QweakSimWShutters Class Reference

#include <QweakSimWShutters.hh>

Collaboration diagram for QweakSimWShutters:

Public Member Functions
	QweakSimWShutters (G4int n)
	Constructor. More...
	~QweakSimWShutters ()
	Destructor. More...
void	ConstructWShutters (G4VPhysicalVolume *)
void	DestroyComponent ()
void	SetWShutters_CenterPositionInX (G4double xPos)
void	SetWShutters_CenterPositionInY (G4double yPos)
void	SetWShutters_CenterPositionInZ (G4double zPos)
G4double	GetWShutters_CenterPositionInX ()
G4double	GetWShutters_CenterPositionInY ()
G4double	GetWShutters_CenterPositionInZ ()
void	SetWShuttersMaterial (G4String)
void	SetWShutters_LengthInX (G4double dim)
void	SetWShutters_LengthInY (G4double dim)
void	SetWShutters_LengthInZ (G4double dim)
G4double	GetWShutters_LengthInX ()
G4double	GetWShutters_LengthInY ()
G4double	GetWShutters_LengthInZ ()
void	SetWShuttersNumber (G4int n)
G4int	GetWShuttersNumber ()
void	SetEnabled ()
void	SetDisabled ()
void	SetWShutters_Material (G4String)

Private Attributes
G4int	WShutterNum
QweakSimMaterial *	pMaterial
G4LogicalVolume *	WShutters_Logical
G4VPhysicalVolume *	WShutters_Physical
G4Box *	WShutters_Box
G4Trap *	WShutters_Trap
G4VSolid *	WShutters_Solid
G4Material *	WShutters_Material
G4VisAttributes *	WShutters_VisAtt
G4RotationMatrix *	Rot
G4RotationMatrix *	WRot
QweakSimWShuttersMessenger *	WShutters_Messenger
G4double	WShutters_Length_X
G4double	WShutters_Length_Y
G4double	WShutters_Length_Z
G4double	WShutters_CenterXPosition
G4double	WShutters_CenterYPosition
G4double	WShutters_CenterZPosition

Detailed Description

Definition at line 35 of file QweakSimWShutters.hh.

Constructor & Destructor Documentation

QweakSimWShutters::QweakSimWShutters

(

G4int

n

)

Constructor.

Definition at line 16 of file QweakSimWShutters.cc.

References QweakSimMaterial::GetInstance(), inch, pMaterial, Rot, WRot, WShutters_Box, WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, WShutters_Length_X, WShutters_Length_Y, WShutters_Length_Z, WShutters_Logical, WShutters_Material, WShutters_Messenger, WShutters_Physical, WShutters_Solid, WShutters_Trap, and WShutters_VisAtt.

{
  WShutters_Logical  = NULL;
  WShutters_Physical = NULL;
  WShutters_Box      = NULL;
  WShutters_Trap     = NULL;
  WShutters_Solid    = NULL;
  WShutters_Material = NULL;
  WShutters_VisAtt   = NULL;

  Rot = NULL;
  WRot = NULL;

  WShutters_Length_X        =   2.687*inch;
  WShutters_Length_Y        =   3.7*inch;
  WShutters_Length_Z        =    2.0*inch;



  WShutters_CenterXPosition = 0.5 * WShutters_Length_X + 2.625*inch;
  WShutters_CenterYPosition = 0.0*inch;
  WShutters_CenterZPosition = -(0.5 * WShutters_Length_Z)-220.939*inch;

  WShutters_Messenger = new QweakSimWShuttersMessenger(this,n);

 // get access to material definition
  pMaterial = QweakSimMaterial::GetInstance();
}

Here is the call graph for this function:

QweakSimWShutters::~QweakSimWShutters

(

)

Destructor.

Definition at line 46 of file QweakSimWShutters.cc.

{ }

Member Function Documentation

void QweakSimWShutters::ConstructWShutters

(

G4VPhysicalVolume *

MotherVolume

)

Definition at line 49 of file QweakSimWShutters.cc.

References QweakSimMaterial::GetMaterial(), inch, pMaterial, pSurfChk, Rot, WRot, WShutterNum, WShutters_Box, WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, WShutters_Length_X, WShutters_Length_Y, WShutters_Length_Z, WShutters_Logical, WShutters_Material, WShutters_Physical, WShutters_Solid, WShutters_Trap, and WShutters_VisAtt.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{

  //  assign material
  WShutters_Material = pMaterial->GetMaterial("TungstenAlloy");

  G4ThreeVector positionWShutters;
  G4ThreeVector Trans;



  Rot = new G4RotationMatrix;
  Rot->rotateY(-M_PI/2*rad);
  Trans = G4ThreeVector(-2.688*inch,0,0);

  WShutters_Box = new G4Box("WShutters_Box", WShutters_Length_X*0.5, WShutters_Length_Y*0.5, WShutters_Length_Z*0.5);
  WShutters_Trap = new G4Trap("WShutters_Trap", 0.5*WShutters_Length_Z, 0.5*WShutters_Length_Z, 0.5*2.125*inch, 0.5*WShutters_Length_Y,0.5*2.688*inch);
  WShutters_Solid = new G4UnionSolid("WShutters_Box+WShutters_Trap", WShutters_Box, WShutters_Trap, Rot, Trans);

  WRot = new G4RotationMatrix;
  WRot->rotateZ(M_PI*rad);

  //***************************************************************************
  //  Define WShutters logical and physical volumes

  WShutters_Logical = new G4LogicalVolume(WShutters_Solid,
                                      WShutters_Material,
                                         "WShutters_Log",
                                         0,0,0);

  positionWShutters = G4ThreeVector(WShutters_CenterXPosition,
                                WShutters_CenterYPosition,
                                WShutters_CenterZPosition);

  if(WShutterNum==1){
    WShutters_Physical = new G4PVPlacement(0,
                                        positionWShutters,
                                        "WShutters",
                                        WShutters_Logical,
                                        MotherVolume,
                                        false,
                                        0,
                                        pSurfChk);
  }else if(WShutterNum==2){
    WShutters_Physical = new G4PVPlacement(WRot,
                                            positionWShutters,
                                            "WShutters",
                                            WShutters_Logical,
                                            MotherVolume,
                                            false,
                                            0,
                                            pSurfChk);
  }
  //***************************************************************************

  //  Formating
  G4Color blue (0.,0.,1.);

  WShutters_VisAtt = new G4VisAttributes(blue);
  WShutters_VisAtt->SetVisibility(true);
  WShutters_Logical->SetVisAttributes(WShutters_VisAtt);

}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimWShutters::DestroyComponent

(

)

G4double QweakSimWShutters::GetWShutters_CenterPositionInX ( )

inline

Definition at line 85 of file QweakSimWShutters.hh.

References WShutters_CenterXPosition.

{return WShutters_CenterXPosition;}

G4double QweakSimWShutters::GetWShutters_CenterPositionInY ( )

inline

Definition at line 86 of file QweakSimWShutters.hh.

References WShutters_CenterYPosition.

{return WShutters_CenterYPosition;}

G4double QweakSimWShutters::GetWShutters_CenterPositionInZ ( )

inline

Definition at line 87 of file QweakSimWShutters.hh.

References WShutters_CenterZPosition.

{return WShutters_CenterZPosition;}

G4double QweakSimWShutters::GetWShutters_LengthInX ( )

inline

Definition at line 95 of file QweakSimWShutters.hh.

References WShutters_Length_X.

{return WShutters_Length_X;}

G4double QweakSimWShutters::GetWShutters_LengthInY ( )

inline

Definition at line 96 of file QweakSimWShutters.hh.

References WShutters_Length_Y.

{return WShutters_Length_Y;}

G4double QweakSimWShutters::GetWShutters_LengthInZ ( )

inline

Definition at line 97 of file QweakSimWShutters.hh.

References WShutters_Length_Z.

{return WShutters_Length_Z;}

G4int QweakSimWShutters::GetWShuttersNumber ( )

inline

Definition at line 103 of file QweakSimWShutters.hh.

References WShutterNum.

{return WShutterNum;}

void QweakSimWShutters::SetDisabled

(

)

Definition at line 176 of file QweakSimWShutters.cc.

References SetWShutters_Material(), WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, WShutters_Physical, and WShutters_VisAtt.

Referenced by QweakSimDetectorConstruction::ConstructQweak(), and QweakSimWShuttersMessenger::SetNewValue().

{
  // Disables the WShutters by changing the material to air,
  // moving the wall 5m into the floor and hiding it.
  WShutters_VisAtt->SetVisibility(true);
  SetWShutters_Material("Air");
  WShutters_Physical->SetTranslation(G4ThreeVector(WShutters_CenterXPosition,
                                               WShutters_CenterYPosition + 200*cm,
                                               WShutters_CenterZPosition));

}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimWShutters::SetEnabled

(

)

Definition at line 162 of file QweakSimWShutters.cc.

References SetWShutters_Material(), WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, WShutters_Material, WShutters_Physical, and WShutters_VisAtt.

Referenced by QweakSimWShuttersMessenger::SetNewValue().

{
  //  Enables the WShutters
  WShutters_VisAtt->SetVisibility(true);
  SetWShutters_Material(WShutters_Material->GetName());
  WShutters_Physical->SetTranslation(G4ThreeVector(WShutters_CenterXPosition,
                                               WShutters_CenterYPosition,
                                               WShutters_CenterZPosition));


}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimWShutters::SetWShutters_CenterPositionInX

(

G4double

xPos

)

Definition at line 123 of file QweakSimWShutters.cc.

References WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, and WShutters_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{
  //  Sets X position of the WShutters
  WShutters_CenterXPosition = xPos;
  WShutters_Physical->SetTranslation(G4ThreeVector(WShutters_CenterXPosition,
                           WShutters_CenterYPosition,
                           WShutters_CenterZPosition));
}

Here is the caller graph for this function:

void QweakSimWShutters::SetWShutters_CenterPositionInY

(

G4double

yPos

)

Definition at line 133 of file QweakSimWShutters.cc.

References WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, and WShutters_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{
  //  Sets Y position of the WShutters
  WShutters_CenterYPosition = yPos;
  WShutters_Physical->SetTranslation(G4ThreeVector(WShutters_CenterXPosition,
                           WShutters_CenterYPosition,
                           WShutters_CenterZPosition));
}

Here is the caller graph for this function:

void QweakSimWShutters::SetWShutters_CenterPositionInZ

(

G4double

zPos

)

Definition at line 143 of file QweakSimWShutters.cc.

References WShutters_CenterXPosition, WShutters_CenterYPosition, WShutters_CenterZPosition, and WShutters_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{
  //  Sets Z position of the WShutters
  WShutters_CenterZPosition = zPos;
  WShutters_Physical->SetTranslation(G4ThreeVector(WShutters_CenterXPosition,
                           WShutters_CenterYPosition,
                           WShutters_CenterZPosition));
}

Here is the caller graph for this function:

void QweakSimWShutters::SetWShutters_LengthInX ( G4double  dim )

inline

Definition at line 91 of file QweakSimWShutters.hh.

References WShutters_Length_X.

{WShutters_Length_X = dim;}

void QweakSimWShutters::SetWShutters_LengthInY ( G4double  dim )

inline

Definition at line 92 of file QweakSimWShutters.hh.

References WShutters_Length_Y.

{WShutters_Length_Y = dim;}

void QweakSimWShutters::SetWShutters_LengthInZ ( G4double  dim )

inline

Definition at line 93 of file QweakSimWShutters.hh.

References WShutters_Length_Z.

{WShutters_Length_Z = dim;}

void QweakSimWShutters::SetWShutters_Material

(

G4String

materialName

)

Definition at line 154 of file QweakSimWShutters.cc.

References WShutters_Logical.

Referenced by QweakSimDetectorConstruction::ConstructQweak(), SetDisabled(), and SetEnabled().

{
  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
  WShutters_Logical->SetMaterial(pttoMaterial);
}

Here is the caller graph for this function:

void QweakSimWShutters::SetWShuttersMaterial

(

G4String

materialName

)

Definition at line 114 of file QweakSimWShutters.cc.

References WShutters_Logical.

{
  //  Sets WShutters material
  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
  if (pttoMaterial)
    WShutters_Logical->SetMaterial(pttoMaterial);
}

void QweakSimWShutters::SetWShuttersNumber ( G4int  n )

inline

Definition at line 102 of file QweakSimWShutters.hh.

References WShutterNum.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{       WShutterNum = n;}

Here is the caller graph for this function:

Field Documentation

QweakSimMaterial* QweakSimWShutters::pMaterial

private

Definition at line 41 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), and QweakSimWShutters().

G4RotationMatrix* QweakSimWShutters::Rot

private

Definition at line 52 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), and QweakSimWShutters().

G4RotationMatrix* QweakSimWShutters::WRot

private

Definition at line 53 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), and QweakSimWShutters().

G4int QweakSimWShutters::WShutterNum

private

Definition at line 40 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShuttersNumber(), and SetWShuttersNumber().

G4Box* QweakSimWShutters::WShutters_Box

private

Definition at line 45 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), and QweakSimWShutters().

G4double QweakSimWShutters::WShutters_CenterXPosition

private

Definition at line 65 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShutters_CenterPositionInX(), QweakSimWShutters(), SetDisabled(), SetEnabled(), SetWShutters_CenterPositionInX(), SetWShutters_CenterPositionInY(), and SetWShutters_CenterPositionInZ().

G4double QweakSimWShutters::WShutters_CenterYPosition

private

Definition at line 66 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShutters_CenterPositionInY(), QweakSimWShutters(), SetDisabled(), SetEnabled(), SetWShutters_CenterPositionInX(), SetWShutters_CenterPositionInY(), and SetWShutters_CenterPositionInZ().

G4double QweakSimWShutters::WShutters_CenterZPosition

private

Definition at line 67 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShutters_CenterPositionInZ(), QweakSimWShutters(), SetDisabled(), SetEnabled(), SetWShutters_CenterPositionInX(), SetWShutters_CenterPositionInY(), and SetWShutters_CenterPositionInZ().

G4double QweakSimWShutters::WShutters_Length_X

private

Definition at line 58 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShutters_LengthInX(), QweakSimWShutters(), and SetWShutters_LengthInX().

G4double QweakSimWShutters::WShutters_Length_Y

private

Definition at line 59 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShutters_LengthInY(), QweakSimWShutters(), and SetWShutters_LengthInY().

G4double QweakSimWShutters::WShutters_Length_Z

private

Definition at line 60 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), GetWShutters_LengthInZ(), QweakSimWShutters(), and SetWShutters_LengthInZ().

G4LogicalVolume* QweakSimWShutters::WShutters_Logical

private

Definition at line 43 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), QweakSimWShutters(), SetWShutters_Material(), and SetWShuttersMaterial().

G4Material* QweakSimWShutters::WShutters_Material

private

Definition at line 49 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), QweakSimWShutters(), and SetEnabled().

QweakSimWShuttersMessenger* QweakSimWShutters::WShutters_Messenger

private

Definition at line 56 of file QweakSimWShutters.hh.

Referenced by QweakSimWShutters().

G4VPhysicalVolume* QweakSimWShutters::WShutters_Physical

private

Definition at line 44 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), QweakSimWShutters(), SetDisabled(), SetEnabled(), SetWShutters_CenterPositionInX(), SetWShutters_CenterPositionInY(), and SetWShutters_CenterPositionInZ().

G4VSolid* QweakSimWShutters::WShutters_Solid

private

Definition at line 47 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), and QweakSimWShutters().

G4Trap* QweakSimWShutters::WShutters_Trap

private

Definition at line 46 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), and QweakSimWShutters().

G4VisAttributes* QweakSimWShutters::WShutters_VisAtt

private

Definition at line 50 of file QweakSimWShutters.hh.

Referenced by ConstructWShutters(), QweakSimWShutters(), SetDisabled(), and SetEnabled().

---

The documentation for this class was generated from the following files:

• QweakSimWShutters.hh
• QweakSimWShutters.cc
