QweakSimTriggerScintillator Class Reference

Definition of the Trigger Scintillator detector. More...

#include <QweakSimTriggerScintillator.hh>

Collaboration diagram for QweakSimTriggerScintillator:

Public Member Functions
	QweakSimTriggerScintillator ()
	~QweakSimTriggerScintillator ()
void	ConstructComponent (G4VPhysicalVolume *MotherVolume)
void	DefineTriggerScintillatorGeometry ()
void	DestroyComponent ()
void	SetTriggerScintillatorMaterial (G4String materialName)
void	SetTriggerScintillatorCenterPositionInX (G4double xPos, G4int pkg=0)
void	SetTriggerScintillatorCenterPositionInY (G4double yPos, G4int pkg=0)
void	SetTriggerScintillatorCenterPositionInZ (G4double zPos, G4int pkg=0)
void	SetTriggerScintillatorTiltAngle (G4double tiltangle)
void	SetTriggerScintillatorPhiAngle (G4double phiangle)
void	SetTriggerScintillatorThickness (G4double thickness)
G4LogicalVolume *	GetTriggerScintillator_LogicalVolume ()
G4VPhysicalVolume *	GetTriggerScintillator_PhysicalVolume ()

Private Member Functions
void	TriggerScintillatorGeometryPVUpdate ()
void	PlaceTriggerScintillator_MasterContainers ()

Private Attributes
QweakSimTriggerScintillatorMessenger *	TriggerScintillatorMessenger
QweakSimMaterial *	pMaterial
G4VPhysicalVolume *	theMotherPV
G4LogicalVolume *	TriggerScintillatorContainer_Logical
std::vector< G4VPhysicalVolume * >	TriggerScintillatorContainer_Physical
G4Material *	TriggerScintillatorContainer_Material
G4LogicalVolume *	TriggerScintillator_Logical
G4VPhysicalVolume *	TriggerScintillator_Physical
G4Material *	TriggerScintillator_Material
G4double	Container_FullLength_X
G4double	Container_FullLength_Y
G4double	Container_FullLength_Z
G4double	StraightBar_FullLength
G4double	StraightBar_FullHeight
G4double	StraightBar_FullThickness
G4double	TriggerScintillatorCenterZPosition
G4double	Tilting_Angle
G4double	Phi_Angle
G4double	Thickness
G4ThreeVector	Position_TriggerScintillatorContainer
std::vector< G4RotationMatrix * >	Rotation_TriggerScintillatorContainer
G4ThreeVector	Translation_SingleBarRight
G4VSensitiveDetector *	TriggerScintillatorSD
std::vector< G4double >	Position_TriggerScintillatorContainer_X
std::vector< G4double >	Position_TriggerScintillatorContainer_Y
std::vector< G4double >	Position_TriggerScintillatorContainer_Z

Detailed Description

Definition of the Trigger Scintillator detector.

Placeholder for a long explaination

Definition at line 57 of file QweakSimTriggerScintillator.hh.

Constructor & Destructor Documentation

QweakSimTriggerScintillator::QweakSimTriggerScintillator

(

)

Definition at line 33 of file QweakSimTriggerScintillator.cc.

References Container_FullLength_X, Container_FullLength_Y, Container_FullLength_Z, QweakSimMaterial::GetInstance(), QweakSimMaterial::GetMaterial(), Phi_Angle, pMaterial, Position_TriggerScintillatorContainer_X, Position_TriggerScintillatorContainer_Y, Position_TriggerScintillatorContainer_Z, Rotation_TriggerScintillatorContainer, StraightBar_FullHeight, StraightBar_FullLength, StraightBar_FullThickness, Tilting_Angle, TriggerScintillator_Logical, TriggerScintillator_Material, TriggerScintillator_Physical, TriggerScintillatorContainer_Logical, TriggerScintillatorContainer_Material, TriggerScintillatorContainer_Physical, TriggerScintillatorMessenger, and TriggerScintillatorSD.

{
  // initialize some pointers
  TriggerScintillatorMessenger = NULL;
  pMaterial                 = NULL;

  TriggerScintillatorContainer_Logical  = NULL;
 // TriggerScintillatorContainer_Physical = NULL;
  TriggerScintillatorContainer_Physical.resize(2,0);
  TriggerScintillatorContainer_Material = NULL;

  TriggerScintillator_Logical   = NULL;
  TriggerScintillator_Physical  = NULL;
  TriggerScintillator_Material  = NULL;


  //Rotation_TriggerScintillatorContainer = NULL;

  // pointer to the sensitive detector
  TriggerScintillatorSD      = NULL;


  TriggerScintillatorMessenger = new QweakSimTriggerScintillatorMessenger(this); //Messenger for first TS Control
  TriggerScintillatorMessenger = new QweakSimTriggerScintillatorMessenger(this,1); // Messenger for second TS Control

  pMaterial = QweakSimMaterial::GetInstance();

  // get cerenkov material
  //CerenkovContainer_Material = pMaterial->GetMaterial("HeGas");

  TriggerScintillatorContainer_Material = pMaterial->GetMaterial("Air");
  TriggerScintillator_Material          = pMaterial->GetMaterial("Scintillator");

  // define container values
  Container_FullLength_X = 220.0*cm;     // Full X length
  Container_FullLength_Y =  60.0*cm;     // Full Y length
  Container_FullLength_Z =   1.27*cm;     // Full Z length , just a bit thicker to get an air gap

 // define container values
  StraightBar_FullLength    =  210.00*cm;    // Full X length
  StraightBar_FullHeight    =   58.00*cm;    // Full Y length
  StraightBar_FullThickness =    1.00*cm;    // Full Z length

   // tilting angle of V-shaped TriggerScintillator against the vertical plane
  Tilting_Angle   =  0.0*degree;

  //Phi angle of TriggerScintillator of Package 1
  Phi_Angle = 0.0*degree;

  Position_TriggerScintillatorContainer_X.resize(2,0);
  Position_TriggerScintillatorContainer_Y.resize(2,0);
  Position_TriggerScintillatorContainer_Z.resize(2,0);
  Rotation_TriggerScintillatorContainer.resize(2,0);
  for (size_t i=0; i< Position_TriggerScintillatorContainer_Z.size();i++)
  {
  // define center position of Container in MotherVolume
  Position_TriggerScintillatorContainer_X[i] =   0.0*cm;

//jpan@nuclear.uwinnipeg.ca
  //Position_TriggerScintillatorContainer_Y = 319.0*cm;
  Position_TriggerScintillatorContainer_Y[i] = 328.0*cm;

//jpan@nuclear.uwinnipeg.ca
  //Position_TriggerScintillatorContainer_Z = 555.0*cm; // adjusted by Jie
  Position_TriggerScintillatorContainer_Z[i] = 545.0*cm; // adjusted by Jie

  // define Rotation matrix for Container orientated in MotherVolume
  Rotation_TriggerScintillatorContainer[i] = new G4RotationMatrix();

  }

 }

Here is the call graph for this function:

QweakSimTriggerScintillator::~QweakSimTriggerScintillator

(

)

Definition at line 107 of file QweakSimTriggerScintillator.cc.

References TriggerScintillator_Logical, TriggerScintillator_Physical, TriggerScintillatorContainer_Logical, and TriggerScintillatorMessenger.

{

//    if (Rotation_TriggerScintillatorContainer)    delete Rotation_TriggerScintillatorContainer;

    if (TriggerScintillator_Physical)             delete TriggerScintillator_Physical;
    if (TriggerScintillator_Logical)              delete TriggerScintillator_Logical;

  //  if (TriggerScintillatorContainer_Physical)    delete TriggerScintillatorContainer_Physical;
    if (TriggerScintillatorContainer_Logical)     delete TriggerScintillatorContainer_Logical;

    if (TriggerScintillatorMessenger)             delete TriggerScintillatorMessenger;
}

Member Function Documentation

void QweakSimTriggerScintillator::ConstructComponent

(

G4VPhysicalVolume *

MotherVolume

)

Definition at line 130 of file QweakSimTriggerScintillator.cc.

References Container_FullLength_X, Container_FullLength_Y, Container_FullLength_Z, PlaceTriggerScintillator_MasterContainers(), pSurfChk, StraightBar_FullHeight, StraightBar_FullLength, StraightBar_FullThickness, theMotherPV, TriggerScintillator_Logical, TriggerScintillator_Material, TriggerScintillator_Physical, TriggerScintillatorContainer_Logical, TriggerScintillatorContainer_Material, and TriggerScintillatorSD.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{
  G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::ConstructComponent() " << G4endl << G4endl;
  theMotherPV = MotherVolume; //Saving pointer to the MotherVolume
  //-----------------------------------------------------------
  // location and orientation of the TriggerScintillator Container
  //-----------------------------------------------------------

  // I prefere to tilt the Detector inside its container rather than
  // tilting the container. Why? I don't know what to do if
  // I want to place 8 containers, each tilted by Tilting_Angle,
  // but to which axis then ?!
 // Rotation_TriggerScintillatorContainer->rotateX(Tilting_Angle);


  // define Container for the V shape Scintillator Detector
  G4cout << G4endl << "###### QweakSimTriggerScintillator: Define TriggerScintillatorContainer_Solid " << G4endl << G4endl;

  G4Box* TriggerScintillatorContainer_Solid  = new G4Box("TriggerScintillatorContainer_Solid",
                0.5 * Container_FullLength_X ,    // half X length required by Geant4
                0.5 * Container_FullLength_Y ,    // half Y length required by Geant4
                0.5 * Container_FullLength_Z );   // half Z length required by Geant4

  // define Container logical volume
  G4cout << G4endl << "###### QweakSimTriggerScintillator: Define TriggerScintillatorContainer_Logical " << G4endl << G4endl;

  TriggerScintillatorContainer_Logical  = new G4LogicalVolume(TriggerScintillatorContainer_Solid,
                    TriggerScintillatorContainer_Material,
                    "TriggerScintillatorContainer_Logical",
                    0,0,0);


  // define ScintillatorContainer physical volume
  PlaceTriggerScintillator_MasterContainers();

  G4Box* StraightBar_Solid    = new G4Box("StraightBar_Sol",
            0.5 * StraightBar_FullLength,       // half X length required by Geant4
            0.5 * StraightBar_FullHeight,      // half Y length required by Geant4
            0.5 * StraightBar_FullThickness );  // half Z length required by Geant4


// Testing: use unly straight bar (w/o chambers)
 TriggerScintillator_Logical  = new G4LogicalVolume( StraightBar_Solid,
                 TriggerScintillator_Material,
                 "TriggerScintillator_Logical",
                 0,0,0);


  // define center position of TriggerScintillator within Container
  G4ThreeVector Position_TriggerScintillator  = G4ThreeVector(0,0,0);

  // define Scintillator physical volume
  G4cout << G4endl << "###### QweakSimShieldingWall: Define TriggerScintillator Physical " << G4endl << G4endl;
  TriggerScintillator_Physical   = new G4PVPlacement(0,
                 Position_TriggerScintillator,
                 TriggerScintillator_Logical,
                 "TriggerScintillator_Physical",
                 TriggerScintillatorContainer_Logical,
                 false,
                 0,
                 pSurfChk);


  G4cout << G4endl << "###### QweakSimTriggerScintillator: Setting Sensitive Detectors " << G4endl << G4endl;

  // Sensitive detectors
  //------------------------------------------------
  // All managed (deleted) by SDManager

   G4SDManager* SDman = G4SDManager::GetSDMpointer();


   //#######################################################
   // define drift chamber elements as sensitiv detectors
   // "sensitivity" will be handled by class QweakSimVDCSD
   //#######################################################


   //***********************************************************
   TriggerScintillatorSD = new QweakSimTriggerScintillator_DetectorSD("/TriggerScintillatorSD");
   SDman->AddNewDetector(TriggerScintillatorSD);

   // add Scintillator detector as a sensitiv element
   //TriggerScintillator_Logical->SetSensitiveDetector(TriggerScintillatorSD);
   TriggerScintillatorContainer_Logical->SetSensitiveDetector(TriggerScintillatorSD);
   //***********************************************************


G4cout << G4endl << "###### QweakSimTriggerScintillator: Setting Attributes " << G4endl << G4endl;

 G4Colour  orange    ( 255/255., 127/255.,   0/255.);
 G4Colour  blue      (   0/255.,   0/255., 255/255.);
 // G4Colour  magenta   ( 255/255.,   0/255., 255/255.);
 G4Colour  grey      ( 127/255., 127/255., 127/255.);
 G4Colour  lightblue   ( 139/255., 208/255., 255/255.);
 G4Colour  lightorange ( 255/255., 189/255., 165/255.);

 //------------------------------------------
 // Visual Attributes for:  ScintillatorContainer
 //------------------------------------------
 G4VisAttributes* TriggerScintillatorContainerVisAtt = new G4VisAttributes(blue);
 //TriggerScintillatorContainerVisAtt->SetVisibility(false);
 TriggerScintillatorContainerVisAtt->SetVisibility(true);
 TriggerScintillatorContainerVisAtt->SetForceWireframe(true);
 //TriggerScintillatorContainerVisAtt->SetForceSolid(true);
 TriggerScintillatorContainer_Logical->SetVisAttributes(TriggerScintillatorContainerVisAtt);

 //-----------------------------------------
 // Visual Attributes for:  TriggerScintillator
 //-----------------------------------------
//  G4VisAttributes* TriggerScintillatorVisAtt = new G4VisAttributes(lightblue);
//  TriggerScintillatorVisAtt->SetVisibility(true);
//  // Needed for the correct visualization using Coin3D
//  //TriggerScintillatorVisAtt->SetForceSolid(true);
//  //TriggerScintillatorVisAtt->SetForceWireframe(true);
//  TriggerScintillator_Logical->SetVisAttributes(TriggerScintillatorVisAtt);
//
G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::ConstructComponent() " << G4endl << G4endl;

} // end of  QweakSimTriggerScintillator::ConstructComponent()

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimTriggerScintillator::DefineTriggerScintillatorGeometry

(

)

Definition at line 122 of file QweakSimTriggerScintillator.cc.

{
  G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::DefineTriggerScintillatorGeometry() " << G4endl << G4endl;
  G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::DefineTriggerScintillatorGeometry() " << G4endl << G4endl;
}

void QweakSimTriggerScintillator::DestroyComponent

(

)

Definition at line 271 of file QweakSimTriggerScintillator.cc.

{
}

G4LogicalVolume* QweakSimTriggerScintillator::GetTriggerScintillator_LogicalVolume ( )

inline

Definition at line 76 of file QweakSimTriggerScintillator.hh.

References TriggerScintillator_Logical.

{return TriggerScintillator_Logical;}

G4VPhysicalVolume* QweakSimTriggerScintillator::GetTriggerScintillator_PhysicalVolume ( )

inline

Definition at line 77 of file QweakSimTriggerScintillator.hh.

References TriggerScintillator_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{return TriggerScintillator_Physical;}

Here is the caller graph for this function:

void QweakSimTriggerScintillator::PlaceTriggerScintillator_MasterContainers ( )

private

Definition at line 356 of file QweakSimTriggerScintillator.cc.

References Phi_Angle, Position_TriggerScintillatorContainer, Position_TriggerScintillatorContainer_X, Position_TriggerScintillatorContainer_Y, Position_TriggerScintillatorContainer_Z, pSurfChk, Rotation_TriggerScintillatorContainer, theMotherPV, Tilting_Angle, TriggerScintillatorContainer_Logical, and TriggerScintillatorContainer_Physical.

Referenced by ConstructComponent(), and TriggerScintillatorGeometryPVUpdate().

{
    G4cout << G4endl << "###### QweakSimTriggerScintillator: Define TriggerScintillatorContainer_Physical " << G4endl << G4endl;
    for (size_t i=0; i< TriggerScintillatorContainer_Physical.size();i++)
    {

     G4double phi = Phi_Angle + i * 180.0 * degree;
     Rotation_TriggerScintillatorContainer[i] = new G4RotationMatrix();
     Rotation_TriggerScintillatorContainer[i]->rotateZ(-phi);
     Rotation_TriggerScintillatorContainer[i]->rotateX(Tilting_Angle);

     Position_TriggerScintillatorContainer  = G4ThreeVector(Position_TriggerScintillatorContainer_X[i],
                   Position_TriggerScintillatorContainer_Y[i],
                   Position_TriggerScintillatorContainer_Z[i]);

     Position_TriggerScintillatorContainer.rotateZ(phi);

     TriggerScintillatorContainer_Physical[i]   = new G4PVPlacement(Rotation_TriggerScintillatorContainer[i],
                      Position_TriggerScintillatorContainer,
                      "TriggerScintillatorContainer_Physical",
                      TriggerScintillatorContainer_Logical,
                      theMotherPV,
                      false,
                      i,
                      pSurfChk);
    }
}

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInX	(	G4double	xPos,
		G4int	pkg = 0
	)

Definition at line 296 of file QweakSimTriggerScintillator.cc.

References Position_TriggerScintillatorContainer_X, and TriggerScintillatorGeometryPVUpdate().

Referenced by QweakSimTriggerScintillatorMessenger::SetNewValue().

{
    G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::SetScintillatorCenterPositionInX() " << G4endl << G4endl;

    Position_TriggerScintillatorContainer_X[pkg] =xPos;
    TriggerScintillatorGeometryPVUpdate();

    G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInX() " << G4endl << G4endl;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInY	(	G4double	yPos,
		G4int	pkg = 0
	)

Definition at line 307 of file QweakSimTriggerScintillator.cc.

References Position_TriggerScintillatorContainer_Y, and TriggerScintillatorGeometryPVUpdate().

Referenced by QweakSimTriggerScintillatorMessenger::SetNewValue().

{
    G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInY() " << G4endl << G4endl;

    Position_TriggerScintillatorContainer_Y[pkg] = yPos;
    TriggerScintillatorGeometryPVUpdate();

 G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInY() " << G4endl << G4endl;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInZ	(	G4double	zPos,
		G4int	pkg = 0
	)

Definition at line 318 of file QweakSimTriggerScintillator.cc.

References Position_TriggerScintillatorContainer_Z, and TriggerScintillatorGeometryPVUpdate().

Referenced by QweakSimTriggerScintillatorMessenger::SetNewValue().

{
    G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInZ() " << G4endl << G4endl;

    Position_TriggerScintillatorContainer_Z[pkg] = zPos;
    TriggerScintillatorGeometryPVUpdate();

    G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::SetTriggerScintillatorCenterPositionInZ() " << G4endl << G4endl;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorMaterial

(

G4String

materialName

)

Definition at line 253 of file QweakSimTriggerScintillator.cc.

References TriggerScintillator_Logical.

Referenced by QweakSimTriggerScintillatorMessenger::SetNewValue().

{
  // search the material by its name
  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
  if (pttoMaterial)
     {
  G4cout << "==== Changing TriggerScintillator Detector Material: Looking up Material  " << G4endl;
                TriggerScintillator_Logical->SetMaterial(pttoMaterial);
  G4cout << "==== Changing Scintillator detector  Material:  Now the TriggerScintillator is made of " << materialName << G4endl;
     }
  else {
      G4cerr << "==== ERROR: Changing TriggerScintillator Detector Material failed" << G4endl;
  }

}

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorPhiAngle

(

G4double

phiangle

)

Definition at line 343 of file QweakSimTriggerScintillator.cc.

References Phi_Angle, and TriggerScintillatorGeometryPVUpdate().

Referenced by QweakSimVDCMessenger::SetNewValue().

{
    //G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::SetTriggerScintillatorPhiAngle() " << G4endl << G4endl;

       // assign new azimuthal angle
       Phi_Angle = phiangle -90.0*degree;

       TriggerScintillatorGeometryPVUpdate();

       G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::SetTriggerScintillatorPhiAngle() " << G4endl << G4endl;

}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorThickness

(

G4double

thickness

)

Definition at line 276 of file QweakSimTriggerScintillator.cc.

References Thickness, and TriggerScintillator_Logical.

Referenced by QweakSimTriggerScintillatorMessenger::SetNewValue().

{
    G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::SetTriggerScintillatorThickness() " << G4endl << G4endl;

    G4Box *box = NULL;

    Thickness = thickness;

    if(TriggerScintillator_Logical)
      box = (G4Box*) TriggerScintillator_Logical->GetSolid();
    if(box)
      box->SetZHalfLength(0.5*Thickness);


    G4RunManager::GetRunManager()->GeometryHasBeenModified();

    G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::SetTriggerScintillatorThickness() " << G4endl << G4endl;
}

Here is the caller graph for this function:

void QweakSimTriggerScintillator::SetTriggerScintillatorTiltAngle

(

G4double

tiltangle

)

Definition at line 330 of file QweakSimTriggerScintillator.cc.

References Tilting_Angle, and TriggerScintillatorGeometryPVUpdate().

Referenced by QweakSimTriggerScintillatorMessenger::SetNewValue().

{
    G4cout << G4endl << "###### Calling QweakSimTriggerScintillator::SetTriggerScintillatorTiltAngle() " << G4endl << G4endl;

    // assign new tilting
    Tilting_Angle = tiltangle;

    TriggerScintillatorGeometryPVUpdate();

    G4cout << G4endl << "###### Leaving QweakSimTriggerScintillator::SetTriggerScintillatorTiltAngle() " << G4endl << G4endl;
}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimTriggerScintillator::TriggerScintillatorGeometryPVUpdate ( )

private

Definition at line 383 of file QweakSimTriggerScintillator.cc.

References PlaceTriggerScintillator_MasterContainers(), Rotation_TriggerScintillatorContainer, TriggerScintillatorContainer_Logical, and TriggerScintillatorContainer_Physical.

Referenced by SetTriggerScintillatorCenterPositionInX(), SetTriggerScintillatorCenterPositionInY(), SetTriggerScintillatorCenterPositionInZ(), SetTriggerScintillatorPhiAngle(), and SetTriggerScintillatorTiltAngle().

{
    for (size_t i=0; i< TriggerScintillatorContainer_Physical.size();i++) {
          if (TriggerScintillatorContainer_Logical)
            TriggerScintillatorContainer_Logical->RemoveDaughter(TriggerScintillatorContainer_Physical[i]);

          delete TriggerScintillatorContainer_Physical[i];
          TriggerScintillatorContainer_Physical[i] = 0;

          delete Rotation_TriggerScintillatorContainer[i];
          Rotation_TriggerScintillatorContainer[i] = 0;

      }

    PlaceTriggerScintillator_MasterContainers();
}

Here is the call graph for this function:

Here is the caller graph for this function:

Field Documentation

G4double QweakSimTriggerScintillator::Container_FullLength_X

private

Definition at line 98 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4double QweakSimTriggerScintillator::Container_FullLength_Y

private

Definition at line 99 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4double QweakSimTriggerScintillator::Container_FullLength_Z

private

Definition at line 100 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4double QweakSimTriggerScintillator::Phi_Angle

private

Definition at line 110 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and SetTriggerScintillatorPhiAngle().

QweakSimMaterial* QweakSimTriggerScintillator::pMaterial

private

Definition at line 86 of file QweakSimTriggerScintillator.hh.

Referenced by QweakSimTriggerScintillator().

G4ThreeVector QweakSimTriggerScintillator::Position_TriggerScintillatorContainer

private

Definition at line 115 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers().

std::vector<G4double> QweakSimTriggerScintillator::Position_TriggerScintillatorContainer_X

private

Definition at line 124 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and SetTriggerScintillatorCenterPositionInX().

std::vector<G4double> QweakSimTriggerScintillator::Position_TriggerScintillatorContainer_Y

private

Definition at line 125 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and SetTriggerScintillatorCenterPositionInY().

std::vector<G4double> QweakSimTriggerScintillator::Position_TriggerScintillatorContainer_Z

private

Definition at line 126 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and SetTriggerScintillatorCenterPositionInZ().

std::vector<G4RotationMatrix*> QweakSimTriggerScintillator::Rotation_TriggerScintillatorContainer

private

Definition at line 116 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and TriggerScintillatorGeometryPVUpdate().

G4double QweakSimTriggerScintillator::StraightBar_FullHeight

private

Definition at line 103 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4double QweakSimTriggerScintillator::StraightBar_FullLength

private

Definition at line 102 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4double QweakSimTriggerScintillator::StraightBar_FullThickness

private

Definition at line 104 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4VPhysicalVolume* QweakSimTriggerScintillator::theMotherPV

private

Definition at line 88 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and PlaceTriggerScintillator_MasterContainers().

G4double QweakSimTriggerScintillator::Thickness

private

Definition at line 111 of file QweakSimTriggerScintillator.hh.

Referenced by SetTriggerScintillatorThickness().

G4double QweakSimTriggerScintillator::Tilting_Angle

private

Definition at line 109 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and SetTriggerScintillatorTiltAngle().

G4ThreeVector QweakSimTriggerScintillator::Translation_SingleBarRight

private

Definition at line 119 of file QweakSimTriggerScintillator.hh.

G4LogicalVolume* QweakSimTriggerScintillator::TriggerScintillator_Logical

private

Definition at line 94 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), GetTriggerScintillator_LogicalVolume(), QweakSimTriggerScintillator(), SetTriggerScintillatorMaterial(), SetTriggerScintillatorThickness(), and ~QweakSimTriggerScintillator().

G4Material* QweakSimTriggerScintillator::TriggerScintillator_Material

private

Definition at line 96 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

G4VPhysicalVolume* QweakSimTriggerScintillator::TriggerScintillator_Physical

private

Definition at line 95 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), GetTriggerScintillator_PhysicalVolume(), QweakSimTriggerScintillator(), and ~QweakSimTriggerScintillator().

G4double QweakSimTriggerScintillator::TriggerScintillatorCenterZPosition

private

Definition at line 106 of file QweakSimTriggerScintillator.hh.

G4LogicalVolume* QweakSimTriggerScintillator::TriggerScintillatorContainer_Logical

private

Definition at line 90 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), TriggerScintillatorGeometryPVUpdate(), and ~QweakSimTriggerScintillator().

G4Material* QweakSimTriggerScintillator::TriggerScintillatorContainer_Material

private

Definition at line 92 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

std::vector<G4VPhysicalVolume*> QweakSimTriggerScintillator::TriggerScintillatorContainer_Physical

private

Definition at line 91 of file QweakSimTriggerScintillator.hh.

Referenced by PlaceTriggerScintillator_MasterContainers(), QweakSimTriggerScintillator(), and TriggerScintillatorGeometryPVUpdate().

QweakSimTriggerScintillatorMessenger* QweakSimTriggerScintillator::TriggerScintillatorMessenger

private

Definition at line 84 of file QweakSimTriggerScintillator.hh.

Referenced by QweakSimTriggerScintillator(), and ~QweakSimTriggerScintillator().

G4VSensitiveDetector* QweakSimTriggerScintillator::TriggerScintillatorSD

private

Definition at line 122 of file QweakSimTriggerScintillator.hh.

Referenced by ConstructComponent(), and QweakSimTriggerScintillator().

---

The documentation for this class was generated from the following files:

• QweakSimTriggerScintillator.hh
• QweakSimTriggerScintillator.cc
