QwMoller.cc File Reference

Moller data analysis. More...

#include <iostream>
#include <math.h>
#include <sstream>
#include <boost/random.hpp>
#include <TROOT.h>
#include <TFile.h>
#include <TTree.h>
#include "QwLog.h"
#include "QwOptionsParity.h"
#include "QwEventBuffer.h"
#include "QwHelicity.h"
#include "QwHelicityPattern.h"
#include "QwHistogramHelper.h"
#include "QwSubsystemArrayParity.h"
#include "QwMollerDetector.h"

Include dependency graph for QwMoller.cc:

Go to the source code of this file.

Functions
void	setOptions ()
int	main (int argc, char *argv[])

Variables
static const int	scal_num = 96
float	gscalar [scal_num]
float	gscaler_old [scal_num]
float	gscaler_new [scal_num]
float	gscaler_change [scal_num]
static bool	bTree = true
static bool	bHisto = true
static bool	bHelicity = true

Detailed Description

Moller data analysis.

Definition in file QwMoller.cc.

Function Documentation

int main	(	int	argc,
		char *	argv[]
	)

Set the expected options, command line arguments and the configuration filename

Message logging facilities

Fill the search paths for the parameter files; this sets a static variable within the QwParameterFile class which will be used by all instances. The "scratch" directory should be first.

Create the running sum

System setup complete, Here's where we would loop over all specified runs

First, do processing of non-physics events...

Add event into the subsystem

Helicity pattern

Accumulate the running sum to calculate the event based running average

Print the helicity information

Fill the histograms

Fill the expert tree

Fill the tree

TODO We need another check here to test for pattern validity. Right now the first 24 cycles are also added to the histograms.

Periodically print event number

end of loop over events

Close ROOT file

Definition at line 54 of file QwMoller.cc.

References QwHelicityPattern::AccumulateRunningBurstSum(), QwSubsystemArrayParity::AccumulateRunningSum(), QwParameterFile::AppendToSearchPath(), bHelicity, bHisto, bTree, QwHelicityPattern::CalculateAsymmetry(), QwHelicityPattern::CalculateBurstAverage(), QwSubsystemArrayParity::CalculateRunningAverage(), QwHelicityPattern::CalculateRunningAverage(), QwHelicityPattern::CalculateRunningBurstAverage(), QwHelicityPattern::ClearBurstSum(), QwEventBuffer::CloseDataFile(), QwSubsystemArrayParity::ConstructBranchAndVector(), QwHelicityPattern::ConstructBranchAndVector(), QwHelicityPattern::ConstructHistograms(), QwSubsystemArray::ConstructHistograms(), QwSubsystemArray::ConstructTree(), DefineOptionsParity(), QwLog::endl(), QwSubsystemArrayParity::FillHistograms(), QwHelicityPattern::FillHistograms(), QwEventBuffer::FillSubsystemData(), QwSubsystemArray::FillTree(), QwSubsystemArrayParity::FillTreeVector(), getenv_safe(), getenv_safe_string(), QwEventBuffer::GetEvent(), QwEventBuffer::GetEventNumber(), QwOptions::GetValue(), gQwHists, gQwLog, gQwOptions, QwOptions::HasValue(), QwSubsystemArrayParity::IncrementErrorCounters(), QwLog::InitLogFile(), QwHelicityPattern::IsBurstSumEnabled(), QwHelicityPattern::IsCompletePattern(), QwHelicityPattern::IsEndOfBurst(), QwEventBuffer::IsPhysicsEvent(), QwEventBuffer::IsROCConfigurationEvent(), QwHelicityPattern::IsRunningSumEnabled(), QwLog::kDebug, QwLog::kMessage, QwLog::kTruncate, QwHelicityPattern::LoadEventData(), QwHistogramHelper::LoadHistParamsFromFile(), QwEventBuffer::OpenDataFile(), QwOptions::Parse(), QwHelicityPattern::PrintRunningAverage(), QwHelicityPattern::PrintRunningBurstAverage(), QwSubsystemArrayParity::PrintValue(), QwSubsystemArray::ProcessEvent(), QwSubsystemArray::ProcessOptions(), QwError, QwMessage, MQwCodaControlEvent::ReportRunSummary(), QwOptions::SetCommandLine(), QwOptions::SetConfigFile(), QwLog::SetFileThreshold(), setOptions(), QwLog::SetScreenThreshold(), and QwSubsystemArray::UpdateEventTypeMask().

{

  std::cout << std::endl << " -= Moller Run Analyzer Started =-" << std::endl;
  //QwParameterFile::AppendToSearchPath(".");
  gQwOptions.SetConfigFile("moller.flags");

  /// Set the expected options, command line arguments and the configuration filename
  setOptions();
  gQwOptions.SetCommandLine(argc, argv);

  DefineOptionsParity(gQwOptions);
  gQwOptions.Parse();

  std::cout << "bcm_offsets: " << gQwOptions.GetValue<float>("bcm1_offset") << ' ' << gQwOptions.GetValue<float>("bcm2_offset") << ' ' << \
               gQwOptions.GetValue<float>("bcm3_offset") << std::endl;

  std::cout << "bcm_gains: " << gQwOptions.GetValue<float>("bcm1_gain") << ' ' << gQwOptions.GetValue<float>("bcm2_gain") << ' ' <<
               gQwOptions.GetValue<float>("bcm3_gain") << std::endl;

  std::cout << "norm_bcm: " << gQwOptions.GetValue<float>("norm_bcm") << std::endl;

  /// Message logging facilities
  gQwLog.InitLogFile("Moller.log", QwLog::kTruncate);
  gQwLog.SetScreenThreshold(QwLog::kMessage);
  gQwLog.SetFileThreshold(QwLog::kDebug);

  ///  Fill the search paths for the parameter files; this sets a static
  ///  variable within the QwParameterFile class which will be used by
  ///  all instances.  The "scratch" directory should be first.
  QwParameterFile::AppendToSearchPath(getenv_safe_string("QW_PRMINPUT"));
  QwParameterFile::AppendToSearchPath(getenv_safe_string("QWANALYSIS") + "/Parity/prminput");

  // Load histogram definitions
  gQwHists.LoadHistParamsFromFile("moller_hists.in");



  // Detector array
  QwSubsystemArrayParity detectors(gQwOptions);
  detectors.ProcessOptions(gQwOptions);
  detectors.UpdateEventTypeMask();

  ///  Create the running sum
  QwSubsystemArrayParity runningsum(detectors);

  // Helicity pattern
  QwHelicityPattern helicitypattern(detectors);

  // Event buffer
  QwEventBuffer eventbuffer;

  std::string fileName;

  /// System setup complete,
  /// Here's where we would loop over all specified runs
  //UInt_t runnumber_min = (UInt_t) gQwOptions.GetIntValuePairFirst("run");
  //UInt_t runnumber_max = (UInt_t) gQwOptions.GetIntValuePairLast("run");
  //std::cout << "RUN: " << runnumber_min << " to " << runnumber_max << std::endl;
  for (UInt_t run = 15; run <= 15; run++) {

    // Data file (input)
    if (gQwOptions.HasValue("input_file")){
      fileName = gQwOptions.GetValue<std::string>("input_file");
    } else { // if (eventbuffer.OpenDataFile(TString("moller-moller_") + Form("%ld.log.0",run),"R")) {
      fileName = TString("moller-moller_") + Form("%u.log.0",run);
      //     } else {
      //       QwError << "No Input File Specified!" << std::endl;
      //       return 1;
    }

    // Open Data file
    if (eventbuffer.OpenDataFile(fileName,"R") != CODA_OK) {
      QwError << "Could not open file!" << QwLog::endl;
      return 1;
    }

    // ROOT file output (histograms)
    TString rootfilename = getenv_safe("QW_ROOTFILES")
                         + TString("/Moller_") + Form("%u.root",run);
    TFile rootfile(rootfilename, "RECREATE", "QWeak ROOT file");

    if (bHisto) {
      rootfile.cd();
      detectors.ConstructHistograms(rootfile.mkdir("moller_histo"));
      if (bHelicity) {
        rootfile.cd();
        helicitypattern.ConstructHistograms(rootfile.mkdir("hel_histo"));
      }
    }

    // ROOT file output (expert tree)
    if (bTree) {
      rootfile.cd();
      detectors.ConstructTree(rootfile.mkdir("expert"));
    }


    // ROOT file output (trees)
    TTree *mpstree;
    TTree *heltree;
    std::vector <Double_t> mpsvector;
    std::vector <Double_t> helvector;

    if (bTree) {
      // MPS events
      rootfile.cd();
      mpstree = new TTree("MPS_Tree","MPS event data tree");
      mpsvector.reserve(6000);
      TString dummystr="";
      detectors.ConstructBranchAndVector(mpstree, dummystr, mpsvector);

      rootfile.cd();
      if (bHelicity) {
        // Helicity events (per multiplet)
        rootfile.cd();
        heltree = new TTree("HEL_Tree","Helicity event data tree");
        helvector.reserve(6000);
        TString dummystr="";
        helicitypattern.ConstructBranchAndVector(heltree, dummystr, helvector);
      }
    }



    while (eventbuffer.GetEvent() == CODA_OK) {

      /// First, do processing of non-physics events...
      if (eventbuffer.IsROCConfigurationEvent()) {
          std::cout << "it is ROC CONFIG event\n";
          // Send ROC configuration event data to the subsystem objects.
        // eventbuffer.FillSubsystemConfigurationData(detectors);
      }

      if (!eventbuffer.IsPhysicsEvent()) continue;

      /// Add event into the subsystem
      eventbuffer.FillSubsystemData(detectors);

      detectors.ProcessEvent();
      detectors.IncrementErrorCounters();

      /// Helicity pattern
      helicitypattern.LoadEventData(detectors);

      /// Accumulate the running sum to calculate the event based running average
      runningsum.AccumulateRunningSum(detectors);

      /// Print the helicity information
      //if (bHelicity && false) {
        // - actual helicity
        //std::cout << (helicity->GetHelicityReported() == 0 ? "-" : helicity->GetHelicityReported() == 1 ? "+" : "?");
        // - delayed helicity
        //std::cout << (helicity->GetHelicityActual() == 0 ? "(-) " : helicity->GetHelicityActual() == 1 ? "(+) " : "(?) ");
        //if (helicity->GetPhaseNumber() == kMultiplet) {
        //  std::cout << std::uppercase << std::hex << helicity->GetRandomSeedActual() << ",  \t";
        //  std::cout << helicity->GetRandomSeedDelayed() << std::dec << std::endl;
        //}
      //}

      /// Fill the histograms
      if (bHisto) detectors.FillHistograms();

      /// Fill the expert tree
      if (bTree) detectors.FillTree();

      /// Fill the tree
      if (bTree) {
        detectors.FillTreeVector(mpsvector);
        mpstree->Fill();
      }

      /// TODO We need another check here to test for pattern validity.  Right
      /// now the first 24 cycles are also added to the histograms.
      if (bHelicity && helicitypattern.IsCompletePattern()) {
        helicitypattern.CalculateAsymmetry();
        if (bHisto) helicitypattern.FillHistograms();
       // helicitypattern.ClearEventData();
      }


      /// Periodically print event number
      if (eventbuffer.GetEventNumber() % 5000 == 0){
        QwMessage << "Number of events processed so far: " << eventbuffer.GetEventNumber() << QwLog::endl;
      }

   } /// end of loop over events

    std::cout << "Last event processed: " << eventbuffer.GetEventNumber() << std::endl;
    /// Close ROOT file
    rootfile.Write(0,TObject::kOverwrite);

    // Close data file and print run summary
    eventbuffer.CloseDataFile();
    eventbuffer.ReportRunSummary();

  } // end of loop over runs

  if (helicitypattern.IsEndOfBurst()) {
    helicitypattern.AccumulateRunningBurstSum();
    helicitypattern.CalculateBurstAverage();
    helicitypattern.ClearBurstSum();
  }

  if (helicitypattern.IsRunningSumEnabled()) {
    helicitypattern.CalculateRunningAverage();
    helicitypattern.PrintRunningAverage();
    if (helicitypattern.IsBurstSumEnabled()) {
      helicitypattern.CalculateRunningBurstAverage();
      helicitypattern.PrintRunningBurstAverage();
    }
  }

  // This will calculate running averages over single helicity events
  runningsum.CalculateRunningAverage();
  QwMessage << " Running average of events" << QwLog::endl;
  QwMessage << " =========================" << QwLog::endl;
  runningsum.PrintValue();


  std::cout << std::endl << " -= Moller Run Analyzer Ended =-" << std::endl << std::endl;
  return 0;
}

void setOptions

(

)

Definition at line 278 of file QwMoller.cc.

References QwOptions::AddOptions(), and gQwOptions.

Referenced by main().

                 {
  gQwOptions.AddOptions()("EXPERIMENT", po::value<std::string>(), "Name of the experiment");
  gQwOptions.AddOptions()("input_file,f", po::value<std::string>(), "Input file to be used");
  gQwOptions.AddOptions()("input_directory,d", po::value<std::string>(), "Directory to be searched for input files, default is current");
  gQwOptions.AddOptions()("output_directory,o", po::value<std::string>(), "Directory where output files are saved");
  gQwOptions.AddOptions()("pol_factor", po::value<float>(), "This needs to be explained to me");
  gQwOptions.AddOptions()("bcm1_offset", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcm2_offset", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcm3_offset", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcm1_gain", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcm2_gain", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcm3_gain", po::value<float>(), " ");
  gQwOptions.AddOptions()("norm_bcm", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcm1_index", po::value<int>(), " ");
  gQwOptions.AddOptions()("bcm2_index", po::value<int>(), " ");
  gQwOptions.AddOptions()("bcm3_index", po::value<int>(), " ");
  gQwOptions.AddOptions()("clock_index", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcur_limit", po::value<float>(), " ");
  gQwOptions.AddOptions()("timebin", po::value<float>(), " ");
  gQwOptions.AddOptions()("bcur_units", po::value<std::string>(), " ");
  gQwOptions.AddOptions()("helicity_pattern", po::value<int>()->default_value(4), "Length of the helicity window, should be 4, 8, or 16");
}

Here is the call graph for this function:

Here is the caller graph for this function:

Variable Documentation

bool bHelicity = true

static

Definition at line 50 of file QwMoller.cc.

Referenced by main().

bool bHisto = true

static

Definition at line 49 of file QwMoller.cc.

Referenced by main().

bool bTree = true

static

Definition at line 48 of file QwMoller.cc.

Referenced by main().

float gscalar[scal_num]

Definition at line 45 of file QwMoller.cc.

float gscaler_change[scal_num]

Definition at line 45 of file QwMoller.cc.

float gscaler_new[scal_num]

Definition at line 45 of file QwMoller.cc.

float gscaler_old[scal_num]

Definition at line 45 of file QwMoller.cc.

const int scal_num = 96

static

Definition at line 44 of file QwMoller.cc.
