#include <VQwBCM.h>

Inheritance diagram for VQwBCM:

Collaboration diagram for VQwBCM:

Public Member Functions
virtual	~VQwBCM ()

virtual Int_t	ProcessEvBuffer (UInt_t *buffer, UInt_t word_position_in_buffer, UInt_t subelement=0)=0
	Process the CODA event buffer for this element. More...

virtual void	ConstructHistograms (TDirectory *folder, TString &prefix)=0
	Construct the histograms for this data element. More...

virtual void	FillHistograms ()=0
	Fill the histograms for this data element. More...

virtual void	SetSingleEventCuts (UInt_t errorflag, Double_t min, Double_t max, Double_t stability)=0
	Inherited from VQwDataElement to set the upper and lower limits (fULimit and fLLimit), stability % and the error flag on this channel. More...

virtual void	Ratio (const VQwBCM &numer, const VQwBCM &denom)

virtual void	ClearEventData ()=0
	Clear the event data in this element. More...

virtual void	InitializeChannel (TString name, TString datatosave)=0

virtual void	InitializeChannel (TString subsystem, TString name, TString datatosave)=0

virtual void	LoadChannelParameters (QwParameterFile &paramfile)=0

virtual Bool_t	NeedsExternalClock ()=0

virtual void	SetExternalClockPtr (const VQwHardwareChannel *clock)=0

virtual void	SetExternalClockName (const std::string name)=0

virtual Double_t	GetNormClockValue ()=0

virtual void	SetDefaultSampleSize (Int_t sample_size)=0

virtual void	SetEventCutMode (Int_t bcuts)=0

virtual UInt_t	UpdateErrorFlag ()
	Update the error flag based on the error flags of internally contained objects Return paramter is the "Eventcut Error Flag". More...

virtual void	UpdateErrorFlag (const VQwBCM *ev_error)=0

virtual void	SetPedestal (Double_t ped)=0

virtual void	SetCalibrationFactor (Double_t calib)=0

virtual void	RandomizeEventData (int helicity, double time)=0

virtual void	EncodeEventData (std::vector< UInt_t > &buffer)=0

virtual Bool_t	ApplySingleEventCuts ()=0

virtual void	IncrementErrorCounters ()=0

virtual void	ProcessEvent ()=0

virtual void	Scale (Double_t factor)=0

virtual void	CalculateRunningAverage ()=0

virtual void	AccumulateRunningSum (const VQwBCM &value)=0

virtual void	DeaccumulateRunningSum (VQwBCM &value)=0

virtual void	ConstructBranchAndVector (TTree *tree, TString &prefix, std::vector< Double_t > &values)=0

virtual void	ConstructBranch (TTree *tree, TString &prefix)=0

virtual void	ConstructBranch (TTree *tree, TString &prefix, QwParameterFile &modulelist)=0

virtual void	FillTreeVector (std::vector< Double_t > &values) const =0

virtual std::vector < QwDBInterface >	GetDBEntry ()=0

virtual std::vector < QwErrDBInterface >	GetErrDBEntry ()=0

virtual Double_t	GetValue ()=0

virtual Double_t	GetValueError ()=0

virtual Double_t	GetValueWidth ()=0

virtual const VQwHardwareChannel *	GetCharge () const =0

virtual void	SetRandomEventParameters (Double_t mean, Double_t sigma)=0

virtual void	SetRandomEventAsymmetry (Double_t asymmetry)=0

virtual void	AddRandomEventDriftParameters (Double_t amplitude, Double_t phase, Double_t frequency)=0

virtual VQwBCM &	operator= (const VQwBCM &value)=0

virtual VQwBCM &	operator+= (const VQwBCM &value)=0

virtual VQwBCM &	operator-= (const VQwBCM &value)=0

virtual void	SetBCMForCombo (VQwBCM *bcm, Double_t weight, Double_t sumqw)=0

Public Member Functions inherited from VQwDataElement
	VQwDataElement ()
	Default constructor. More...

	VQwDataElement (const VQwDataElement &value)
	Copy constructor. More...

virtual	~VQwDataElement ()
	Virtual destructor. More...

Bool_t	IsNameEmpty () const
	Is the name of this element empty? More...

void	SetElementName (const TString &name)
	Set the name of this element. More...

virtual const TString &	GetElementName () const
	Get the name of this element. More...

size_t	GetNumberOfDataWords ()
	Get the number of data words in this data element. More...

UInt_t	GetGoodEventCount () const

virtual void	AssignValueFrom (const VQwDataElement *valueptr)

virtual VQwDataElement &	operator+= (const VQwDataElement &value)
	Addition-assignment operator. More...

virtual VQwDataElement &	operator-= (const VQwDataElement &value)
	Subtraction-assignment operator. More...

virtual void	Sum (const VQwDataElement &value1, const VQwDataElement &value2)
	Sum operator. More...

virtual void	Difference (const VQwDataElement &value1, const VQwDataElement &value2)
	Difference operator. More...

virtual void	Ratio (const VQwDataElement &numer, const VQwDataElement &denom)
	Ratio operator. More...

virtual void	PrintValue () const
	Print single line of value and error of this data element. More...

virtual void	PrintInfo () const
	Print multiple lines of information about this data element. More...

virtual void	PrintErrorCounters () const
	report number of events failed due to HW and event cut failure More...

virtual UInt_t	GetEventcutErrorFlag ()
	return the error flag on this channel/device More...

virtual void	SetNeedsExternalClock (Bool_t needed)

virtual std::string	GetExternalClockName ()

TString	GetSubsystemName () const
	Return the name of the inheriting subsystem name. More...

void	SetSubsystemName (TString sysname)
	Set the name of the inheriting subsystem name. More...

TString	GetModuleType () const
	Return the type of the beam instrument. More...

void	SetModuleType (TString ModuleType)
	set the type of the beam instrument More...

Public Member Functions inherited from MQwHistograms
void	ShareHistograms (const MQwHistograms *source)
	Share histogram pointers between objects. More...

Static Public Member Functions
static VQwBCM *	Create (TString subsystemname, TString type, TString name, TString clock="")
	A fast way of creating a BCM of specified type. More...

static VQwBCM *	Create (const VQwBCM &source)

static VQwBCM *	CreateCombo (TString subsystemname, TString type, TString name)
	A fast way of creating a combo BCM of specified type. More...

static VQwBCM *	CreateCombo (const VQwBCM &source)

Protected Member Functions
	VQwBCM (VQwDataElement &beamcurrent)

	VQwBCM (VQwDataElement &beamcurrent, TString name)

Protected Member Functions inherited from VQwDataElement
void	SetNumberOfDataWords (const UInt_t &numwords)
	Set the number of data words in this data element. More...

virtual VQwDataElement &	operator= (const VQwDataElement &value)
	Arithmetic assignment operator: Should only copy event-based data. More...

virtual void	UpdateErrorFlag (const UInt_t &error)

Protected Member Functions inherited from MQwHistograms
	MQwHistograms ()
	Default constructor. More...

	MQwHistograms (const MQwHistograms &source)
	Copy constructor. More...

virtual	~MQwHistograms ()
	Virtual destructor. More...

virtual MQwHistograms &	operator= (const MQwHistograms &value)

void	Fill_Pointer (TH1_ptr hist_ptr, Double_t value)

void	AddHistogram (TH1 *h)
	Register a histogram. More...

Protected Attributes
VQwDataElement &	fBeamCurrent_ref

Protected Attributes inherited from VQwDataElement
TString	fElementName
	Name of this data element. More...

UInt_t	fNumberOfDataWords
	Number of raw data words in this data element. More...

Int_t	fGoodEventCount
	Number of good events accumulated in this element. More...

TString	fSubsystemName

TString	fModuleType

UInt_t	fErrorFlag
	This the standard error code generated for the channel that contains the global/local/stability flags and the Device error code (Unique error code for HW failures) More...

UInt_t	fErrorConfigFlag
	contains the global/local/stability flags More...

Protected Attributes inherited from MQwHistograms
std::vector< TH1_ptr >	fHistograms
	Histograms associated with this data element. More...

Additional Inherited Members
Public Types inherited from VQwDataElement
enum	EDataToSave { kRaw = 0, kDerived }

Detailed Description

Definition at line 32 of file VQwBCM.h.

Constructor & Destructor Documentation

VQwBCM::VQwBCM ( VQwDataElement & beamcurrent )

inlineprotected

Definition at line 41 of file VQwBCM.h.

41 : fBeamCurrent_ref(beamcurrent) { };

VQwBCM::fBeamCurrent_ref

VQwDataElement & fBeamCurrent_ref

Definition: VQwBCM.h:118

VQwBCM::VQwBCM	(	VQwDataElement &	beamcurrent,
		TString	name
	)

inlineprotected

Definition at line 42 of file VQwBCM.h.

42 : fBeamCurrent_ref(beamcurrent) { };

VQwBCM::fBeamCurrent_ref

VQwDataElement & fBeamCurrent_ref

Definition: VQwBCM.h:118

virtual VQwBCM::~VQwBCM ( )

inlinevirtual

Definition at line 45 of file VQwBCM.h.

45 { };

Member Function Documentation

virtual void VQwBCM::AccumulateRunningSum ( const VQwBCM & value )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::AddRandomEventDriftParameters	(	Double_t	amplitude,
		Double_t	phase,
		Double_t	frequency
	)

pure virtual

Implemented in QwBCM< T >.

Referenced by main().

Here is the caller graph for this function:

virtual Bool_t VQwBCM::ApplySingleEventCuts ( )

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::CalculateRunningAverage ( )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::ClearEventData ( )

pure virtual

Clear the event data in this element.

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual void VQwBCM::ConstructBranch	(	TTree *	tree,
		TString &	prefix
	)

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::ConstructBranch	(	TTree *	tree,
		TString &	prefix,
		QwParameterFile &	modulelist
	)

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::ConstructBranchAndVector	(	TTree *	tree,
		TString &	prefix,
		std::vector< Double_t > &	values
	)

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::ConstructHistograms	(	TDirectory *	folder,
		TString &	prefix
	)

pure virtual

Construct the histograms for this data element.

Implements VQwDataElement.

Implemented in QwBCM< T >.

VQwBCM * VQwBCM::Create	(	TString	subsystemname,
		TString	type,
		TString	name,
		TString	clock = `""`
	)

static

A fast way of creating a BCM of specified type.

Definition at line 27 of file VQwBCM.cc.

References QwMessage, and QwWarning.

Referenced by QwBeamLine::AddToElementList(), and QwBeamLine::CopyTemplatedDataElements().

 {
   Bool_t localDebug = kFALSE;
   type.ToUpper();
   if( localDebug ) QwMessage<<"Creating BCM of type: "<<type<<" with name: "<<
     name<<". Subsystem Name: " <<subsystemname<<" and clock name="<<clock<<"\n";
   // (jc2) As a first try, let's do this the ugly way (but rather very
   // simple), just list out the types of BCM's supported by this code!!!
   if( type == "VQWK") {
     return new QwBCM<QwVQWK_Channel>(subsystemname,name,type);
   } else if ( type == "SIS3801" ) {
     return new QwBCM<QwSIS3801_Channel>(subsystemname,name,type,clock);
   } else if ( type == "SCALER" || type == "SIS3801D24" ) {
     return new QwBCM<QwSIS3801D24_Channel>(subsystemname,name,type,clock);
   } else { // Unsupported one!
     QwWarning << "BCM of type="<<type<<" is UNSUPPORTED!!\n";
     exit(-1);
   }
 }

Here is the caller graph for this function:

VQwBCM * VQwBCM::Create ( const VQwBCM & source )

static

Definition at line 47 of file VQwBCM.cc.

References QwLog::endl(), VQwDataElement::GetModuleType(), QwMessage, and QwWarning.

 {
   Bool_t localDebug = kFALSE;
   TString type = source.GetModuleType();
   type.ToUpper();
   if( localDebug ) QwMessage<<"Creating BCM of type: "<<type<<QwLog::endl;
   // (jc2) As a first try, let's do this the ugly way (but rather very
   // simple), just list out the types of BCM's supported by this code!!!
   if( type == "VQWK") {
     return new QwBCM<QwVQWK_Channel>(dynamic_cast<const QwBCM<QwVQWK_Channel>&>(source));
   } else if ( type == "SIS3801" ) {
     return new QwBCM<QwSIS3801_Channel>(dynamic_cast<const QwBCM<QwSIS3801_Channel>&>(source));
   } else if ( type == "SCALER" || type == "SIS3801D24" ) {
     return new QwBCM<QwSIS3801D24_Channel>(dynamic_cast<const QwBCM<QwSIS3801D24_Channel>&>(source));
   } else { // Unsupported one!
     QwWarning << "BCM of type="<<type<<" is UNSUPPORTED!!\n";
     exit(-1);
   }
 }

Here is the call graph for this function:

VQwBCM * VQwBCM::CreateCombo	(	TString	subsystemname,
		TString	type,
		TString	name
	)

static

A fast way of creating a combo BCM of specified type.

Definition at line 70 of file VQwBCM.cc.

References QwMessage, and QwWarning.

Referenced by QwBeamLine::CopyTemplatedDataElements(), and QwBeamLine::LoadChannelMap().

 {
   Bool_t localDebug = kFALSE;
   type.ToUpper();
   if( localDebug ) QwMessage<<"Creating CombinedBCM of type: "<<type<<" with name: "<<
     name<<". Subsystem Name: " <<subsystemname<<"\n";
   // (jc2) As a first try, let's do this the ugly way (but rather very
   // simple), just list out the types of BCM's supported by this code!!!
   if( type == "VQWK") {
     return new QwCombinedBCM<QwVQWK_Channel>(subsystemname,name,type);
   } else if ( type == "SIS3801" ) { // Default SCALER channel
     return new QwCombinedBCM<QwSIS3801_Channel>(subsystemname,name,type);
   } else if ( type == "SCALER" || type == "SIS3801D24" ) {
     return new QwCombinedBCM<QwSIS3801D24_Channel>(subsystemname,name,type);
   } else { // Unsupported one!
     QwWarning << "BCM of type="<<type<<" is UNSUPPORTED!!\n";
     exit(-1);
   }
 }

Here is the caller graph for this function:

VQwBCM * VQwBCM::CreateCombo ( const VQwBCM & source )

static

Definition at line 90 of file VQwBCM.cc.

References QwLog::endl(), VQwDataElement::GetModuleType(), QwMessage, and QwWarning.

 {
   Bool_t localDebug = kFALSE;
   TString type = source.GetModuleType();
   type.ToUpper();
   if( localDebug ) QwMessage<<"Creating CombinedBCM of type: "<<type<< QwLog::endl;
   // (jc2) As a first try, let's do this the ugly way (but rather very
   // simple), just list out the types of BCM's supported by this code!!!
   if( type == "VQWK") {
     return new QwCombinedBCM<QwVQWK_Channel>(dynamic_cast<const QwCombinedBCM<QwVQWK_Channel>&>(source));
   } else if ( type == "SIS3801" ) { // Default SCALER channel
     return new QwCombinedBCM<QwSIS3801_Channel>(dynamic_cast<const QwCombinedBCM<QwSIS3801_Channel>&>(source));
   } else if ( type == "SCALER" || type == "SIS3801D24" ) {
     return new QwCombinedBCM<QwSIS3801D24_Channel>(dynamic_cast<const QwCombinedBCM<QwSIS3801D24_Channel>&>(source));
   } else { // Unsupported one!
     QwWarning << "BCM of type="<<type<<" is UNSUPPORTED!!\n";
     exit(-1);
   }
 }

Here is the call graph for this function:

virtual void VQwBCM::DeaccumulateRunningSum ( VQwBCM & value )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::EncodeEventData ( std::vector< UInt_t > & buffer )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::FillHistograms ( )

pure virtual

Fill the histograms for this data element.

Implements VQwDataElement.

Implemented in QwBCM< T >.

virtual void VQwBCM::FillTreeVector ( std::vector< Double_t > & values ) const

pure virtual

Implemented in QwBCM< T >.

virtual const VQwHardwareChannel* VQwBCM::GetCharge ( ) const

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual std::vector<QwDBInterface> VQwBCM::GetDBEntry ( )

pure virtual

Implemented in QwBCM< T >.

virtual std::vector<QwErrDBInterface> VQwBCM::GetErrDBEntry ( )

pure virtual

Implemented in QwBCM< T >.

virtual Double_t VQwBCM::GetNormClockValue ( )

pure virtual

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual Double_t VQwBCM::GetValue ( )

pure virtual

Implemented in QwBCM< T >.

virtual Double_t VQwBCM::GetValueError ( )

pure virtual

Implemented in QwBCM< T >.

virtual Double_t VQwBCM::GetValueWidth ( )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::IncrementErrorCounters ( )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::InitializeChannel	(	TString	name,
		TString	datatosave
	)

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::InitializeChannel	(	TString	subsystem,
		TString	name,
		TString	datatosave
	)

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::LoadChannelParameters ( QwParameterFile & paramfile )

pure virtual

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual Bool_t VQwBCM::NeedsExternalClock ( )

pure virtual

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual VQwBCM& VQwBCM::operator+= ( const VQwBCM & value )

pure virtual

Implemented in QwBCM< T >.

virtual VQwBCM& VQwBCM::operator-= ( const VQwBCM & value )

pure virtual

Implemented in QwBCM< T >.

virtual VQwBCM& VQwBCM::operator= ( const VQwBCM & value )

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual Int_t VQwBCM::ProcessEvBuffer	(	UInt_t *	buffer,
		UInt_t	num_words_left,
		UInt_t	subelement = `0`
	)

pure virtual

Process the CODA event buffer for this element.

Implements VQwDataElement.

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::ProcessEvent ( )

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::RandomizeEventData	(	int	helicity,
		double	time
	)

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::Ratio	(	const VQwBCM &	numer,
		const VQwBCM &	denom
	)

inlinevirtual

Reimplemented in QwBCM< T >.

Definition at line 53 of file VQwBCM.h.

54 { std::cerr << "Ratio not defined! (VQwBCM)" << std::endl; }

virtual void VQwBCM::Scale ( Double_t factor )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::SetBCMForCombo	(	VQwBCM *	bcm,
		Double_t	weight,
		Double_t	sumqw
	)

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::SetCalibrationFactor ( Double_t calib )

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::SetDefaultSampleSize ( Int_t sample_size )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::SetEventCutMode ( Int_t bcuts )

pure virtual

Implemented in QwBCM< T >.

virtual void VQwBCM::SetExternalClockName ( const std::string name )

pure virtual

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual void VQwBCM::SetExternalClockPtr ( const VQwHardwareChannel * clock )

pure virtual

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual void VQwBCM::SetPedestal ( Double_t ped )

pure virtual

Implemented in QwBCM< T >, and QwCombinedBCM< T >.

virtual void VQwBCM::SetRandomEventAsymmetry ( Double_t asymmetry )

pure virtual

Implemented in QwBCM< T >.

Referenced by main().

Here is the caller graph for this function:

virtual void VQwBCM::SetRandomEventParameters	(	Double_t	mean,
		Double_t	sigma
	)

pure virtual

Implemented in QwBCM< T >.

Referenced by main().

Here is the caller graph for this function:

virtual void VQwBCM::SetSingleEventCuts	(	UInt_t	errorflag,
		Double_t	min,
		Double_t	max,
		Double_t	stability
	)

pure virtual

Inherited from VQwDataElement to set the upper and lower limits (fULimit and fLLimit), stability % and the error flag on this channel.

Reimplemented from VQwDataElement.

Implemented in QwBCM< T >.

virtual UInt_t VQwBCM::UpdateErrorFlag ( )

inlinevirtual

Update the error flag based on the error flags of internally contained objects Return paramter is the "Eventcut Error Flag".

Reimplemented from VQwDataElement.

Reimplemented in QwCombinedBCM< T >.

Definition at line 70 of file VQwBCM.h.

References VQwDataElement::GetEventcutErrorFlag().

70 {return this->GetEventcutErrorFlag();};

VQwDataElement::GetEventcutErrorFlag

virtual UInt_t GetEventcutErrorFlag()

return the error flag on this channel/device

Definition: VQwDataElement.h:145

Here is the call graph for this function:

virtual void VQwBCM::UpdateErrorFlag ( const VQwBCM * ev_error )

pure virtual

Implemented in QwBCM< T >.

Field Documentation

VQwDataElement& VQwBCM::fBeamCurrent_ref

protected

Definition at line 118 of file VQwBCM.h.

The documentation for this class was generated from the following files:

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Field Documentation
