolume * UpstreamRing_Physical

G4double UpstreamRing_CenterXPosition

G4double UpstreamRing_CenterYPosition

G4double UpstreamRing_CenterZPosition

G4LogicalVolume * DownstreamRing_Logical

G4VPhysicalVolume * DownstreamRing_Physical

G4double DownstreamRing_CenterXPosition

G4double DownstreamRing_CenterYPosition

G4double DownstreamRing_CenterZPosition

G4double kRail_FullLength_X

G4double kRail_FullLength_Y

G4double kRail_FullLength_Z

G4double kRail_CenterPositionInR

G4double kRail_CenterPositionInZ

G4ThreeVector Translation_LeftRail

G4ThreeVector Translation_RightRail

G4RotationMatrix * Rotation_Rail

G4LogicalVolume * Rail_Logical

G4VPhysicalVolume * LeftRail_Physical

G4VPhysicalVolume * RightRail_Physical

G4double kRod_LR_RadiusMin

G4double kRod_LR_RadiusMax

G4double kRod_LR_FullThickness

G4double kRod_LR_PhiAngleStart

G4double kRod_LR_PhiAngleEnd

G4double kRod_LR_StubLength

G4double kRod_LR_Distance

G4double kRod_LR_CenterPositionInR

std::vector< G4double > kRod_LR_CenterPositionInX

std::vector< G4double > kRod_LR_CenterPositionInY

std::vector< G4double > kRod_LR_CenterPositionInZ

G4LogicalVolume * Rod_LeftRight_Logical

std::vector< G4VPhysicalVolume * > Rod_LeftRight_Physical

G4ThreeVector Translation_RodLeftUpstream

G4ThreeVector Translation_RodLeftDownstream

G4ThreeVector Translation_RodRightUpstream

G4ThreeVector Translation_RodRightDownstream

G4RotationMatrix * Rotation_Rod_LR

G4double kSliderSupport_FullLength_X

G4double kSliderSupport_FullLength_Y

G4double kSliderSupport_FullLength_Z

G4double kSliderSupport_CenterPositionInX

G4double kSliderSupport_CenterPositionInY

G4double kSliderSupport_CenterPositionInZ

G4ThreeVector Translation_LeftSliderSupport

G4ThreeVector Translation_RightSliderSupport

G4RotationMatrix * Rotation_SliderSupportLeft

G4RotationMatrix * Rotation_SliderSupportRight

G4LogicalVolume * SliderSupportLeft_Logical

std::vector< G4VPhysicalVolume * > SliderSupportLeft_Physical

G4LogicalVolume * SliderSupportRight_Logical

std::vector< G4VPhysicalVolume * > SliderSupportRight_Physical

std::vector< G4SubtractionSolid * > SliderSupportSubtraction_TempSolid


Detailed Description

Definition of the Support/Shielding of the Collimators.

Placeholder for a long explaination

Definition at line 75 of file QweakSimVDCRotator.hh.

Constructor & Destructor Documentation

QweakSimVDCRotator::QweakSimVDCRotator ( )

Constructor.

Definition at line 52 of file QweakSimVDCRotator.cc.

References DownstreamRing_CenterXPosition, DownstreamRing_CenterYPosition, DownstreamRing_CenterZPosition, DownstreamRing_Logical, DownstreamRing_Physical, QweakSimMaterial::GetInstance(), kAngle_GlobalRotation, kRail_CenterPositionInR, kRail_CenterPositionInZ, kRail_FullLength_X, kRail_FullLength_Y, kRail_FullLength_Z, kRing_FullThickness, kRing_PhiAngleEnd, kRing_PhiAngleStart, kRing_RadiusMax, kRing_RadiusMin, kRod_LR_CenterPositionInX, kRod_LR_CenterPositionInY, kRod_LR_CenterPositionInZ, kRod_LR_Distance, kRod_LR_FullThickness, kRod_LR_PhiAngleEnd, kRod_LR_PhiAngleStart, kRod_LR_RadiusMax, kRod_LR_RadiusMin, kRod_LR_StubLength, kSliderSupport_CenterPositionInX, kSliderSupport_CenterPositionInY, kSliderSupport_CenterPositionInZ, kSliderSupport_FullLength_X, kSliderSupport_FullLength_Y, kSliderSupport_FullLength_Z, LeftRail_Physical, pMaterial, Rail_Logical, RightRail_Physical, Rod_LeftRight_Logical, Rod_LeftRight_Physical, Rotation_Rail, Rotation_Rod_LR, Rotation_SliderSupportLeft, Rotation_SliderSupportRight, SliderSupportLeft_Logical, SliderSupportLeft_Physical, SliderSupportRight_Logical, SliderSupportRight_Physical, SliderSupportSubtraction_TempSolid, theMotherVolume, UpstreamRing_CenterXPosition, UpstreamRing_CenterYPosition, UpstreamRing_CenterZPosition, UpstreamRing_Logical, and UpstreamRing_Physical.

53 {
54  G4cout << G4endl << "###### Calling QweakSimVDCRotator::QweakCollimatorSupport() " << G4endl << G4endl;
55
56  theMotherVolume = NULL;
57
58  kAngle_GlobalRotation = 90.0*degree;
59
60  // Upstream Ring
61  UpstreamRing_Logical = NULL;
62  UpstreamRing_Physical = NULL;
63
66
67  kRing_RadiusMax = 1168.0*mm;
68  kRing_RadiusMin = 1016.0*mm;
69  kRing_FullThickness = 2.0*2.54*cm;
70  kRing_PhiAngleStart = 0.0*degree;
71  kRing_PhiAngleEnd = 360.0*degree;
72
75  UpstreamRing_CenterZPosition = 4310.36*mm;
76
79  DownstreamRing_CenterZPosition = 5088.23*mm;
80
81  //==========
82  // Rails
83  //==========
84
85  Rail_Logical = NULL;
86  LeftRail_Physical = NULL;
87  RightRail_Physical = NULL;
88
89  Rotation_Rail = NULL;
90
91  kRail_FullLength_X = 1.75*2.54*cm;
92  kRail_FullLength_Y = 114.00*2.54*cm;
93  kRail_FullLength_Z = 5.00*2.54*cm;
94
95  kRail_CenterPositionInR = (49.1314*2.54*cm + 0.5*kRail_FullLength_X);
97
98
99
100  //==================
101  // Rods: Left/Right
102  //==================
103
104  Rod_LeftRight_Logical = NULL;
105  Rotation_Rod_LR = NULL;
106
107  kRod_LR_RadiusMin = 0.0*cm;
108  kRod_LR_RadiusMax = 1.0220*2.54*cm;
109  kRod_LR_FullThickness = 2.8250*2.54*cm;
110  kRod_LR_PhiAngleStart = 0.0*degree;
111  kRod_LR_PhiAngleEnd = 360.0*degree;
112
113  //----------------------
114  // [0]: Upstream,Left rod
115  // [1]: Downstream,Left rod
116  // [2]: Upstream,Right rod
117  // [3]: Downstream,Right rod
118  //----------------------
119  kRod_LR_StubLength = 2.8250*2.54*cm;
120  kRod_LR_Distance = 12.5000*2.54*cm;
121
122  kRod_LR_CenterPositionInX.clear();
123  kRod_LR_CenterPositionInX.resize(4);
124  kRod_LR_CenterPositionInX[0] = -1.0*(61.0371*2.54*cm - 0.5*kRod_LR_StubLength);
125  kRod_LR_CenterPositionInX[1] = -1.0*(61.0371*2.54*cm - 0.5*kRod_LR_StubLength);
126  kRod_LR_CenterPositionInX[2] = 1.0*(61.0371*2.54*cm - 0.5*kRod_LR_StubLength);
127  kRod_LR_CenterPositionInX[3] = 1.0*(61.0371*2.54*cm - 0.5*kRod_LR_StubLength);
128
129  kRod_LR_CenterPositionInY.clear();
130  kRod_LR_CenterPositionInY.resize(4);
131  kRod_LR_CenterPositionInY[0] = 111.7677*2.54*cm;
132  kRod_LR_CenterPositionInY[1] = 111.7677*2.54*cm;
133  kRod_LR_CenterPositionInY[2] = 111.7677*2.54*cm;
134  kRod_LR_CenterPositionInY[3] = 111.7677*2.54*cm;
135
136  kRod_LR_CenterPositionInZ.clear();
137  kRod_LR_CenterPositionInZ.resize(4);
138  kRod_LR_CenterPositionInZ[0] = 178.8866*2.54*cm;
139  kRod_LR_CenterPositionInZ[1] = 178.8866*2.54*cm + kRod_LR_Distance;
140  kRod_LR_CenterPositionInZ[2] = 178.8866*2.54*cm;
141  kRod_LR_CenterPositionInZ[3] = 178.8866*2.54*cm + kRod_LR_Distance;
142
143  //----------------------
144  // [0]: Upstream rod
145  // [1]: Downstream rod
146  //----------------------
147  //
148  Rod_LeftRight_Physical.clear();
149  Rod_LeftRight_Physical.resize(4);
150
151
152  //===============
153  // Slider Support
154  //===============
155  kSliderSupport_FullLength_X = 203.20*mm;
156  kSliderSupport_FullLength_Y = 1930.40*mm;
157  kSliderSupport_FullLength_Z = 356.97*mm;
158
162
165
168  SliderSupportLeft_Physical.resize(2);
169
172  SliderSupportRight_Physical.resize(2);
173
174  // needed for shaping
177
178
179  //==================================
180  // get access to material definition
181  //==================================
182  //
184
185  G4cout << G4endl << "###### Leaving QweakSimVDCRotator::QweakCollimatorSupport() " << G4endl << G4endl;
186 }
G4double DownstreamRing_CenterYPosition
G4LogicalVolume * DownstreamRing_Logical
G4RotationMatrix * Rotation_Rail
G4LogicalVolume * SliderSupportRight_Logical
std::vector< G4double > kRod_LR_CenterPositionInX
G4VPhysicalVolume * LeftRail_Physical
static QweakSimMaterial * GetInstance()
QweakSimMaterial * pMaterial
G4double kSliderSupport_FullLength_Z
std::vector< G4SubtractionSolid * > SliderSupportSubtraction_TempSolid
std::vector< G4VPhysicalVolume * > SliderSupportRight_Physical
G4RotationMatrix * Rotation_Rod_LR
G4double DownstreamRing_CenterXPosition
G4VPhysicalVolume * theMotherVolume
std::vector< G4double > kRod_LR_CenterPositionInZ
G4double UpstreamRing_CenterZPosition
G4double UpstreamRing_CenterXPosition
std::vector< G4double > kRod_LR_CenterPositionInY
G4double kSliderSupport_CenterPositionInX
G4VPhysicalVolume * RightRail_Physical
G4RotationMatrix * Rotation_SliderSupportRight
G4double kSliderSupport_FullLength_X
std::vector< G4VPhysicalVolume * > Rod_LeftRight_Physical
G4double kSliderSupport_CenterPositionInY
G4LogicalVolume * Rail_Logical
std::vector< G4VPhysicalVolume * > SliderSupportLeft_Physical
G4VPhysicalVolume * UpstreamRing_Physical
G4double kSliderSupport_FullLength_Y
G4RotationMatrix * Rotation_SliderSupportLeft
G4double DownstreamRing_CenterZPosition
G4double kSliderSupport_CenterPositionInZ
G4double UpstreamRing_CenterYPosition
G4LogicalVolume * UpstreamRing_Logical
G4LogicalVolume * SliderSupportLeft_Logical
G4LogicalVolume * Rod_LeftRight_Logical
G4VPhysicalVolume * DownstreamRing_Physical

+ Here is the call graph for this function:

QweakSimVDCRotator::~QweakSimVDCRotator ( )

Destructor.

Definition at line 189 of file QweakSimVDCRotator.cc.

189 { }

Member Function Documentation

void QweakSimVDCRotator::ConstructMount ( )

Definition at line 427 of file QweakSimVDCRotator.cc.

References QweakSimMaterial::GetMaterial(), kRod_LR_FullThickness, kRod_LR_PhiAngleEnd, kRod_LR_PhiAngleStart, kRod_LR_RadiusMax, kRod_LR_RadiusMin, PlacePVMount(), pMaterial, and Rod_LeftRight_Logical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

428 {
429
430  G4cout << G4endl << "###### Calling QweakSimVDCRotator::ConstructMount() " << G4endl << G4endl;
431
432  // assign material
433  G4Material* Rod_LeftRight_Material = pMaterial->GetMaterial("StainlessSteel");
434
435
436
437  //**********************************************************************************
438  //Construct
439  G4Tubs* Rod_LeftRight_Solid = new G4Tubs("Rod_LR_Sol",
445  );
446
447  //**********************************************************************************
448  // Define UpstreamRing logical and physical volumes
449
450  Rod_LeftRight_Logical = new G4LogicalVolume( Rod_LeftRight_Solid,
451  Rod_LeftRight_Material,
452  "Rod_LeftRight_Logical",
453  0,
454  0,0);
455
456  //**********************************************************************************
457
458  //Make it pretty...
459  G4Colour blue (0.,0.,1.);
460  G4Colour mangenta (237/255.,173/255.,255/255.);
461  G4Colour mangenta1 (104/255., 49/255., 94/255.);
462  G4Colour aluminum ( 169/255. , 172/255. , 182/255.);
463  G4Color lightsteelblue ( 176/255. , 196/255. , 222/255.);
464  //**********************************************************************************
465  G4VisAttributes* Rod_LeftRight_VisAtt = new G4VisAttributes(mangenta);
466  Rod_LeftRight_VisAtt ->SetVisibility(true);
467  Rod_LeftRight_Logical ->SetVisAttributes(Rod_LeftRight_VisAtt);
468  //**********************************************************************************
469
470  // Place the physical volume(s) into the MotherVolume
471  PlacePVMount();
472
473 } // end of ConstructMount()
QweakSimMaterial * pMaterial
G4Material * GetMaterial(G4String material)
G4LogicalVolume * Rod_LeftRight_Logical

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimVDCRotator::ConstructRails ( )

Definition at line 334 of file QweakSimVDCRotator.cc.

References QweakSimMaterial::GetMaterial(), kRail_FullLength_X, kRail_FullLength_Y, kRail_FullLength_Z, PlacePVRails(), pMaterial, and Rail_Logical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

335 {
336  G4cout << G4endl << "###### Calling QweakSimVDCRotator::ConstructRails() " << G4endl << G4endl;
337
338  // assign material
339  G4Material* Rail_Material = pMaterial->GetMaterial("StainlessSteel");
340
341
342  G4Box* Rail_Solid = new G4Box("Rail_Solid",
343  0.5 * kRail_FullLength_X ,
344  0.5 * kRail_FullLength_Y ,
345  0.5 * kRail_FullLength_Z );
346
347
348  Rail_Logical = new G4LogicalVolume( Rail_Solid,
349  Rail_Material,
350  "Rail_Logical",
351  0,
352  0,0);
353
354  //Make it pretty...
355  G4Colour blue (0.,0.,1.);
356  G4Colour mangenta (237/255.,173/255.,255/255.);
357  G4Colour mangenta1 (104/255., 49/255., 94/255.);
358  G4Colour aluminum ( 169/255. , 172/255. , 182/255.);
359  G4Color lightsteelblue ( 176/255. , 196/255. , 222/255.);
360  //**********************************************************************************
361  G4VisAttributes* Rails_VisAtt = new G4VisAttributes(blue);
362  Rails_VisAtt->SetVisibility(true);
363  // Rails_VisAtt->SetForceSolid(true);
364  // Ring_VisAtt->SetForceWireframe(true);
365  Rail_Logical ->SetVisAttributes(Rails_VisAtt);
366  //**********************************************************************************
367
368  // Place the physical volume of the rails into theMotherVolume
369  PlacePVRails();
370
371 } // end of ConstructRails()
QweakSimMaterial * pMaterial
G4Material * GetMaterial(G4String material)
G4LogicalVolume * Rail_Logical

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimVDCRotator::ConstructRings ( )

Definition at line 234 of file QweakSimVDCRotator.cc.

References DownstreamRing_CenterXPosition, DownstreamRing_CenterYPosition, DownstreamRing_CenterZPosition, DownstreamRing_Logical, DownstreamRing_Physical, QweakSimMaterial::GetMaterial(), kRing_FullThickness, kRing_PhiAngleEnd, kRing_PhiAngleStart, kRing_RadiusMax, kRing_RadiusMin, pMaterial, pSurfChk, theMotherVolume, UpstreamRing_CenterXPosition, UpstreamRing_CenterYPosition, UpstreamRing_CenterZPosition, UpstreamRing_Logical, and UpstreamRing_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

235 {
236  G4cout << G4endl << "###### Calling QweakSimVDCRotator::ConstructSupport() " << G4endl << G4endl;
237
238  // assign material
239  G4Material* Ring_Material = pMaterial->GetMaterial("StainlessSteel");
240
241
242  //===============
243  // Upstream Ring
244  //===============
245  G4ThreeVector positionUpstreamRing(UpstreamRing_CenterXPosition,
248
249  //**********************************************************************************
250  //Construct
251  G4Tubs* UpstreamRing_Solid = new G4Tubs("UpstreamRing_Sol",
257  );
258
259  //**********************************************************************************
260  // Define UpstreamRing logical and physical volumes
261
262  UpstreamRing_Logical = new G4LogicalVolume( UpstreamRing_Solid,
263  Ring_Material,
264  "UpstreamRing_Log",
265  0,0,0);
266
267  UpstreamRing_Physical = new G4PVPlacement(0,
268  positionUpstreamRing,
269  "UpstreamRing",
272  false,
273  0,
274  pSurfChk);
275
276  //**********************************************************************************
277
278  //===============
279  // Downstream Ring
280  //===============
281  G4ThreeVector positionDownstreamRing(DownstreamRing_CenterXPosition,
284
285  //**********************************************************************************
286  //Construct
287  G4Tubs* DownstreamRing_Solid = new G4Tubs("DownstreamRing_Sol",
293  );
294
295  //**********************************************************************************
296  // Define DownsreamRing logical and physical volumes
297
298  DownstreamRing_Logical = new G4LogicalVolume( DownstreamRing_Solid,
299  Ring_Material,
300  "DownstreamRing_Log",
301  0,0,0);
302
303  DownstreamRing_Physical = new G4PVPlacement(0,
304  positionDownstreamRing,
305  "UpstreamRing",
308  false,
309  0,
310  pSurfChk);
311
312  //Make it pretty...
313  G4Colour blue (0.,0.,1.);
314  G4Colour mangenta (237/255.,173/255.,255/255.);
315  G4Colour mangenta1 (104/255., 49/255., 94/255.);
316  G4Colour aluminum ( 169/255. , 172/255. , 182/255.);
317  G4Color lightsteelblue ( 176/255. , 196/255. , 222/255.);
318
319  //**********************************************************************************
320  G4VisAttributes* Ring_VisAtt = new G4VisAttributes(aluminum);
321  Ring_VisAtt->SetVisibility(true);
322  // Ring_VisAtt->SetForceSolid(true);
323  // Ring_VisAtt->SetForceWireframe(true);
324  UpstreamRing_Logical ->SetVisAttributes(Ring_VisAtt);
325  DownstreamRing_Logical ->SetVisAttributes(Ring_VisAtt);
326  //**********************************************************************************
327
328
329  G4cout << G4endl << "###### Leaving QweakSimVDCRotator::ConstructSupport() " << G4endl << G4endl;
330
331 }
G4double DownstreamRing_CenterYPosition
G4LogicalVolume * DownstreamRing_Logical
QweakSimMaterial * pMaterial
G4double DownstreamRing_CenterXPosition
G4VPhysicalVolume * theMotherVolume
G4double UpstreamRing_CenterZPosition
G4double UpstreamRing_CenterXPosition
G4Material * GetMaterial(G4String material)
G4VPhysicalVolume * UpstreamRing_Physical
G4double DownstreamRing_CenterZPosition
static const G4bool pSurfChk
G4double UpstreamRing_CenterYPosition
G4LogicalVolume * UpstreamRing_Logical
G4VPhysicalVolume * DownstreamRing_Physical

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimVDCRotator::ConstructRotatorMasterContainer ( )

Definition at line 192 of file QweakSimVDCRotator.cc.

References QweakSimMaterial::GetMaterial(), kAngle_GlobalRotation, kRail_CenterPositionInR, kRail_CenterPositionInZ, kSliderSupport_FullLength_Z, pMaterial, pSurfChk, RotatorMasterContainer_Physical, and theMotherVolume.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

193 {
194  G4cout << G4endl << "###### Calling QweakSimVDCRotator::RotatorMasterContainer() " << G4endl << G4endl;
195
196  G4Box* RotatorMasterContainer_Solid = new G4Box("RotatorMasterContainer_Solid",
197  0.5 * (6.6*m),
198  0.5 * (2.0*kRail_CenterPositionInR+50.0*cm),
199  0.5 * (kSliderSupport_FullLength_Z +2.0*cm ));
200
201  G4LogicalVolume* RotatorMasterContainer_Logical = new G4LogicalVolume( RotatorMasterContainer_Solid,
202  pMaterial->GetMaterial("Air"),
203  "RotatorMasterContainer_Logical",
204  0,
205  0,0);
206
207  G4Colour aluminum ( 169/255. , 172/255. , 182/255.);
208  G4VisAttributes* RotatorMasterContainer_VisAtt = new G4VisAttributes(aluminum);
209  RotatorMasterContainer_VisAtt->SetForceWireframe(true);
210  RotatorMasterContainer_VisAtt->SetVisibility(false);
211  RotatorMasterContainer_Logical->SetVisAttributes(RotatorMasterContainer_VisAtt);
212
213  // Place the physical volume into theMotherVolume
214
215  G4ThreeVector Translation_RotatorMasterContainer;
216  Translation_RotatorMasterContainer.setZ(kRail_CenterPositionInZ);
217
218  G4RotationMatrix* Rotation_RotatorMasterContainer = new G4RotationMatrix();
219  Rotation_RotatorMasterContainer->rotateZ(kAngle_GlobalRotation);
220
221  RotatorMasterContainer_Physical = new G4PVPlacement(Rotation_RotatorMasterContainer,
222  Translation_RotatorMasterContainer,
223  "RotatorMasterContainer_Physical",
224  RotatorMasterContainer_Logical,
226  false,
227  0,
228  pSurfChk);
229
230 }
QweakSimMaterial * pMaterial
G4double kSliderSupport_FullLength_Z
G4VPhysicalVolume * theMotherVolume
G4Material * GetMaterial(G4String material)
G4VPhysicalVolume * RotatorMasterContainer_Physical
static const G4bool pSurfChk

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimVDCRotator::ConstructSliderSupport ( )

Definition at line 577 of file QweakSimVDCRotator.cc.

References QweakSimMaterial::GetMaterial(), kSliderSupport_FullLength_X, kSliderSupport_FullLength_Y, kSliderSupport_FullLength_Z, PlacePVSliderSupport(), pMaterial, SliderSupportLeft_Logical, SliderSupportRight_Logical, and SliderSupportSubtraction_TempSolid.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

578 {
579  G4cout << G4endl << "###### Calling QweakSimVDCRotator::ConstructSliderSupport() " << G4endl << G4endl;
580
581  // assign material
582  G4Material* SliderSupport_Material = pMaterial->GetMaterial("StainlessSteel");
583
584
585  G4Box* SliderSupportLeft_Solid = new G4Box("SliderSupportLeft_Solid",
589
590  G4Box* SliderSupportRight_Solid = new G4Box("SliderSupportRight_Solid",
594
595
596  //-------------------------------------------------------------------------------------------------------------------------------
597
598  G4Box* SubtractInnerBox_Solid = new G4Box("SubtractInnerBox_Solid",
599  0.5 * 2*4.00*2.54*cm,
600  0.5 * kSliderSupport_FullLength_Y +0.1*mm,
601  0.5 * 3.50*2.54*cm);
602
603
604  std::vector< G4ThreeVector > LocalTranslation_InnerBox_Subtract;
605  LocalTranslation_InnerBox_Subtract.clear();
606  LocalTranslation_InnerBox_Subtract.resize(4);
607
608  // Left Slider: Upstream Inner Box
609  LocalTranslation_InnerBox_Subtract[0].setX(-1.0*(0.5*203.20*mm));
610  LocalTranslation_InnerBox_Subtract[0].setY(0.0*cm);
611  LocalTranslation_InnerBox_Subtract[0].setZ(-1.0*(1.0+0.5*3.50)*2.54*cm);
612
613  // Left Slider: Downstream Inner Box
614  LocalTranslation_InnerBox_Subtract[1].setX(-1.0*(0.5*203.20*mm));
615  LocalTranslation_InnerBox_Subtract[1].setY(0.0*cm);
616  LocalTranslation_InnerBox_Subtract[1].setZ(+1.0*(1.0+0.5*3.50)*2.54*cm);
617
618
619  // Right Slider: Upstream Inner Box
620  LocalTranslation_InnerBox_Subtract[2].setX(+1.0*(0.5*203.20*mm));
621  LocalTranslation_InnerBox_Subtract[2].setY(0.0*cm);
622  LocalTranslation_InnerBox_Subtract[2].setZ(-1.0*(1.0+0.5*3.50)*2.54*cm);
623
624  // Right Slider: Downstream Inner Box
625  LocalTranslation_InnerBox_Subtract[3].setX(+1.0*(0.5*203.20*mm));
626  LocalTranslation_InnerBox_Subtract[3].setY(0.0*cm);
627  LocalTranslation_InnerBox_Subtract[3].setZ(+1.0*(1.0+0.5*3.50)*2.54*cm);
628
629
630  // dummy rotation matrix
631  G4RotationMatrix LocalRotation_InnerBox_Subtraction;
632
633  G4Transform3D Transform3D_InnerUpstreamSubtraction_LeftSlider(LocalRotation_InnerBox_Subtraction, LocalTranslation_InnerBox_Subtract[0] );
634  //
635  SliderSupportSubtraction_TempSolid[4] = new G4SubtractionSolid ("SliderLeft-InnerUpstreamBox",
636  SliderSupportLeft_Solid,
637  //SliderSupportSubtraction_TempSolid[1],
638  SubtractInnerBox_Solid,
639  Transform3D_InnerUpstreamSubtraction_LeftSlider);
640
641  G4Transform3D Transform3D_InnerUpstreamSubtraction_RightSlider(LocalRotation_InnerBox_Subtraction, LocalTranslation_InnerBox_Subtract[2] );
642  //
643  SliderSupportSubtraction_TempSolid[5] = new G4SubtractionSolid ("SliderRight-InnerUpstreamBox",
644  SliderSupportRight_Solid,
645  //SliderSupportSubtraction_TempSolid[1],
646  SubtractInnerBox_Solid,
647  Transform3D_InnerUpstreamSubtraction_RightSlider);
648
649
650  G4Transform3D Transform3D_InnerDownstreamSubtraction_LeftSlider(LocalRotation_InnerBox_Subtraction, LocalTranslation_InnerBox_Subtract[1] );
651  //
652  SliderSupportSubtraction_TempSolid[6] = new G4SubtractionSolid ("SliderLeft-InnerDownstreamBox",
654  SubtractInnerBox_Solid,
655  Transform3D_InnerDownstreamSubtraction_LeftSlider);
656
657  G4Transform3D Transform3D_InnerDownstreamSubtraction_RightSlider(LocalRotation_InnerBox_Subtraction, LocalTranslation_InnerBox_Subtract[3] );
658  //
659  SliderSupportSubtraction_TempSolid[7] = new G4SubtractionSolid ("SliderRight-InnerDownstreamBox",
661  SubtractInnerBox_Solid,
662  Transform3D_InnerDownstreamSubtraction_RightSlider);
663
664
665  //-------------------------------------------------------------------------------------------------------------------------------
666  G4Box* SubtractBottomBox_Solid = new G4Box("SubtractBottomBox_Solid",
667  0.5 * 2*3.25*2.54*cm,
668  0.5 * kSliderSupport_FullLength_Y +0.1*mm,
669  0.5 * 9.00*2.54*cm);
670
671
672  std::vector< G4ThreeVector > LocalTranslation_BottomBox_Subtract;
673  LocalTranslation_BottomBox_Subtract.clear();
674  LocalTranslation_BottomBox_Subtract.resize(2);
675
676  // Left Slider: Bottom Box
677  LocalTranslation_BottomBox_Subtract[0].setX(+1.0*(0.5*203.20*mm));
678  LocalTranslation_BottomBox_Subtract[0].setY(0.0*cm);
679  LocalTranslation_BottomBox_Subtract[0].setZ(0.0*cm);
680
681  // Right Slider: Bottom Box
682  LocalTranslation_BottomBox_Subtract[1].setX(-1.0*(0.5*203.20*mm));
683  LocalTranslation_BottomBox_Subtract[1].setY(0.0*cm);
684  LocalTranslation_BottomBox_Subtract[1].setZ(0.0*cm);
685
686
687
688  // dummy rotation matrix
689  G4RotationMatrix LocalRotation_BottomBox_Subtraction;
690
691  G4Transform3D Transform3D_BottomSubtraction_LeftSlider(LocalRotation_BottomBox_Subtraction, LocalTranslation_BottomBox_Subtract[0] );
692  //
693  SliderSupportSubtraction_TempSolid[8] = new G4SubtractionSolid ("SliderLeft-BottomBox",
694  //SliderSupportLeft_Solid,
696  SubtractBottomBox_Solid,
697  Transform3D_BottomSubtraction_LeftSlider);
698
699  G4Transform3D Transform3D_BottomSubtraction_RightSlider(LocalRotation_BottomBox_Subtraction, LocalTranslation_BottomBox_Subtract[1] );
700  //
701  SliderSupportSubtraction_TempSolid[9] = new G4SubtractionSolid ("SliderRight-BottomBox",
702  //SliderSupportRight_Solid,
704  SubtractBottomBox_Solid,
705  Transform3D_BottomSubtraction_RightSlider);
706  //-------------------------------------------------------------------------------------------------------------------------------
707  G4Box* SubtractOuterBox_Solid = new G4Box("SubtractOuterBox_Solid",
708  0.5 * 6.82*2.54*cm + 0.1*mm,
709  0.5 * kSliderSupport_FullLength_Y +0.1*mm,
710  0.5 * (2*1.937)*2.54*cm);
711
712
713  std::vector< G4ThreeVector > LocalTranslation_OuterBox_Subtract;
714  LocalTranslation_OuterBox_Subtract.clear();
715  LocalTranslation_OuterBox_Subtract.resize(2);
716
717  // Upstream Outer Box
718  LocalTranslation_OuterBox_Subtract[0].setX(0.0*cm);
719  LocalTranslation_OuterBox_Subtract[0].setY(0.0*cm);
720  LocalTranslation_OuterBox_Subtract[0].setZ(-1.0*(4.50+2.527)*2.54*cm);
721
722  // Downstream Outer Box
723  LocalTranslation_OuterBox_Subtract[1].setX(0.0*cm);
724  LocalTranslation_OuterBox_Subtract[1].setY(0.0*cm);
725  LocalTranslation_OuterBox_Subtract[1].setZ(+1.0*(4.50+2.527)*2.54*cm);
726
727
728  // dummy rotation matrix
729  G4RotationMatrix LocalRotation_OuterBox_Subtraction;
730
731  G4Transform3D Transform3D_OuterUpstreamSubtraction(LocalRotation_OuterBox_Subtraction, LocalTranslation_OuterBox_Subtract[0] );
732
733  SliderSupportSubtraction_TempSolid[0] = new G4SubtractionSolid ("SliderLeft-OuterUpstreamBox",
734  //SliderSupportLeft_Solid,
736  SubtractOuterBox_Solid,
737  Transform3D_OuterUpstreamSubtraction);
738
739  SliderSupportSubtraction_TempSolid[1] = new G4SubtractionSolid ("SliderRight-OuterUpstreamBox",
740  //SliderSupportRight_Solid,
742  SubtractOuterBox_Solid,
743  Transform3D_OuterUpstreamSubtraction);
744
745  G4Transform3D Transform3D_OuterDownstreamSubtraction(LocalRotation_OuterBox_Subtraction, LocalTranslation_OuterBox_Subtract[1] );
746
747  SliderSupportSubtraction_TempSolid[2] = new G4SubtractionSolid ("SliderLeft-OuterDownstreamBox",
749  SubtractOuterBox_Solid,
750  Transform3D_OuterDownstreamSubtraction);
751
752  SliderSupportSubtraction_TempSolid[3] = new G4SubtractionSolid ("SliderRight-OuterDownstreamBox",
754  SubtractOuterBox_Solid,
755  Transform3D_OuterDownstreamSubtraction);
756
757
758  //-------------------------------------------------------------------------------------------------------------------------------
759
760
761
762  //==================================================================================================
763  // Define final SliderSupport logical volume
764  //==================================================================================================
765  G4cout << G4endl << "###### QweakSimVDCRotator: Define SliderSupport_Logical " << G4endl << G4endl;
766
768  SliderSupport_Material,
769  "SliderSupportLeft_Logical",
770  0,
771  0,0);
772
774  SliderSupport_Material,
775  "SliderSupportRight_Logical",
776  0,
777  0,0);
778  //==================================================================================================
779
780  //Make it pretty...
781  G4Colour blue (0.,0.,1.);
782  G4Colour mangenta (237/255.,173/255.,255/255.);
783  G4Colour mangenta1 (104/255., 49/255., 94/255.);
784  G4Colour aluminum ( 169/255. , 172/255. , 182/255.);
785  G4Color lightsteelblue ( 176/255. , 196/255. , 222/255.);
786  //**********************************************************************************
787  G4VisAttributes* SliderSupport_VisAtt = new G4VisAttributes(lightsteelblue);
788  SliderSupport_VisAtt ->SetVisibility(true);
789  SliderSupportLeft_Logical ->SetVisAttributes(SliderSupport_VisAtt);
790  SliderSupportRight_Logical ->SetVisAttributes(SliderSupport_VisAtt);
791  //**********************************************************************************
792
795
796 } // end of ConstructSliderSupport()
G4LogicalVolume * SliderSupportRight_Logical
QweakSimMaterial * pMaterial
G4double kSliderSupport_FullLength_Z
void PlacePVSliderSupport(int pkg)
std::vector< G4SubtractionSolid * > SliderSupportSubtraction_TempSolid
G4double kSliderSupport_FullLength_X
G4Material * GetMaterial(G4String material)
G4double kSliderSupport_FullLength_Y
G4LogicalVolume * SliderSupportLeft_Logical

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

G4LogicalVolume* QweakSimVDCRotator::GetUpstreamRing_LogicalVolume ( )
inline

Definition at line 207 of file QweakSimVDCRotator.hh.

References UpstreamRing_Logical.

207 {return UpstreamRing_Logical;}
G4LogicalVolume * UpstreamRing_Logical
G4VPhysicalVolume* QweakSimVDCRotator::GetUpstreamRing_PhysicalVolume ( )
inline

Definition at line 208 of file QweakSimVDCRotator.hh.

References UpstreamRing_Physical.

208 {return UpstreamRing_Physical;}
G4VPhysicalVolume * UpstreamRing_Physical
void QweakSimVDCRotator::PlacePVMount ( )

Definition at line 476 of file QweakSimVDCRotator.cc.

References kRod_LR_CenterPositionInX, kRod_LR_CenterPositionInY, pSurfChk, Rod_LeftRight_Logical, Rod_LeftRight_Physical, Rotation_Rod_LR, RotatorMasterContainer_Physical, Translation_RodLeftDownstream, Translation_RodLeftUpstream, Translation_RodRightDownstream, and Translation_RodRightUpstream.

Referenced by ConstructMount().

477 {
478
479  G4ThreeVector* CenterRodLeftUpstream = new G4ThreeVector();
480  G4ThreeVector* CenterRodLeftDownstream = new G4ThreeVector();
481
482  G4ThreeVector* CenterRodRightUpstream = new G4ThreeVector();
483  G4ThreeVector* CenterRodRightDownstream = new G4ThreeVector();
484
485
486  CenterRodLeftUpstream->setX(kRod_LR_CenterPositionInX[0]);
487  CenterRodLeftUpstream->setY(kRod_LR_CenterPositionInY[0]);
488  //CenterRodLeftUpstream->setZ(kRod_LR_CenterPositionInZ[0]);
489  //
490  CenterRodLeftDownstream->setX(kRod_LR_CenterPositionInX[1]);
491  CenterRodLeftDownstream->setY(kRod_LR_CenterPositionInY[1]);
492  //CenterRodLeftDownstream->setZ(kRod_LR_CenterPositionInZ[1]);
493
494
495  CenterRodRightUpstream->setX(kRod_LR_CenterPositionInX[2]);
496  CenterRodRightUpstream->setY(kRod_LR_CenterPositionInY[2]);
497  //CenterRodRightUpstream->setZ(kRod_LR_CenterPositionInZ[2]);
498  //
499  CenterRodRightDownstream->setX(kRod_LR_CenterPositionInX[3]);
500  CenterRodRightDownstream->setY(kRod_LR_CenterPositionInY[3]);
501  //CenterRodRightDownstream->setZ(kRod_LR_CenterPositionInZ[3]);
502
503
504
505  // rotate center vectors of rails
506 // CenterRodLeftUpstream ->rotateZ(kAngle_GlobalRotation);
507 // CenterRodLeftDownstream ->rotateZ(kAngle_GlobalRotation);
508 // CenterRodRightUpstream ->rotateZ(kAngle_GlobalRotation);
509 // CenterRodRightDownstream ->rotateZ(kAngle_GlobalRotation);
510
511
512  Translation_RodLeftUpstream.setX( CenterRodLeftUpstream->y() );
513  Translation_RodLeftUpstream.setY( CenterRodLeftUpstream->x() );
514  //Translation_RodLeftUpstream.setZ( CenterRodLeftUpstream->z() );
515  //
516  Translation_RodLeftDownstream.setX( CenterRodLeftDownstream->y() );
517  Translation_RodLeftDownstream.setY( CenterRodLeftDownstream->x() );
518  //Translation_RodLeftDownstream.setZ( CenterRodLeftDownstream->z() );
519
520
521  Translation_RodRightUpstream.setX( CenterRodRightUpstream->y() );
522  Translation_RodRightUpstream.setY( CenterRodRightUpstream->x() );
523  //Translation_RodRightUpstream.setZ( CenterRodRightUpstream->z() );
524  //
525  Translation_RodRightDownstream.setX( CenterRodRightDownstream->y() );
526  Translation_RodRightDownstream.setY( CenterRodRightDownstream->x() );
527  //Translation_RodRightDownstream.setZ( CenterRodRightDownstream->z() );
528
529
530
531  Rotation_Rod_LR = new G4RotationMatrix();
532  Rotation_Rod_LR->rotateY(90*degree);
533  //Rotation_Rod_LR->rotateX(kAngle_GlobalRotation -90*degree);
534  Rotation_Rod_LR->rotateX(-90*degree);
535
536
537
538  Rod_LeftRight_Physical[0] = new G4PVPlacement(Rotation_Rod_LR,
540  "RodLR_LeftUpstream_Physical",
543  false,
544  0,
545  pSurfChk);
546
547  Rod_LeftRight_Physical[1] = new G4PVPlacement(Rotation_Rod_LR,
549  "RodLR_RightUpstream_Physical",
552  false,
553  0,
554  pSurfChk);
555
556  Rod_LeftRight_Physical[2] = new G4PVPlacement(Rotation_Rod_LR,
558  "RodLR_LeftDownstream_Physical",
561  false,
562  0,
563  pSurfChk);
564
565  Rod_LeftRight_Physical[3] = new G4PVPlacement(Rotation_Rod_LR,
567  "RodLR_RightDownstream_Physical",
570  false,
571  0,
572  pSurfChk);
573
574 } // end of PlacePVMount()
std::vector< G4double > kRod_LR_CenterPositionInX
G4RotationMatrix * Rotation_Rod_LR
G4ThreeVector Translation_RodRightUpstream
std::vector< G4double > kRod_LR_CenterPositionInY
std::vector< G4VPhysicalVolume * > Rod_LeftRight_Physical
G4ThreeVector Translation_RodLeftUpstream
G4VPhysicalVolume * RotatorMasterContainer_Physical
G4ThreeVector Translation_RodRightDownstream
static const G4bool pSurfChk
G4ThreeVector Translation_RodLeftDownstream
G4LogicalVolume * Rod_LeftRight_Logical

+ Here is the caller graph for this function:

void QweakSimVDCRotator::PlacePVRails ( )

Definition at line 374 of file QweakSimVDCRotator.cc.

References kRail_CenterPositionInR, LeftRail_Physical, pSurfChk, Rail_Logical, RightRail_Physical, Rotation_Rail, RotatorMasterContainer_Physical, Translation_LeftRail, and Translation_RightRail.

Referenced by ConstructRails().

375 {
376
377  G4ThreeVector* CenterRailLeft = new G4ThreeVector();
378  G4ThreeVector* CenterRailRight = new G4ThreeVector();
379
380  CenterRailLeft->setX(-1.0*kRail_CenterPositionInR);
381  CenterRailLeft->setY(0.0*cm);
382  CenterRailLeft->setZ(0.0*cm);
383
384  CenterRailRight->setX(1.0*kRail_CenterPositionInR);
385  CenterRailRight->setY(0.0*cm);
386  CenterRailRight->setZ(0.0*cm);
387
388  // rotate center vectors of rails
389  // CenterRailLeft ->rotateZ(kAngle_GlobalRotation);
390  // CenterRailRight ->rotateZ(kAngle_GlobalRotation);
391
392  Translation_LeftRail.setX( CenterRailLeft->y() );
393  Translation_LeftRail.setY( CenterRailLeft->x() );
394  //Translation_LeftRail.setZ(kRail_CenterPositionInZ);
395
396  Translation_RightRail.setX( CenterRailRight->y() );
397  Translation_RightRail.setY( CenterRailRight->x() );
398  //Translation_RightRail.setZ(kRail_CenterPositionInZ);
399
400  // since the SingleCoil_ClampPlate_Logical is defined for a vertical orientation
401  // but the translation assumes a horizontal orinetation, we have to subtract 90*deg
402  Rotation_Rail = new G4RotationMatrix();
403  //Rotation_Rail->rotateZ(kAngle_GlobalRotation -90*degree);
404  Rotation_Rail->rotateZ( -90*degree);
405
406
407  LeftRail_Physical = new G4PVPlacement(Rotation_Rail,
409  "LeftRail_Physical",
410  Rail_Logical,
412  false,
413  0,
414  pSurfChk);
415
416  RightRail_Physical = new G4PVPlacement(Rotation_Rail,
418  "RightRail_Physical",
419  Rail_Logical,
421  false,
422  0,
423  pSurfChk);
424 }
G4RotationMatrix * Rotation_Rail
G4VPhysicalVolume * LeftRail_Physical
G4VPhysicalVolume * RightRail_Physical
G4LogicalVolume * Rail_Logical
G4ThreeVector Translation_RightRail
G4ThreeVector Translation_LeftRail
G4VPhysicalVolume * RotatorMasterContainer_Physical
static const G4bool pSurfChk

+ Here is the caller graph for this function:

void QweakSimVDCRotator::PlacePVSliderSupport ( int  pkg)

Definition at line 802 of file QweakSimVDCRotator.cc.

References kSliderSupport_CenterPositionInX, kSliderSupport_CenterPositionInY, pSurfChk, Rotation_SliderSupportLeft, Rotation_SliderSupportRight, RotatorMasterContainer_Physical, SliderSupportLeft_Logical, SliderSupportLeft_Physical, SliderSupportRight_Logical, SliderSupportRight_Physical, Translation_LeftSliderSupport, and Translation_RightSliderSupport.

Referenced by ConstructSliderSupport().

803 {
804
805  G4ThreeVector* leftcenter = new G4ThreeVector();
806  G4ThreeVector* rightcenter = new G4ThreeVector();
807
808
809  // set the vectors to the center of left and right slider support
810  // located at 12 o'clock. Then rotate these vectors to the final
811  // positions and extract the new vector components
812  // This procedure is easier than the calculation by hand
813
814
815  leftcenter->setX(-1.0*kSliderSupport_CenterPositionInX);
816  leftcenter->setY( kSliderSupport_CenterPositionInY);
817  //leftcenter->setZ( kSliderSupport_CenterPositionInZ);
818
819  rightcenter->setX( kSliderSupport_CenterPositionInX);
820  rightcenter->setY( kSliderSupport_CenterPositionInY);
821  //rightcenter->setZ( kSliderSupport_CenterPositionInZ);
822
823  // rotate center vector to coils
824  //leftcenter ->rotateZ(kAngle_GlobalRotation);
825  //rightcenter ->rotateZ(kAngle_GlobalRotation);
826
827
828  double reverser = 1.0;
829  if(pkg == 2)
830  reverser = -1.0;
831
832  Translation_LeftSliderSupport.setX( reverser*leftcenter->y() );
833  Translation_LeftSliderSupport.setY( reverser*leftcenter->x() );
834  //Translation_LeftSliderSupport.setZ( leftcenter->z() );
835
836  Translation_RightSliderSupport.setX( reverser*rightcenter->y() );
837  Translation_RightSliderSupport.setY( reverser*rightcenter->x() );
838  //Translation_RightSliderSupport.setZ( rightcenter->z() );
839
840
841  // since the SingleCoil_ClampPlate_Logical is defined for a vertical orientation
842  // but the translation assumes a horizontal orinetation, we have to subtract 90*deg
843  Rotation_SliderSupportLeft = new G4RotationMatrix();
844  //Rotation_SliderSupportLeft->rotateZ(kAngle_GlobalRotation -90*degree + (pkg-1)*180.0*degree);
845  Rotation_SliderSupportLeft->rotateZ( -90*degree + (pkg-1)*180.0*degree);
846
847  Rotation_SliderSupportRight = new G4RotationMatrix();
848  //Rotation_SliderSupportRight->rotateZ(kAngle_GlobalRotation -90*degree + (pkg-1)*180.0*degree);
849  Rotation_SliderSupportRight->rotateZ( -90*degree + (pkg-1)*180.0*degree);
850
851
852  //place sliders for package 1, 2
853
854  SliderSupportLeft_Physical.at(pkg-1) = new G4PVPlacement(Rotation_SliderSupportLeft,
856  Form("SliderSupportLeft_Pkg%d_Physical",pkg),
859  false,
860  0,
861  pSurfChk);
862
863  SliderSupportRight_Physical.at(pkg-1) = new G4PVPlacement(Rotation_SliderSupportRight,
865  Form("SliderSupportRight_Pkg%d_Physical",pkg),
868  false,
869  0,
870  pSurfChk);
871
872 } // end of PlacePV_SliderSupport()
G4LogicalVolume * SliderSupportRight_Logical
std::vector< G4VPhysicalVolume * > SliderSupportRight_Physical
G4double kSliderSupport_CenterPositionInX
G4RotationMatrix * Rotation_SliderSupportRight
G4ThreeVector Translation_RightSliderSupport
G4double kSliderSupport_CenterPositionInY
G4VPhysicalVolume * RotatorMasterContainer_Physical
std::vector< G4VPhysicalVolume * > SliderSupportLeft_Physical
G4ThreeVector Translation_LeftSliderSupport
G4RotationMatrix * Rotation_SliderSupportLeft
static const G4bool pSurfChk
G4LogicalVolume * SliderSupportLeft_Logical

+ Here is the caller graph for this function:

void QweakSimVDCRotator::SetMotherVolume ( G4VPhysicalVolume *  mv)
inline

Definition at line 193 of file QweakSimVDCRotator.hh.

References theMotherVolume.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

193 { theMotherVolume = mv;}
G4VPhysicalVolume * theMotherVolume

+ Here is the caller graph for this function:

void QweakSimVDCRotator::SetRingMaterial ( G4String  materialName)

Sets the material of the skider rings

Parameters
materialNameName of the material defined in class QweakSimG4Material

Definition at line 875 of file QweakSimVDCRotator.cc.

References DownstreamRing_Logical, and UpstreamRing_Logical.

876 {
877 //---------------------------------------------------------------------------------------------
878 //! Sets the material of the skider rings
879  /*!
880
881  \param materialName Name of the material defined in class QweakSimG4Material
882
883  */
884 //---------------------------------------------------------------------------------------------
885
886  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
887
888  if (pttoMaterial)
889  {
890  UpstreamRing_Logical ->SetMaterial(pttoMaterial);
891  DownstreamRing_Logical ->SetMaterial(pttoMaterial);
892  }
893 }
G4LogicalVolume * DownstreamRing_Logical
G4LogicalVolume * UpstreamRing_Logical
void QweakSimVDCRotator::SetRotationAngleInPhi ( G4double  vdc_phiangle)

Definition at line 896 of file QweakSimVDCRotator.cc.

References kAngle_GlobalRotation, and RotatorMasterContainer_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak(), and QweakSimVDCMessenger::SetNewValue().

897 {
898  G4cout << G4endl << "###### Calling QweakSimVDCRotator::SetRotationAngleInPhi() " << G4endl << G4endl;
899
900  kAngle_GlobalRotation = vdc_phiangle -90.0*degree;
901
902  G4RotationMatrix* Rotation_RotatorMasterContainer = new G4RotationMatrix();
903  Rotation_RotatorMasterContainer->setPhi(vdc_phiangle);
904  RotatorMasterContainer_Physical->SetRotation(Rotation_RotatorMasterContainer);
905
906 }
G4VPhysicalVolume * RotatorMasterContainer_Physical

+ Here is the caller graph for this function:

Field Documentation

G4double QweakSimVDCRotator::DownstreamRing_CenterXPosition
private

Definition at line 108 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::DownstreamRing_CenterYPosition
private

Definition at line 109 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::DownstreamRing_CenterZPosition
private

Definition at line 110 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4LogicalVolume* QweakSimVDCRotator::DownstreamRing_Logical
private

Definition at line 105 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), QweakSimVDCRotator(), and SetRingMaterial().

G4VPhysicalVolume* QweakSimVDCRotator::DownstreamRing_Physical
private

Definition at line 106 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

QweakSimVDC* QweakSimVDCRotator::DualVDC
private

Definition at line 82 of file QweakSimVDCRotator.hh.

G4double QweakSimVDCRotator::kAngle_GlobalRotation
private
G4double QweakSimVDCRotator::kRail_CenterPositionInR
private
G4double QweakSimVDCRotator::kRail_CenterPositionInZ
private

Definition at line 118 of file QweakSimVDCRotator.hh.

Referenced by ConstructRotatorMasterContainer(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRail_FullLength_X
private

Definition at line 114 of file QweakSimVDCRotator.hh.

Referenced by ConstructRails(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRail_FullLength_Y
private

Definition at line 115 of file QweakSimVDCRotator.hh.

Referenced by ConstructRails(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRail_FullLength_Z
private

Definition at line 116 of file QweakSimVDCRotator.hh.

Referenced by ConstructRails(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRing_FullThickness
private

Definition at line 92 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRing_PhiAngleEnd
private

Definition at line 94 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRing_PhiAngleStart
private

Definition at line 93 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRing_RadiusMax
private

Definition at line 91 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRing_RadiusMin
private

Definition at line 90 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_CenterPositionInR
private

Definition at line 140 of file QweakSimVDCRotator.hh.

std::vector< G4double > QweakSimVDCRotator::kRod_LR_CenterPositionInX
private

Definition at line 142 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount(), and QweakSimVDCRotator().

std::vector< G4double > QweakSimVDCRotator::kRod_LR_CenterPositionInY
private

Definition at line 143 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount(), and QweakSimVDCRotator().

std::vector< G4double > QweakSimVDCRotator::kRod_LR_CenterPositionInZ
private

Definition at line 144 of file QweakSimVDCRotator.hh.

Referenced by QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_Distance
private

Definition at line 138 of file QweakSimVDCRotator.hh.

Referenced by QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_FullThickness
private

Definition at line 133 of file QweakSimVDCRotator.hh.

Referenced by ConstructMount(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_PhiAngleEnd
private

Definition at line 135 of file QweakSimVDCRotator.hh.

Referenced by ConstructMount(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_PhiAngleStart
private

Definition at line 134 of file QweakSimVDCRotator.hh.

Referenced by ConstructMount(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_RadiusMax
private

Definition at line 132 of file QweakSimVDCRotator.hh.

Referenced by ConstructMount(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_RadiusMin
private

Definition at line 131 of file QweakSimVDCRotator.hh.

Referenced by ConstructMount(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kRod_LR_StubLength
private

Definition at line 137 of file QweakSimVDCRotator.hh.

Referenced by QweakSimVDCRotator().

G4double QweakSimVDCRotator::kSliderSupport_CenterPositionInX
private

Definition at line 165 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kSliderSupport_CenterPositionInY
private

Definition at line 166 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kSliderSupport_CenterPositionInZ
private

Definition at line 167 of file QweakSimVDCRotator.hh.

Referenced by QweakSimVDCRotator().

G4double QweakSimVDCRotator::kSliderSupport_FullLength_X
private

Definition at line 161 of file QweakSimVDCRotator.hh.

Referenced by ConstructSliderSupport(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kSliderSupport_FullLength_Y
private

Definition at line 162 of file QweakSimVDCRotator.hh.

Referenced by ConstructSliderSupport(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::kSliderSupport_FullLength_Z
private
G4VPhysicalVolume* QweakSimVDCRotator::LeftRail_Physical
private

Definition at line 125 of file QweakSimVDCRotator.hh.

Referenced by PlacePVRails(), and QweakSimVDCRotator().

G4LogicalVolume* QweakSimVDCRotator::Rail_Logical
private

Definition at line 124 of file QweakSimVDCRotator.hh.

Referenced by ConstructRails(), PlacePVRails(), and QweakSimVDCRotator().

G4VPhysicalVolume* QweakSimVDCRotator::RightRail_Physical
private

Definition at line 126 of file QweakSimVDCRotator.hh.

Referenced by PlacePVRails(), and QweakSimVDCRotator().

G4LogicalVolume* QweakSimVDCRotator::Rod_LeftRight_Logical
private

Definition at line 146 of file QweakSimVDCRotator.hh.

Referenced by ConstructMount(), PlacePVMount(), and QweakSimVDCRotator().

std::vector< G4VPhysicalVolume* > QweakSimVDCRotator::Rod_LeftRight_Physical
private

Definition at line 148 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount(), and QweakSimVDCRotator().

G4RotationMatrix* QweakSimVDCRotator::Rotation_Rail
private

Definition at line 122 of file QweakSimVDCRotator.hh.

Referenced by PlacePVRails(), and QweakSimVDCRotator().

G4RotationMatrix* QweakSimVDCRotator::Rotation_Rod_LR
private

Definition at line 155 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount(), and QweakSimVDCRotator().

G4RotationMatrix* QweakSimVDCRotator::Rotation_SliderSupportLeft
private

Definition at line 172 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport(), and QweakSimVDCRotator().

G4RotationMatrix* QweakSimVDCRotator::Rotation_SliderSupportRight
private

Definition at line 173 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport(), and QweakSimVDCRotator().

G4VPhysicalVolume* QweakSimVDCRotator::RotatorMasterContainer_Physical
private
G4LogicalVolume* QweakSimVDCRotator::SliderSupportLeft_Logical
private
std::vector<G4VPhysicalVolume*> QweakSimVDCRotator::SliderSupportLeft_Physical
private

Definition at line 176 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport(), and QweakSimVDCRotator().

G4LogicalVolume* QweakSimVDCRotator::SliderSupportRight_Logical
private
std::vector<G4VPhysicalVolume*> QweakSimVDCRotator::SliderSupportRight_Physical
private

Definition at line 179 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport(), and QweakSimVDCRotator().

std::vector< G4SubtractionSolid* > QweakSimVDCRotator::SliderSupportSubtraction_TempSolid
private

Definition at line 182 of file QweakSimVDCRotator.hh.

Referenced by ConstructSliderSupport(), and QweakSimVDCRotator().

G4VPhysicalVolume* QweakSimVDCRotator::theMotherVolume
private
G4ThreeVector QweakSimVDCRotator::Translation_LeftRail
private

Definition at line 120 of file QweakSimVDCRotator.hh.

Referenced by PlacePVRails().

G4ThreeVector QweakSimVDCRotator::Translation_LeftSliderSupport
private

Definition at line 169 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport().

G4ThreeVector QweakSimVDCRotator::Translation_RightRail
private

Definition at line 121 of file QweakSimVDCRotator.hh.

Referenced by PlacePVRails().

G4ThreeVector QweakSimVDCRotator::Translation_RightSliderSupport
private

Definition at line 170 of file QweakSimVDCRotator.hh.

Referenced by PlacePVSliderSupport().

G4ThreeVector QweakSimVDCRotator::Translation_RodLeftDownstream
private

Definition at line 151 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount().

G4ThreeVector QweakSimVDCRotator::Translation_RodLeftUpstream
private

Definition at line 150 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount().

G4ThreeVector QweakSimVDCRotator::Translation_RodRightDownstream
private

Definition at line 153 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount().

G4ThreeVector QweakSimVDCRotator::Translation_RodRightUpstream
private

Definition at line 152 of file QweakSimVDCRotator.hh.

Referenced by PlacePVMount().

G4double QweakSimVDCRotator::UpstreamRing_CenterXPosition
private

Definition at line 100 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::UpstreamRing_CenterYPosition
private

Definition at line 101 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4double QweakSimVDCRotator::UpstreamRing_CenterZPosition
private

Definition at line 102 of file QweakSimVDCRotator.hh.

Referenced by ConstructRings(), and QweakSimVDCRotator().

G4LogicalVolume* QweakSimVDCRotator::UpstreamRing_Logical
private
G4VPhysicalVolume* QweakSimVDCRotator::UpstreamRing_Physical
private

The documentation for this class was generated from the following files:
