QweakSimGEM_WirePlaneSD Class Reference

Checks for a valid GEM ReadoutPlane hit and stores the hit information (I know there is no wire plane ... just for consistent class names ) More...

#include <QweakSimGEM_WirePlaneSD.hh>

Inherits G4VSensitiveDetector.

Public Member Functions

 QweakSimGEM_WirePlaneSD (G4String name)

 ~QweakSimGEM_WirePlaneSD ()

void Initialize (G4HCofThisEvent *HCE)

G4bool ProcessHits (G4Step *aStep, G4TouchableHistory *ROhist)

void EndOfEvent (G4HCofThisEvent *HCE)


Private Attributes

QweakSimGEM_WirePlane_HitsCollection * hitsCollection

G4int HCID


Detailed Description

Checks for a valid GEM ReadoutPlane hit and stores the hit information (I know there is no wire plane ... just for consistent class names )

Placeholder for a long explaination

Definition at line 43 of file QweakSimGEM_WirePlaneSD.hh.

Constructor & Destructor Documentation

QweakSimGEM_WirePlaneSD::QweakSimGEM_WirePlaneSD ( G4String  name)

Definition at line 30 of file QweakSimGEM_WirePlaneSD.cc.

References HCID.

31 :G4VSensitiveDetector(name)
32 {
33 // G4cout << G4endl << "###### Calling QweakSimGEM_WirePlaneSD::QweakSimGEM_WirePlaneSD() " << G4endl << G4endl;
34
35  collectionName.insert("GEMWirePlaneCollection"); //collectionName[0]
36  HCID = -1;
37
38 // G4cout << G4endl << "###### Leaving QweakSimGEM_WirePlaneSD::QweakSimGEM_WirePlaneSD() " << G4endl << G4endl;
39 }
QweakSimGEM_WirePlaneSD::~QweakSimGEM_WirePlaneSD ( )

Definition at line 42 of file QweakSimGEM_WirePlaneSD.cc.

43 {
44  //G4cout << G4endl << "###### Calling QweakSimGEM_WirePlaneSD::~QweakSimGEM_WirePlaneSD() " << G4endl << G4endl;
45  //delete hitsCollection;
46  //G4cout << G4endl << "###### Leaving QweakSimGEM_WirePlaneSD::~QweakSimGEM_WirePlaneSD() " << G4endl << G4endl;
47 }

Member Function Documentation

void QweakSimGEM_WirePlaneSD::EndOfEvent ( G4HCofThisEvent *  HCE)

Definition at line 245 of file QweakSimGEM_WirePlaneSD.cc.

246 {
247  //G4cout << G4endl << "###### Calling QweakSimGEM_WirePlaneSD::EndOfEvent() " << G4endl << G4endl;
248
249 // G4int NbHits = hitsCollection->entries();
250 // G4cout << "\n-------->Hits Collection: in this event they are " << NbHits
251 // << " hits in the Wire Planes: " << G4endl;
252 // for (G4int i=0;i<NbHits;i++) (*hitsCollection)[i]->Print();
253
254  //G4cout << G4endl << "###### Leaving QweakSimGEM_WirePlaneSD::EndOfEvent() " << G4endl << G4endl;
255
256 }
void QweakSimGEM_WirePlaneSD::Initialize ( G4HCofThisEvent *  HCE)

Definition at line 50 of file QweakSimGEM_WirePlaneSD.cc.

References HCID, and hitsCollection.

51 {
52  //G4cout << G4endl << "###### Calling QweakSimGEM_WirePlaneSD::Initialize() " << G4endl << G4endl;
53
54  hitsCollection = new QweakSimGEM_WirePlane_HitsCollection(SensitiveDetectorName,collectionName[0]);
55
56  HCID = G4SDManager::GetSDMpointer()->GetCollectionID(collectionName[0]);
57
58  HCE->AddHitsCollection( HCID, hitsCollection );
59
60  //G4cout << G4endl << "###### Leaving QweakSimGEM_WirePlaneSD::Initialize() " << G4endl << G4endl;
61
62 }
QweakSimGEM_WirePlaneSD::hitsCollection
QweakSimGEM_WirePlane_HitsCollection * hitsCollection
Definition: QweakSimGEM_WirePlaneSD.hh:55
QweakSimGEM_WirePlane_HitsCollection
G4THitsCollection< QweakSimGEM_WirePlaneHit > QweakSimGEM_WirePlane_HitsCollection
Definition: QweakSimGEM_WirePlaneHit.hh:144
G4bool QweakSimGEM_WirePlaneSD::ProcessHits ( G4Step *  aStep,
G4TouchableHistory *  ROhist
)

Definition at line 64 of file QweakSimGEM_WirePlaneSD.cc.

References hitsCollection, QweakSimGEM_WirePlaneHit::StoreGEMID(), QweakSimGEM_WirePlaneHit::StoreGlobalTime(), QweakSimGEM_WirePlaneHit::StoreKineticEnergy(), QweakSimGEM_WirePlaneHit::StoreLocalMomentum(), QweakSimGEM_WirePlaneHit::StoreLocalPosition(), QweakSimGEM_WirePlaneHit::StoreOriginVertexKineticEnergy(), QweakSimGEM_WirePlaneHit::StoreOriginVertexMomentumDirection(), QweakSimGEM_WirePlaneHit::StoreOriginVertexPosition(), QweakSimGEM_WirePlaneHit::StoreTotalEnergy(), QweakSimGEM_WirePlaneHit::StoreWirePlaneID(), QweakSimGEM_WirePlaneHit::StoreWorldMomentum(), and QweakSimGEM_WirePlaneHit::StoreWorldPosition().

65 {
66  //G4cout << G4endl << "###### Calling QweakSimGEM_WirePlaneSD::ProcessHits() " << G4endl << G4endl;
67
68
69  G4double charge = aStep->GetTrack()->GetDefinition()->GetPDGCharge();
70
71 // G4cout << "%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% Charge =" << charge << G4endl;
72
73  // dismiss photons
74  if(charge==0.) return false;
75
76
77  G4StepPoint* preStepPoint = aStep->GetPreStepPoint();
78  G4StepPoint* postStepPoint = aStep->GetPreStepPoint();
79  G4TouchableHistory* theTouchable = (G4TouchableHistory*)(preStepPoint->GetTouchable());
80  G4VPhysicalVolume* physVol = theTouchable->GetVolume();
81
82  // we are only interested if the particle is crossing a boundary (glass->vaccuum)
83  if (postStepPoint->GetStepStatus() != fGeomBoundary) {
84 // G4cout << "=======================================================================" << G4endl;
85 // G4cout << ">>>> QweakSimGEM_WirePlaneSD: We are NOT crossing a boundary <<<<<<" << G4endl;
86 // G4cout << ">>>> Aborting QweakSimGEM_WirePlaneSD::ProcessHits <<<<<<" << G4endl;
87 // G4cout << "=======================================================================" << G4endl;
88
89  return false;
90  }
91
92 // G4cout << "================== We are in volume :" << physVol->GetName() << G4endl << G4endl;
93
94
95  if(strcmp(physVol->GetName(),"GEM_AnodeCopperLayer_Physical") == 0 ) {
96
97 // G4cout << "=============================================================" << G4endl;
98 // G4cout << ">>>>>>> Particle crossing : GEM_AnodeCopperLayer_Physical <<<<<<<<<" << G4endl;
99 // G4cout << "=============================================================" << G4endl;
100
101 // G4int trackID = aStep->GetTrack()->GetTrackID();
102 // G4cout << "====> Track ID : " << trackID << G4endl;
103
104 // G4int parentID = aStep->GetTrack()->GetParentID();
105 // G4cout << "====> Parent ID : " << parentID << G4endl;
106
107
108
109 // G4int MotherCopyNo = theTouchable->GetVolume(1)->GetCopyNo(); // Several MotherVolumes
110  G4int WirePlaneCopyNo = theTouchable->GetVolume()->GetCopyNo(); // but only one WirePlane per MV
111 // G4int MotherReplicaNo = theTouchable->GetReplicaNumber(1); // Several MotherVolumes
112
113 //pqwang@jlab.org
114 //there are 3 fold MotherVolume, the GEMID must be taken from the outer container
115 // for decoding correct GEMID in the EventAction
116 // G4int MotherCopyNo2 = theTouchable->GetVolume(2)->GetCopyNo(); // Several MotherVolumes
117 // G4int MotherReplicaNo2 = theTouchable->GetReplicaNumber(2); // Several MotherVolumes
118
119  G4int MotherCopyNo3 = theTouchable->GetVolume(3)->GetCopyNo(); // Several MotherVolumes
120 // G4int MotherReplicaNo3 = theTouchable->GetReplicaNumber(3); // Several MotherVolumes
121
122 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane MV CopyNumber :" << MotherCopyNo << G4endl;
123 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane CopyNumber :" << WirePlaneCopyNo << G4endl;
124 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane ReplicaNumber :" << MotherReplicaNo << G4endl;
125 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane MV CopyNumber2 :" << MotherCopyNo2 << G4endl;
126 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane ReplicaNumber2 :" << MotherReplicaNo2 << G4endl;
127
128
129  G4ThreeVector worldPos = preStepPoint->GetPosition();
130 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane WorldPos.X [cm]:" << worldPos.x()/cm << G4endl;
131 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane WorldPos.Y [cm]:" << worldPos.y()/cm << G4endl;
132 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane WorldPos.Z [cm]:" << worldPos.z()/cm << G4endl;
133
134  G4ThreeVector localPos = theTouchable->GetHistory()->GetTopTransform().TransformPoint(worldPos);
135 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane LocalPos.X [cm]:" << localPos.x()/cm << G4endl;
136 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane LocalPos.Y [cm]:" << localPos.y()/cm << G4endl;
137 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane LocalPos.Z [cm]:" << localPos.z()/cm << G4endl;
138
139  G4ThreeVector worldMomentum = preStepPoint->GetMomentum();
140 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane WorldMomentum.X [GeV]:" << worldMomentum.x()/GeV << G4endl;
141 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane WorldMomentum.Y [GeV]:" << worldMomentum.y()/GeV << G4endl;
142 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane WorldMomentum.Z [GeV]:" << worldMomentum.z()/GeV << G4endl;
143
144  G4ThreeVector localMomentum = theTouchable->GetHistory()->GetTopTransform().TransformPoint(worldMomentum);
145 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane LocalMomentum.X [GeV]:" << localMomentum.x()/GeV << G4endl;
146 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane LocalMomentum.Y [GeV]:" << localMomentum.y()/GeV << G4endl;
147 // G4cout << "%%%%%%%%%%%%%%%%%%% WirePlane LocalMomentum.Z [GeV]:" << localMomentum.z()/GeV << G4endl;
148
149  G4double currentKineticEnergy = preStepPoint->GetKineticEnergy();
150  G4double currentTotalEnergy = preStepPoint->GetTotalEnergy();
151
152  // Vertex: where this track was generated
153  G4ThreeVector originVertexPosition = aStep->GetTrack()->GetVertexPosition();
154  G4ThreeVector originVertexMomentumDirection = aStep->GetTrack()->GetVertexMomentumDirection();
155  G4double originVertexKineticEnergy = aStep->GetTrack()->GetVertexKineticEnergy();
156
157 // G4cout << "====> originVertexPosition_X [cm] : " << originVertexPosition.x()/cm << G4endl;
158 // G4cout << "====> originVertexPosition_Y [cm] : " << originVertexPosition.y()/cm << G4endl;
159 // G4cout << "====> originVertexPosition_Z [cm] : " << originVertexPosition.z()/cm << G4endl;
160
161 // G4cout << "====> originVertexMomentumDirection_X : " << originVertexMomentumDirection.x() << G4endl;
162 // G4cout << "====> originVertexMomentumDirection_Y : " << originVertexMomentumDirection.y() << G4endl;
163 // G4cout << "====> originVertexMomentumDirection_Z : " << originVertexMomentumDirection.z() << G4endl;
164
165 // G4cout << "====> originVertexKineticEnergy [Mev] : " << originVertexKineticEnergy/MeV << G4endl;
166
167
168
169 // G4double target_zcut = -630*cm;
170
171 // if (originVertexPosition.z()/cm > target_zcut/cm)
172 // {
173 // G4cout << "################################################################" << G4endl;
174 // G4cout << ">>>>>>>>>>>> originVertexPosition.z > 630cm !!! <<<<<<<<<<<" << G4endl;
175 // G4cout << ">>>>>>>>>>>> Track does not origin from target <<<<<<<<<<<" << G4endl;
176 // G4cout << ">>>>>>>>>>>> Aborting QweakSimGEM_WirePlaneSD::ProcessHits() <<<<<<<<<<<" << G4endl;
177 // G4cout << "################################################################" << G4endl;
178 //
179 // return false;
180 //
181 // }
182
183 // // get User Track Info
184 // QweakSimTrackInformation* info = (QweakSimTrackInformation*) (aStep->GetTrack()->GetUserInformation());
185 // info->Print();
186
187 // G4double primaryQ2 = info->GetPrimaryQ2();
188 // G4double crossSection = info->GetCrossSection();
189 // G4double crossSectionWeight = info->GetCrossSectionWeight();
190 // G4int primaryEventNumber = info->GetPrimaryEventNumber();
191
192 // G4cout << " @@@@@@@@@@@@@@@@@@@@@@@ Original Track Q2 : " << primaryQ2 << G4endl;
193 // G4cout << " @@@@@@@@@@@@@@@@@@@@@@@ Original Track Event Number : " << primaryEventNumber << G4endl;
194 // G4cout << " @@@@@@@@@@@@@@@@@@@@@@@ Original CrossSection Weight (ub) : " << crossSectionWeight << G4endl << G4endl;
195
196
197
198 // G4cout << " =====> Storing GEM hit information into aHit" << G4endl;
199
200  // QweakSimGEMHit* aHit = new QweakSimGEMHit(MotherCopyNo); // there is only one plane per motherVolume
201  QweakSimGEM_WirePlaneHit* aHit = new QweakSimGEM_WirePlaneHit(); // there is only one plane per motherVolume
202
203 //pqwang@jlab.org
204 //there are 3 fold MotherVolume, the GEMID must be taken from the outer container
205 // for decoding correct GEMID in the EventAction
206  aHit->StoreGEMID(MotherCopyNo3); // 0: Front GEM , 1: Back GEM
207  aHit->StoreWirePlaneID(WirePlaneCopyNo); // [0,5] : WirePlane #0 to #5 (6 wire plane in total per GEM)
208
209  aHit->StoreWorldPosition(worldPos);
210  aHit->StoreLocalPosition(localPos);
211
212  aHit->StoreWorldMomentum(worldMomentum);
213  aHit->StoreLocalMomentum(localMomentum);
214
215  aHit->StoreGlobalTime(preStepPoint->GetGlobalTime());
216
217  aHit->StoreOriginVertexPosition(originVertexPosition);
218  aHit->StoreOriginVertexMomentumDirection(originVertexMomentumDirection);
219  aHit->StoreOriginVertexKineticEnergy(originVertexKineticEnergy);
220
221 // aHit->StorePrimaryQ2(primaryQ2);
222 // aHit->StoreCrossSection(crossSection);
223 // aHit->StoreCrossSectionWeight(crossSectionWeight);
224 // aHit->StorePrimaryEventNumber(primaryEventNumber);
225
226  aHit->StoreKineticEnergy(currentKineticEnergy);
227  aHit->StoreTotalEnergy(currentTotalEnergy);
228
229
230  // now store all the hit information into the hit collection
231  hitsCollection->insert(aHit);
232
233  //delete aHit; // NOT ALLOWED, Geant4 crashes
234
235  } // end of if(strcmp(physVol->GetName(),"GEM_WirePlane_Physical")==0)
236
237
238  //G4cout << G4endl << "###### Leaving QweakSimGEM_WirePlaneSD::ProcessHits() " << G4endl << G4endl;
239
240  return true;
241 }
QweakSimGEM_WirePlaneHit::StoreOriginVertexKineticEnergy
void StoreOriginVertexKineticEnergy(G4double ekin)
Definition: QweakSimGEM_WirePlaneHit.hh:116
QweakSimGEM_WirePlaneSD::hitsCollection
QweakSimGEM_WirePlane_HitsCollection * hitsCollection
Definition: QweakSimGEM_WirePlaneSD.hh:55
QweakSimGEM_WirePlaneHit::StoreWorldPosition
void StoreWorldPosition(G4ThreeVector gxyz)
Definition: QweakSimGEM_WirePlaneHit.hh:101
QweakSimGEM_WirePlaneHit::StoreWirePlaneID
void StoreWirePlaneID(G4int wireplane_ID)
Definition: QweakSimGEM_WirePlaneHit.hh:92
QweakSimGEM_WirePlaneHit::StoreLocalPosition
void StoreLocalPosition(G4ThreeVector lxyz)
Definition: QweakSimGEM_WirePlaneHit.hh:98
QweakSimGEM_WirePlaneHit::StoreLocalMomentum
void StoreLocalMomentum(G4ThreeVector lpxyz)
Definition: QweakSimGEM_WirePlaneHit.hh:104
QweakSimGEM_WirePlaneHit::StoreOriginVertexMomentumDirection
void StoreOriginVertexMomentumDirection(G4ThreeVector pxyz)
Definition: QweakSimGEM_WirePlaneHit.hh:113
QweakSimGEM_WirePlaneHit
Handling of a Readoutplane Hit of the GEM detector (I know there is no wire plane ...
Definition: QweakSimGEM_WirePlaneHit.hh:40
QweakSimGEM_WirePlaneHit::StoreWorldMomentum
void StoreWorldMomentum(G4ThreeVector gpxyz)
Definition: QweakSimGEM_WirePlaneHit.hh:107
QweakSimGEM_WirePlaneHit::StoreOriginVertexPosition
void StoreOriginVertexPosition(G4ThreeVector xyz)
Definition: QweakSimGEM_WirePlaneHit.hh:110
QweakSimGEM_WirePlaneHit::StoreKineticEnergy
void StoreKineticEnergy(G4double ekin)
Definition: QweakSimGEM_WirePlaneHit.hh:135

+ Here is the call graph for this function:

Field Documentation

G4int QweakSimGEM_WirePlaneSD::HCID
private

Definition at line 57 of file QweakSimGEM_WirePlaneSD.hh.

Referenced by Initialize(), and QweakSimGEM_WirePlaneSD().

QweakSimGEM_WirePlane_HitsCollection* QweakSimGEM_WirePlaneSD::hitsCollection
private

Definition at line 55 of file QweakSimGEM_WirePlaneSD.hh.

Referenced by Initialize(), and ProcessHits().

The documentation for this class was generated from the following files:
