QweakSimCerenkovDetector Class Reference

#include <QweakSimCerenkovDetector.hh>

+ Collaboration diagram for QweakSimCerenkovDetector:

Public Member Functions

 QweakSimCerenkovDetector (QweakSimUserInformation *)

virtual ~QweakSimCerenkovDetector ()

void SetMotherVolume (G4VPhysicalVolume *mv)

void PlacePVCerenkovMasterContainer ()

void ConstructComponent (G4VPhysicalVolume *MotherVolume)

void DefineCerenkovGeometry ()

void DestroyComponent ()

void SetNumberOfDetectors (G4int number)

void SetCerenkovDetectorMaterial (G4String materialName)

void SetPreradiatorMaterial (G4String materialName)

void SetContainerMaterial (G4String materialName)

void SetCerenkovDetectorCenterPositionInX (G4double xPos, G4int octant)

void SetCerenkovDetectorCenterPositionInY (G4double yPos, G4int octant)

void SetCerenkovDetectorCenterPositionInZ (G4double zPos, G4int octant)

void SetCerenkovDetectorRotationInX (G4double xRot, G4int octant)

void SetCerenkovDetectorRotationInY (G4double yRot, G4int octant)

void SetCerenkovDetectorRotationInZ (G4double zRot, G4int octant)

void SetCerenkovDetectorTiltAngle (G4double tiltangle)

void SetCerenkovDetectorThickness (G4double thickness)

void CerenkovGeometryPVUpdate ()

G4LogicalVolume * GetCerenkovDetector_LogicalVolume ()

G4VPhysicalVolume * GetCerenkovDetector_PhysicalVolume ()

G4LogicalVolume * GetPMT_LogicalVolume ()

G4VPhysicalVolume * GetPMT_PhysicalVolume ()


Private Attributes

QweakSimUserInformation * myUserInfo

std::vector
< QweakSimCerenkovDetectorMessenger * > 		CerenkovDetectorMessenger

QweakSimMaterial * pMaterial

G4VPhysicalVolume * theMotherPV

G4int NumberOfCerenkovDetectors

std::vector< G4VPhysicalVolume * > CerenkovMasterContainer_Physical

std::vector< G4ThreeVector > Translation_CerenkovMasterContainer

std::vector< G4RotationMatrix * > Rotation_CerenkovMasterContainer

std::vector< G4RotationMatrix * > Rotation_SideBracket

std::vector< G4ThreeVector > Position_SideBracket

std::vector< G4RotationMatrix * > Rotation_EndBracket

std::vector< G4ThreeVector > Position_EndBracket

std::vector< G4RotationMatrix * > Rotation_SideBracketPad

std::vector< G4ThreeVector > Position_SideBracketPad

std::vector< G4RotationMatrix * > Rotation_EndBracketPad

std::vector< G4ThreeVector > Position_EndBracketPad

G4LogicalVolume * CerenkovContainer_Logical

G4VPhysicalVolume * CerenkovContainer_Physical

G4Material * CerenkovContainer_Material

G4LogicalVolume * ActiveArea_Logical

G4VPhysicalVolume * ActiveArea_Physical

G4Material * ActiveArea_Material

G4LogicalVolume * QuartzBar_LogicalLeft

G4LogicalVolume * QuartzBar_LogicalRight

G4VPhysicalVolume * QuartzBar_PhysicalLeft

G4VPhysicalVolume * QuartzBar_PhysicalRight

G4Material * QuartzBar_Material

G4LogicalVolume * LightGuide_LogicalLeft

G4LogicalVolume * LightGuide_LogicalRight

G4VPhysicalVolume * LightGuide_PhysicalLeft

G4VPhysicalVolume * LightGuide_PhysicalRight

G4Material * LightGuide_Material

G4LogicalVolume * QuartzGlue_Logical

G4VPhysicalVolume * QuartzGlue_PhysicalLeft

G4VPhysicalVolume * QuartzGlue_PhysicalCenter

G4VPhysicalVolume * QuartzGlue_PhysicalRight

G4Material * QuartzGlue_Material

G4LogicalVolume * Radiator_Logical

G4VPhysicalVolume * Radiator_Physical

G4Material * Radiator_Material

G4LogicalVolume * PMT_PbShield_Logical

G4VPhysicalVolume * PMT_PbShield_Physical

G4Material * PMT_PbShield_Material

G4LogicalVolume * PMTContainer_Logical

G4VPhysicalVolume * PMTContainer_PhysicalLeft

G4VPhysicalVolume * PMTContainer_PhysicalRight

G4Material * PMTContainer_Material

G4LogicalVolume * PMTQuartzOpticalFilm_Logical

G4VPhysicalVolume * PMTQuartzOpticalFilm_Physical

G4Material * PMTQuartzOpticalFilm_Material

G4LogicalVolume * PMTEntranceWindow_Logical

G4VPhysicalVolume * PMTEntranceWindow_Physical

G4Material * PMTEntranceWindow_Material

G4LogicalVolume * Cathode_Logical

G4VPhysicalVolume * Cathode_Physical

G4Material * Cathode_Material

G4LogicalVolume * Frame_Logical

G4VPhysicalVolume * Frame_Physical

G4Material * Frame_Material

G4LogicalVolume * CrossBar_Logical

G4VPhysicalVolume * CrossBarR_Physical

G4VPhysicalVolume * CrossBarL_Physical

G4LogicalVolume * FrontWindow_Logical

G4VPhysicalVolume * FrontWindow_Physical

G4LogicalVolume * BackWindow_Logical

G4VPhysicalVolume * BackWindow_Physical

G4Material * Window_Material

G4LogicalVolume * FrontClip_Logical

G4VPhysicalVolume * FrontClip_Physical

G4LogicalVolume * BackClip_Logical

G4VPhysicalVolume * BackClip_Physical

G4LogicalVolume * SquareFlange_Logical

G4VPhysicalVolume * SquareFlangeR_Physical

G4VPhysicalVolume * SquareFlangeL_Physical

G4LogicalVolume * SquareFlangeSeal_Logical

G4VPhysicalVolume * SquareFlangeSealR_Physical

G4VPhysicalVolume * SquareFlangeSealL_Physical

G4LogicalVolume * PMTHousingWall_Logical

G4VPhysicalVolume * PMTHousingWallR_Physical

G4VPhysicalVolume * PMTHousingWallL_Physical

G4LogicalVolume * PMTHousingFlange_Logical

G4VPhysicalVolume * PMTHousingFlangeR_Physical

G4VPhysicalVolume * PMTHousingFlangeL_Physical

G4LogicalVolume * PMTHousingLid_Logical

G4VPhysicalVolume * PMTHousingLidR_Physical

G4VPhysicalVolume * PMTHousingLidL_Physical

G4LogicalVolume * SideBracket_Logical

std::vector< G4VPhysicalVolume * > SideBracket_Physical

G4LogicalVolume * EndBracket_Logical

std::vector< G4VPhysicalVolume * > EndBracket_Physical

G4LogicalVolume * SideBracketPad_Logical

std::vector< G4VPhysicalVolume * > SideBracketPad_Physical

G4LogicalVolume * EndBracketPad_Logical

std::vector< G4VPhysicalVolume * > EndBracketPad_Physical

G4Material * BracketPad_Material

G4LogicalVolume * ExoSkeltonFrame_Logical

G4VPhysicalVolume * ExoSkeltonFrame_Physical

G4Material * ExoSkeltonFrame_Material

G4double Container_FullLength_X

G4double Container_FullLength_Y

G4double Container_FullLength_Z

G4double ExoSkeltonFrame_X

G4double ExoSkeltonFrame_Y

G4double ExoSkeltonFrame_Z

G4double ExoSkeltonInnerFrame_X

G4double ExoSkeltonInnerFrame_Y

G4double ExoSkeltonInnerFrame_Z

G4double Frame_FullLength_X

G4double Frame_FullLength_Y

G4double Frame_FullLength_Z

G4double Frame_InnerFullLength_X

G4double Frame_InnerFullLength_Y

G4double Frame_InnerFullLength_Z

G4double SideBracketLength_X

G4double SideBracketLength_Y

G4double SideBracketLength_Z

G4double SideBracketCutLength_X

G4double SideBracketCutLength_Y

G4double SideBracketCutLength_Z

G4double EndBracketLength_X

G4double EndBracketLength_Y

G4double EndBracketLength_Z

G4double EndBracketCutLength_X

G4double EndBracketCutLength_Y

G4double EndBracketCutLength_Z

G4double SideBracketPadLength_X

G4double SideBracketPadLength_Y

G4double SideBracketPadLength_Z

G4double SideBracketPadCutLength_X

G4double SideBracketPadCutLength_Y

G4double SideBracketPadCutLength_Z

G4double EndBracketPadLength_X

G4double EndBracketPadLength_Y

G4double EndBracketPadLength_Z

G4double EndBracketPadCutLength_X

G4double EndBracketPadCutLength_Y

G4double EndBracketPadCutLength_Z

G4double WindowThickness

G4double ActiveArea_FullLength_X

G4double ActiveArea_FullLength_Y

G4double ActiveArea_FullLength_Z

G4double GlueFilm_FullLength_X

G4double GlueFilm_FullLength_Y

G4double GlueFilm_FullLength_Z

G4double Chamfer_FullLength

G4double Chamfer_FullHeight

G4double Chamfer_FullThickness

G4double QuartzBar_FullLength

G4double QuartzBar_FullHeight

G4double QuartzBar_FullThickness

G4double LightGuide_FullLength

G4double LightGuide_FullWidth1

G4double LightGuide_FullWidth2

G4double LightGuide_FullThickness

G4double PMTContainer_Diameter

G4double PMTContainer_FullLength_Z

G4double PMTQuartzOpticalFilm_Diameter

G4double PMTQuartzOpticalFilm_Thickness

G4double PMTEntranceWindow_Diameter

G4double PMTEntranceWindow_Thickness

G4double Cathode_Diameter

G4double Cathode_Thickness

G4double CerenkovDetectorCenterZPosition

G4double LGAngCutXDim

G4double LGAngCutYDim

G4double LGAngCutZDim

std::vector< G4SubtractionSolid * > RightQuartz_Solid

std::vector< G4SubtractionSolid * > LeftQuartz_Solid

std::vector< G4SubtractionSolid * > LeftGuide_Solid

std::vector< G4SubtractionSolid * > RightGuide_Solid

G4Material * mirror_material

std::vector< G4LogicalVolume * > mirror_logical

std::vector< G4VPhysicalVolume * > mirror_physical

G4double Tilting_Angle

G4double Kink_Angle

G4double Thickness

G4ThreeVector Position_CerenkovContainer

G4RotationMatrix * Rotation_CerenkovContainer

G4ThreeVector Position_Chamfer1

G4RotationMatrix Rotation_Chamfer1

G4ThreeVector Position_Chamfer2

G4RotationMatrix Rotation_Chamfer2

G4ThreeVector Position_Chamfer3

G4RotationMatrix Rotation_Chamfer3

G4ThreeVector Position_Chamfer4

G4RotationMatrix Rotation_Chamfer4

G4ThreeVector Position_AngCut1

G4RotationMatrix Rotation_AngCut1

G4ThreeVector Position_AngCut2

G4RotationMatrix Rotation_AngCut2

G4ThreeVector Position_LGRight

G4RotationMatrix Rotation_LGRight

G4ThreeVector Position_LGLeft

G4RotationMatrix Rotation_LGLeft

G4ThreeVector Position_LGFaceMirrorLeft

G4RotationMatrix Rotation_LGFaceMirrorLeft

G4ThreeVector Position_LGEdgeMirrorLeft

G4RotationMatrix Rotation_LGEdgeMirrorLeft

G4ThreeVector Position_LGFaceMirrorRight

G4RotationMatrix Rotation_LGFaceMirrorRight

G4ThreeVector Position_LGEdgeMirrorRight

G4RotationMatrix Rotation_LGEdgeMirrorRight

G4ThreeVector Translation_SingleBarLeft

G4RotationMatrix Rotation_SingleBarLeft

G4ThreeVector Translation_SingleBarRight

G4RotationMatrix Rotation_SingleBarRight

G4ThreeVector Translation_PMTContainerLeft

G4RotationMatrix Rotation_PMTContainerLeft

G4ThreeVector Translation_PMTContainerRight

G4RotationMatrix Rotation_PMTContainerRight

G4ThreeVector Translation_Cathode

G4RotationMatrix Rotation_Cathode

G4ThreeVector Translation_PMTQuartzOpticalFilm

G4RotationMatrix Rotation_PMTQuartzOpticalFilm

G4ThreeVector Translation_PMTEntranceWindow

G4RotationMatrix Rotation_PMTEntranceWindow

G4VSensitiveDetector * CerenkovDetectorSD

G4VSensitiveDetector * CerenkovRadiatorSD

G4VSensitiveDetector * CerenkovDetector_PMTSD

std::vector< G4double > Position_CerenkovContainer_X

std::vector< G4double > Position_CerenkovContainer_Y

std::vector< G4double > Position_CerenkovContainer_Z

std::vector< G4double > Rotation_CerenkovContainer_X

std::vector< G4double > Rotation_CerenkovContainer_Y

std::vector< G4double > Rotation_CerenkovContainer_Z

G4double Default_Position_CerenkovContainer_X

G4double Default_Position_CerenkovContainer_Y

G4double Default_Position_CerenkovContainer_Z

G4double Default_Rotation_CerenkovContainer_X

G4double Default_Rotation_CerenkovContainer_Y

G4double Default_Rotation_CerenkovContainer_Z

G4double Container_Center_X

G4double Container_Center_Y

G4double Container_Center_Z

G4ThreeVector Container_Center


Detailed Description

Definition at line 20 of file QweakSimCerenkovDetector.hh.

Constructor & Destructor Documentation

QweakSimCerenkovDetector::QweakSimCerenkovDetector ( QweakSimUserInformation *  userInfo)

Definition at line 8 of file QweakSimCerenkovDetector.cc.

References ActiveArea_FullLength_X, ActiveArea_FullLength_Y, ActiveArea_FullLength_Z, ActiveArea_Logical, ActiveArea_Material, ActiveArea_Physical, BracketPad_Material, Cathode_Diameter, Cathode_Logical, Cathode_Material, Cathode_Physical, Cathode_Thickness, CerenkovContainer_Logical, CerenkovContainer_Material, CerenkovContainer_Physical, CerenkovDetector_PMTSD, CerenkovDetectorSD, CerenkovRadiatorSD, Chamfer_FullHeight, Chamfer_FullLength, Chamfer_FullThickness, Container_Center, Container_Center_X, Container_Center_Y, Container_Center_Z, Container_FullLength_X, Container_FullLength_Y, Container_FullLength_Z, Default_Position_CerenkovContainer_X, Default_Position_CerenkovContainer_Y, Default_Position_CerenkovContainer_Z, Default_Rotation_CerenkovContainer_X, Default_Rotation_CerenkovContainer_Y, Default_Rotation_CerenkovContainer_Z, Frame_Logical, Frame_Material, Frame_Physical, QweakSimMaterial::GetInstance(), QweakSimMaterial::GetMaterial(), GlueFilm_FullLength_X, GlueFilm_FullLength_Y, GlueFilm_FullLength_Z, inch, LeftGuide_Solid, LeftQuartz_Solid, LightGuide_FullLength, LightGuide_FullThickness, LightGuide_FullWidth1, LightGuide_FullWidth2, LightGuide_LogicalLeft, LightGuide_LogicalRight, LightGuide_Material, LightGuide_PhysicalLeft, LightGuide_PhysicalRight, mirror_logical, mirror_material, mirror_physical, myUserInfo, NumberOfCerenkovDetectors, pMaterial, PMT_PbShield_Material, PMTContainer_Diameter, PMTContainer_FullLength_Z, PMTContainer_Logical, PMTContainer_Material, PMTContainer_PhysicalLeft, PMTContainer_PhysicalRight, PMTEntranceWindow_Diameter, PMTEntranceWindow_Logical, PMTEntranceWindow_Material, PMTEntranceWindow_Physical, PMTEntranceWindow_Thickness, PMTQuartzOpticalFilm_Diameter, PMTQuartzOpticalFilm_Logical, PMTQuartzOpticalFilm_Material, PMTQuartzOpticalFilm_Physical, PMTQuartzOpticalFilm_Thickness, Position_SideBracket, Position_SideBracketPad, QuartzBar_FullHeight, QuartzBar_FullLength, QuartzBar_FullThickness, QuartzBar_LogicalLeft, QuartzBar_LogicalRight, QuartzBar_Material, QuartzBar_PhysicalLeft, QuartzBar_PhysicalRight, QuartzGlue_Logical, QuartzGlue_Material, QuartzGlue_PhysicalCenter, QuartzGlue_PhysicalLeft, QuartzGlue_PhysicalRight, Radiator_Material, RightGuide_Solid, RightQuartz_Solid, Rotation_CerenkovContainer, Rotation_SideBracket, Rotation_SideBracketPad, SetNumberOfDetectors(), SideBracket_Logical, SideBracket_Physical, SideBracketPad_Logical, SideBracketPad_Physical, theMotherPV, Tilting_Angle, and Window_Material.

8  {
9
10  // initialize some pointers
11  myUserInfo = userInfo;
12
13  pMaterial = NULL;
14
15  theMotherPV = NULL;
16
17  CerenkovContainer_Logical = NULL;
18  CerenkovContainer_Physical = NULL;
19  CerenkovContainer_Material = NULL;
20
21  Frame_Logical = NULL;
22  Frame_Physical = NULL;
23  Frame_Material = NULL;
24
25  SideBracket_Logical = NULL;
26  SideBracketPad_Logical = NULL;
27
28  ActiveArea_Logical = NULL;
29  ActiveArea_Physical = NULL;
30  ActiveArea_Material = NULL;
31
32  LightGuide_LogicalLeft = NULL;
33  LightGuide_LogicalRight = NULL;
34  LightGuide_PhysicalLeft = NULL;
35  LightGuide_PhysicalRight = NULL;
36  LightGuide_Material = NULL;
37
38  QuartzBar_LogicalLeft = NULL;
39  QuartzBar_LogicalRight = NULL;
40  QuartzBar_PhysicalLeft = NULL;
41  QuartzBar_PhysicalRight = NULL;
42  QuartzBar_Material = NULL;
43
44  QuartzGlue_Logical = NULL;
45  QuartzGlue_PhysicalLeft = NULL;
46  QuartzGlue_PhysicalCenter = NULL;
47  QuartzGlue_PhysicalRight = NULL;
48  QuartzGlue_Material = NULL;
49
50  PMTContainer_Logical = NULL;
51  PMTContainer_PhysicalLeft = NULL;
52  PMTContainer_PhysicalRight = NULL;
53  PMTContainer_Material = NULL;
54
55  PMTEntranceWindow_Logical = NULL;
56  PMTEntranceWindow_Physical = NULL;
57  PMTEntranceWindow_Material = NULL;
58
59  Cathode_Logical = NULL;
60  Cathode_Physical = NULL;
61  Cathode_Material = NULL;
62
63  PMTQuartzOpticalFilm_Logical = NULL;
64  PMTQuartzOpticalFilm_Physical = NULL;
65  PMTQuartzOpticalFilm_Material = NULL;
66
67  Rotation_CerenkovContainer = NULL;
68
69  // pointer to the sensitive detector
70  CerenkovDetectorSD = NULL;
71  CerenkovRadiatorSD = NULL;
72  CerenkovDetector_PMTSD = NULL;
73
74  // clear vector containing temp solids for boolean soild union
75  LeftQuartz_Solid.clear();
76  LeftQuartz_Solid.resize(4); //need 4 chamfers on quartz bar proper
77  RightQuartz_Solid.clear();
78  RightQuartz_Solid.resize(4); //need 4 chamfers on quartz bar proper
79  LeftGuide_Solid.clear();
80  LeftGuide_Solid.resize(5); //need 4 chamfers + 1 angle cut on light guide
81  RightGuide_Solid.clear();
82  RightGuide_Solid.resize(5); //need 4 chamfers + 1 angle cut on light guide
83
84  mirror_logical.clear();
85  mirror_physical.clear();
86
87  mirror_logical.resize(8);
88  mirror_physical.resize(8);
89
90  SideBracket_Physical.clear();
91  Rotation_SideBracket.clear();
92  Position_SideBracket.clear();
93
94  SideBracketPad_Physical.clear();
95  Rotation_SideBracketPad.clear();
96  Position_SideBracketPad.clear();
97
98  pMaterial = QweakSimMaterial::GetInstance();
99
100  //CerenkovContainer_Material = pMaterial->GetMaterial("Air");
101  CerenkovContainer_Material = pMaterial->GetMaterial("Air");
102  ActiveArea_Material = pMaterial->GetMaterial("Air");
103  QuartzBar_Material = pMaterial->GetMaterial("Quartz");
104  LightGuide_Material = pMaterial->GetMaterial("Quartz");
105  PMTContainer_Material = pMaterial->GetMaterial("Air"); //Vacuum
106  PMTEntranceWindow_Material = pMaterial->GetMaterial("LimeGlass");
107  PMTQuartzOpticalFilm_Material = pMaterial->GetMaterial("SiElast_Glue");
108  Cathode_Material = pMaterial->GetMaterial("Photocathode");
109  Radiator_Material = pMaterial->GetMaterial("PBA");
110  PMT_PbShield_Material = pMaterial->GetMaterial("Lead");
111  QuartzGlue_Material = pMaterial->GetMaterial("SiElast_Glue");
112  mirror_material = pMaterial->GetMaterial("Mirror");
113  Frame_Material = pMaterial->GetMaterial("Aluminum");
114  Window_Material = pMaterial->GetMaterial("Tyvek");
115  BracketPad_Material = pMaterial->GetMaterial("Tyvek");
116
117  Container_Center_X = 0.0*cm;
118  Container_Center_Y = 0.0*cm;
119  Container_Center_Z = -4.25*cm;
120
121  Container_Center = G4ThreeVector(Container_Center_X, Container_Center_Y, Container_Center_Z);
122
123  Default_Position_CerenkovContainer_X = 0*cm;
124  Default_Position_CerenkovContainer_Y = 335.17*cm;
125  Default_Position_CerenkovContainer_Z = 577.88*cm-Container_Center_Z;
126
127  Default_Rotation_CerenkovContainer_X = 0*deg;
128  Default_Rotation_CerenkovContainer_Y = 0*deg;
129  Default_Rotation_CerenkovContainer_Z = 0*deg;
130
131  LightGuide_FullLength = 18.00*cm;
132  LightGuide_FullWidth1 = 18.00*cm;
133  LightGuide_FullWidth2 = 18.00*cm;
134  LightGuide_FullThickness = 1.25*cm;
135
136  QuartzBar_FullLength = 100.00*cm; // Full X length
137  QuartzBar_FullHeight = 18.00*cm; // Full Y length
138  QuartzBar_FullThickness = 1.25*cm; // Full Z length
139
140  GlueFilm_FullLength_X = 0.1*mm;
141  GlueFilm_FullLength_Y = 18.00*cm;
142  GlueFilm_FullLength_Z = 1.25*cm;
143
144  ActiveArea_FullLength_X = 2.0*(LightGuide_FullLength + QuartzBar_FullLength +GlueFilm_FullLength_X) + GlueFilm_FullLength_X +2.0*mm;
145  ActiveArea_FullLength_Y = QuartzBar_FullHeight + 1.0*mm;
146  ActiveArea_FullLength_Z = QuartzBar_FullThickness + 2.0*mm;
147
148  Container_FullLength_X = 95.6*inch;
149  Container_FullLength_Y = 9.6*inch;
150  Container_FullLength_Z = 14.0*inch+2.0*Container_Center_Z;
151
152  Chamfer_FullLength = 120.00*cm;
153  Chamfer_FullHeight = 7.00*mm;
154  Chamfer_FullThickness = 7.00*mm;
155
156  G4double ReductionInPhotocathodeDiameter = 5*mm;
157
158  PMTQuartzOpticalFilm_Thickness= 0.1*mm;
159  PMTQuartzOpticalFilm_Diameter = 12.7*cm;
160
161  PMTEntranceWindow_Thickness = 1.0*mm; // assumed PMT glass thickness
162  PMTEntranceWindow_Diameter = 12.7*cm;//QuartzBar_FullHeight;
163
164  Cathode_Thickness = 1.0*mm;
165  Cathode_Diameter = PMTEntranceWindow_Diameter - ReductionInPhotocathodeDiameter;
166
167  PMTContainer_Diameter = PMTEntranceWindow_Diameter+1.0*mm;
168  PMTContainer_FullLength_Z = 2.0*mm+PMTEntranceWindow_Thickness+Cathode_Thickness;
169
170  Tilting_Angle = 0.0*degree;
171
172  NumberOfCerenkovDetectors = 8;
173  SetNumberOfDetectors(8); // needs to be at the end, updates geometry
174 }
QweakSimCerenkovDetector::LeftGuide_Solid
std::vector< G4SubtractionSolid * > LeftGuide_Solid
Definition: QweakSimCerenkovDetector.hh:298
QweakSimCerenkovDetector::CerenkovRadiatorSD
G4VSensitiveDetector * CerenkovRadiatorSD
Definition: QweakSimCerenkovDetector.hh:376
QweakSimCerenkovDetector::CerenkovContainer_Physical
G4VPhysicalVolume * CerenkovContainer_Physical
Definition: QweakSimCerenkovDetector.hh:88
QweakSimCerenkovDetector::Position_SideBracket
std::vector< G4ThreeVector > Position_SideBracket
Definition: QweakSimCerenkovDetector.hh:75
QweakSimCerenkovDetector::Rotation_SideBracketPad
std::vector< G4RotationMatrix * > Rotation_SideBracketPad
Definition: QweakSimCerenkovDetector.hh:80
QweakSimMaterial::GetInstance
static QweakSimMaterial * GetInstance()
Definition: QweakSimMaterial.hh:75
QweakSimCerenkovDetector::PMTEntranceWindow_Logical
G4LogicalVolume * PMTEntranceWindow_Logical
Definition: QweakSimCerenkovDetector.hh:130
QweakSimCerenkovDetector::myUserInfo
QweakSimUserInformation * myUserInfo
Definition: QweakSimCerenkovDetector.hh:58
QweakSimCerenkovDetector::QuartzGlue_PhysicalCenter
G4VPhysicalVolume * QuartzGlue_PhysicalCenter
Definition: QweakSimCerenkovDetector.hh:109
QweakSimCerenkovDetector::QuartzBar_PhysicalLeft
G4VPhysicalVolume * QuartzBar_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:97
QweakSimCerenkovDetector::ActiveArea_Physical
G4VPhysicalVolume * ActiveArea_Physical
Definition: QweakSimCerenkovDetector.hh:92
QweakSimCerenkovDetector::CerenkovContainer_Logical
G4LogicalVolume * CerenkovContainer_Logical
Definition: QweakSimCerenkovDetector.hh:87
QweakSimCerenkovDetector::CerenkovDetectorSD
G4VSensitiveDetector * CerenkovDetectorSD
Definition: QweakSimCerenkovDetector.hh:375
QweakSimCerenkovDetector::CerenkovDetector_PMTSD
G4VSensitiveDetector * CerenkovDetector_PMTSD
Definition: QweakSimCerenkovDetector.hh:377
QweakSimCerenkovDetector::SideBracket_Physical
std::vector< G4VPhysicalVolume * > SideBracket_Physical
Definition: QweakSimCerenkovDetector.hh:179
QweakSimCerenkovDetector::mirror_physical
std::vector< G4VPhysicalVolume * > mirror_physical
Definition: QweakSimCerenkovDetector.hh:304
inch
static const G4double inch
Definition: QweakSimSystemOfUnits.hh:35
QweakSimCerenkovDetector::QuartzBar_PhysicalRight
G4VPhysicalVolume * QuartzBar_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:98
QweakSimCerenkovDetector::Position_SideBracketPad
std::vector< G4ThreeVector > Position_SideBracketPad
Definition: QweakSimCerenkovDetector.hh:81
QweakSimCerenkovDetector::mirror_logical
std::vector< G4LogicalVolume * > mirror_logical
Definition: QweakSimCerenkovDetector.hh:303
QweakSimCerenkovDetector::RightGuide_Solid
std::vector< G4SubtractionSolid * > RightGuide_Solid
Definition: QweakSimCerenkovDetector.hh:299
QweakSimCerenkovDetector::PMTEntranceWindow_Physical
G4VPhysicalVolume * PMTEntranceWindow_Physical
Definition: QweakSimCerenkovDetector.hh:131
QweakSimMaterial::GetMaterial
G4Material * GetMaterial(G4String material)
Definition: QweakSimMaterial.hh:81
QweakSimCerenkovDetector::SideBracketPad_Physical
std::vector< G4VPhysicalVolume * > SideBracketPad_Physical
Definition: QweakSimCerenkovDetector.hh:185
QweakSimCerenkovDetector::RightQuartz_Solid
std::vector< G4SubtractionSolid * > RightQuartz_Solid
Definition: QweakSimCerenkovDetector.hh:296
QweakSimCerenkovDetector::QuartzGlue_PhysicalRight
G4VPhysicalVolume * QuartzGlue_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:110
QweakSimCerenkovDetector::LeftQuartz_Solid
std::vector< G4SubtractionSolid * > LeftQuartz_Solid
Definition: QweakSimCerenkovDetector.hh:297
QweakSimCerenkovDetector::PMTContainer_PhysicalRight
G4VPhysicalVolume * PMTContainer_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:123
QweakSimCerenkovDetector::LightGuide_PhysicalRight
G4VPhysicalVolume * LightGuide_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:104
QweakSimCerenkovDetector::Rotation_CerenkovContainer
G4RotationMatrix * Rotation_CerenkovContainer
Definition: QweakSimCerenkovDetector.hh:312
QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Physical
G4VPhysicalVolume * PMTQuartzOpticalFilm_Physical
Definition: QweakSimCerenkovDetector.hh:127
QweakSimCerenkovDetector::QuartzBar_LogicalRight
G4LogicalVolume * QuartzBar_LogicalRight
Definition: QweakSimCerenkovDetector.hh:96
QweakSimCerenkovDetector::Rotation_SideBracket
std::vector< G4RotationMatrix * > Rotation_SideBracket
Definition: QweakSimCerenkovDetector.hh:74
QweakSimCerenkovDetector::LightGuide_PhysicalLeft
G4VPhysicalVolume * LightGuide_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:103
QweakSimCerenkovDetector::PMTContainer_PhysicalLeft
G4VPhysicalVolume * PMTContainer_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:122
QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Logical
G4LogicalVolume * PMTQuartzOpticalFilm_Logical
Definition: QweakSimCerenkovDetector.hh:126
QweakSimCerenkovDetector::QuartzGlue_PhysicalLeft
G4VPhysicalVolume * QuartzGlue_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:108

+ Here is the call graph for this function:

QweakSimCerenkovDetector::~QweakSimCerenkovDetector ( )
virtual

Definition at line 177 of file QweakSimCerenkovDetector.cc.

References CerenkovDetectorMessenger.

177  {
178  for(size_t h=0; h<CerenkovDetectorMessenger.size(); h++){
179  delete CerenkovDetectorMessenger[h];
180  }
181 }
QweakSimCerenkovDetector::CerenkovDetectorMessenger
std::vector< QweakSimCerenkovDetectorMessenger * > CerenkovDetectorMessenger
Definition: QweakSimCerenkovDetector.hh:60

Member Function Documentation

void QweakSimCerenkovDetector::CerenkovGeometryPVUpdate ( )

Definition at line 2510 of file QweakSimCerenkovDetector.cc.

References CerenkovContainer_Logical, CerenkovMasterContainer_Physical, PlacePVCerenkovMasterContainer(), and Rotation_CerenkovMasterContainer.

Referenced by SetCerenkovDetectorCenterPositionInX(), SetCerenkovDetectorCenterPositionInY(), SetCerenkovDetectorCenterPositionInZ(), SetCerenkovDetectorRotationInX(), SetCerenkovDetectorRotationInY(), SetCerenkovDetectorRotationInZ(), SetCerenkovDetectorTiltAngle(), and SetNumberOfDetectors().

2510  {
2511  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::CerenkovGeometryPVUpdate()" << G4endl << G4endl;
2512
2513  for (size_t i=0; i< CerenkovMasterContainer_Physical.size();i++) {
2514  if (CerenkovContainer_Logical)
2515  CerenkovContainer_Logical->RemoveDaughter(CerenkovMasterContainer_Physical[i]);
2516
2517  delete CerenkovMasterContainer_Physical[i];
2518  CerenkovMasterContainer_Physical[i] = 0;
2519
2520  delete Rotation_CerenkovMasterContainer[i];
2521  Rotation_CerenkovMasterContainer[i] = 0;
2522  }
2523
2524  // Place the physical volume of the rods with the new phi angle
2525  PlacePVCerenkovMasterContainer();
2526
2527  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::CerenkovGeometryPVUpdate()" << G4endl << G4endl;
2528 }
QweakSimCerenkovDetector::CerenkovContainer_Logical
G4LogicalVolume * CerenkovContainer_Logical
Definition: QweakSimCerenkovDetector.hh:87
QweakSimCerenkovDetector::CerenkovMasterContainer_Physical
std::vector< G4VPhysicalVolume * > CerenkovMasterContainer_Physical
Definition: QweakSimCerenkovDetector.hh:70
QweakSimCerenkovDetector::Rotation_CerenkovMasterContainer
std::vector< G4RotationMatrix * > Rotation_CerenkovMasterContainer
Definition: QweakSimCerenkovDetector.hh:72

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::ConstructComponent ( G4VPhysicalVolume *  MotherVolume)

Definition at line 191 of file QweakSimCerenkovDetector.cc.

References ActiveArea_FullLength_X, ActiveArea_FullLength_Y, ActiveArea_FullLength_Z, ActiveArea_Logical, ActiveArea_Material, ActiveArea_Physical, BackClip_Logical, BackClip_Physical, BackWindow_Logical, BackWindow_Physical, BracketPad_Material, Cathode_Diameter, Cathode_Logical, Cathode_Material, Cathode_Physical, Cathode_Thickness, CerenkovContainer_Logical, CerenkovContainer_Material, CerenkovDetector_PMTSD, CerenkovDetectorSD, CerenkovRadiatorSD, Chamfer_FullHeight, Chamfer_FullLength, Chamfer_FullThickness, Container_Center, Container_FullLength_X, Container_FullLength_Y, Container_FullLength_Z, CrossBar_Logical, CrossBarL_Physical, CrossBarR_Physical, EndBracket_Logical, EndBracket_Physical, EndBracketCutLength_X, EndBracketCutLength_Y, EndBracketCutLength_Z, EndBracketLength_X, EndBracketLength_Y, EndBracketLength_Z, EndBracketPad_Logical, EndBracketPad_Physical, EndBracketPadCutLength_X, EndBracketPadCutLength_Y, EndBracketPadCutLength_Z, EndBracketPadLength_X, EndBracketPadLength_Y, EndBracketPadLength_Z, ExoSkeltonFrame_Logical, ExoSkeltonFrame_Physical, ExoSkeltonFrame_X, ExoSkeltonFrame_Y, ExoSkeltonFrame_Z, ExoSkeltonInnerFrame_X, ExoSkeltonInnerFrame_Y, ExoSkeltonInnerFrame_Z, Frame_FullLength_X, Frame_FullLength_Y, Frame_FullLength_Z, Frame_InnerFullLength_X, Frame_InnerFullLength_Y, Frame_InnerFullLength_Z, Frame_Logical, Frame_Material, Frame_Physical, FrontClip_Logical, FrontClip_Physical, FrontWindow_Logical, FrontWindow_Physical, GlueFilm_FullLength_X, GlueFilm_FullLength_Y, GlueFilm_FullLength_Z, inch, LeftGuide_Solid, LeftQuartz_Solid, LGAngCutXDim, LGAngCutYDim, LGAngCutZDim, LightGuide_FullLength, LightGuide_FullThickness, LightGuide_FullWidth1, LightGuide_FullWidth2, LightGuide_LogicalLeft, LightGuide_LogicalRight, LightGuide_Material, LightGuide_PhysicalLeft, LightGuide_PhysicalRight, mirror_logical, mirror_material, myUserInfo, PlacePVCerenkovMasterContainer(), PMT_PbShield_Logical, PMT_PbShield_Material, PMT_PbShield_Physical, PMTContainer_Diameter, PMTContainer_FullLength_Z, PMTContainer_Logical, PMTContainer_Material, PMTContainer_PhysicalLeft, PMTContainer_PhysicalRight, PMTEntranceWindow_Diameter, PMTEntranceWindow_Logical, PMTEntranceWindow_Material, PMTEntranceWindow_Physical, PMTEntranceWindow_Thickness, PMTHousingFlange_Logical, PMTHousingFlangeL_Physical, PMTHousingFlangeR_Physical, PMTHousingLid_Logical, PMTHousingLidL_Physical, PMTHousingLidR_Physical, PMTHousingWall_Logical, PMTHousingWallL_Physical, PMTHousingWallR_Physical, PMTQuartzOpticalFilm_Diameter, PMTQuartzOpticalFilm_Logical, PMTQuartzOpticalFilm_Material, PMTQuartzOpticalFilm_Physical, PMTQuartzOpticalFilm_Thickness, Position_AngCut1, Position_AngCut2, Position_Chamfer1, Position_Chamfer2, Position_Chamfer3, Position_Chamfer4, Position_EndBracket, Position_EndBracketPad, Position_LGEdgeMirrorLeft, Position_LGEdgeMirrorRight, Position_LGLeft, Position_LGRight, Position_SideBracket, Position_SideBracketPad, pSurfChk, QuartzBar_FullHeight, QuartzBar_FullLength, QuartzBar_FullThickness, QuartzBar_LogicalLeft, QuartzBar_LogicalRight, QuartzBar_Material, QuartzBar_PhysicalLeft, QuartzBar_PhysicalRight, QuartzGlue_Logical, QuartzGlue_Material, QuartzGlue_PhysicalCenter, QuartzGlue_PhysicalLeft, QuartzGlue_PhysicalRight, Radiator_Logical, Radiator_Material, Radiator_Physical, RightGuide_Solid, RightQuartz_Solid, Rotation_AngCut1, Rotation_AngCut2, Rotation_Chamfer1, Rotation_Chamfer2, Rotation_Chamfer3, Rotation_Chamfer4, Rotation_EndBracket, Rotation_EndBracketPad, Rotation_LGEdgeMirrorLeft, Rotation_LGEdgeMirrorRight, Rotation_LGLeft, Rotation_LGRight, Rotation_PMTContainerLeft, Rotation_PMTContainerRight, Rotation_SideBracket, Rotation_SideBracketPad, SideBracket_Logical, SideBracket_Physical, SideBracketCutLength_X, SideBracketCutLength_Y, SideBracketCutLength_Z, SideBracketLength_X, SideBracketLength_Y, SideBracketLength_Z, SideBracketPad_Logical, SideBracketPad_Physical, SideBracketPadCutLength_X, SideBracketPadCutLength_Y, SideBracketPadCutLength_Z, SideBracketPadLength_X, SideBracketPadLength_Y, SideBracketPadLength_Z, SquareFlange_Logical, SquareFlangeL_Physical, SquareFlangeR_Physical, SquareFlangeSeal_Logical, SquareFlangeSealL_Physical, SquareFlangeSealR_Physical, theMotherPV, Translation_Cathode, Translation_PMTContainerLeft, Translation_PMTContainerRight, Translation_PMTEntranceWindow, Translation_PMTQuartzOpticalFilm, Window_Material, and WindowThickness.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

191  {
192  //----------------------------------------------
193  // save the pointer to the physical mothervolume
194  //----------------------------------------------
195  //
196  theMotherPV = MotherVolume;
197
198
199 //****************************************************************************************************
200 //******************************Define Detector Container*********************************************/
201
202 //jpan@nuclear.uwinnipeg.ca
203  //for(size_t g=0; g<Position_CerenkovContainer_X.size(); g++){
204
205  //Position_CerenkovContainer = G4ThreeVector(Position_CerenkovContainer_X[g],
206  // Position_CerenkovContainer_Y[g],
207  // Position_CerenkovContainer_Z[g]);
208
209  //Rotation_CerenkovContainer = new G4RotationMatrix();
210
211  //Rotation_CerenkovContainer->rotateX(Tilting_Angle);
212
213  G4Box* CerenkovContainer_Solid = new G4Box("CerenkovContainer_Solid",
214  0.5 * Container_FullLength_X , // half X length required by Geant4
215  0.5 * Container_FullLength_Y , // half Y length required by Geant4
216  0.5 * Container_FullLength_Z ); // half Z length required by Geant4
217
218  CerenkovContainer_Logical = new G4LogicalVolume(CerenkovContainer_Solid,
219  CerenkovContainer_Material,
220  "CerenkovContainer_Logical",
221  0,0,0);
222
223
224 //******************************Define Detector OuterFrame*************************
225
226  Frame_FullLength_X = 95.5*inch;
227  Frame_FullLength_Y = 9.5*inch;
228  Frame_FullLength_Z = 2.0*inch;
229
230  Frame_InnerFullLength_X = (95.5-0.75*2.0)*inch;
231  Frame_InnerFullLength_Y = (9.5-0.75*2.0)*inch;
232  Frame_InnerFullLength_Z = 2.0*inch+0.1*mm; // a bit larger to avoid sharing surface with the outer which may cause vis-problem
233
234  G4Box* OuterFrame = new G4Box("OuterFrame",
235  0.5 * Frame_FullLength_X ,
236  0.5 * Frame_FullLength_Y ,
237  0.5 * Frame_FullLength_Z );
238
239  G4Box* InnerFrame = new G4Box("InnerFrame",
240  0.5 * Frame_InnerFullLength_X ,
241  0.5 * Frame_InnerFullLength_Y ,
242  0.5 * Frame_InnerFullLength_Z );
243
244  G4SubtractionSolid* Frame_Solid = new G4SubtractionSolid("OuterFrame-InnerFrame", OuterFrame, InnerFrame);
245
246  Frame_Logical = new G4LogicalVolume(Frame_Solid,
247  Frame_Material,
248  "Frame_Log",
249  0,0,0);
250
251  G4ThreeVector Position_Frame = G4ThreeVector(0,0,0.25*inch);
252
253  Frame_Physical = new G4PVPlacement(0,Position_Frame + Container_Center,
254  Frame_Logical,
255  "Frame_Physical",
256  CerenkovContainer_Logical,
257  false,0,
258  pSurfChk);
259
260
261 //****************************************************************************************************
262 //******************************Define Side Bracket*******************************************
263
264  SideBracketLength_X = 3.0*inch;
265  SideBracketLength_Y = 0.75*inch;
266  SideBracketLength_Z = 1.75*inch;
267
268  SideBracketCutLength_X = 3.0*inch+0.1*mm;
269  SideBracketCutLength_Y = 0.5*inch+0.1*mm;
270  SideBracketCutLength_Z = 0.75*inch;
271
272  G4Box* OuterSideBracket = new G4Box("OuterSideBracket",
273  0.5 * SideBracketLength_X,
274  0.5 * SideBracketLength_Y,
275  0.5 * SideBracketLength_Z);
276
277  G4Box* InnerSideBracket = new G4Box("InnerSideBracket",
278  0.5 * SideBracketCutLength_X,
279  0.5 * SideBracketCutLength_Y,
280  0.5 * SideBracketCutLength_Z);
281
282  G4RotationMatrix* cutRot = new G4RotationMatrix(0,0,0);
283  G4ThreeVector cutTrans(0, 0.125*inch, -0.25*inch);
284
285  G4SubtractionSolid* SideBracket_Solid = new G4SubtractionSolid("OuterSideBracket-InnerSideBracket",
286  OuterSideBracket,
287  InnerSideBracket,
288  cutRot,
289  cutTrans);
290
291  SideBracket_Logical = new G4LogicalVolume(SideBracket_Solid,
292  Frame_Material,
293  "SideBracket_Log",
294  0,0,0);
295
296  for (G4int i=0; i<12; i++) {
297  Rotation_SideBracket.push_back(new G4RotationMatrix(0,0,0));
298  if (i>=6) Rotation_SideBracket[i]->rotateZ(180.0*degree);
299  }
300
301  Position_SideBracket.push_back (G4ThreeVector(3.0*inch,-3.625*inch,0.25*inch) );
302  Position_SideBracket.push_back (G4ThreeVector(-3.0*inch,-3.625*inch,0.25*inch) );
303  Position_SideBracket.push_back (G4ThreeVector(35.37*inch,-3.625*inch,0.25*inch) );
304  Position_SideBracket.push_back (G4ThreeVector(-35.37*inch,-3.625*inch,0.25*inch) );
305  Position_SideBracket.push_back (G4ThreeVector(43.62*inch,-3.625*inch,0.25*inch) );
306  Position_SideBracket.push_back (G4ThreeVector(-43.62*inch,-3.625*inch,0.25*inch) );
307  Position_SideBracket.push_back (G4ThreeVector(3.0*inch,3.625*inch,0.25*inch) );
308  Position_SideBracket.push_back (G4ThreeVector(-3.0*inch,3.625*inch,0.25*inch) );
309  Position_SideBracket.push_back (G4ThreeVector(35.37*inch,3.625*inch,0.25*inch) );
310  Position_SideBracket.push_back (G4ThreeVector(-35.37*inch,3.625*inch,0.25*inch) );
311  Position_SideBracket.push_back (G4ThreeVector(43.62*inch,3.625*inch,0.25*inch) );
312  Position_SideBracket.push_back (G4ThreeVector(-43.62*inch,3.625*inch,0.25*inch) );
313
314
315  for (G4int i = 0; i<12; i++) {
316  SideBracket_Physical.push_back( new G4PVPlacement(Rotation_SideBracket.at(i),Position_SideBracket.at(i) + Container_Center,
317  SideBracket_Logical,
318  "SideBracket_Physical",
319  CerenkovContainer_Logical,
320  false,i,
321  pSurfChk));
322
323  }
324
325 //******************************Define Side Bracket Pad*******************************************
326
327  SideBracketPadLength_X = SideBracketLength_X;
328  SideBracketPadLength_Y = SideBracketCutLength_Y-0.2*mm;
329  SideBracketPadLength_Z = SideBracketCutLength_Z-0.2*mm;
330
331  SideBracketPadCutLength_X = SideBracketCutLength_X;
332  SideBracketPadCutLength_Y = SideBracketCutLength_Y-5.0*mm;
333  SideBracketPadCutLength_Z = QuartzBar_FullThickness;
334
335  G4Box* OuterSideBracketPad = new G4Box("OuterSideBracketPad",
336  0.5 * SideBracketPadLength_X,
337  0.5 * SideBracketPadLength_Y,
338  0.5 * SideBracketPadLength_Z);
339
340  G4Box* InnerSideBracketPad = new G4Box("InnerSideBracketPad",
341  0.5 * SideBracketPadCutLength_X,
342  0.5 * SideBracketPadCutLength_Y,
343  0.5 * SideBracketPadCutLength_Z);
344
345  G4RotationMatrix* PadCutRot = new G4RotationMatrix(0,0,0);
346  //G4ThreeVector PadCutTrans(0, 0.125*inch, -0.25*inch);
347  // (front , bottom, back)
348  G4ThreeVector PadCutTrans(0., 0.11*inch, 0.);
349
350  G4SubtractionSolid* SideBracketPad_Solid = new G4SubtractionSolid("OuterSideBracketPad-InnerSideBracketPad",
351  OuterSideBracketPad,
352  InnerSideBracketPad,
353  PadCutRot,
354  PadCutTrans);
355
356  SideBracketPad_Logical = new G4LogicalVolume(SideBracketPad_Solid,
357  BracketPad_Material,
358  "SideBracketPad_Log",
359  0,0,0);
360
361  for (G4int i=0; i<12; i++) {
362  Rotation_SideBracketPad.push_back(new G4RotationMatrix(0,0,0));
363  if (i>=6) Rotation_SideBracketPad[i]->rotateZ(180.0*degree);
364  }
365
366  Position_SideBracketPad.push_back (G4ThreeVector(3.0*inch,-3.5*inch,0.) );
367  Position_SideBracketPad.push_back (G4ThreeVector(-3.0*inch,-3.5*inch,0.) );
368  Position_SideBracketPad.push_back (G4ThreeVector(35.37*inch,-3.5*inch,0.) );
369  Position_SideBracketPad.push_back (G4ThreeVector(-35.37*inch,-3.5*inch,0.) );
370  Position_SideBracketPad.push_back (G4ThreeVector(43.62*inch,-3.5*inch,0.) );
371  Position_SideBracketPad.push_back (G4ThreeVector(-43.62*inch,-3.5*inch,0.) );
372  Position_SideBracketPad.push_back (G4ThreeVector(3.0*inch,3.5*inch,0.) );
373  Position_SideBracketPad.push_back (G4ThreeVector(-3.0*inch,3.5*inch,0.) );
374  Position_SideBracketPad.push_back (G4ThreeVector(35.37*inch,3.5*inch,0.) );
375  Position_SideBracketPad.push_back (G4ThreeVector(-35.37*inch,3.5*inch,0.) );
376  Position_SideBracketPad.push_back (G4ThreeVector(43.62*inch,3.5*inch,0.) );
377  Position_SideBracketPad.push_back (G4ThreeVector(-43.62*inch,3.5*inch,0.) );
378
379
380  for (G4int i = 0; i<12; i++) {
381  SideBracketPad_Physical.push_back( new G4PVPlacement(Rotation_SideBracketPad.at(i),Position_SideBracketPad.at(i) + Container_Center,
382  SideBracketPad_Logical,
383  "SideBracketPad_Physical",
384  CerenkovContainer_Logical,
385  false,i,
386  pSurfChk));
387
388  }
389
390 //******************************Define End Bracket *******************************************
391
392  EndBracketLength_X = 1.5*inch;
393  EndBracketLength_Y = 0.75*inch;
394  EndBracketLength_Z = 1.75*inch;
395
396  EndBracketCutLength_X = 1.5*inch+0.1*mm;
397  EndBracketCutLength_Y = 0.5*inch+0.1*mm;
398  EndBracketCutLength_Z = 0.75*inch;
399
400  G4Box* OuterEndBracket = new G4Box("OuterEndBracket",
401  0.5 * EndBracketLength_X,
402  0.5 * EndBracketLength_Y,
403  0.5 * EndBracketLength_Z);
404
405  G4Box* InnerEndBracket = new G4Box("InnerEndBracket",
406  0.5 * EndBracketCutLength_X,
407  0.5 * EndBracketCutLength_Y,
408  0.5 * EndBracketCutLength_Z);
409
410  //G4RotationMatrix* cutRot = new G4RotationMatrix(0,0,0);
411  //G4ThreeVector cutTrans(0, 0.125*inch, -0.25*inch);
412
413  G4SubtractionSolid* EndBracket_Solid = new G4SubtractionSolid("OuterEndBracket-InnerEndBracket",
414  OuterEndBracket,
415  InnerEndBracket,
416  cutRot,
417  cutTrans);
418
419  EndBracket_Logical = new G4LogicalVolume(EndBracket_Solid,
420  Frame_Material,
421  "EndBracket_Log",
422  0,0,0);
423
424  for (G4int i=0; i<4; i++) {
425  Rotation_EndBracket.push_back(new G4RotationMatrix(0,0,0));
426  if (i<2) Rotation_EndBracket[i]->rotateZ(-90.0*degree);
427  else Rotation_EndBracket[i]->rotateZ(90.0*degree);
428  }
429
430  G4double Distance_EndBracketToBarCenter = Frame_InnerFullLength_X*0.5 - 0.375*inch;
431
432  Position_EndBracket.push_back (G4ThreeVector(Distance_EndBracketToBarCenter,3.0*inch,0.25*inch) );
433  Position_EndBracket.push_back (G4ThreeVector(Distance_EndBracketToBarCenter,-3.0*inch,0.25*inch) );
434  Position_EndBracket.push_back (G4ThreeVector(-Distance_EndBracketToBarCenter,3.0*inch,0.25*inch) );
435  Position_EndBracket.push_back (G4ThreeVector(-Distance_EndBracketToBarCenter,-3.0*inch,0.25*inch) );
436
437  for (G4int i = 0; i<4; i++) {
438  EndBracket_Physical.push_back( new G4PVPlacement(Rotation_EndBracket.at(i),Position_EndBracket.at(i) + Container_Center,
439  EndBracket_Logical,
440  "EndBracket_Physical",
441  CerenkovContainer_Logical,
442  false,i,
443  pSurfChk));
444
445  }
446
447 //******************************Define End Bracket Pad*******************************************
448
449  EndBracketPadLength_X = EndBracketLength_X;
450  EndBracketPadLength_Y = EndBracketCutLength_Y-0.1*mm;
451  EndBracketPadLength_Z = EndBracketCutLength_Z-0.1*mm;
452
453  EndBracketPadCutLength_X = EndBracketPadLength_X+0.1*mm;
454  EndBracketPadCutLength_Y = EndBracketCutLength_Y-5.0*mm;
455  EndBracketPadCutLength_Z = QuartzBar_FullThickness;;
456
457  G4Box* OuterEndBracketPad = new G4Box("OuterEndBracketPad",
458  0.5 * EndBracketPadLength_X,
459  0.5 * EndBracketPadLength_Y,
460  0.5 * EndBracketPadLength_Z);
461
462  G4Box* InnerEndBracketPad = new G4Box("InnerEndBracketPad",
463  0.5 * EndBracketPadCutLength_X,
464  0.5 * EndBracketPadCutLength_Y,
465  0.5 * EndBracketPadCutLength_Z);
466
467  //G4RotationMatrix* cutRot = new G4RotationMatrix(0,0,0);
468  //G4ThreeVector cutTrans(0, 0.125*inch, -0.25*inch);
469
470  G4ThreeVector EndPadCutTrans(0., 0.19*inch, 0.);
471
472  G4SubtractionSolid* EndBracketPad_Solid = new G4SubtractionSolid("OuterEndBracketPad-InnerEndBracketPad",
473  OuterEndBracketPad,
474  InnerEndBracketPad,
475  PadCutRot,
476  EndPadCutTrans);
477
478  EndBracketPad_Logical = new G4LogicalVolume(EndBracketPad_Solid,
479  BracketPad_Material,
480  "EndBracketPad_Log",
481  0,0,0);
482
483  for (G4int i=0; i<4; i++) {
484  Rotation_EndBracketPad.push_back(new G4RotationMatrix(0,0,0));
485  if (i<2) Rotation_EndBracketPad[i]->rotateZ(-90.0*degree);
486  else Rotation_EndBracketPad[i]->rotateZ(90.0*degree);
487  }
488
489  G4double Distance_EndBracketPadToBarCenter = Frame_InnerFullLength_X*0.5 - 0.5*inch;
490
491  Position_EndBracketPad.push_back (G4ThreeVector(Distance_EndBracketPadToBarCenter,3.0*inch,0.) );
492  Position_EndBracketPad.push_back (G4ThreeVector(Distance_EndBracketPadToBarCenter,-3.0*inch,0.) );
493  Position_EndBracketPad.push_back (G4ThreeVector(-Distance_EndBracketPadToBarCenter,3.0*inch,0.) );
494  Position_EndBracketPad.push_back (G4ThreeVector(-Distance_EndBracketPadToBarCenter,-3.0*inch,0.) );
495
496  for (G4int i = 0; i<4; i++) {
497  EndBracketPad_Physical.push_back( new G4PVPlacement(Rotation_EndBracketPad.at(i),Position_EndBracketPad.at(i) + Container_Center,
498  EndBracketPad_Logical,
499  "EndBracketPad_Physical",
500  CerenkovContainer_Logical,
501  false,i,
502  pSurfChk));
503  }
504
505
506
507 //******************************Define the Cross Bar *******************************************
508
509  G4double CrossBar_FullLength_X = 1.5*inch;
510  G4double CrossBar_FullLength_Y = Frame_FullLength_Y - 0.75*2.0*inch;
511  G4double CrossBar_FullLength_Z = 0.75*inch;
512
513  G4Box* CrossBar_Solid = new G4Box("CrossBar_Solid",
514  0.5 * CrossBar_FullLength_X ,
515  0.5 * CrossBar_FullLength_Y ,
516  0.5 * CrossBar_FullLength_Z );
517
518  CrossBar_Logical = new G4LogicalVolume(CrossBar_Solid,
519  Frame_Material,
520  "CrossBar_Log",
521  0,0,0);
522
523  G4ThreeVector Position_CrossBar_R = G4ThreeVector((47.75-8.25)*inch,0,0.25*inch+0.625*inch);
524  G4ThreeVector Position_CrossBar_L = G4ThreeVector(-(47.75-8.25)*inch,0,0.25*inch+0.625*inch);
525
526  CrossBarR_Physical = new G4PVPlacement(0,Position_CrossBar_R + Container_Center,
527  CrossBar_Logical,
528  "CrossBarR_Physical",
529  CerenkovContainer_Logical,
530  false,0,
531  pSurfChk);
532
533  CrossBarL_Physical = new G4PVPlacement(0,Position_CrossBar_L + Container_Center,
534  CrossBar_Logical,
535  "CrossBarL_Physical",
536  CerenkovContainer_Logical,
537  false,0,
538  pSurfChk);
539
540 //******************************Define Detector Windows *******************************************
541
542  WindowThickness = 5.0*mm;
543
544  G4Box* FrontWindow_Solid = new G4Box("FrontWindow_Solid",
545  0.5 * Frame_FullLength_X ,
546  0.5 * Frame_FullLength_Y ,
547  0.5 * WindowThickness );
548
549  FrontWindow_Logical = new G4LogicalVolume(FrontWindow_Solid,
550  Window_Material,
551  "FrontWindow_Log",
552  0,0,0);
553
554  G4ThreeVector Position_FrontWindow = G4ThreeVector(0,0,0.25*inch-(1.0*inch+2.5*mm));
555
556  FrontWindow_Physical = new G4PVPlacement(0,Position_FrontWindow + Container_Center,
557  FrontWindow_Logical,
558  "FrontWindow_Physical",
559  CerenkovContainer_Logical,
560  false,0,
561  pSurfChk);
562
563
564  G4Box* BackWindow_Solid = new G4Box("BackWindow_Solid",
565  0.5 * Frame_FullLength_X - 8.25*inch,
566  0.5 * Frame_FullLength_Y ,
567  0.5 * WindowThickness );
568
569  BackWindow_Logical = new G4LogicalVolume(BackWindow_Solid,
570  Window_Material,
571  "BackWindow_Log",
572  0,0,0);
573
574  G4ThreeVector Position_BackWindow = G4ThreeVector(0,0,0.25*inch+1.0*inch+2.5*mm);
575
576  BackWindow_Physical = new G4PVPlacement(0,Position_BackWindow + Container_Center,
577  BackWindow_Logical,
578  "BackWindow_Physical",
579  CerenkovContainer_Logical,
580  false,0,
581  pSurfChk);
582
583
584 //******************************Define Front Window Clip*******************************************
585
586  G4double FrontClip_FullLength_X = 95.5*inch;
587  G4double FrontClip_FullLength_Y = 9.5*inch;
588  G4double FrontClip_FullLength_Z = 0.38*inch;
589
590  G4double FrontClip_InnerFullLength_X = (95.5-0.75*2.0)*inch;
591  G4double FrontClip_InnerFullLength_Y = (9.5-0.75*2.0)*inch;
592  G4double FrontClip_InnerFullLength_Z = 0.38*inch+1.0*mm; // a bit larger to avoid sharing surface with the outer which may cause vis-problem
593
594  G4Box* FrontClip_Outer = new G4Box("FrontClip_Outer",
595  0.5 * FrontClip_FullLength_X ,
596  0.5 * FrontClip_FullLength_Y ,
597  0.5 * FrontClip_FullLength_Z );
598
599  G4Box* FrontClip_Inner = new G4Box("FrontClip_Inner",
600  0.5 * FrontClip_InnerFullLength_X ,
601  0.5 * FrontClip_InnerFullLength_Y ,
602  0.5 * FrontClip_InnerFullLength_Z );
603
604  G4SubtractionSolid* FrontClip_Solid = new G4SubtractionSolid("FrontClip_Outer-FrontClip_Inner",
605  FrontClip_Outer,
606  FrontClip_Inner);
607
608  FrontClip_Logical = new G4LogicalVolume(FrontClip_Solid,
609  Frame_Material,
610  "FrontClip_Log",
611  0,0,0);
612
613  G4ThreeVector Position_FrontClip = G4ThreeVector(0,0,0.25*inch -(1.0*inch+5.0*mm+0.38/2.0*inch));
614
615  FrontClip_Physical = new G4PVPlacement(0,Position_FrontClip + Container_Center,
616  FrontClip_Logical,
617  "FrontClip_Physical",
618  CerenkovContainer_Logical,
619  false,0,
620  pSurfChk);
621
622 //******************************Define Back Window Clip*******************************************
623
624  G4double BackClip_FullLength_X = 95.5*inch - 8.25*2.0*inch;
625  G4double BackClip_FullLength_Y = 9.5*inch;
626  G4double BackClip_FullLength_Z = 0.38*inch;
627
628  G4double BackClip_InnerFullLength_X = 95.5*inch - 9.0*2.0*inch;
629  G4double BackClip_InnerFullLength_Y = (9.5-0.75*2.0)*inch;
630  G4double BackClip_InnerFullLength_Z = 0.38*inch+0.1*mm; // a bit larger to avoid sharing surface with the outer which may cause vis-problem
631
632  G4Box* BackClip_Outer = new G4Box("BackClip_Outer",
633  0.5 * BackClip_FullLength_X ,
634  0.5 * BackClip_FullLength_Y ,
635  0.5 * BackClip_FullLength_Z );
636
637  G4Box* BackClip_Inner = new G4Box("BackClip_Inner",
638  0.5 * BackClip_InnerFullLength_X ,
639  0.5 * BackClip_InnerFullLength_Y ,
640  0.5 * BackClip_InnerFullLength_Z );
641
642  G4SubtractionSolid* BackClip_Solid = new G4SubtractionSolid("BackClip_Outer-BackClip_Inner",
643  BackClip_Outer,
644  BackClip_Inner);
645
646  BackClip_Logical = new G4LogicalVolume(BackClip_Solid,
647  Frame_Material,
648  "BackClip_Log",
649  0,0,0);
650
651  G4ThreeVector Position_BackClip = G4ThreeVector(0,0,0.25*inch + 1.0*inch+5.0*mm+0.38/2.0*inch);
652
653  BackClip_Physical = new G4PVPlacement(0,Position_BackClip + Container_Center,
654  BackClip_Logical,
655  "BackClip_Physical",
656  CerenkovContainer_Logical,
657  false,0,
658  pSurfChk);
659
660 //******************************Define Square Flange Seal*******************************************
661
662  G4double SquareFlangeSeal_FullLength_X = 8.21*inch;
663  G4double SquareFlangeSeal_FullLength_Y = 9.50*inch;
664  G4double SquareFlangeSeal_FullLength_Z = 5.0*mm;
665
666  G4Box* SquareSealOuter_Solid = new G4Box("SquareSealOuter_Solid",
667  0.5 * SquareFlangeSeal_FullLength_X,
668  0.5 * SquareFlangeSeal_FullLength_Y,
669  0.5 * SquareFlangeSeal_FullLength_Z);
670
671  G4Box* SquareSealInner_Solid = new G4Box("SquareSealInner_Solid",
672  0.5 * SquareFlangeSeal_FullLength_X - 0.75*inch,
673  0.5 * SquareFlangeSeal_FullLength_Y - 0.75*inch,
674  0.5 * SquareFlangeSeal_FullLength_Z + 0.1*mm);
675
676  G4SubtractionSolid* SquareFlangeSeal_Solid
677  = new G4SubtractionSolid("SquareSealOuter_Solid-SquareSealInner_Solid",
678  SquareSealOuter_Solid,
679  SquareSealInner_Solid);
680
681  SquareFlangeSeal_Logical = new G4LogicalVolume(SquareFlangeSeal_Solid,
682  Window_Material,
683  "SquareFlangeSeal_Log",
684  0,0,0);
685
686  G4ThreeVector Position_SquareFlangeSeal_R = G4ThreeVector((47.75-8.21/2.0)*inch,
687  0,
688  0.25*inch + 1.0*inch+2.5*mm);
689
690  G4ThreeVector Position_SquareFlangeSeal_L = G4ThreeVector(-(47.75-8.21/2.0)*inch,
691  0,
692  0.25*inch + 1.0*inch+2.5*mm);
693
694  SquareFlangeSealR_Physical = new G4PVPlacement(0,Position_SquareFlangeSeal_R + Container_Center,
695  SquareFlangeSeal_Logical,
696  "SquareFlangeSealR_Physical",
697  CerenkovContainer_Logical,
698  false,0,
699  pSurfChk);
700
701  SquareFlangeSealL_Physical = new G4PVPlacement(0,Position_SquareFlangeSeal_L + Container_Center,
702  SquareFlangeSeal_Logical,
703  "SquareFlangeSealL_Physical",
704  CerenkovContainer_Logical,
705  false,0,
706  pSurfChk);
707
708 //******************************Define Square Flange *******************************************
709
710  G4double SquareFlange_FullLength_X = 8.21*inch;
711  G4double SquareFlange_FullLength_Y = 9.50*inch;
712  G4double SquareFlange_FullLength_Z = 0.38*inch;
713
714  G4double CutOuterRadius = 5.75*0.5*inch;
715  G4double CutInnerRadius = 0.0*inch;
716  G4double CutThickness = 0.38*inch+0.1*mm;
717
718  G4Box* SquareBase_Solid = new G4Box("SquareBase_Solid",
719  0.5 * SquareFlange_FullLength_X,
720  0.5 * SquareFlange_FullLength_Y,
721  0.5 * SquareFlange_FullLength_Z);
722
723  G4Tubs* CylinderCut_Solid = new G4Tubs("CylinderCut_Solid",
724  CutInnerRadius,
725  CutOuterRadius,
726  0.5 * CutThickness,
727  0.0, 360.0*degree);
728
729  G4SubtractionSolid* SquareFlange_Solid = new G4SubtractionSolid("SquareBase_Solid-CylinderCut_Solid",
730  SquareBase_Solid,
731  CylinderCut_Solid);
732
733  SquareFlange_Logical = new G4LogicalVolume(SquareFlange_Solid,
734  Frame_Material,
735  "SquareFlange_Log",
736  0,0,0);
737
738  G4ThreeVector Position_SquareFlange_R = G4ThreeVector((47.75-8.21/2.0)*inch,
739  0,
740  0.25*inch + 1.0*inch+5.0*mm+0.38/2.0*inch);
741
742  G4ThreeVector Position_SquareFlange_L = G4ThreeVector(-(47.75-8.21/2.0)*inch,
743  0,
744  0.25*inch + 1.0*inch+5.0*mm+0.38/2.0*inch);
745
746  SquareFlangeR_Physical = new G4PVPlacement(0,Position_SquareFlange_R + Container_Center,
747  SquareFlange_Logical,
748  "SquareFlangeR_Physical",
749  CerenkovContainer_Logical,
750  false,0,
751  pSurfChk);
752
753  SquareFlangeL_Physical = new G4PVPlacement(0,Position_SquareFlange_L + Container_Center,
754  SquareFlange_Logical,
755  "SquareFlangeL_Physical",
756  CerenkovContainer_Logical,
757  false,0,
758  pSurfChk);
759
760 //******************************Define PMT Housing Wall *******************************************
761
762  G4double PMTHousingWallOuterRadius = 6.63*0.5*inch;
763  G4double PMTHousingWallInnerRadius = 6.07*0.5*inch;
764  G4double PMTHousingWallLength = 3.53*inch;
765
766  G4Tubs* PMTHousingWall_Solid = new G4Tubs("PMTHousingWall_Solid",
767  PMTHousingWallInnerRadius,
768  PMTHousingWallOuterRadius,
769  0.5 * PMTHousingWallLength,
770  0.0, 360.0*degree);
771
772  PMTHousingWall_Logical = new G4LogicalVolume(PMTHousingWall_Solid,
773  Frame_Material,
774  "PMTHousingWall_Log",
775  0,0,0);
776
777  G4ThreeVector Position_PMTHousingWall_R = G4ThreeVector((47.75-8.21/2.0)*inch,
778  0,
779  0.25*inch + 1.0*inch+5.0*mm+0.38*inch+PMTHousingWallLength*0.5);
780
781  G4ThreeVector Position_PMTHousingWall_L = G4ThreeVector(-(47.75-8.21/2.0)*inch,
782  0,
783  0.25*inch + 1.0*inch+5.0*mm+0.38*inch+PMTHousingWallLength*0.5);
784
785  PMTHousingWallR_Physical = new G4PVPlacement(0,Position_PMTHousingWall_R + Container_Center,
786  PMTHousingWall_Logical,
787  "PMTHousingWallR_Physical",
788  CerenkovContainer_Logical,
789  false,0,
790  pSurfChk);
791
792  PMTHousingWallL_Physical = new G4PVPlacement(0,Position_PMTHousingWall_L + Container_Center,
793  PMTHousingWall_Logical,
794  "PMTHousingWallL_Physical",
795  CerenkovContainer_Logical,
796  false,0,
797  pSurfChk);
798
799 //******************************Define PMT Housing Flange ******************
800
801  G4double PMTHousingFlangeOuterRadius = 7.88*0.5*inch;
802  G4double PMTHousingFlangeInnerRadius = 5.75*0.5*inch;
803  G4double PMTHousingFlangeLength = 0.75*inch;
804
805  G4Tubs* PMTHousingFlange_Solid = new G4Tubs("PMTHousingFlange_Solid",
806  PMTHousingFlangeInnerRadius,
807  PMTHousingFlangeOuterRadius,
808  0.5 * PMTHousingFlangeLength,
809  0.0, 360.0*degree);
810
811  PMTHousingFlange_Logical = new G4LogicalVolume(PMTHousingFlange_Solid,
812  Frame_Material,
813  "PMTHousingFlange_Log",
814  0,0,0);
815
816  G4ThreeVector Position_PMTHousingFlange_R = G4ThreeVector((47.75-8.21/2.0)*inch,
817  0,
818  0.25*inch + 1.0*inch+5.0*mm+0.38*inch+PMTHousingWallLength+PMTHousingFlangeLength*0.5);
819
820  G4ThreeVector Position_PMTHousingFlange_L = G4ThreeVector(-(47.75-8.21/2.0)*inch,
821  0,
822  0.25*inch + 1.0*inch+5.0*mm+0.38*inch+PMTHousingWallLength+PMTHousingFlangeLength*0.5);
823
824  PMTHousingFlangeR_Physical = new G4PVPlacement(0,Position_PMTHousingFlange_R + Container_Center,
825  PMTHousingFlange_Logical,
826  "PMTHousingFlangeR_Physical",
827  CerenkovContainer_Logical,
828  false,0,
829  pSurfChk);
830
831  PMTHousingFlangeL_Physical = new G4PVPlacement(0,Position_PMTHousingFlange_L + Container_Center,
832  PMTHousingFlange_Logical,
833  "PMTHousingFlangeL_Physical",
834  CerenkovContainer_Logical,
835  false,0,
836  pSurfChk);
837
838 //******************************Define PMT Housing Lid *******************************************
839
840  G4double phiStart = 0.0;
841  G4double phiTotal = 360*degree;
842  G4int numZPlanes = 9;
843  G4double rInner[9] = { 6.5/2.0*inch, 6.5/2.0*inch, 2.52/2.0*inch, 2.52/2.0*inch, 2.52/2.0*inch, 2.52/2.0*inch, 2.52/2.0*inch, 2.52/2.0*inch, 2.52/2.0*inch};
844  G4double rOuter[9] = { 7.88/2.0*inch, 7.88/2.0*inch, 7.88/2.0*inch, 7.88/2.0*inch, 2.75/2.0*inch, 2.75/2.0*inch, 3.0/2.0*inch, 3.0/2.0*inch, 2.99/2.0*inch,};
845  G4double zPlane[9] = { 0.0, 0.37*inch, 0.38*inch, 0.39*inch, 0.5*inch, 0.69*inch, 0.70*inch, 0.85*inch, 0.86*inch };
846
847  G4Polycone* PMTHousingLid_Solid = new G4Polycone("PMTHousingLid_Soild",
848  phiStart,
849  phiTotal,
850  numZPlanes,
851  zPlane,
852  rInner,
853  rOuter);
854
855  PMTHousingLid_Logical = new G4LogicalVolume(PMTHousingLid_Solid,
856  Frame_Material,
857  "PMTHousingLid_Log",
858  0,0,0);
859
860  G4ThreeVector Position_PMTHousingLid_R = G4ThreeVector( (47.75-8.21/2.0)*inch,
861  0,
862  0.25*inch+1.0*inch+5.0*mm+0.38*inch+PMTHousingWallLength+PMTHousingFlangeLength);
863
864  G4ThreeVector Position_PMTHousingLid_L = G4ThreeVector( -(47.75-8.21/2.0)*inch,
865  0,
866  0.25*inch+1.0*inch+5.0*mm+0.38*inch+PMTHousingWallLength+PMTHousingFlangeLength);
867
868  PMTHousingLidR_Physical = new G4PVPlacement(0,Position_PMTHousingLid_R + Container_Center,
869  PMTHousingLid_Logical,
870  "PMTHousingLidR_Physical",
871  CerenkovContainer_Logical,
872  false,0,
873  pSurfChk);
874
875  PMTHousingLidL_Physical = new G4PVPlacement(0,Position_PMTHousingLid_L + Container_Center,
876  PMTHousingLid_Logical,
877  "PMTHousingLidL_Physical",
878  CerenkovContainer_Logical,
879  false,0,
880  pSurfChk);
881
882 //******************************Define Exo-Skelton Frame*************************
883
884  ExoSkeltonFrame_X = Frame_FullLength_X+0.2*cm;
885  ExoSkeltonFrame_Y = Frame_FullLength_Y+6.0*inch;
886  ExoSkeltonFrame_Z = 3.0*inch;
887
888  ExoSkeltonInnerFrame_X = ExoSkeltonFrame_X+0.2*mm;
889  ExoSkeltonInnerFrame_Y = Frame_FullLength_Y+0.2*cm;
890  ExoSkeltonInnerFrame_Z = ExoSkeltonFrame_Z+0.1*mm; // a bit larger to avoid sharing surface with the outer which may cause vis-problem
891
892  G4Box* ExoSkeltonOuterFrame = new G4Box("ExoSkeltonOuterFrame",
893  0.5 * ExoSkeltonFrame_X ,
894  0.5 * ExoSkeltonFrame_Y ,
895  0.5 * ExoSkeltonFrame_Z );
896
897  G4Box* ExoSkeltonInnerFrame = new G4Box("ExoSkeltonInnerFrame",
898  0.5 * ExoSkeltonInnerFrame_X ,
899  0.5 * ExoSkeltonInnerFrame_Y ,
900  0.5 * ExoSkeltonInnerFrame_Z );
901
902  G4SubtractionSolid* ExoSkeltonFrame_Solid = new G4SubtractionSolid("ExoSkeltonOuterFrame-ExoSkeltonInnerFrame", ExoSkeltonOuterFrame, ExoSkeltonInnerFrame);
903
904  ExoSkeltonFrame_Logical = new G4LogicalVolume(ExoSkeltonFrame_Solid,
905  Frame_Material,
906  "ExoSkeltonFrame_Log",
907  0,0,0);
908
909  G4ThreeVector Position_ExoSkeltonFrame = G4ThreeVector(0,0,-1.0*inch);
910
911  ExoSkeltonFrame_Physical = new G4PVPlacement(0,Position_ExoSkeltonFrame + Container_Center,
912  ExoSkeltonFrame_Logical,
913  "ExoSkeltonFrame_Physical",
914  CerenkovContainer_Logical,
915  false,0,
916  pSurfChk);
917
918
919 //****************************************************************************************************
920
921
922 //******************************Define Detector Active Area*******************************************
923
924  G4Box* ActiveArea_Solid = new G4Box("CerenkoDetector_Solid",
925  0.5 * ActiveArea_FullLength_X ,
926  0.5 * ActiveArea_FullLength_Y ,
927  0.5 * ActiveArea_FullLength_Z );
928
929  ActiveArea_Logical = new G4LogicalVolume(ActiveArea_Solid,
930  ActiveArea_Material,
931  "ActiveArea_Log",
932  0,0,0);
933
934  G4ThreeVector Position_ActiveArea = G4ThreeVector(0,0,0);
935
936  ActiveArea_Physical = new G4PVPlacement(0,Position_ActiveArea + Container_Center,
937  ActiveArea_Logical,
938  "ActiveArea_Physical",
939  CerenkovContainer_Logical,
940  false,0,
941  pSurfChk);
942
943 //****************************************************************************************************
944 //****************************************************************************************************
945
946
947  G4double ChamferRotation = 45.0*degree;
948  G4double ChamferScew = 0.0;
949  G4double delta = 0.0;
950
951 //****************************************************************************************************
952 //******************************Define Right Detector Quartz Bar With Chamfers************************
953
954
955  G4Box* Chamfer_Solid = new G4Box("Chamfer_Solid",
956  0.5 * Chamfer_FullLength, // half X length required by Geant4
957  0.5 * Chamfer_FullHeight , // half Y length required by Geant4
958  0.5 * Chamfer_FullThickness );
959
960 // G4Box* QuartzBar_Solid = new G4Box("QuartzBar_Solid",
961 // 0.5 * QuartzBar_FullLength, // half X length required by Geant4
962 // 0.5 * QuartzBar_FullHeight, // half Y length required by Geant4
963 // 0.5 * QuartzBar_FullThickness ); // half Z length required by Geant4
964
965  G4Trd* QuartzBar_Solid = new G4Trd("QuartzBar_Solid",
966  0.5*QuartzBar_FullLength,
967  0.5*QuartzBar_FullLength,
968  0.5*QuartzBar_FullHeight+0.1*cm,
969  0.5*QuartzBar_FullHeight-0.1*cm,
970  0.5*QuartzBar_FullThickness);
971
972  //Boolean Union:
973  //Upper-upstream edge chamfer
974
975  ChamferScew = 0.021486*degree;
976  delta = 0.5*(Chamfer_FullHeight - 1.0*mm)/sqrt(2.0);
977  G4double ChamferAdjRotZ = atan(sin(ChamferScew)*cos(90*degree - ChamferRotation));
978  G4double ChamferAdjRotY = atan(sin(ChamferScew)*sin(90*degree - ChamferRotation));
979  Position_Chamfer1.setX(0.0*cm);//33.333333*cm);
980  Position_Chamfer1.setY(0.5*QuartzBar_FullHeight + delta);
981  Position_Chamfer1.setZ(-(0.5*QuartzBar_FullThickness + delta));
982  Rotation_Chamfer1.rotateX(45.0*degree);
983  Rotation_Chamfer1.rotateY(ChamferAdjRotY);
984  Rotation_Chamfer1.rotateZ(ChamferAdjRotZ);
985  G4Transform3D Transform_Chamfer1(Rotation_Chamfer1,Position_Chamfer1);
986  Rotation_Chamfer1.rotateZ(-ChamferAdjRotZ);
987  Rotation_Chamfer1.rotateY(-ChamferAdjRotY);
988
989  RightQuartz_Solid[0]= new G4SubtractionSolid ("UpperUpstreamChamfer-RightQuartzBar",
990  QuartzBar_Solid,
991  Chamfer_Solid,
992  Transform_Chamfer1);
993
994  //Boolean Union:
995  //Upper-downstream edge chamfer
996
997  delta = 0.5*(Chamfer_FullHeight - 0.5*mm)/sqrt(2.0);
998  ChamferScew = 0.0;//0.014*degree;
999  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(ChamferRotation));
1000  ChamferAdjRotY = atan(sin(ChamferScew)*sin(ChamferRotation));
1001  Position_Chamfer2.setX(0.0*mm);
1002  Position_Chamfer2.setY(0.5*QuartzBar_FullHeight + delta);
1003  Position_Chamfer2.setZ(0.5*QuartzBar_FullThickness + delta);
1004  Rotation_Chamfer2.rotateX(45.0*degree);
1005  Rotation_Chamfer2.rotateY(-ChamferAdjRotY);
1006  Rotation_Chamfer2.rotateZ(ChamferAdjRotZ);
1007  G4Transform3D Transform_Chamfer2(Rotation_Chamfer2,Position_Chamfer2);
1008  Rotation_Chamfer2.rotateZ(-ChamferAdjRotZ);
1009  Rotation_Chamfer2.rotateY(ChamferAdjRotY);
1010
1011  RightQuartz_Solid[1] = new G4SubtractionSolid ("UpperDownstreamChamfer-RightQuartzBar",
1012  RightQuartz_Solid[0],
1013  Chamfer_Solid,
1014  Transform_Chamfer2);
1015
1016  //Boolean Union:
1017  //Lower-Upstream edge chamfer
1018  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(ChamferRotation));
1019  ChamferAdjRotY = atan(sin(ChamferScew)*sin(ChamferRotation));
1020  Position_Chamfer3.setX(0.0*mm);
1021  Position_Chamfer3.setY(-(0.5*QuartzBar_FullHeight + delta));
1022  Position_Chamfer3.setZ(-(0.5*QuartzBar_FullThickness + delta));
1023  Rotation_Chamfer3.rotateX(45.0*degree);
1024  Rotation_Chamfer3.rotateY(ChamferAdjRotY);
1025  Rotation_Chamfer3.rotateZ(-ChamferAdjRotZ);
1026  G4Transform3D Transform_Chamfer3(Rotation_Chamfer3,Position_Chamfer3);
1027  Rotation_Chamfer3.rotateZ(ChamferAdjRotZ);
1028  Rotation_Chamfer3.rotateY(-ChamferAdjRotY);
1029
1030  RightQuartz_Solid[2] = new G4SubtractionSolid ("LowerUpstreamChamfer-RightQuartzBar",
1031  RightQuartz_Solid[1],Chamfer_Solid,
1032  Transform_Chamfer3);
1033
1034  //Boolean Union:
1035  //Lower-Downstream edge chamfer
1036  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(90*degree - ChamferRotation));
1037  ChamferAdjRotY = atan(sin(ChamferScew)*sin(90*degree - ChamferRotation));
1038  Position_Chamfer4.setX(0.0*mm);
1039  Position_Chamfer4.setY(-(0.5*QuartzBar_FullHeight + delta));
1040  Position_Chamfer4.setZ(0.5*QuartzBar_FullThickness + delta);
1041  Rotation_Chamfer4.rotateX(45.0*degree);
1042  Rotation_Chamfer4.rotateY(-ChamferAdjRotY);
1043  Rotation_Chamfer4.rotateZ(-ChamferAdjRotZ);
1044  G4Transform3D Transform_Chamfer4(Rotation_Chamfer4,Position_Chamfer4);
1045  Rotation_Chamfer4.rotateY(ChamferAdjRotY);
1046  Rotation_Chamfer4.rotateZ(ChamferAdjRotZ);
1047
1048  RightQuartz_Solid[3] = new G4SubtractionSolid ("LowerUpstreamChamfer-RightQuartzBar",
1049  RightQuartz_Solid[2], Chamfer_Solid,
1050  Transform_Chamfer4);
1051
1052
1053  QuartzBar_LogicalRight = new G4LogicalVolume(RightQuartz_Solid[3],
1054  QuartzBar_Material,
1055  "QuartzBar_LogicalRight",
1056  0,0,0);
1057
1058  G4ThreeVector Position_RightQuartzBar = G4ThreeVector(-0.5*(QuartzBar_FullLength+GlueFilm_FullLength_X),0,0);
1059
1060  QuartzBar_PhysicalRight = new G4PVPlacement(0,Position_RightQuartzBar,
1061  QuartzBar_LogicalRight,
1062  "QuartzBar_PhysicalRight",
1063  ActiveArea_Logical,
1064  false,0,
1065  pSurfChk);
1066
1067 //****************************************************************************************************
1068 //****************************************************************************************************
1069
1070 //****************************************************************************************************
1071 //******************************Define Center Quartz Glue Film ***************************************
1072
1073
1074  G4Box* CenterGlueFilm_Solid = new G4Box("CenterGlueFilm_Solid",
1075  0.5 * GlueFilm_FullLength_X,
1076  0.5 * GlueFilm_FullLength_Y,
1077  0.5 * GlueFilm_FullLength_Z);
1078
1079  QuartzGlue_Logical = new G4LogicalVolume(CenterGlueFilm_Solid,
1080  QuartzGlue_Material,
1081  "CenterGlueFilm_Log",
1082  0,0,0);
1083
1084  G4ThreeVector Position_CenterGlueFilm = G4ThreeVector(0,0,0);
1085
1086  QuartzGlue_PhysicalCenter = new G4PVPlacement(0,Position_CenterGlueFilm,
1087  QuartzGlue_Logical,
1088  "QuartzGlue_PhysicalCenter",
1089  ActiveArea_Logical,
1090  false,0,
1091  pSurfChk);
1092
1093 //****************************************************************************************************
1094 //****************************************************************************************************
1095
1096 //****************************************************************************************************
1097 //******************************Define Right Quartz Glue Film ****************************************
1098
1099  G4ThreeVector Position_RightGlueFilm = G4ThreeVector(-1.0*(QuartzBar_FullLength+GlueFilm_FullLength_X),0,0);
1100
1101  QuartzGlue_PhysicalRight = new G4PVPlacement(0,Position_RightGlueFilm,
1102  QuartzGlue_Logical,
1103  "QuartzGlue_PhysicalRight",
1104  ActiveArea_Logical,
1105  false,1,
1106  pSurfChk);
1107
1108 //****************************************************************************************************
1109 //****************************************************************************************************
1110
1111 //****************************************************************************************************
1112 //******************************Define Left Detector Quartz Bar With Chamfers ***********************
1113
1114
1115  //Boolean Union:
1116  //Upper-upstream edge chamfer
1117
1118  ChamferScew = -0.021486*degree;
1119  delta = 0.5*(Chamfer_FullHeight - 1.0*mm)/sqrt(2.0);
1120  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(90*degree - ChamferRotation));
1121  ChamferAdjRotY = atan(sin(ChamferScew)*sin(90*degree - ChamferRotation));
1122  Position_Chamfer1.setX(0.0*cm);//33.333333*cm);
1123  Position_Chamfer1.setY(0.5*QuartzBar_FullHeight + delta);
1124  Position_Chamfer1.setZ(-(0.5*QuartzBar_FullThickness + delta));
1125 // Rotation_Chamfer1.rotateX(45.0*degree);
1126  Rotation_Chamfer1.rotateY(ChamferAdjRotY);
1127  Rotation_Chamfer1.rotateZ(ChamferAdjRotZ);
1128  G4Transform3D Transform_Chamfer5(Rotation_Chamfer1,Position_Chamfer1);
1129  Rotation_Chamfer1.rotateZ(-ChamferAdjRotZ);
1130  Rotation_Chamfer1.rotateY(-ChamferAdjRotY);
1131
1132  LeftQuartz_Solid[0]= new G4SubtractionSolid ("UpperUpstreamChamfer-LeftQuartzBar",
1133  QuartzBar_Solid,
1134  Chamfer_Solid,
1135  Transform_Chamfer5);
1136
1137  //Boolean Union:
1138  //Upper-downstream edge chamfer
1139
1140  delta = 0.5*(Chamfer_FullHeight - 0.5*mm)/sqrt(2.0);
1141  ChamferScew = 0.0;//0.014*degree;
1142  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(ChamferRotation));
1143  ChamferAdjRotY = atan(sin(ChamferScew)*sin(ChamferRotation));
1144  Position_Chamfer2.setX(0.0*mm);
1145  Position_Chamfer2.setY(0.5*QuartzBar_FullHeight + delta);
1146  Position_Chamfer2.setZ(0.5*QuartzBar_FullThickness + delta);
1147 // Rotation_Chamfer2.rotateX(45.0*degree);
1148  Rotation_Chamfer2.rotateY(-ChamferAdjRotY);
1149  Rotation_Chamfer2.rotateZ(ChamferAdjRotZ);
1150  G4Transform3D Transform_Chamfer6(Rotation_Chamfer2,Position_Chamfer2);
1151  Rotation_Chamfer2.rotateZ(-ChamferAdjRotZ);
1152  Rotation_Chamfer2.rotateY(ChamferAdjRotY);
1153
1154  LeftQuartz_Solid[1] = new G4SubtractionSolid ("UpperDownstreamChamfer-LeftQuartzBar",
1155  LeftQuartz_Solid[0],
1156  Chamfer_Solid,
1157  Transform_Chamfer6);
1158
1159  //Boolean Union:
1160  //Lower-Upstream edge chamfer
1161  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(ChamferRotation));
1162  ChamferAdjRotY = atan(sin(ChamferScew)*sin(ChamferRotation));
1163  Position_Chamfer3.setX(0.0*mm);
1164  Position_Chamfer3.setY(-(0.5*QuartzBar_FullHeight + delta));
1165  Position_Chamfer3.setZ(-(0.5*QuartzBar_FullThickness + delta));
1166 // Rotation_Chamfer3.rotateX(45.0*degree);
1167  Rotation_Chamfer3.rotateY(ChamferAdjRotY);
1168  Rotation_Chamfer3.rotateZ(-ChamferAdjRotZ);
1169  G4Transform3D Transform_Chamfer7(Rotation_Chamfer3,Position_Chamfer3);
1170  Rotation_Chamfer3.rotateZ(ChamferAdjRotZ);
1171  Rotation_Chamfer3.rotateY(-ChamferAdjRotY);
1172
1173  LeftQuartz_Solid[2] = new G4SubtractionSolid ("LowerUpstreamChamfer-LeftQuartzBar",
1174  LeftQuartz_Solid[1],Chamfer_Solid,
1175  Transform_Chamfer7);
1176
1177  //Boolean Union:
1178  //Lower-Downstream edge chamfer
1179  ChamferAdjRotZ = atan(sin(ChamferScew)*cos(90*degree - ChamferRotation));
1180  ChamferAdjRotY = atan(sin(ChamferScew)*sin(90*degree - ChamferRotation));
1181  Position_Chamfer4.setX(0.0*mm);
1182  Position_Chamfer4.setY(-(0.5*QuartzBar_FullHeight + delta));
1183  Position_Chamfer4.setZ(0.5*QuartzBar_FullThickness + delta);
1184 // Rotation_Chamfer4.rotateX(45.0*degree);
1185  Rotation_Chamfer4.rotateY(-ChamferAdjRotY);
1186  Rotation_Chamfer4.rotateZ(-ChamferAdjRotZ);
1187  G4Transform3D Transform_Chamfer8(Rotation_Chamfer4,Position_Chamfer4);
1188  Rotation_Chamfer4.rotateY(ChamferAdjRotY);
1189  Rotation_Chamfer4.rotateZ(ChamferAdjRotZ);
1190
1191  LeftQuartz_Solid[3] = new G4SubtractionSolid ("LowerUpstreamChamfer-LeftQuartzBar",
1192  LeftQuartz_Solid[2], Chamfer_Solid,
1193  Transform_Chamfer8);
1194
1195
1196  QuartzBar_LogicalLeft = new G4LogicalVolume(LeftQuartz_Solid[3],
1197  QuartzBar_Material,
1198  "QuartzBar_LogicalLeft",
1199  0,0,0);
1200
1201  G4ThreeVector Position_LeftQuartzBar = G4ThreeVector(0.5*(QuartzBar_FullLength+GlueFilm_FullLength_X),0,0);
1202
1203  QuartzBar_PhysicalLeft = new G4PVPlacement(0,Position_LeftQuartzBar,
1204  QuartzBar_LogicalLeft,
1205  "QuartzBar_PhysicalLeft",
1206  ActiveArea_Logical,
1207  false,0,
1208  pSurfChk);
1209
1210 //****************************************************************************************************
1211 //****************************************************************************************************
1212
1213 //****************************************************************************************************
1214 //******************************Define Left Quartz Glue Film *****************************************
1215
1216  G4ThreeVector Position_LeftGlueFilm = G4ThreeVector((QuartzBar_FullLength+GlueFilm_FullLength_X),0,0);
1217
1218  QuartzGlue_PhysicalLeft = new G4PVPlacement(0,Position_LeftGlueFilm,
1219  QuartzGlue_Logical,
1220  "QuartzGlue_PhysicalLeft",
1221  ActiveArea_Logical,
1222  false,1,
1223  pSurfChk);
1224
1225 //****************************************************************************************************
1226 //****************************************************************************************************
1227
1228 //****************************************************************************************************
1229 //******************************Define Light Guides With Chamfers And Any Sculpting*******************
1230
1231  G4double redfr = 1.0; //0.5
1232  G4double pTheta = atan(LightGuide_FullThickness*(1 - redfr)/(2.0*LightGuide_FullLength));
1233
1234  G4Trap* LightGuide_Solid = new G4Trap("LightGuide_Solid",
1235  0.5*LightGuide_FullLength,pTheta,0.0,
1236  0.5*LightGuide_FullWidth1,
1237  redfr*0.5*LightGuide_FullThickness,
1238  redfr*0.5*LightGuide_FullThickness,0.0,
1239  0.5*LightGuide_FullWidth2,
1240  0.5*LightGuide_FullThickness,
1241  0.5*LightGuide_FullThickness,
1242  0.0);
1243
1244  LGAngCutXDim = 8.0*cm;
1245  LGAngCutYDim = LightGuide_FullWidth1+1.0*cm;
1246  LGAngCutZDim = 2.0*cm;
1247
1248  G4Box* LGEdgeAngleCut_Solid = new G4Box("LGEdgeAngleCut_Solid",
1249  0.5*LGAngCutXDim,
1250  0.5*LGAngCutYDim,
1251  0.5*LGAngCutZDim);
1252  G4double ad = 0.0; //45.0; //0.0;
1253  G4double ar = ad*4.0*atan(1.0)/180.0;
1254  G4double dx = 0.5*LGAngCutZDim*cos(ar)-0.5*(LightGuide_FullThickness -
1255  LGAngCutZDim*sin(ar))*tan(ar)
1256  + LightGuide_FullThickness*(1 - redfr)*tan(ar);
1257
1258
1259
1260 //******************************Left Light Guide *****************************************************
1261
1262  //Boolean Union:
1263  //Left Light Guide Angular cut-off at edge
1264  Position_AngCut1.setX(0.0*cm);
1265  Position_AngCut1.setY(0.0*cm);
1266  Position_AngCut1.setZ(-(0.5*LightGuide_FullLength+dx));
1267  Rotation_AngCut1.rotateY(ad*degree);
1268  G4Transform3D Transform_AngCut1(Rotation_AngCut1,Position_AngCut1);
1269
1270  LeftGuide_Solid[0] = new G4SubtractionSolid ("LGLeft-AngCut",
1271  LightGuide_Solid,
1272  LGEdgeAngleCut_Solid,
1273  Transform_AngCut1);
1274
1275  delta = 0.5*(Chamfer_FullHeight - 0.5*mm)/sqrt(2.0);
1276
1277  Position_Chamfer1.setX(-(0.5*QuartzBar_FullThickness + delta));
1278  Position_Chamfer1.setY(0.5*QuartzBar_FullHeight + delta);
1279  Position_Chamfer1.setZ(0.0);
1280  Rotation_Chamfer1.rotateY(90.0*degree);
1281  G4Transform3D Transform_Chamfer9(Rotation_Chamfer1,Position_Chamfer1);
1282
1283  LeftGuide_Solid[1]= new G4SubtractionSolid ("LeftLGChamfer1",
1284  LeftGuide_Solid[0],
1285  Chamfer_Solid,
1286  Transform_Chamfer9);
1287
1288
1289  Position_Chamfer2.setX(0.5*QuartzBar_FullThickness + delta);
1290  Position_Chamfer2.setY(0.5*QuartzBar_FullHeight + delta);
1291  Position_Chamfer2.setZ(0.0*cm);
1292  Rotation_Chamfer2.rotateY(90.0*degree);
1293  G4Transform3D Transform_Chamfer10(Rotation_Chamfer2,Position_Chamfer2);
1294
1295  LeftGuide_Solid[2]= new G4SubtractionSolid ("LeftLGChamfer2",
1296  LeftGuide_Solid[1],
1297  Chamfer_Solid,
1298  Transform_Chamfer10);
1299
1300
1301  Position_Chamfer3.setX(0.5*QuartzBar_FullThickness + delta);
1302  Position_Chamfer3.setY(-(0.5*QuartzBar_FullHeight + delta));
1303  Position_Chamfer3.setZ(0.0*cm);
1304  Rotation_Chamfer3.rotateY(90.0*degree);
1305  G4Transform3D Transform_Chamfer11(Rotation_Chamfer3,Position_Chamfer3);
1306
1307  LeftGuide_Solid[3]= new G4SubtractionSolid ("LeftLGChamfer3",
1308  LeftGuide_Solid[2],
1309  Chamfer_Solid,
1310  Transform_Chamfer11);
1311
1312  Position_Chamfer4.setX(-(0.5*QuartzBar_FullThickness + delta));
1313  Position_Chamfer4.setY(-(0.5*QuartzBar_FullHeight + delta));
1314  Position_Chamfer4.setZ(0.0*cm);
1315  Rotation_Chamfer4.rotateY(90.0*degree);
1316  G4Transform3D Transform_Chamfer12(Rotation_Chamfer4,Position_Chamfer4);
1317
1318  LeftGuide_Solid[4]= new G4SubtractionSolid ("LeftLGChamfer4",
1319  LeftGuide_Solid[3],
1320  Chamfer_Solid,
1321  Transform_Chamfer12);
1322
1323
1324
1325 //******************************Right Light Guide ****************************************************
1326
1327
1328  //Boolean Union:
1329  //Right Light Guide Angular cut-off at edge
1330  Position_AngCut2.setX(0.0*cm);
1331  Position_AngCut2.setY(0.0*cm);
1332  Position_AngCut2.setZ(-(0.5*LightGuide_FullLength+dx));
1333  Rotation_AngCut2.rotateY(-ad*degree);
1334  G4Transform3D Transform_AngCut2(Rotation_AngCut2,Position_AngCut2);
1335
1336  RightGuide_Solid[0] = new G4SubtractionSolid ("LGRight-AngCut",
1337  LightGuide_Solid,
1338  LGEdgeAngleCut_Solid,
1339  Transform_AngCut2);
1340
1341  G4Transform3D Transform_Chamfer13(Rotation_Chamfer1,Position_Chamfer1);
1342
1343  RightGuide_Solid[1]= new G4SubtractionSolid ("RightLGChamfer1",
1344  RightGuide_Solid[0],
1345  Chamfer_Solid,
1346  Transform_Chamfer13);
1347
1348
1349  G4Transform3D Transform_Chamfer14(Rotation_Chamfer2,Position_Chamfer2);
1350
1351  RightGuide_Solid[2]= new G4SubtractionSolid ("RightLGChamfer2",
1352  RightGuide_Solid[1],
1353  Chamfer_Solid,
1354  Transform_Chamfer14);
1355
1356
1357  G4Transform3D Transform_Chamfer15(Rotation_Chamfer3,Position_Chamfer3);
1358
1359  RightGuide_Solid[3]= new G4SubtractionSolid ("RightLGChamfer3",
1360  RightGuide_Solid[2],
1361  Chamfer_Solid,
1362  Transform_Chamfer15);
1363
1364  G4Transform3D Transform_Chamfer16(Rotation_Chamfer4,Position_Chamfer4);
1365
1366  RightGuide_Solid[4]= new G4SubtractionSolid ("RightLGChamfer4",
1367  RightGuide_Solid[3],
1368  Chamfer_Solid,
1369  Transform_Chamfer16);
1370
1371 //****************************************************************************************************
1372 //****************************************************************************************************
1373
1374
1375
1376  //Boolean Union:
1377  //Left Light Guide
1378  Position_LGLeft.setX((QuartzBar_FullLength+0.5*LightGuide_FullLength+1.5*GlueFilm_FullLength_X));
1379  Position_LGLeft.setY(0.0*cm);
1380  Position_LGLeft.setZ(0.0*cm - LightGuide_FullThickness*(1 - redfr)/(4.0));
1381  Rotation_LGLeft.rotateY(-90.0*degree);
1382  G4Transform3D Transform_LGLeft(Rotation_LGLeft,Position_LGLeft);
1383
1384  //Boolean Union:
1385  //Right Light Guide
1386  Position_LGRight.setX(-(QuartzBar_FullLength+0.5*LightGuide_FullLength+1.5*GlueFilm_FullLength_X));
1387  Position_LGRight.setY(0.0*cm);
1388  Position_LGRight.setZ(0.0*cm - LightGuide_FullThickness*(1 - redfr)/(4.0));
1389 // Rotation_LGRight.rotateY(-90.0*degree);
1390  Rotation_LGRight.rotateY(90.0*degree);
1391 // Rotation_LGRight.rotateZ(180.0*degree);
1392  G4Transform3D Transform_LGRight(Rotation_LGRight,Position_LGRight);
1393
1394
1395  LightGuide_LogicalLeft = new G4LogicalVolume(LeftGuide_Solid[4],
1396  LightGuide_Material,
1397  "LightGuide_LogicalLeft",
1398  0,0,0);
1399
1400
1401  LightGuide_PhysicalLeft = new G4PVPlacement(Transform_LGLeft,
1402  LightGuide_LogicalLeft,
1403  "LightGuide_PhysicalLeft",
1404  ActiveArea_Logical,
1405  false,0,
1406  pSurfChk);
1407
1408
1409  LightGuide_LogicalRight = new G4LogicalVolume(RightGuide_Solid[4],
1410  LightGuide_Material,
1411  "LightGuide_LogicalRight",
1412  0,0,0);
1413
1414
1415  LightGuide_PhysicalRight = new G4PVPlacement(Transform_LGRight,
1416  LightGuide_LogicalRight,
1417  "LightGuide_PhysicalRight",
1418  ActiveArea_Logical,
1419  false,0,
1420  pSurfChk);
1421
1422
1423  //******************************Face Mirrors***********************
1424
1425 // G4Trd* LGFaceMirror_Solid = new G4Trd("LGFaceMirror_Solid",
1426 // 0.1*mm,0.1*mm,
1427 // 0.5*LightGuide_FullWidth1,
1428 // 0.5*LightGuide_FullWidth2,
1429 // 0.5*LightGuide_FullLength -
1430 // 0.5*LightGuide_FullThickness*tan(ar)+
1431 // 0.5*LightGuide_FullThickness*(1 - redfr)*tan(ar));
1432
1433
1434 // Position_LGFaceMirrorLeft.setX(0.5*(QuartzBar_FullLength+LightGuide_FullLength)-
1435 // 0.5*LightGuide_FullThickness*tan(ar)+
1436 // 0.5*LightGuide_FullThickness*(1 - redfr)*tan(ar));
1437 // Position_LGFaceMirrorLeft.setY(0.0*cm);
1438 // Position_LGFaceMirrorLeft.setZ(-0.5*LightGuide_FullThickness - 0.1*mm);
1439 // Rotation_LGFaceMirrorLeft.rotateY(-90.0*degree);
1440 // G4Transform3D Transform_LGFMLeft(Rotation_LGFaceMirrorLeft,Position_LGFaceMirrorLeft);
1441
1442
1443 // mirror_logical[0] = new G4LogicalVolume(LGFaceMirror_Solid,
1444 // mirror_material,
1445 // "mirrorface_log1",
1446 // 0,0,0);
1447
1448 // mirror_physical[0] = new G4PVPlacement(Transform_LGFMLeft,
1449 // mirror_logical[0],
1450 // "mirrorface_physical1",
1451 // CerenkovContainer_Logical,
1452 // false,
1453 // 0, // copy number for left PMTContainer
1454 // pSurfChk);
1455
1456 //******************************Face Mirrors******************
1457
1458
1459 //******************************Edge Mirrors******************
1460
1461  G4Box* LGEdgeMirror_Solid = new G4Box("LGEdgeMirror_Solid",
1462  0.1*mm,0.5*LightGuide_FullWidth1,
1463  redfr*0.5*LightGuide_FullThickness/cos(ar));
1464
1465  Position_LGEdgeMirrorLeft.setX(1.5*GlueFilm_FullLength_X + QuartzBar_FullLength+LightGuide_FullLength+0.1*mm/cos(ar)-
1466  0.5*LightGuide_FullThickness*tan(ar)+
1467  0.5*LightGuide_FullThickness*(1 - redfr)*tan(ar));
1468  Position_LGEdgeMirrorLeft.setY(0.0*cm);
1469  Position_LGEdgeMirrorLeft.setZ(-0.5*LightGuide_FullThickness*(1-redfr));
1470  Rotation_LGEdgeMirrorLeft.rotateY(ad*degree);
1471  G4Transform3D Transform_LGEMLeft(Rotation_LGEdgeMirrorLeft,Position_LGEdgeMirrorLeft);
1472
1473
1474  mirror_logical[1] = new G4LogicalVolume(LGEdgeMirror_Solid,
1475  mirror_material,
1476  "mirrorface_log2",
1477  0,0,0);
1478
1479 // mirror_physical[1] = new G4PVPlacement(Transform_LGEMLeft,
1480 // mirror_logical[1],
1481 // "mirrorface_physical2",
1482 // ActiveArea_Logical,
1483 // false,
1484 // 0, // copy number for left PMTContainer
1485 // pSurfChk);
1486
1487  Position_LGEdgeMirrorRight.setX(-1.5*GlueFilm_FullLength_X-QuartzBar_FullLength-LightGuide_FullLength-0.1*mm/cos(ar)+
1488  0.5*LightGuide_FullThickness*tan(ar)-
1489  0.5*LightGuide_FullThickness*(1 - redfr)*tan(ar));
1490  Position_LGEdgeMirrorRight.setY(0.0*cm);
1491  Position_LGEdgeMirrorRight.setZ(-0.5*LightGuide_FullThickness*(1-redfr));
1492  Rotation_LGEdgeMirrorRight.rotateY(-ad*degree);
1493  G4Transform3D Transform_LGEMRight(Rotation_LGEdgeMirrorRight,Position_LGEdgeMirrorRight);
1494
1495
1496  mirror_logical[3] = new G4LogicalVolume(LGEdgeMirror_Solid,
1497  mirror_material,
1498  "mirrorface_log4",
1499  0,0,0);
1500
1501 // mirror_physical[3] = new G4PVPlacement(Transform_LGEMRight,
1502 // mirror_logical[3],
1503 // "mirrorface_physical4",
1504 // ActiveArea_Logical,
1505 // false,
1506 // 0,
1507 // pSurfChk);
1508
1509 //******************************Edge Mirrors**************************
1510 //********************************************************************
1511
1512
1513
1514 //*********************************************************
1515 //******************************Radiator*******************
1516
1517  G4double Radiator_FullWidth = 8.62*inch;
1518
1519  G4Box* RadiatorSolid = new G4Box("Radiator_Sol",
1520  QuartzBar_FullLength, // half X length required by Geant4
1521  0.5*Radiator_FullWidth, // 0.5*Frame_FullLength_Y // half Y length required by Geant4
1522  1.0*cm ); // half Z length required by Geant4
1523
1524  Radiator_Logical = new G4LogicalVolume(RadiatorSolid,
1525  Radiator_Material,
1526  "Radiator_Log",
1527  0,0,0);
1528
1529  G4ThreeVector Position_Radiator = G4ThreeVector(0, 0,-5.0*cm);//-2.0*cm);
1530
1531  Radiator_Physical = new G4PVPlacement(0,Position_Radiator + Container_Center,
1532  Radiator_Logical,
1533  "Radiator_Physical",
1534  CerenkovContainer_Logical,
1535  false,
1536  0,
1537  pSurfChk);
1538
1539 //******************************Radiator****************************
1540 //******************************************************************
1541
1542 //******************************PMT_PbShield*******************
1543
1544  // Each Pb brick is 8x4x2 [inch], each PMT has 2 Pb bricks, i.e. 8x8x2 [inch]
1545
1546  G4Box* PMT_PbShieldSolid = new G4Box("PMT_PbShield_Sol",
1547  0.5*8.0*inch, // half X length required by Geant4
1548  0.5*8.0*inch, // half Y length required by Geant4
1549  0.5*2.0*inch ); // half Z length required by Geant4
1550
1551  PMT_PbShield_Logical = new G4LogicalVolume(PMT_PbShieldSolid,
1552  PMT_PbShield_Material,
1553  "PMT_PbShield_Log",
1554  0,0,0);
1555
1556  G4ThreeVector Position_PMT_PbShield_Left = G4ThreeVector(-100.0*cm-4.0*inch, 0, -6.5*cm);
1557  G4ThreeVector Position_PMT_PbShield_Right = G4ThreeVector( 100.0*cm+4.0*inch, 0, -6.5*cm);
1558
1559  PMT_PbShield_Physical = new G4PVPlacement(0,Position_PMT_PbShield_Left + Container_Center,
1560  PMT_PbShield_Logical,
1561  "PMT_PbShield_Physical",
1562  CerenkovContainer_Logical,
1563  false,
1564  0,
1565  pSurfChk);
1566
1567  PMT_PbShield_Physical = new G4PVPlacement(0,Position_PMT_PbShield_Right + Container_Center,
1568  PMT_PbShield_Logical,
1569  "PMT_PbShield_Physical",
1570  CerenkovContainer_Logical,
1571  false,
1572  1,
1573  pSurfChk);
1574 //******************************Radiator****************************
1575
1576
1577  //-----------------------------------
1578  // define the PMTContainer
1579  //-----------------------------------
1580
1581  G4double thetaY = atan(LightGuide_FullThickness*(1 - redfr)/(LightGuide_FullLength));
1582  G4double Xoffs = 0.0*cm;//7.0*cm;
1583
1584  //Flat on guide face configuration
1585  G4double PMTContXShift = QuartzBar_FullLength + LightGuide_FullLength - 0.5*PMTEntranceWindow_Diameter - Xoffs;
1586  G4double PMTContYShift = 0.0;
1587  G4double PMTContZShift = 0.5*QuartzBar_FullThickness + 0.5*PMTContainer_FullLength_Z
1588  - (LightGuide_FullLength - 0.5*PMTEntranceWindow_Diameter-Xoffs)*tan(thetaY);
1589
1590  // relocation of the left Photon Detector Container
1591  Translation_PMTContainerLeft.setX(1.0*PMTContXShift);
1592  Translation_PMTContainerLeft.setY(1.0*PMTContYShift);
1593  Translation_PMTContainerLeft.setZ(1.0*PMTContZShift);
1594
1595 // //On guide edge configuration
1596 // Rotation_PMTContainerLeft.rotateY(90.0*degree);
1597
1598  //Flat on guide face configuration
1599  Rotation_PMTContainerLeft.rotateY(thetaY);
1600  G4Transform3D Transform3D_PMTContainerLeft(Rotation_PMTContainerLeft,
1601  Translation_PMTContainerLeft);
1602
1603  // relocation of the right Photon Detector Container
1604  Translation_PMTContainerRight.setX(-1.0*PMTContXShift);
1605  Translation_PMTContainerRight.setY(1.0*PMTContYShift);
1606  Translation_PMTContainerRight.setZ(1.0*PMTContZShift);
1607
1608 // //On guide edge configuration
1609 // Rotation_PMTContainerLeft.rotateY(-90.0*cm);
1610
1611  //Flat on guide face configuration
1612  Rotation_PMTContainerRight.rotateY(-thetaY);
1613  G4Transform3D Transform3D_PMTContainerRight(Rotation_PMTContainerRight,
1614  Translation_PMTContainerRight);
1615
1616
1617
1618  G4double PMTQuartzOpticalFilmZShift = 0.5*(PMTQuartzOpticalFilm_Thickness - PMTContainer_FullLength_Z);
1619
1620  // relocation of the PMTEntranceWindow
1621  Translation_PMTQuartzOpticalFilm.setX(0.0*cm);
1622  Translation_PMTQuartzOpticalFilm.setY(0.0*cm);
1623  Translation_PMTQuartzOpticalFilm.setZ(PMTQuartzOpticalFilmZShift);
1624
1625  //-------------------------------------------------------------------------------------
1626  // location and orientation of the PMT Entrance Window within the PMT Container
1627  //-------------------------------------------------------------------------------------
1628
1629  G4double PMTEntWindZShift = 0.5*(PMTEntranceWindow_Thickness - PMTContainer_FullLength_Z)+PMTQuartzOpticalFilm_Thickness;
1630
1631  // relocation of the PMTEntranceWindow
1632  Translation_PMTEntranceWindow.setX(0.0*cm);
1633  Translation_PMTEntranceWindow.setY(0.0*cm);
1634  Translation_PMTEntranceWindow.setZ(PMTEntWindZShift);
1635
1636  //-------------------------------------------------------------------------------------
1637  // location and orientation of the cathode WITHIN the PMT
1638  //-------------------------------------------------------------------------------------
1639
1640  G4double CathodeZShift = PMTEntranceWindow_Thickness + 0.5*(Cathode_Thickness - PMTContainer_FullLength_Z) + PMTQuartzOpticalFilm_Thickness;
1641
1642  // location of the Photon Detector relative to Photon Detector Container
1643  Translation_Cathode.setX(0.0*cm);
1644  Translation_Cathode.setY(0.0*cm);
1645  Translation_Cathode.setZ(CathodeZShift);
1646
1647
1648  // G4Box* PMTContainer_Solid = new G4Box("PMTContainer_Solid",
1649  // 0.5 * PMTContainer_FullLength_X, // half X
1650  // 0.5 * PMTContainer_FullLength_Y , // half Y
1651  // 0.5 * PMTContainer_FullLength_Z); // half Z
1652  G4Tubs* PMTContainer_Solid = new G4Tubs("PMTContainer_Solid",0.0*cm,
1653  0.5 * PMTContainer_Diameter,
1654  0.5 * PMTContainer_FullLength_Z,
1655  0.0*degree,360.0*degree);
1656
1657
1658  PMTContainer_Logical = new G4LogicalVolume(PMTContainer_Solid,
1659  PMTContainer_Material,
1660  "PMTContainer_Log",
1661  0,0,0);
1662
1663  // left side
1664  PMTContainer_PhysicalLeft = new G4PVPlacement(Transform3D_PMTContainerLeft,
1665  PMTContainer_Logical,
1666  "PMTContainer_Physical",
1667  ActiveArea_Logical,
1668  false,
1669  0, // copy number for left PMTContainer
1670  pSurfChk);
1671
1672  // right side
1673  PMTContainer_PhysicalRight = new G4PVPlacement(Transform3D_PMTContainerRight,
1674  PMTContainer_Logical,
1675  "PMTContainer_Physical",
1676  ActiveArea_Logical,
1677  false,
1678  1, // copy number for right PMTContainer
1679  pSurfChk);
1680
1681
1682  //----------------------------------------
1683  // define the glue or grease or cookie layer
1684  //----------------------------------------
1685
1686
1687  G4Tubs* PMTQuartzOpticalFilm_Solid = new G4Tubs("PMTQuartzOpticalFilm_Solid",0.0*cm,
1688  0.5*PMTQuartzOpticalFilm_Diameter,
1689  0.5*PMTQuartzOpticalFilm_Thickness,
1690  0.0*degree,360.0*degree);
1691
1692  PMTQuartzOpticalFilm_Logical = new G4LogicalVolume(PMTQuartzOpticalFilm_Solid,
1693  PMTQuartzOpticalFilm_Material,
1694  "PMTQuartzOpticalFilm_Log",
1695  0,0,0);
1696  PMTQuartzOpticalFilm_Physical = new G4PVPlacement(0,Translation_PMTQuartzOpticalFilm,
1697  PMTQuartzOpticalFilm_Logical,
1698  "PMTQuartzOpticalFilm_Physical",
1699  PMTContainer_Logical,
1700  false, 0, pSurfChk); // copy number for left photon detector
1701
1702
1703
1704  //----------------------------------------
1705  // define the PMTEntranceWindow
1706  //----------------------------------------
1707
1708  G4Tubs* PMTEntranceWindow_Solid = new G4Tubs("PMTEntranceWindow_Solid",0.0*cm,
1709  0.5*PMTEntranceWindow_Diameter,
1710  0.5*PMTEntranceWindow_Thickness,
1711  0.0*degree,360.0*degree);
1712
1713  PMTEntranceWindow_Logical = new G4LogicalVolume(PMTEntranceWindow_Solid,
1714  PMTEntranceWindow_Material,
1715  "PMTEntranceWindow_Log",
1716  0,0,0);
1717  PMTEntranceWindow_Physical = new G4PVPlacement(0,Translation_PMTEntranceWindow,
1718  PMTEntranceWindow_Logical,
1719  "PMTEntranceWindow_Physical",
1720  PMTContainer_Logical,
1721  false, 0, pSurfChk); // copy number for left photon detector
1722
1723  //---------------------------
1724  // define the Photon Detector
1725  //---------------------------
1726
1727  G4Tubs* Cathode_Solid = new G4Tubs("Cathode_Solid",0.0*cm,0.5*Cathode_Diameter,
1728  0.5*Cathode_Thickness,0.0*degree,360.0*degree);
1729
1730  Cathode_Logical = new G4LogicalVolume(Cathode_Solid,Cathode_Material,"Cathode_Log",0,0,0);
1731
1732  Cathode_Physical = new G4PVPlacement(0,Translation_Cathode,Cathode_Logical,"Cathode_Physical",PMTContainer_Logical,
1733  false, 0, pSurfChk); // copy number for left photon detector
1734
1735
1736
1737
1738
1739  //=============================================================================================
1740
1741
1742
1743
1744
1745  //=============================================================================================
1746  /*
1747  Position_CerenkovContainer = G4ThreeVector(Position_CerenkovContainer_X[g],
1748  Position_CerenkovContainer_Y[g],
1749  Position_CerenkovContainer_Z[g]);
1750
1751  // define Rotation matrix for Container orientated in MotherVolume
1752  Rotation_CerenkovContainer = new G4RotationMatrix();
1753  Rotation_CerenkovContainer -> rotateX(Tilting_Angle);
1754
1755  CerenkovContainer_Physical = new G4PVPlacement(Rotation_CerenkovContainer,
1756  Position_CerenkovContainer + Container_Center,
1757  "CerenkovContainer_Physical",
1758  CerenkovContainer_Logical,
1759  MotherVolume,
1760  false,
1761  0,
1762  pSurfChk);
1763  */
1764  //}
1765 //----------------------------------------------
1766
1767
1768  //============================================================================
1769  // place the 8 CerenkovMasterContainer_Physical into the physical MotherVolume
1770  //============================================================================
1771  //
1772  PlacePVCerenkovMasterContainer();
1773
1774
1775 // Setting Optical Properties
1776
1777  const G4int nEntries = 11;
1778  G4double PhotonEnergy[nEntries] = {
1779  1.54986*eV, //800.59 nm
1780  1.77127*eV, //700.51 nm
1781  2.06648*eV, //600.44 nm
1782  2.47978*eV, //500.37 nm
1783  2.8178*eV, //440.34 nm
1784  3.09973*eV, //400.29 nm
1785  3.5424*eV, //350.27 nm
1786  4.13297*eV, //300.22 nm
1787  4.95956*eV, //250.18 nm
1788  5.51063*eV, //225.16 nm
1789  5.90424*eV //210.15 nm
1790  };
1791
1792  G4double Reflectivity[nEntries];
1793  G4double mylambda;
1794  for (G4int kk= 0; kk < nEntries; kk++) {
1795  // Nevens empiric formular for the reflectivity
1796  // lamda = h*c/E
1797
1798  mylambda = (h_Planck*c_light/PhotonEnergy[kk])/nanometer;
1799  Reflectivity[kk] = 1.0 - 0.027*exp(-0.004608*mylambda);
1800  //Reflectivity[kk] = 1.0;
1801  };
1802
1803  G4OpticalSurface* QuartzBarLeft_OpticalSurface = new G4OpticalSurface("QuartzBarLeftOpticalSurface");
1804  G4OpticalSurface* QuartzBarRight_OpticalSurface = new G4OpticalSurface("QuartzBarRightOpticalSurface");
1805  G4OpticalSurface* LightGuideLeft_OpticalSurface = new G4OpticalSurface("LightGuideLeftOpticalSurface");
1806  G4OpticalSurface* LightGuideRight_OpticalSurface = new G4OpticalSurface("LightGuideRightOpticalSurface");
1807
1808  G4OpticalSurface* GlueFilmCenter_OpticalSurface = new G4OpticalSurface("GlueFilmCenterOpticalSurface");
1809  G4OpticalSurface* GlueFilmLeft_OpticalSurface = new G4OpticalSurface("GlueFilmLeftOpticalSurface");
1810  G4OpticalSurface* GlueFilmRight_OpticalSurface = new G4OpticalSurface("GlueFilmRightOpticalSurface");
1811
1812
1813 /* wdc: commented out unused objects
1814
1815  G4LogicalBorderSurface* QuartzBarLeft_BorderSurface
1816  = new G4LogicalBorderSurface("QuartzBarLeft_BorderSurface",
1817  QuartzBar_PhysicalLeft,
1818  ActiveArea_Physical,
1819  QuartzBarLeft_OpticalSurface);
1820
1821  G4LogicalBorderSurface* QuartzBarRight_BorderSurface
1822  = new G4LogicalBorderSurface("QuartzBarRight_BorderSurface",
1823  QuartzBar_PhysicalRight,
1824  ActiveArea_Physical,
1825  QuartzBarRight_OpticalSurface);
1826
1827  G4LogicalBorderSurface* LightGuideLeft_BorderSurface
1828  = new G4LogicalBorderSurface("LightGuideLeft_BorderSurface",
1829  LightGuide_PhysicalLeft,
1830  ActiveArea_Physical,
1831  LightGuideLeft_OpticalSurface);
1832
1833  G4LogicalBorderSurface* LightGuideRight_BorderSurface
1834  = new G4LogicalBorderSurface("LightGuideRight_BorderSurface",
1835  LightGuide_PhysicalRight,
1836  ActiveArea_Physical,
1837  LightGuideRight_OpticalSurface);
1838
1839  G4LogicalBorderSurface* GlueFilmRight_BorderSurface
1840  = new G4LogicalBorderSurface("GlueFilmRight_BorderSurface",
1841  QuartzGlue_PhysicalRight,
1842  ActiveArea_Physical,
1843  GlueFilmRight_OpticalSurface);
1844
1845  G4LogicalBorderSurface* GlueFilmCenter_BorderSurface
1846  = new G4LogicalBorderSurface("GlueFilmCenter_BorderSurface",
1847  QuartzGlue_PhysicalCenter,
1848  ActiveArea_Physical,
1849  GlueFilmCenter_OpticalSurface);
1850
1851  G4LogicalBorderSurface* GlueFilmLeft_BorderSurface
1852  = new G4LogicalBorderSurface("GlueFilmLeft_BorderSurface",
1853  QuartzGlue_PhysicalLeft,
1854  ActiveArea_Physical,
1855  GlueFilmLeft_OpticalSurface);
1856 */
1857
1858 // boundary optical properties between pad and quartz
1859
1860  G4OpticalSurface* LeftEndPad_Quartz_OpticalSurface = new G4OpticalSurface("LeftEndPadQuartzOpticalSurface");
1861  G4OpticalSurface* RightEndPad_Quartz_OpticalSurface = new G4OpticalSurface("RightEndPadQuartzOpticalSurface");
1862  G4OpticalSurface* SidePad_LeftLightGuide_OpticalSurface
1863  = new G4OpticalSurface("SidePadLeftLightGuideOpticalSurface");
1864  G4OpticalSurface* SidePad_RightLightGuide_OpticalSurface
1865  = new G4OpticalSurface("SidePadRightLightGuideOpticalSurface");
1866  G4OpticalSurface* SidePad_QuartzBarLeft_OpticalSurface
1867  = new G4OpticalSurface("SidePadQuartzBarLeftOpticalSurface");
1868  G4OpticalSurface* SidePad_QuartzBarRight_OpticalSurface
1869  = new G4OpticalSurface("SidePadQuartzBarRightOpticalSurface");
1870
1871  for(size_t i=0; i<EndBracketPad_Physical.size();i++) {
1872
1873 /* wdc: commented out unused objects
1874
1875  //G4LogicalBorderSurface* LeftEndPad_Quartz_BorderSurface =
1876  new G4LogicalBorderSurface("LeftEndPad_Quartz_BS",
1877  LightGuide_PhysicalLeft,
1878  EndBracketPad_Physical[i],
1879  LeftEndPad_Quartz_OpticalSurface);
1880
1881  //G4LogicalBorderSurface* RightEndPad_Quartz_BorderSurface =
1882  new G4LogicalBorderSurface("RightEndPad_Quartz_BS",
1883  LightGuide_PhysicalRight,
1884  EndBracketPad_Physical[i],
1885  RightEndPad_Quartz_OpticalSurface);
1886 */
1887  }
1888
1889  for(size_t i=0; i<SideBracketPad_Physical.size();i++) {
1890
1891 /* wdc: commented out unused objects
1892
1893  //G4LogicalBorderSurface* SidePad_LeftLightGuide_BorderSurface =
1894  new G4LogicalBorderSurface("SidePad_LeftLightGuide_BS",
1895  LightGuide_PhysicalLeft,
1896  SideBracketPad_Physical[i],
1897  SidePad_LeftLightGuide_OpticalSurface);
1898
1899  //G4LogicalBorderSurface* SidePad_RightLightGuide_BorderSurface =
1900  new G4LogicalBorderSurface("SidePad_RightLightGuide_BS",
1901  LightGuide_PhysicalRight,
1902  SideBracketPad_Physical[i],
1903  SidePad_RightLightGuide_OpticalSurface);
1904
1905  //G4LogicalBorderSurface* SidePad_QuartzBarLeft_BorderSurface =
1906  new G4LogicalBorderSurface("SidePad_QuartzBarLeft_BS",
1907  QuartzBar_PhysicalLeft,
1908  SideBracketPad_Physical[i],
1909  SidePad_QuartzBarLeft_OpticalSurface);
1910
1911  //G4LogicalBorderSurface* SidePad_QuartzBarRight_BorderSurface =
1912  new G4LogicalBorderSurface("SidePad_QuartzBarRight_BS",
1913  QuartzBar_PhysicalRight,
1914  SideBracketPad_Physical[i],
1915  SidePad_QuartzBarRight_OpticalSurface);
1916
1917 */
1918  }
1919
1920  QuartzBarLeft_OpticalSurface->SetType(dielectric_dielectric);
1921  QuartzBarLeft_OpticalSurface->SetFinish(polished);
1922  QuartzBarLeft_OpticalSurface->SetPolish(0.997);
1923  QuartzBarLeft_OpticalSurface->SetModel(glisur);
1924
1925  QuartzBarRight_OpticalSurface->SetType(dielectric_dielectric);
1926  QuartzBarRight_OpticalSurface->SetFinish(polished);
1927  QuartzBarRight_OpticalSurface->SetPolish(0.997);
1928  QuartzBarRight_OpticalSurface->SetModel(glisur);
1929
1930  LightGuideLeft_OpticalSurface->SetType(dielectric_dielectric);
1931  LightGuideLeft_OpticalSurface->SetFinish(polished);
1932  LightGuideLeft_OpticalSurface->SetPolish(0.997);
1933  LightGuideLeft_OpticalSurface->SetModel(glisur);
1934
1935  LightGuideRight_OpticalSurface->SetType(dielectric_dielectric);
1936  LightGuideRight_OpticalSurface->SetFinish(polished);
1937  LightGuideRight_OpticalSurface->SetPolish(0.997);
1938  LightGuideRight_OpticalSurface->SetModel(glisur);
1939
1940  GlueFilmLeft_OpticalSurface->SetType(dielectric_dielectric);
1941  GlueFilmLeft_OpticalSurface->SetFinish(polished);
1942  GlueFilmLeft_OpticalSurface->SetPolish(0.9);
1943  GlueFilmLeft_OpticalSurface->SetModel(glisur);
1944
1945  GlueFilmCenter_OpticalSurface->SetType(dielectric_dielectric);
1946  GlueFilmCenter_OpticalSurface->SetFinish(polished);
1947  GlueFilmCenter_OpticalSurface->SetPolish(0.9);
1948  GlueFilmCenter_OpticalSurface->SetModel(glisur);
1949
1950  GlueFilmRight_OpticalSurface->SetType(dielectric_dielectric);
1951  GlueFilmRight_OpticalSurface->SetFinish(polished);
1952  GlueFilmRight_OpticalSurface->SetPolish(0.9);
1953  GlueFilmRight_OpticalSurface->SetModel(glisur);
1954
1955
1956 //##############################################
1957
1958  G4OpticalSurface* BracketPad_OpticalSurface =
1959  new G4OpticalSurface("BracketPad_Optical_Surface");
1960  BracketPad_OpticalSurface->SetType(dielectric_metal);
1961  BracketPad_OpticalSurface->SetFinish(ground);
1962  BracketPad_OpticalSurface->SetModel(glisur);
1963  new G4LogicalSkinSurface("SideBracketPad_SkinSurface",SideBracketPad_Logical,BracketPad_OpticalSurface);
1964  new G4LogicalSkinSurface("EndBracketPad_SkinSurface",EndBracketPad_Logical,BracketPad_OpticalSurface);
1965
1966  G4double Pad_Reflectivity[nEntries]={0.,0.,0.,0.,0.,0.,0.,0.,0.,0.,0.};
1967  G4MaterialPropertiesTable *BracketPad_MPT = new G4MaterialPropertiesTable();
1968  BracketPad_MPT->AddProperty("REFLECTIVITY",PhotonEnergy,Pad_Reflectivity,nEntries);
1969  BracketPad_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
1970
1971  LeftEndPad_Quartz_OpticalSurface->SetType(dielectric_metal);
1972  LeftEndPad_Quartz_OpticalSurface->SetFinish(polished);
1973  LeftEndPad_Quartz_OpticalSurface->SetPolish(0.9);
1974  LeftEndPad_Quartz_OpticalSurface->SetModel(glisur);
1975  LeftEndPad_Quartz_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
1976
1977  RightEndPad_Quartz_OpticalSurface->SetType(dielectric_metal);
1978  RightEndPad_Quartz_OpticalSurface->SetFinish(polished);
1979  RightEndPad_Quartz_OpticalSurface->SetPolish(0.9);
1980  RightEndPad_Quartz_OpticalSurface->SetModel(glisur);
1981  RightEndPad_Quartz_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
1982
1983  SidePad_LeftLightGuide_OpticalSurface->SetType(dielectric_metal);
1984  SidePad_LeftLightGuide_OpticalSurface->SetFinish(polished);
1985  SidePad_LeftLightGuide_OpticalSurface->SetPolish(0.9);
1986  SidePad_LeftLightGuide_OpticalSurface->SetModel(glisur);
1987  SidePad_LeftLightGuide_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
1988
1989  SidePad_RightLightGuide_OpticalSurface->SetType(dielectric_metal);
1990  SidePad_RightLightGuide_OpticalSurface->SetFinish(polished);
1991  SidePad_RightLightGuide_OpticalSurface->SetPolish(0.9);
1992  SidePad_RightLightGuide_OpticalSurface->SetModel(glisur);
1993  SidePad_RightLightGuide_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
1994
1995  SidePad_QuartzBarLeft_OpticalSurface->SetType(dielectric_metal);
1996  SidePad_QuartzBarLeft_OpticalSurface->SetFinish(polished);
1997  SidePad_QuartzBarLeft_OpticalSurface->SetPolish(0.9);
1998  SidePad_QuartzBarLeft_OpticalSurface->SetModel(glisur);
1999  SidePad_QuartzBarLeft_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
2000
2001  SidePad_QuartzBarRight_OpticalSurface->SetType(dielectric_metal);
2002  SidePad_QuartzBarRight_OpticalSurface->SetFinish(polished);
2003  SidePad_QuartzBarRight_OpticalSurface->SetPolish(0.9);
2004  SidePad_QuartzBarRight_OpticalSurface->SetModel(glisur);
2005  SidePad_QuartzBarRight_OpticalSurface->SetMaterialPropertiesTable(BracketPad_MPT);
2006
2007 //#####################################################3
2008
2009  G4MaterialPropertiesTable *quartzST = new G4MaterialPropertiesTable();
2010  quartzST->AddProperty("REFLECTIVITY", PhotonEnergy , Reflectivity, nEntries);
2011  QuartzBarLeft_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2012  QuartzBarRight_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2013  LightGuideLeft_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2014  LightGuideRight_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2015  GlueFilmLeft_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2016  GlueFilmCenter_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2017  GlueFilmRight_OpticalSurface->SetMaterialPropertiesTable(quartzST);
2018
2019  G4OpticalSurface* ActiveArea_OpticalSurface = new G4OpticalSurface("ActiveAreaOpticalSurface");
2020 // G4LogicalBorderSurface* ActiveArea_BorderSurface
2021 // = new G4LogicalBorderSurface("ActiveArea_BorderSurface",
2022 // ActiveArea_Physical,
2023 // CerenkovMasterContainer_Physical,
2024 // ActiveArea_OpticalSurface);
2025
2026  ActiveArea_OpticalSurface->SetFinish(groundbackpainted); //new for wrapping test
2027 // ActiveArea_OpticalSurface->SetPolish(0.0); //new for wrapping test
2028 // ActiveArea_OpticalSurface->SetModel(glisur); //new for wrapping test
2029  ActiveArea_OpticalSurface->SetModel(unified); //new for wrapping test
2030  ActiveArea_OpticalSurface->SetSigmaAlpha(0.25); //new for wrapping test
2031
2032  // for wrapping test
2033  G4double RefractiveIndex_Air[nEntries] = {1.0,1.0,1.0,1.0,1.0,1.0,1.0,1.0,1.0,1.0,1.0};
2034  G4double MilliPoreRefl[nEntries] = {0.94,0.94,0.945,0.945,0.95,0.95,0.945,0.91,0.85,0.80,0.80};
2035  G4double specularlobe[nEntries] = {0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1};
2036  G4double specularspike[nEntries] = {0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1};
2037  G4double backscatter[nEntries] = {0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1,0.1};
2038
2039  G4MaterialPropertiesTable *myST = new G4MaterialPropertiesTable();
2040
2041  myST->AddProperty("RINDEX", PhotonEnergy , RefractiveIndex_Air, nEntries); //new for wrapping test
2042  myST->AddProperty("REFLECTIVITY", PhotonEnergy , MilliPoreRefl, nEntries); //new for wrapping test
2043  myST->AddProperty("SPECULARLOBECONSTANT", PhotonEnergy ,specularlobe,nEntries); //new for wrapping test
2044  myST->AddProperty("SPECULARSPIKECONSTANT",PhotonEnergy,specularspike,nEntries); //new for wrapping test
2045  myST->AddProperty("BACKSCATTERCONSTANT",PhotonEnergy,backscatter,nEntries); //new for wrapping test
2046 // myST->AddProperty("ABSLENGTH", PhotonEnergy, AbsorptionCoeff_Air, nEntries); //new for wrapping test
2047
2048  ActiveArea_OpticalSurface->SetMaterialPropertiesTable(myST);
2049
2050  // Set Optical Properties for the Detector Windows
2051  G4OpticalSurface* Window_OpticalSurface = new G4OpticalSurface("Window_Optical_Surface");
2052  Window_OpticalSurface->SetType(dielectric_metal);
2053  Window_OpticalSurface->SetFinish(ground);
2054  Window_OpticalSurface->SetModel(glisur);
2055  new G4LogicalSkinSurface("FrontWindow_SkinSurface",FrontWindow_Logical,Window_OpticalSurface);
2056  new G4LogicalSkinSurface("BackWindow_SkinSurface",BackWindow_Logical,Window_OpticalSurface);
2057
2058  G4double Tyvek_Reflectivity[nEntries]={0.95,0.95,0.95,0.95,0.95,0.95,0.95,0.90,0.90,0.85,0.85};
2059  G4MaterialPropertiesTable *Window_MPT = new G4MaterialPropertiesTable();
2060  Window_MPT->AddProperty("REFLECTIVITY",PhotonEnergy,Tyvek_Reflectivity,nEntries);
2061  Window_OpticalSurface->SetMaterialPropertiesTable(Window_MPT);
2062
2063 // set bracket optical properties
2064  G4OpticalSurface* Bracket_OpticalSurface =
2065  new G4OpticalSurface("Bracket_Optical_Surface");
2066  Bracket_OpticalSurface->SetType(dielectric_metal);
2067  Bracket_OpticalSurface->SetFinish(ground);
2068  Bracket_OpticalSurface->SetModel(glisur);
2069  new G4LogicalSkinSurface("SideBracket_SkinSurface",SideBracket_Logical,Bracket_OpticalSurface);
2070  new G4LogicalSkinSurface("EndBracket_SkinSurface",EndBracket_Logical,Bracket_OpticalSurface);
2071
2072  G4double Bracket_Reflectivity[nEntries]={0.8,0.8,0.8,0.8,0.8,0.8,0.8,0.8,0.8,0.8,0.8};
2073  G4MaterialPropertiesTable *Bracket_MPT = new G4MaterialPropertiesTable();
2074  Bracket_MPT->AddProperty("REFLECTIVITY",PhotonEnergy,Bracket_Reflectivity,nEntries);
2075  Bracket_OpticalSurface->SetMaterialPropertiesTable(Bracket_MPT);
2076
2077
2078  //Setting Skin Optical Properties for GlueFilm
2079  G4OpticalSurface* GlueFilm_OpticalSurface = new G4OpticalSurface("GlueFilmOpticalSurface");
2080  GlueFilm_OpticalSurface->SetType(dielectric_dielectric);
2081  GlueFilm_OpticalSurface->SetFinish(polished);
2082  GlueFilm_OpticalSurface->SetPolish(0.9);
2083  GlueFilm_OpticalSurface->SetModel(glisur);
2084  new G4LogicalSkinSurface("GlueFilm_SkinSurface",QuartzGlue_Logical,GlueFilm_OpticalSurface);
2085
2086  //Setting the Optical Properties of PMTs
2087
2088  // peiqing, Dec. 20, 2011
2089  // if QE is processed in EventAction, set it to 100% here
2090  G4double Photocathode_Efficiency[nEntries]={0.0080, //800.59 nm
2091  0.0298, //700.51 nm
2092  0.0638, //600.44 nm
2093  0.1240, //500.37 nm
2094  0.1670, //440.34 nm
2095  0.1770, //400.29 nm
2096  0.1800, //350.27 nm
2097  0.2110, //300.22 nm
2098  0.1780, //250.18 nm
2099  0.0890, //225.16 nm
2100  0.0355 //210.15 nm
2101  };
2102
2103 // G4double Photocathode_Efficiency[nEntries]={1, //800.59 nm
2104 // 1, //700.51 nm
2105 // 1, //600.44 nm
2106 // 1, //500.37 nm
2107 // 1, //440.34 nm
2108 // 1, //400.29 nm
2109 // 1, //350.27 nm
2110 // 1, //300.22 nm
2111 // 1, //250.18 nm
2112 // 1, //225.16 nm
2113 // 1 //210.15 nm
2114 // };
2115
2116 //S20 reflectance taken from "Optics Communications, issue 180, 2000. p89–102"
2117 //average of 40 degree incident angle assumed
2118 ////data below 400 nm, taken from //http://www.photek.com/support/Papers/
2119 //Experimental%20data%20on%20the%20reflection%20and%20transmission%20spectral%20response%20of%20photocathodes.pdf
2120  G4double Photocathode_Reflectivity[nEntries]={
2121  0.25, //800 nm
2122  0.25, //700 nm
2123  0.25, //600 nm
2124  0.25, //500 nm
2125  0.25, //440 nm
2126  0.25, //400 nm
2127  0.25, //350 nm
2128  0.25, //300 nm
2129  0.25, //250 nm
2130  0.25, //225 nm
2131  0.25 //210 nm
2132  };
2133
2134  G4OpticalSurface* Photocathode_OpticalSurface = new G4OpticalSurface("Photocathode_OS");
2135  Photocathode_OpticalSurface ->SetType(dielectric_metal);
2136  Photocathode_OpticalSurface ->SetFinish(polished);
2137  Photocathode_OpticalSurface ->SetModel(glisur);
2138
2139  G4MaterialPropertiesTable* Photocathode_MPT = new G4MaterialPropertiesTable();
2140  Photocathode_MPT->AddProperty("REFLECTIVITY", PhotonEnergy, Photocathode_Reflectivity,nEntries);
2141  Photocathode_MPT->AddProperty("EFFICIENCY", PhotonEnergy, Photocathode_Efficiency,nEntries);
2142  Photocathode_OpticalSurface ->SetMaterialPropertiesTable(Photocathode_MPT);
2143
2144  new G4LogicalBorderSurface("PMT_BorderSurface",
2145  PMTEntranceWindow_Physical,
2146  Cathode_Physical,
2147  Photocathode_OpticalSurface);
2148
2149  // Setting Sensitive detectors
2150  G4SDManager* SDman = G4SDManager::GetSDMpointer();
2151
2152  CerenkovDetectorSD = new QweakSimCerenkov_DetectorSD("/CerenkovDetectorSD");
2153  SDman->AddNewDetector(CerenkovDetectorSD);
2154  ActiveArea_Logical->SetSensitiveDetector(CerenkovDetectorSD);
2155
2156  CerenkovRadiatorSD = new QweakSimCerenkov_RadiatorSD("/CerenkovRadiatorSD");
2157  SDman->AddNewDetector(CerenkovRadiatorSD);
2158  Radiator_Logical->SetSensitiveDetector(CerenkovRadiatorSD);
2159
2160  CerenkovDetector_PMTSD = new QweakSimCerenkov_PMTSD("/CerenkovPMTSD",myUserInfo);
2161  SDman->AddNewDetector(CerenkovDetector_PMTSD);
2162  Cathode_Logical->SetSensitiveDetector(CerenkovDetector_PMTSD);
2163
2164
2165  // Setting Vis Attributes
2166  G4cout << G4endl << "###### QweakSimCerenkovDetector: Setting Vis Attributes " << G4endl << G4endl;
2167
2168  G4Colour orange ( 255/255., 127/255., 0/255.);
2169  G4Colour blue ( 0/255., 0/255., 255/255.);
2170  G4Colour magenta ( 255/255., 0/255., 255/255.);
2171  G4Colour grey ( 127/255., 127/255., 127/255.);
2172  G4Colour lightblue ( 139/255., 208/255., 255/255.);
2173  G4Colour lightorange ( 255/255., 189/255., 165/255.);
2174  G4Colour khaki3 ( 205/255., 198/255., 115/255.);
2175  G4Colour brown (178/255., 102/255., 26/255.);
2176  G4Colour darkbrown (100/255., 50/255., 10/255.);
2177
2178 //------------------------------------------
2179 // Visual Attributes for: Radiator
2180 //------------------------------------------
2181  G4VisAttributes* RadiatorVisAtt = new G4VisAttributes(lightblue);
2182  RadiatorVisAtt->SetVisibility(true);
2183  Radiator_Logical->SetVisAttributes(RadiatorVisAtt);
2184
2185  G4VisAttributes* PMT_PbShieldVisAtt = new G4VisAttributes(blue);
2186  PMT_PbShieldVisAtt->SetVisibility(true);
2187  PMT_PbShield_Logical->SetVisAttributes(PMT_PbShieldVisAtt);
2188 //------------------------------------------
2189 // Visual Attributes for: CerenkovContainer
2190 //------------------------------------------
2191  G4VisAttributes* CerenkovContainerVisAtt = new G4VisAttributes(blue);
2192  CerenkovContainerVisAtt->SetVisibility(false);
2193 //CerenkovContainerVisAtt->SetVisibility(true);
2194 //CerenkovContainerVisAtt->SetForceWireframe(true);
2195 //CerenkovContainerVisAtt->SetForceSolid(true);
2196  CerenkovContainer_Logical->SetVisAttributes(CerenkovContainerVisAtt);
2197  ActiveArea_Logical->SetVisAttributes(CerenkovContainerVisAtt);
2198
2199 //Visual Attributes for: Exo-Skelton
2200  G4VisAttributes* ExoSkeltonFrameVisAtt = new G4VisAttributes(darkbrown);
2201  ExoSkeltonFrameVisAtt->SetVisibility(true);
2202 //FrameVisAtt->SetForceWireframe(true);
2203 //FrameVisAtt->SetForceSolid(true);
2204  ExoSkeltonFrame_Logical->SetVisAttributes(ExoSkeltonFrameVisAtt);
2205
2206 //------------------------------------------
2207 // Visual Attributes for: Detector Housing
2208 //------------------------------------------
2209  G4VisAttributes* FrameVisAtt = new G4VisAttributes(grey);
2210  FrameVisAtt->SetVisibility(true);
2211 //FrameVisAtt->SetForceWireframe(true);
2212 //FrameVisAtt->SetForceSolid(true);
2213  Frame_Logical->SetVisAttributes(FrameVisAtt);
2214
2215 //------------------------------------------
2216 // Visual Attributes for: Side Brackets
2217 //------------------------------------------
2218  G4VisAttributes* SideBracketVisAtt = new G4VisAttributes(blue);
2219  SideBracketVisAtt->SetVisibility(true);
2220 //SideBracketVisAtt->SetForceWireframe(true);
2221 //SideBracketVisAtt->SetForceSolid(true);
2222  SideBracket_Logical->SetVisAttributes(SideBracketVisAtt);
2223
2224 //------------------------------------------
2225 // Visual Attributes for: End Brackets
2226 //------------------------------------------
2227  G4VisAttributes* EndBracketVisAtt = new G4VisAttributes(blue);
2228  EndBracketVisAtt->SetVisibility(true);
2229 //EndBracketVisAtt->SetForceWireframe(true);
2230 //EndBracketVisAtt->SetForceSolid(true);
2231  EndBracket_Logical->SetVisAttributes(EndBracketVisAtt);
2232
2233 //------------------------------------------
2234 // Visual Attributes for: Side Bracket Pads
2235 //------------------------------------------
2236  G4VisAttributes* SideBracketPadVisAtt = new G4VisAttributes(brown);
2237  SideBracketPadVisAtt->SetVisibility(true);
2238 //SideBracketPadVisAtt->SetForceWireframe(true);
2239  SideBracketPadVisAtt->SetForceSolid(true);
2240  SideBracketPad_Logical->SetVisAttributes(SideBracketPadVisAtt);
2241
2242 //------------------------------------------
2243 // Visual Attributes for: End Bracket Pads
2244 //------------------------------------------
2245  G4VisAttributes* EndBracketPadVisAtt = new G4VisAttributes(brown);
2246  EndBracketPadVisAtt->SetVisibility(true);
2247 //EndBracketPadVisAtt->SetForceWireframe(true);
2248 EndBracketPadVisAtt->SetForceSolid(true);
2249  EndBracketPad_Logical->SetVisAttributes(EndBracketPadVisAtt);
2250
2251
2252 //------------------------------------------
2253 // Visual Attributes for: Detector Window Clip
2254 //------------------------------------------
2255  G4VisAttributes* ClipVisAtt = new G4VisAttributes(lightorange);
2256  ClipVisAtt->SetVisibility(true);
2257 //ClipVisAtt->SetForceWireframe(true);
2258 //ClipVisAtt->SetForceSolid(true);
2259  FrontClip_Logical->SetVisAttributes(ClipVisAtt);
2260  BackClip_Logical->SetVisAttributes(ClipVisAtt);
2261
2262 //-----------------------------------------
2263 // Visual Attributes for: CerenkovDetector
2264 //-----------------------------------------
2265  G4VisAttributes* CerenkovDetectorVisAtt = new G4VisAttributes(orange);
2266  CerenkovDetectorVisAtt->SetVisibility(true);
2267 // Needed for the correct visualization using Coin3D
2268 //CerenkovDetectorVisAtt->SetForceSolid(true);
2269  CerenkovDetectorVisAtt->SetForceWireframe(true);
2270 // ActiveArea_Logical->SetVisAttributes(CerenkovDetectorVisAtt);
2271  QuartzBar_LogicalLeft->SetVisAttributes(CerenkovDetectorVisAtt);
2272  QuartzBar_LogicalRight->SetVisAttributes(CerenkovDetectorVisAtt);
2273  LightGuide_LogicalLeft->SetVisAttributes(CerenkovDetectorVisAtt);
2274  LightGuide_LogicalRight->SetVisAttributes(CerenkovDetectorVisAtt);
2275  QuartzGlue_Logical->SetVisAttributes(CerenkovDetectorVisAtt);
2276
2277 //------------------------------------------------
2278 // Visual Attributes for: PMTContainer
2279 //------------------------------------------------
2280  G4VisAttributes* PMTContainerVisAtt = new G4VisAttributes(blue);
2281  PMTContainerVisAtt->SetVisibility(true);
2282  PMTContainerVisAtt->SetForceWireframe(true);
2283 //PMTContainerVisAtt->SetForceSolid(true);
2284  PMTContainer_Logical->SetVisAttributes(PMTContainerVisAtt);
2285
2286 //-----------------------------------------------------
2287 // Visual Attributes for: PMTEntranceWindow
2288 //-----------------------------------------------------
2289  G4VisAttributes* PMTEntranceWindowVisAtt = new G4VisAttributes(grey);
2290  PMTEntranceWindowVisAtt->SetVisibility(true);
2291 //PMTEntranceWindowVisAtt->SetForceWireframe(true);
2292  PMTEntranceWindowVisAtt->SetForceSolid(true);
2293  PMTEntranceWindow_Logical->SetVisAttributes(PMTEntranceWindowVisAtt);
2294
2295 //---------------------------------------
2296 // Visual Attributes for: PMT
2297 //---------------------------------------
2298  G4VisAttributes* PMTVisAtt = new G4VisAttributes(magenta);
2299  PMTVisAtt->SetVisibility(true);
2300 //PMTVisAtt->SetForceWireframe(true);
2301  PMTVisAtt->SetForceSolid(true);
2302  Cathode_Logical->SetVisAttributes(PMTVisAtt);
2303
2304  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::ConstructComponent() " << G4endl << G4endl;
2305
2306 } // end of QweakSimCerenkovDetector::ConstructComponent()
QweakSimCerenkovDetector::Rotation_EndBracket
std::vector< G4RotationMatrix * > Rotation_EndBracket
Definition: QweakSimCerenkovDetector.hh:77
QweakSimCerenkovDetector::LeftGuide_Solid
std::vector< G4SubtractionSolid * > LeftGuide_Solid
Definition: QweakSimCerenkovDetector.hh:298
QweakSimCerenkovDetector::CerenkovRadiatorSD
G4VSensitiveDetector * CerenkovRadiatorSD
Definition: QweakSimCerenkovDetector.hh:376
QweakSimCerenkovDetector::PMTHousingLidL_Physical
G4VPhysicalVolume * PMTHousingLidL_Physical
Definition: QweakSimCerenkovDetector.hh:176
QweakSimCerenkovDetector::Position_SideBracket
std::vector< G4ThreeVector > Position_SideBracket
Definition: QweakSimCerenkovDetector.hh:75
QweakSimCerenkovDetector::Rotation_SideBracketPad
std::vector< G4RotationMatrix * > Rotation_SideBracketPad
Definition: QweakSimCerenkovDetector.hh:80
QweakSimCerenkovDetector::SquareFlangeSeal_Logical
G4LogicalVolume * SquareFlangeSeal_Logical
Definition: QweakSimCerenkovDetector.hh:162
QweakSimCerenkovDetector::SquareFlangeSealL_Physical
G4VPhysicalVolume * SquareFlangeSealL_Physical
Definition: QweakSimCerenkovDetector.hh:164
QweakSimCerenkovDetector::PMTEntranceWindow_Logical
G4LogicalVolume * PMTEntranceWindow_Logical
Definition: QweakSimCerenkovDetector.hh:130
QweakSimCerenkovDetector::CrossBarR_Physical
G4VPhysicalVolume * CrossBarR_Physical
Definition: QweakSimCerenkovDetector.hh:143
QweakSimCerenkov_RadiatorSD
Storing hit information of the Cerenkov radiator.
Definition: QweakSimCerenkov_RadiatorSD.hh:15
QweakSimCerenkovDetector::myUserInfo
QweakSimUserInformation * myUserInfo
Definition: QweakSimCerenkovDetector.hh:58
QweakSimCerenkovDetector::PMTHousingFlangeL_Physical
G4VPhysicalVolume * PMTHousingFlangeL_Physical
Definition: QweakSimCerenkovDetector.hh:172
QweakSimCerenkovDetector::PMTHousingFlange_Logical
G4LogicalVolume * PMTHousingFlange_Logical
Definition: QweakSimCerenkovDetector.hh:170
QweakSimCerenkovDetector::QuartzGlue_PhysicalCenter
G4VPhysicalVolume * QuartzGlue_PhysicalCenter
Definition: QweakSimCerenkovDetector.hh:109
QweakSimCerenkovDetector::PMTHousingWallL_Physical
G4VPhysicalVolume * PMTHousingWallL_Physical
Definition: QweakSimCerenkovDetector.hh:168
QweakSimCerenkovDetector::QuartzBar_PhysicalLeft
G4VPhysicalVolume * QuartzBar_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:97
QweakSimCerenkovDetector::ActiveArea_Physical
G4VPhysicalVolume * ActiveArea_Physical
Definition: QweakSimCerenkovDetector.hh:92
QweakSimCerenkovDetector::CrossBarL_Physical
G4VPhysicalVolume * CrossBarL_Physical
Definition: QweakSimCerenkovDetector.hh:144
pSurfChk
static const G4bool pSurfChk
Definition: QweakSimSolids.hh:43
QweakSimCerenkovDetector::CerenkovContainer_Logical
G4LogicalVolume * CerenkovContainer_Logical
Definition: QweakSimCerenkovDetector.hh:87
QweakSimCerenkovDetector::CerenkovDetectorSD
G4VSensitiveDetector * CerenkovDetectorSD
Definition: QweakSimCerenkovDetector.hh:375
QweakSimCerenkovDetector::Position_EndBracket
std::vector< G4ThreeVector > Position_EndBracket
Definition: QweakSimCerenkovDetector.hh:78
QweakSimCerenkovDetector::CerenkovDetector_PMTSD
G4VSensitiveDetector * CerenkovDetector_PMTSD
Definition: QweakSimCerenkovDetector.hh:377
QweakSimCerenkovDetector::EndBracket_Physical
std::vector< G4VPhysicalVolume * > EndBracket_Physical
Definition: QweakSimCerenkovDetector.hh:182
QweakSimCerenkovDetector::Rotation_EndBracketPad
std::vector< G4RotationMatrix * > Rotation_EndBracketPad
Definition: QweakSimCerenkovDetector.hh:83
QweakSimCerenkovDetector::SideBracket_Physical
std::vector< G4VPhysicalVolume * > SideBracket_Physical
Definition: QweakSimCerenkovDetector.hh:179
QweakSimCerenkovDetector::ExoSkeltonFrame_Physical
G4VPhysicalVolume * ExoSkeltonFrame_Physical
Definition: QweakSimCerenkovDetector.hh:193
inch
static const G4double inch
Definition: QweakSimSystemOfUnits.hh:35
QweakSimCerenkovDetector::QuartzBar_PhysicalRight
G4VPhysicalVolume * QuartzBar_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:98
QweakSimCerenkovDetector::SquareFlangeL_Physical
G4VPhysicalVolume * SquareFlangeL_Physical
Definition: QweakSimCerenkovDetector.hh:160
QweakSimCerenkovDetector::PMTHousingFlangeR_Physical
G4VPhysicalVolume * PMTHousingFlangeR_Physical
Definition: QweakSimCerenkovDetector.hh:171
QweakSimCerenkovDetector::Position_SideBracketPad
std::vector< G4ThreeVector > Position_SideBracketPad
Definition: QweakSimCerenkovDetector.hh:81
QweakSimCerenkovDetector::mirror_logical
std::vector< G4LogicalVolume * > mirror_logical
Definition: QweakSimCerenkovDetector.hh:303
QweakSimCerenkovDetector::RightGuide_Solid
std::vector< G4SubtractionSolid * > RightGuide_Solid
Definition: QweakSimCerenkovDetector.hh:299
QweakSimCerenkovDetector::PMTHousingWallR_Physical
G4VPhysicalVolume * PMTHousingWallR_Physical
Definition: QweakSimCerenkovDetector.hh:167
QweakSimCerenkovDetector::SquareFlangeSealR_Physical
G4VPhysicalVolume * SquareFlangeSealR_Physical
Definition: QweakSimCerenkovDetector.hh:163
QweakSimCerenkovDetector::PMTEntranceWindow_Physical
G4VPhysicalVolume * PMTEntranceWindow_Physical
Definition: QweakSimCerenkovDetector.hh:131
QweakSimCerenkovDetector::BackWindow_Physical
G4VPhysicalVolume * BackWindow_Physical
Definition: QweakSimCerenkovDetector.hh:149
QweakSimCerenkovDetector::SideBracketPad_Physical
std::vector< G4VPhysicalVolume * > SideBracketPad_Physical
Definition: QweakSimCerenkovDetector.hh:185
QweakSimCerenkovDetector::RightQuartz_Solid
std::vector< G4SubtractionSolid * > RightQuartz_Solid
Definition: QweakSimCerenkovDetector.hh:296
QweakSimCerenkovDetector::SquareFlangeR_Physical
G4VPhysicalVolume * SquareFlangeR_Physical
Definition: QweakSimCerenkovDetector.hh:159
QweakSimCerenkovDetector::FrontWindow_Physical
G4VPhysicalVolume * FrontWindow_Physical
Definition: QweakSimCerenkovDetector.hh:147
QweakSimCerenkovDetector::QuartzGlue_PhysicalRight
G4VPhysicalVolume * QuartzGlue_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:110
QweakSimCerenkovDetector::PMT_PbShield_Physical
G4VPhysicalVolume * PMT_PbShield_Physical
Definition: QweakSimCerenkovDetector.hh:118
QweakSimCerenkovDetector::LeftQuartz_Solid
std::vector< G4SubtractionSolid * > LeftQuartz_Solid
Definition: QweakSimCerenkovDetector.hh:297
QweakSimCerenkovDetector::PMTContainer_PhysicalRight
G4VPhysicalVolume * PMTContainer_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:123
QweakSimCerenkovDetector::LightGuide_PhysicalRight
G4VPhysicalVolume * LightGuide_PhysicalRight
Definition: QweakSimCerenkovDetector.hh:104
QweakSimCerenkov_DetectorSD
Storing hit information of the Cerenkov detector.
Definition: QweakSimCerenkov_DetectorSD.hh:15
QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Physical
G4VPhysicalVolume * PMTQuartzOpticalFilm_Physical
Definition: QweakSimCerenkovDetector.hh:127
QweakSimCerenkovDetector::QuartzBar_LogicalRight
G4LogicalVolume * QuartzBar_LogicalRight
Definition: QweakSimCerenkovDetector.hh:96
QweakSimCerenkovDetector::PMTHousingLidR_Physical
G4VPhysicalVolume * PMTHousingLidR_Physical
Definition: QweakSimCerenkovDetector.hh:175
QweakSimCerenkovDetector::Rotation_SideBracket
std::vector< G4RotationMatrix * > Rotation_SideBracket
Definition: QweakSimCerenkovDetector.hh:74
QweakSimCerenkovDetector::EndBracketPad_Physical
std::vector< G4VPhysicalVolume * > EndBracketPad_Physical
Definition: QweakSimCerenkovDetector.hh:188
QweakSimCerenkovDetector::LightGuide_PhysicalLeft
G4VPhysicalVolume * LightGuide_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:103
QweakSimCerenkovDetector::PMTContainer_PhysicalLeft
G4VPhysicalVolume * PMTContainer_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:122
QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Logical
G4LogicalVolume * PMTQuartzOpticalFilm_Logical
Definition: QweakSimCerenkovDetector.hh:126
QweakSimCerenkovDetector::Position_EndBracketPad
std::vector< G4ThreeVector > Position_EndBracketPad
Definition: QweakSimCerenkovDetector.hh:84
QweakSimCerenkovDetector::FrontClip_Physical
G4VPhysicalVolume * FrontClip_Physical
Definition: QweakSimCerenkovDetector.hh:153
QweakSimCerenkovDetector::QuartzGlue_PhysicalLeft
G4VPhysicalVolume * QuartzGlue_PhysicalLeft
Definition: QweakSimCerenkovDetector.hh:108

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::DefineCerenkovGeometry ( )

Definition at line 184 of file QweakSimCerenkovDetector.cc.

184  {
185  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::DefineCerenkovGeometry() " << G4endl << G4endl;
186  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::DefineCerenkovGeometry() " << G4endl << G4endl;
187 }
void QweakSimCerenkovDetector::DestroyComponent ( )

Definition at line 2394 of file QweakSimCerenkovDetector.cc.

2394  {
2395 }
G4LogicalVolume* QweakSimCerenkovDetector::GetCerenkovDetector_LogicalVolume ( )
inline

Definition at line 50 of file QweakSimCerenkovDetector.hh.

References ActiveArea_Logical.

50 {return ActiveArea_Logical;}
G4VPhysicalVolume* QweakSimCerenkovDetector::GetCerenkovDetector_PhysicalVolume ( )
inline

Definition at line 51 of file QweakSimCerenkovDetector.hh.

References ActiveArea_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

51 {return ActiveArea_Physical;}
QweakSimCerenkovDetector::ActiveArea_Physical
G4VPhysicalVolume * ActiveArea_Physical
Definition: QweakSimCerenkovDetector.hh:92

+ Here is the caller graph for this function:

G4LogicalVolume* QweakSimCerenkovDetector::GetPMT_LogicalVolume ( )
inline

Definition at line 53 of file QweakSimCerenkovDetector.hh.

References Cathode_Logical.

53 {return Cathode_Logical;}
G4VPhysicalVolume* QweakSimCerenkovDetector::GetPMT_PhysicalVolume ( )
inline

Definition at line 54 of file QweakSimCerenkovDetector.hh.

References Cathode_Physical.

54 {return Cathode_Physical;}
void QweakSimCerenkovDetector::PlacePVCerenkovMasterContainer ( )

Definition at line 2531 of file QweakSimCerenkovDetector.cc.

References CerenkovContainer_Logical, CerenkovMasterContainer_Physical, Position_CerenkovContainer_X, Position_CerenkovContainer_Y, Position_CerenkovContainer_Z, pSurfChk, Rotation_CerenkovContainer_X, Rotation_CerenkovContainer_Y, Rotation_CerenkovContainer_Z, Rotation_CerenkovMasterContainer, theMotherPV, Tilting_Angle, and Translation_CerenkovMasterContainer.

Referenced by CerenkovGeometryPVUpdate(), and ConstructComponent().

2531  {
2532  // place 8 CerenkovContainer_Logical plates into the MotherVolume (around the global Z axis)
2533  for (size_t i = 0; i < Rotation_CerenkovMasterContainer.size(); i++) {
2534
2535  // Phi angles of the 8 cerenkovs
2536  G4double AnglePhi_CerenkovMasterContainer = i * 45.0*degree;
2537
2538  // since the CerenkovMasterContainer_Logical is defined for a vertical orientation
2539  // but the translation assumes a horizontal orientation, we have to subtract 90*deg
2540  Rotation_CerenkovMasterContainer[i] = new G4RotationMatrix();
2541  Rotation_CerenkovMasterContainer[i]->rotateZ(-AnglePhi_CerenkovMasterContainer + 90*degree);
2542  Rotation_CerenkovMasterContainer[i]->rotateX(Tilting_Angle);
2543  // Additional small rotations
2544  Rotation_CerenkovMasterContainer[i]->rotateX(Rotation_CerenkovContainer_X[i]);
2545  Rotation_CerenkovMasterContainer[i]->rotateY(Rotation_CerenkovContainer_Y[i]);
2546  Rotation_CerenkovMasterContainer[i]->rotateZ(Rotation_CerenkovContainer_Z[i]);
2547
2548  // set the vectors to the center of the CerenkovContainer
2549  // located at 12 o'clock. Then rotate the centerVector to the 8
2550  // positions and extract the new vector components
2551  // This procedure is easier than the calculation by hand for individual positions/orientations
2552
2553  // define 12' o'clock start location
2554  G4ThreeVector centerVector;
2555  centerVector.setX(Position_CerenkovContainer_X[i]);
2556  centerVector.setY(Position_CerenkovContainer_Y[i]);
2557  centerVector.setZ(Position_CerenkovContainer_Z[i]);
2558
2559  // rotate centerVector to the 8 positions
2560  centerVector.rotateZ(-AnglePhi_CerenkovMasterContainer);
2561
2562  Translation_CerenkovMasterContainer[i].setX(centerVector.y());
2563  Translation_CerenkovMasterContainer[i].setY(centerVector.x());
2564  Translation_CerenkovMasterContainer[i].setZ(centerVector.z());
2565
2566  CerenkovMasterContainer_Physical[i] = new G4PVPlacement(
2567  Rotation_CerenkovMasterContainer[i],
2568  Translation_CerenkovMasterContainer[i],
2569  "CerenkovMasterContainer_Physical",
2570  CerenkovContainer_Logical,
2571  theMotherPV,
2572  false,
2573  i,
2574  pSurfChk);
2575
2576  } // end of for (size_t i=0; i < n; i++)
2577 }
QweakSimCerenkovDetector::Rotation_CerenkovContainer_X
std::vector< G4double > Rotation_CerenkovContainer_X
Definition: QweakSimCerenkovDetector.hh:385
QweakSimCerenkovDetector::Rotation_CerenkovContainer_Y
std::vector< G4double > Rotation_CerenkovContainer_Y
Definition: QweakSimCerenkovDetector.hh:386
QweakSimCerenkovDetector::Translation_CerenkovMasterContainer
std::vector< G4ThreeVector > Translation_CerenkovMasterContainer
Definition: QweakSimCerenkovDetector.hh:71
pSurfChk
static const G4bool pSurfChk
Definition: QweakSimSolids.hh:43
QweakSimCerenkovDetector::CerenkovContainer_Logical
G4LogicalVolume * CerenkovContainer_Logical
Definition: QweakSimCerenkovDetector.hh:87
QweakSimCerenkovDetector::Position_CerenkovContainer_Y
std::vector< G4double > Position_CerenkovContainer_Y
Definition: QweakSimCerenkovDetector.hh:381
QweakSimCerenkovDetector::Position_CerenkovContainer_Z
std::vector< G4double > Position_CerenkovContainer_Z
Definition: QweakSimCerenkovDetector.hh:382
QweakSimCerenkovDetector::Rotation_CerenkovContainer_Z
std::vector< G4double > Rotation_CerenkovContainer_Z
Definition: QweakSimCerenkovDetector.hh:387
QweakSimCerenkovDetector::CerenkovMasterContainer_Physical
std::vector< G4VPhysicalVolume * > CerenkovMasterContainer_Physical
Definition: QweakSimCerenkovDetector.hh:70
QweakSimCerenkovDetector::Rotation_CerenkovMasterContainer
std::vector< G4RotationMatrix * > Rotation_CerenkovMasterContainer
Definition: QweakSimCerenkovDetector.hh:72
QweakSimCerenkovDetector::Position_CerenkovContainer_X
std::vector< G4double > Position_CerenkovContainer_X
Definition: QweakSimCerenkovDetector.hh:380

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorCenterPositionInX ( G4double  xPos,
G4int  octant
)

Definition at line 2431 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), and Position_CerenkovContainer_X.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2431  {
2432  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovCenterPositionInX() " << G4endl << G4endl;
2433
2434  Position_CerenkovContainer_X[octant] = xPos;
2435
2436  CerenkovGeometryPVUpdate();
2437
2438  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovCenterPositionInX() " << G4endl << G4endl;
2439 }
QweakSimCerenkovDetector::Position_CerenkovContainer_X
std::vector< G4double > Position_CerenkovContainer_X
Definition: QweakSimCerenkovDetector.hh:380

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorCenterPositionInY ( G4double  yPos,
G4int  octant
)

Definition at line 2442 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), and Position_CerenkovContainer_Y.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2442  {
2443  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovCenterPositionInY() " << G4endl << G4endl;
2444
2445  Position_CerenkovContainer_Y[octant] = yPos;
2446
2447  CerenkovGeometryPVUpdate();
2448
2449  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovCenterPositionInY() " << G4endl << G4endl;
2450 }
QweakSimCerenkovDetector::Position_CerenkovContainer_Y
std::vector< G4double > Position_CerenkovContainer_Y
Definition: QweakSimCerenkovDetector.hh:381

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorCenterPositionInZ ( G4double  zPos,
G4int  octant
)

Definition at line 2453 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), Container_Center_Z, and Position_CerenkovContainer_Z.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2453  {
2454  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovCenterPositionInZ() " << G4endl << G4endl;
2455
2456  Position_CerenkovContainer_Z[octant] = zPos-Container_Center_Z;
2457
2458  CerenkovGeometryPVUpdate();
2459
2460  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovCenterPositionInZ() " << G4endl << G4endl;
2461 }
QweakSimCerenkovDetector::Position_CerenkovContainer_Z
std::vector< G4double > Position_CerenkovContainer_Z
Definition: QweakSimCerenkovDetector.hh:382

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorMaterial ( G4String  materialName)

Definition at line 2310 of file QweakSimCerenkovDetector.cc.

References LightGuide_LogicalLeft, LightGuide_LogicalRight, QuartzBar_LogicalLeft, QuartzBar_LogicalRight, and QuartzGlue_Logical.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2310  {
2311  // search the material by its name
2312  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
2313  if (pttoMaterial) {
2314  QuartzBar_LogicalLeft->SetMaterial(pttoMaterial);
2315  QuartzBar_LogicalRight->SetMaterial(pttoMaterial);
2316  LightGuide_LogicalLeft->SetMaterial(pttoMaterial);
2317  LightGuide_LogicalRight->SetMaterial(pttoMaterial);
2318  QuartzGlue_Logical->SetMaterial(pttoMaterial);
2319  } else {
2320  G4cerr << "==== ERROR: Changing Cerenkov Detector Material failed" << G4endl;
2321  }
2322
2323 }
QweakSimCerenkovDetector::QuartzBar_LogicalRight
G4LogicalVolume * QuartzBar_LogicalRight
Definition: QweakSimCerenkovDetector.hh:96

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorRotationInX ( G4double  xRot,
G4int  octant
)

Definition at line 2476 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), and Rotation_CerenkovContainer_X.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2476  {
2477  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovRotationInX() " << G4endl << G4endl;
2478
2479  Rotation_CerenkovContainer_X[octant] = xRot;
2480
2481  CerenkovGeometryPVUpdate();
2482
2483  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovRotationInX() " << G4endl << G4endl;
2484 }
QweakSimCerenkovDetector::Rotation_CerenkovContainer_X
std::vector< G4double > Rotation_CerenkovContainer_X
Definition: QweakSimCerenkovDetector.hh:385

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorRotationInY ( G4double  yRot,
G4int  octant
)

Definition at line 2487 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), and Rotation_CerenkovContainer_Y.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2487  {
2488  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovRotationInY() " << G4endl << G4endl;
2489
2490  Rotation_CerenkovContainer_Y[octant] = yRot;
2491
2492  CerenkovGeometryPVUpdate();
2493
2494  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovRotationInY() " << G4endl << G4endl;
2495 }
QweakSimCerenkovDetector::Rotation_CerenkovContainer_Y
std::vector< G4double > Rotation_CerenkovContainer_Y
Definition: QweakSimCerenkovDetector.hh:386

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorRotationInZ ( G4double  zRot,
G4int  octant
)

Definition at line 2498 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), and Rotation_CerenkovContainer_Z.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2498  {
2499  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovRotationInZ() " << G4endl << G4endl;
2500
2501  Rotation_CerenkovContainer_Z[octant] = zRot;
2502
2503  CerenkovGeometryPVUpdate();
2504
2505  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovRotationInZ() " << G4endl << G4endl;
2506 }
QweakSimCerenkovDetector::Rotation_CerenkovContainer_Z
std::vector< G4double > Rotation_CerenkovContainer_Z
Definition: QweakSimCerenkovDetector.hh:387

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorThickness ( G4double  thickness)

Definition at line 2398 of file QweakSimCerenkovDetector.cc.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2398  {
2399  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovDetectorThickness() " << G4endl << G4endl;
2400
2401 // G4Box *box = NULL;
2402
2403 // Thickness = thickness;
2404
2405 // if(CerenkovDetector_Logical)
2406 // box = (G4Box*)CerenkovDetector_Logical->GetSolid();
2407 // if(box)
2408 // box->SetZHalfLength(0.5*Thickness);
2409
2410 // if(PMTContainer_Logical)
2411 // box = (G4Box*)PMTContainer_Logical->GetSolid();
2412 // if(box)
2413 // box->SetZHalfLength(0.5*Thickness);
2414
2415 // if(PMTEntranceWindow_Logical)
2416 // box = (G4Box*)PMTEntranceWindow_Logical->GetSolid();
2417 // if(box)
2418 // box->SetZHalfLength(0.5*Thickness);
2419
2420 // if(Cathode_Logical)
2421 // box = (G4Box*)Cathode_Logical->GetSolid();
2422 // if(box)
2423 // box->SetZHalfLength(0.5*Thickness);
2424
2425 // G4RunManager::GetRunManager()->GeometryHasBeenModified();
2426
2427  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovDetectorThickness() " << G4endl << G4endl;
2428 }

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetCerenkovDetectorTiltAngle ( G4double  tiltangle)

Definition at line 2464 of file QweakSimCerenkovDetector.cc.

References CerenkovGeometryPVUpdate(), and Tilting_Angle.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2464  {
2465  G4cout << G4endl << "###### Calling QweakSimCerenkovDetector::SetCerenkovDetectorTiltAngle() " << G4endl << G4endl;
2466
2467  // assign new tilting
2468  Tilting_Angle = tiltangle;
2469
2470  CerenkovGeometryPVUpdate();
2471
2472  G4cout << G4endl << "###### Leaving QweakSimCerenkovDetector::SetCerenkovDetectorTiltAngle() " << G4endl << G4endl;
2473 }

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetContainerMaterial ( G4String  materialName)

Definition at line 2382 of file QweakSimCerenkovDetector.cc.

References CerenkovContainer_Logical.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2382  {
2383
2384  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
2385  if (pttoMaterial) {
2386  CerenkovContainer_Logical->SetMaterial(pttoMaterial);
2387  } else {
2388  G4cerr << "==== ERROR: Changing Container Material failed" << G4endl;
2389  }
2390
2391 }
QweakSimCerenkovDetector::CerenkovContainer_Logical
G4LogicalVolume * CerenkovContainer_Logical
Definition: QweakSimCerenkovDetector.hh:87

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetMotherVolume ( G4VPhysicalVolume *  mv)
inline

Definition at line 26 of file QweakSimCerenkovDetector.hh.

References theMotherPV.

26 {theMotherPV = mv;}
void QweakSimCerenkovDetector::SetNumberOfDetectors ( G4int  number)

Definition at line 2326 of file QweakSimCerenkovDetector.cc.

References CerenkovDetectorMessenger, CerenkovGeometryPVUpdate(), CerenkovMasterContainer_Physical, Default_Position_CerenkovContainer_X, Default_Position_CerenkovContainer_Y, Default_Position_CerenkovContainer_Z, Default_Rotation_CerenkovContainer_X, Default_Rotation_CerenkovContainer_Y, Default_Rotation_CerenkovContainer_Z, NumberOfCerenkovDetectors, Position_CerenkovContainer_X, Position_CerenkovContainer_Y, Position_CerenkovContainer_Z, Rotation_CerenkovContainer_X, Rotation_CerenkovContainer_Y, Rotation_CerenkovContainer_Z, Rotation_CerenkovMasterContainer, and Translation_CerenkovMasterContainer.

Referenced by QweakSimCerenkovDetector(), and QweakSimCerenkovDetectorMessenger::SetNewValue().

2327 {
2328  // Delete pointers if resizing to something smaller
2329  if (number < NumberOfCerenkovDetectors) {
2330  for (size_t k = number; k < CerenkovDetectorMessenger.size(); k++) {
2331  delete CerenkovDetectorMessenger[k];
2332  delete CerenkovMasterContainer_Physical[k];
2333  delete Rotation_CerenkovMasterContainer[k];
2334  }
2335  }
2336
2337  // Set number of detectors
2338  NumberOfCerenkovDetectors = number;
2339
2340  // Resize objects and fill with zeros
2341  CerenkovDetectorMessenger.resize(NumberOfCerenkovDetectors,0);
2342  CerenkovMasterContainer_Physical.resize(NumberOfCerenkovDetectors,0);
2343  Rotation_CerenkovMasterContainer.resize(NumberOfCerenkovDetectors,0);
2344  Translation_CerenkovMasterContainer.resize(NumberOfCerenkovDetectors);
2345
2346  // Resize positions and set to default values
2347  Position_CerenkovContainer_X.resize(NumberOfCerenkovDetectors,Default_Position_CerenkovContainer_X);
2348  Position_CerenkovContainer_Y.resize(NumberOfCerenkovDetectors,Default_Position_CerenkovContainer_Y);
2349  Position_CerenkovContainer_Z.resize(NumberOfCerenkovDetectors,Default_Position_CerenkovContainer_Z);
2350
2351  // Resize positions and set to default values
2352  Rotation_CerenkovContainer_X.resize(NumberOfCerenkovDetectors,Default_Rotation_CerenkovContainer_X);
2353  Rotation_CerenkovContainer_Y.resize(NumberOfCerenkovDetectors,Default_Rotation_CerenkovContainer_Y);
2354  Rotation_CerenkovContainer_Z.resize(NumberOfCerenkovDetectors,Default_Rotation_CerenkovContainer_Z);
2355
2356  // Creates a messenger for each of the new Cerenkov detectors
2357  for(size_t k = 0; k < CerenkovDetectorMessenger.size(); k++) {
2358  if (CerenkovDetectorMessenger[k] == 0) {
2359  CerenkovDetectorMessenger[k] = new QweakSimCerenkovDetectorMessenger(this, k);
2360  }
2361  }
2362
2363  // Update geometry
2364  CerenkovGeometryPVUpdate();
2365 }
QweakSimCerenkovDetector::Rotation_CerenkovContainer_X
std::vector< G4double > Rotation_CerenkovContainer_X
Definition: QweakSimCerenkovDetector.hh:385
QweakSimCerenkovDetector::Rotation_CerenkovContainer_Y
std::vector< G4double > Rotation_CerenkovContainer_Y
Definition: QweakSimCerenkovDetector.hh:386
QweakSimCerenkovDetector::Translation_CerenkovMasterContainer
std::vector< G4ThreeVector > Translation_CerenkovMasterContainer
Definition: QweakSimCerenkovDetector.hh:71
QweakSimCerenkovDetector::Position_CerenkovContainer_Y
std::vector< G4double > Position_CerenkovContainer_Y
Definition: QweakSimCerenkovDetector.hh:381
QweakSimCerenkovDetector::Position_CerenkovContainer_Z
std::vector< G4double > Position_CerenkovContainer_Z
Definition: QweakSimCerenkovDetector.hh:382
QweakSimCerenkovDetectorMessenger
Scans the input file for /Cerenkov/xyz commands.
Definition: QweakSimCerenkovDetectorMessenger.hh:45
QweakSimCerenkovDetector::Rotation_CerenkovContainer_Z
std::vector< G4double > Rotation_CerenkovContainer_Z
Definition: QweakSimCerenkovDetector.hh:387
QweakSimCerenkovDetector::CerenkovMasterContainer_Physical
std::vector< G4VPhysicalVolume * > CerenkovMasterContainer_Physical
Definition: QweakSimCerenkovDetector.hh:70
QweakSimCerenkovDetector::CerenkovDetectorMessenger
std::vector< QweakSimCerenkovDetectorMessenger * > CerenkovDetectorMessenger
Definition: QweakSimCerenkovDetector.hh:60
QweakSimCerenkovDetector::Rotation_CerenkovMasterContainer
std::vector< G4RotationMatrix * > Rotation_CerenkovMasterContainer
Definition: QweakSimCerenkovDetector.hh:72
QweakSimCerenkovDetector::Position_CerenkovContainer_X
std::vector< G4double > Position_CerenkovContainer_X
Definition: QweakSimCerenkovDetector.hh:380

+ Here is the call graph for this function:

+ Here is the caller graph for this function:

void QweakSimCerenkovDetector::SetPreradiatorMaterial ( G4String  materialName)

Definition at line 2369 of file QweakSimCerenkovDetector.cc.

References Radiator_Logical.

Referenced by QweakSimCerenkovDetectorMessenger::SetNewValue().

2369  {
2370
2371  G4Material* pttoMaterial = G4Material::GetMaterial(materialName);
2372  if (pttoMaterial) {
2373  Radiator_Logical->SetMaterial(pttoMaterial);
2374  } else {
2375  G4cerr << "==== ERROR: Changing Preradiator Material failed" << G4endl;
2376  }
2377
2378 }

+ Here is the caller graph for this function:

Field Documentation

G4double QweakSimCerenkovDetector::ActiveArea_FullLength_X
private

Definition at line 255 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::ActiveArea_FullLength_Y
private

Definition at line 256 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::ActiveArea_FullLength_Z
private

Definition at line 257 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::ActiveArea_Logical
private

Definition at line 91 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), GetCerenkovDetector_LogicalVolume(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::ActiveArea_Material
private

Definition at line 93 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::ActiveArea_Physical
private

Definition at line 92 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), GetCerenkovDetector_PhysicalVolume(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::BackClip_Logical
private

Definition at line 155 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::BackClip_Physical
private

Definition at line 156 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::BackWindow_Logical
private

Definition at line 148 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::BackWindow_Physical
private

Definition at line 149 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4Material* QweakSimCerenkovDetector::BracketPad_Material
private

Definition at line 190 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Cathode_Diameter
private

Definition at line 285 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::Cathode_Logical
private

Definition at line 134 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), GetPMT_LogicalVolume(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::Cathode_Material
private

Definition at line 136 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::Cathode_Physical
private

Definition at line 135 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), GetPMT_PhysicalVolume(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Cathode_Thickness
private

Definition at line 286 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::CerenkovContainer_Logical
private

Definition at line 87 of file QweakSimCerenkovDetector.hh.

Referenced by CerenkovGeometryPVUpdate(), ConstructComponent(), PlacePVCerenkovMasterContainer(), QweakSimCerenkovDetector(), and SetContainerMaterial().

G4Material* QweakSimCerenkovDetector::CerenkovContainer_Material
private

Definition at line 89 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::CerenkovContainer_Physical
private

Definition at line 88 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector().

G4VSensitiveDetector* QweakSimCerenkovDetector::CerenkovDetector_PMTSD
private

Definition at line 377 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::CerenkovDetectorCenterZPosition
private

Definition at line 288 of file QweakSimCerenkovDetector.hh.

std::vector< QweakSimCerenkovDetectorMessenger* > QweakSimCerenkovDetector::CerenkovDetectorMessenger
private

Definition at line 60 of file QweakSimCerenkovDetector.hh.

Referenced by SetNumberOfDetectors(), and ~QweakSimCerenkovDetector().

G4VSensitiveDetector* QweakSimCerenkovDetector::CerenkovDetectorSD
private

Definition at line 375 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4VPhysicalVolume* > QweakSimCerenkovDetector::CerenkovMasterContainer_Physical
private

Definition at line 70 of file QweakSimCerenkovDetector.hh.

Referenced by CerenkovGeometryPVUpdate(), PlacePVCerenkovMasterContainer(), and SetNumberOfDetectors().

G4VSensitiveDetector* QweakSimCerenkovDetector::CerenkovRadiatorSD
private

Definition at line 376 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Chamfer_FullHeight
private

Definition at line 264 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Chamfer_FullLength
private

Definition at line 263 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Chamfer_FullThickness
private

Definition at line 265 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4ThreeVector QweakSimCerenkovDetector::Container_Center
private

Definition at line 404 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Container_Center_X
private

Definition at line 400 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Container_Center_Y
private

Definition at line 401 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Container_Center_Z
private

Definition at line 402 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetCerenkovDetectorCenterPositionInZ().

G4double QweakSimCerenkovDetector::Container_FullLength_X
private

Definition at line 201 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Container_FullLength_Y
private

Definition at line 202 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Container_FullLength_Z
private

Definition at line 203 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::CrossBar_Logical
private

Definition at line 142 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::CrossBarL_Physical
private

Definition at line 144 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::CrossBarR_Physical
private

Definition at line 143 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Default_Position_CerenkovContainer_X
private

Definition at line 390 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

G4double QweakSimCerenkovDetector::Default_Position_CerenkovContainer_Y
private

Definition at line 391 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

G4double QweakSimCerenkovDetector::Default_Position_CerenkovContainer_Z
private

Definition at line 392 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

G4double QweakSimCerenkovDetector::Default_Rotation_CerenkovContainer_X
private

Definition at line 395 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

G4double QweakSimCerenkovDetector::Default_Rotation_CerenkovContainer_Y
private

Definition at line 396 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

G4double QweakSimCerenkovDetector::Default_Rotation_CerenkovContainer_Z
private

Definition at line 397 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

G4LogicalVolume* QweakSimCerenkovDetector::EndBracket_Logical
private

Definition at line 181 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4VPhysicalVolume* > QweakSimCerenkovDetector::EndBracket_Physical
private

Definition at line 182 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketCutLength_X
private

Definition at line 233 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketCutLength_Y
private

Definition at line 234 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketCutLength_Z
private

Definition at line 235 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketLength_X
private

Definition at line 229 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketLength_Y
private

Definition at line 230 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketLength_Z
private

Definition at line 231 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::EndBracketPad_Logical
private

Definition at line 187 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4VPhysicalVolume* > QweakSimCerenkovDetector::EndBracketPad_Physical
private

Definition at line 188 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketPadCutLength_X
private

Definition at line 249 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketPadCutLength_Y
private

Definition at line 250 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketPadCutLength_Z
private

Definition at line 251 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketPadLength_X
private

Definition at line 245 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketPadLength_Y
private

Definition at line 246 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::EndBracketPadLength_Z
private

Definition at line 247 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::ExoSkeltonFrame_Logical
private

Definition at line 192 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4Material* QweakSimCerenkovDetector::ExoSkeltonFrame_Material
private

Definition at line 194 of file QweakSimCerenkovDetector.hh.

G4VPhysicalVolume* QweakSimCerenkovDetector::ExoSkeltonFrame_Physical
private

Definition at line 193 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::ExoSkeltonFrame_X
private

Definition at line 205 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::ExoSkeltonFrame_Y
private

Definition at line 206 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::ExoSkeltonFrame_Z
private

Definition at line 207 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::ExoSkeltonInnerFrame_X
private

Definition at line 209 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::ExoSkeltonInnerFrame_Y
private

Definition at line 210 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::ExoSkeltonInnerFrame_Z
private

Definition at line 211 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Frame_FullLength_X
private

Definition at line 213 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Frame_FullLength_Y
private

Definition at line 214 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Frame_FullLength_Z
private

Definition at line 215 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Frame_InnerFullLength_X
private

Definition at line 217 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Frame_InnerFullLength_Y
private

Definition at line 218 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::Frame_InnerFullLength_Z
private

Definition at line 219 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::Frame_Logical
private

Definition at line 138 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::Frame_Material
private

Definition at line 140 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::Frame_Physical
private

Definition at line 139 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::FrontClip_Logical
private

Definition at line 152 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::FrontClip_Physical
private

Definition at line 153 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::FrontWindow_Logical
private

Definition at line 146 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::FrontWindow_Physical
private

Definition at line 147 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::GlueFilm_FullLength_X
private

Definition at line 259 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::GlueFilm_FullLength_Y
private

Definition at line 260 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::GlueFilm_FullLength_Z
private

Definition at line 261 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::Kink_Angle
private

Definition at line 307 of file QweakSimCerenkovDetector.hh.

std::vector< G4SubtractionSolid* > QweakSimCerenkovDetector::LeftGuide_Solid
private

Definition at line 298 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4SubtractionSolid* > QweakSimCerenkovDetector::LeftQuartz_Solid
private

Definition at line 297 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::LGAngCutXDim
private

Definition at line 290 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::LGAngCutYDim
private

Definition at line 291 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::LGAngCutZDim
private

Definition at line 292 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::LightGuide_FullLength
private

Definition at line 271 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::LightGuide_FullThickness
private

Definition at line 274 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::LightGuide_FullWidth1
private

Definition at line 272 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::LightGuide_FullWidth2
private

Definition at line 273 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::LightGuide_LogicalLeft
private

Definition at line 101 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), QweakSimCerenkovDetector(), and SetCerenkovDetectorMaterial().

G4LogicalVolume* QweakSimCerenkovDetector::LightGuide_LogicalRight
private

Definition at line 102 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), QweakSimCerenkovDetector(), and SetCerenkovDetectorMaterial().

G4Material* QweakSimCerenkovDetector::LightGuide_Material
private

Definition at line 105 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::LightGuide_PhysicalLeft
private

Definition at line 103 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::LightGuide_PhysicalRight
private

Definition at line 104 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4LogicalVolume* > QweakSimCerenkovDetector::mirror_logical
private

Definition at line 303 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::mirror_material
private

Definition at line 302 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4VPhysicalVolume* > QweakSimCerenkovDetector::mirror_physical
private

Definition at line 304 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector().

QweakSimUserInformation* QweakSimCerenkovDetector::myUserInfo
private

Definition at line 58 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4int QweakSimCerenkovDetector::NumberOfCerenkovDetectors
private

Definition at line 67 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector(), and SetNumberOfDetectors().

QweakSimMaterial* QweakSimCerenkovDetector::pMaterial
private

Definition at line 62 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::PMT_PbShield_Logical
private

Definition at line 117 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4Material* QweakSimCerenkovDetector::PMT_PbShield_Material
private

Definition at line 119 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMT_PbShield_Physical
private

Definition at line 118 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::PMTContainer_Diameter
private

Definition at line 276 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::PMTContainer_FullLength_Z
private

Definition at line 277 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::PMTContainer_Logical
private

Definition at line 121 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::PMTContainer_Material
private

Definition at line 124 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTContainer_PhysicalLeft
private

Definition at line 122 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTContainer_PhysicalRight
private

Definition at line 123 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::PMTEntranceWindow_Diameter
private

Definition at line 282 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::PMTEntranceWindow_Logical
private

Definition at line 130 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::PMTEntranceWindow_Material
private

Definition at line 132 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTEntranceWindow_Physical
private

Definition at line 131 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::PMTEntranceWindow_Thickness
private

Definition at line 283 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::PMTHousingFlange_Logical
private

Definition at line 170 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTHousingFlangeL_Physical
private

Definition at line 172 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTHousingFlangeR_Physical
private

Definition at line 171 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::PMTHousingLid_Logical
private

Definition at line 174 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTHousingLidL_Physical
private

Definition at line 176 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTHousingLidR_Physical
private

Definition at line 175 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::PMTHousingWall_Logical
private

Definition at line 166 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTHousingWallL_Physical
private

Definition at line 168 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTHousingWallR_Physical
private

Definition at line 167 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Diameter
private

Definition at line 279 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Logical
private

Definition at line 126 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4Material* QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Material
private

Definition at line 128 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Physical
private

Definition at line 127 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::PMTQuartzOpticalFilm_Thickness
private

Definition at line 280 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4ThreeVector QweakSimCerenkovDetector::Position_AngCut1
private

Definition at line 324 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_AngCut2
private

Definition at line 327 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_CerenkovContainer
private

Definition at line 311 of file QweakSimCerenkovDetector.hh.

std::vector< G4double > QweakSimCerenkovDetector::Position_CerenkovContainer_X
private

Definition at line 380 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), SetCerenkovDetectorCenterPositionInX(), and SetNumberOfDetectors().

std::vector< G4double > QweakSimCerenkovDetector::Position_CerenkovContainer_Y
private

Definition at line 381 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), SetCerenkovDetectorCenterPositionInY(), and SetNumberOfDetectors().

std::vector< G4double > QweakSimCerenkovDetector::Position_CerenkovContainer_Z
private

Definition at line 382 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), SetCerenkovDetectorCenterPositionInZ(), and SetNumberOfDetectors().

G4ThreeVector QweakSimCerenkovDetector::Position_Chamfer1
private

Definition at line 315 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_Chamfer2
private

Definition at line 317 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_Chamfer3
private

Definition at line 319 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_Chamfer4
private

Definition at line 321 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4ThreeVector > QweakSimCerenkovDetector::Position_EndBracket
private

Definition at line 78 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4ThreeVector > QweakSimCerenkovDetector::Position_EndBracketPad
private

Definition at line 84 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_LGEdgeMirrorLeft
private

Definition at line 338 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_LGEdgeMirrorRight
private

Definition at line 344 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_LGFaceMirrorLeft
private

Definition at line 335 of file QweakSimCerenkovDetector.hh.

G4ThreeVector QweakSimCerenkovDetector::Position_LGFaceMirrorRight
private

Definition at line 341 of file QweakSimCerenkovDetector.hh.

G4ThreeVector QweakSimCerenkovDetector::Position_LGLeft
private

Definition at line 332 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Position_LGRight
private

Definition at line 330 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4ThreeVector > QweakSimCerenkovDetector::Position_SideBracket
private

Definition at line 75 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4ThreeVector > QweakSimCerenkovDetector::Position_SideBracketPad
private

Definition at line 81 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::QuartzBar_FullHeight
private

Definition at line 268 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::QuartzBar_FullLength
private

Definition at line 267 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::QuartzBar_FullThickness
private

Definition at line 269 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::QuartzBar_LogicalLeft
private

Definition at line 95 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), QweakSimCerenkovDetector(), and SetCerenkovDetectorMaterial().

G4LogicalVolume* QweakSimCerenkovDetector::QuartzBar_LogicalRight
private

Definition at line 96 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), QweakSimCerenkovDetector(), and SetCerenkovDetectorMaterial().

G4Material* QweakSimCerenkovDetector::QuartzBar_Material
private

Definition at line 99 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::QuartzBar_PhysicalLeft
private

Definition at line 97 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::QuartzBar_PhysicalRight
private

Definition at line 98 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::QuartzGlue_Logical
private

Definition at line 107 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), QweakSimCerenkovDetector(), and SetCerenkovDetectorMaterial().

G4Material* QweakSimCerenkovDetector::QuartzGlue_Material
private

Definition at line 111 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::QuartzGlue_PhysicalCenter
private

Definition at line 109 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::QuartzGlue_PhysicalLeft
private

Definition at line 108 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::QuartzGlue_PhysicalRight
private

Definition at line 110 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4LogicalVolume* QweakSimCerenkovDetector::Radiator_Logical
private

Definition at line 113 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and SetPreradiatorMaterial().

G4Material* QweakSimCerenkovDetector::Radiator_Material
private

Definition at line 115 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4VPhysicalVolume* QweakSimCerenkovDetector::Radiator_Physical
private

Definition at line 114 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4SubtractionSolid* > QweakSimCerenkovDetector::RightGuide_Solid
private

Definition at line 299 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4SubtractionSolid* > QweakSimCerenkovDetector::RightQuartz_Solid
private

Definition at line 296 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_AngCut1
private

Definition at line 325 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_AngCut2
private

Definition at line 328 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_Cathode
private

Definition at line 365 of file QweakSimCerenkovDetector.hh.

G4RotationMatrix* QweakSimCerenkovDetector::Rotation_CerenkovContainer
private

Definition at line 312 of file QweakSimCerenkovDetector.hh.

Referenced by QweakSimCerenkovDetector().

std::vector< G4double > QweakSimCerenkovDetector::Rotation_CerenkovContainer_X
private

Definition at line 385 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), SetCerenkovDetectorRotationInX(), and SetNumberOfDetectors().

std::vector< G4double > QweakSimCerenkovDetector::Rotation_CerenkovContainer_Y
private

Definition at line 386 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), SetCerenkovDetectorRotationInY(), and SetNumberOfDetectors().

std::vector< G4double > QweakSimCerenkovDetector::Rotation_CerenkovContainer_Z
private

Definition at line 387 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), SetCerenkovDetectorRotationInZ(), and SetNumberOfDetectors().

std::vector< G4RotationMatrix* > QweakSimCerenkovDetector::Rotation_CerenkovMasterContainer
private

Definition at line 72 of file QweakSimCerenkovDetector.hh.

Referenced by CerenkovGeometryPVUpdate(), PlacePVCerenkovMasterContainer(), and SetNumberOfDetectors().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_Chamfer1
private

Definition at line 316 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_Chamfer2
private

Definition at line 318 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_Chamfer3
private

Definition at line 320 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_Chamfer4
private

Definition at line 322 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4RotationMatrix* > QweakSimCerenkovDetector::Rotation_EndBracket
private

Definition at line 77 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4RotationMatrix* > QweakSimCerenkovDetector::Rotation_EndBracketPad
private

Definition at line 83 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_LGEdgeMirrorLeft
private

Definition at line 339 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_LGEdgeMirrorRight
private

Definition at line 345 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_LGFaceMirrorLeft
private

Definition at line 336 of file QweakSimCerenkovDetector.hh.

G4RotationMatrix QweakSimCerenkovDetector::Rotation_LGFaceMirrorRight
private

Definition at line 342 of file QweakSimCerenkovDetector.hh.

G4RotationMatrix QweakSimCerenkovDetector::Rotation_LGLeft
private

Definition at line 333 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_LGRight
private

Definition at line 331 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_PMTContainerLeft
private

Definition at line 357 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_PMTContainerRight
private

Definition at line 361 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_PMTEntranceWindow
private

Definition at line 372 of file QweakSimCerenkovDetector.hh.

G4RotationMatrix QweakSimCerenkovDetector::Rotation_PMTQuartzOpticalFilm
private

Definition at line 369 of file QweakSimCerenkovDetector.hh.

std::vector< G4RotationMatrix* > QweakSimCerenkovDetector::Rotation_SideBracket
private

Definition at line 74 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4RotationMatrix* > QweakSimCerenkovDetector::Rotation_SideBracketPad
private

Definition at line 80 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4RotationMatrix QweakSimCerenkovDetector::Rotation_SingleBarLeft
private

Definition at line 349 of file QweakSimCerenkovDetector.hh.

G4RotationMatrix QweakSimCerenkovDetector::Rotation_SingleBarRight
private

Definition at line 353 of file QweakSimCerenkovDetector.hh.

G4LogicalVolume* QweakSimCerenkovDetector::SideBracket_Logical
private

Definition at line 178 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4VPhysicalVolume* > QweakSimCerenkovDetector::SideBracket_Physical
private

Definition at line 179 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::SideBracketCutLength_X
private

Definition at line 225 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketCutLength_Y
private

Definition at line 226 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketCutLength_Z
private

Definition at line 227 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketLength_X
private

Definition at line 221 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketLength_Y
private

Definition at line 222 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketLength_Z
private

Definition at line 223 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::SideBracketPad_Logical
private

Definition at line 184 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

std::vector< G4VPhysicalVolume* > QweakSimCerenkovDetector::SideBracketPad_Physical
private

Definition at line 185 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::SideBracketPadCutLength_X
private

Definition at line 241 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketPadCutLength_Y
private

Definition at line 242 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketPadCutLength_Z
private

Definition at line 243 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketPadLength_X
private

Definition at line 237 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketPadLength_Y
private

Definition at line 238 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4double QweakSimCerenkovDetector::SideBracketPadLength_Z
private

Definition at line 239 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::SquareFlange_Logical
private

Definition at line 158 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::SquareFlangeL_Physical
private

Definition at line 160 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::SquareFlangeR_Physical
private

Definition at line 159 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4LogicalVolume* QweakSimCerenkovDetector::SquareFlangeSeal_Logical
private

Definition at line 162 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::SquareFlangeSealL_Physical
private

Definition at line 164 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::SquareFlangeSealR_Physical
private

Definition at line 163 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4VPhysicalVolume* QweakSimCerenkovDetector::theMotherPV
private

Definition at line 64 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), PlacePVCerenkovMasterContainer(), QweakSimCerenkovDetector(), and SetMotherVolume().

G4double QweakSimCerenkovDetector::Thickness
private

Definition at line 308 of file QweakSimCerenkovDetector.hh.

G4double QweakSimCerenkovDetector::Tilting_Angle
private

Definition at line 306 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), QweakSimCerenkovDetector(), and SetCerenkovDetectorTiltAngle().

G4ThreeVector QweakSimCerenkovDetector::Translation_Cathode
private

Definition at line 364 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

std::vector< G4ThreeVector > QweakSimCerenkovDetector::Translation_CerenkovMasterContainer
private

Definition at line 71 of file QweakSimCerenkovDetector.hh.

Referenced by PlacePVCerenkovMasterContainer(), and SetNumberOfDetectors().

G4ThreeVector QweakSimCerenkovDetector::Translation_PMTContainerLeft
private

Definition at line 356 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Translation_PMTContainerRight
private

Definition at line 360 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Translation_PMTEntranceWindow
private

Definition at line 371 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Translation_PMTQuartzOpticalFilm
private

Definition at line 368 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

G4ThreeVector QweakSimCerenkovDetector::Translation_SingleBarLeft
private

Definition at line 348 of file QweakSimCerenkovDetector.hh.

G4ThreeVector QweakSimCerenkovDetector::Translation_SingleBarRight
private

Definition at line 352 of file QweakSimCerenkovDetector.hh.

G4Material* QweakSimCerenkovDetector::Window_Material
private

Definition at line 150 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent(), and QweakSimCerenkovDetector().

G4double QweakSimCerenkovDetector::WindowThickness
private

Definition at line 253 of file QweakSimCerenkovDetector.hh.

Referenced by ConstructComponent().

The documentation for this class was generated from the following files:
