QweakSimUrbanMscModel Class Reference

#include <QweakSimUrbanMscModel.hh>

Inherits G4VMscModel.

Public Member Functions
	QweakSimUrbanMscModel (const G4String &nam="UrbanMsc96")
virtual	~QweakSimUrbanMscModel ()
void	Initialise (const G4ParticleDefinition *, const G4DataVector &)
void	StartTracking (G4Track *)
G4double	ComputeCrossSectionPerAtom (const G4ParticleDefinition *particle, G4double KineticEnergy, G4double AtomicNumber, G4double AtomicWeight=0., G4double cut=0., G4double emax=DBL_MAX)
G4ThreeVector &	SampleScattering (const G4ThreeVector &, G4double safety)
G4double	ComputeTruePathLengthLimit (const G4Track &track, G4double &currentMinimalStep)
G4double	ComputeGeomPathLength (G4double truePathLength)
G4double	ComputeTrueStepLength (G4double geomStepLength)
G4double	ComputeTheta0 (G4double truePathLength, G4double KineticEnergy)

Private Member Functions
G4double	SimpleScattering (G4double xmeanth, G4double x2meanth)
G4double	SampleCosineTheta (G4double trueStepLength, G4double KineticEnergy)
G4double	SampleDisplacement ()
G4double	LatCorrelation ()
void	SetParticle (const G4ParticleDefinition *)
void	UpdateCache ()
QweakSimUrbanMscModel &	operator= (const QweakSimUrbanMscModel &right)
	QweakSimUrbanMscModel (const QweakSimUrbanMscModel &)

Private Attributes
const G4ParticleDefinition *	particle
G4ParticleChangeForMSC *	fParticleChange
const G4MaterialCutsCouple *	couple
G4LossTableManager *	theManager
G4double	mass
G4double	charge
G4double	ChargeSquare
G4double	masslimite
G4double	lambdalimit
G4double	fr
G4double	taubig
G4double	tausmall
G4double	taulim
G4double	currentTau
G4double	tlimit
G4double	tlimitmin
G4double	tlimitminfix
G4double	tgeom
G4double	geombig
G4double	geommin
G4double	geomlimit
G4double	skindepth
G4double	smallstep
G4double	presafety
G4double	lambda0
G4double	lambdaeff
G4double	tPathLength
G4double	zPathLength
G4double	par1
G4double	par2
G4double	par3
G4double	stepmin
G4double	currentKinEnergy
G4double	currentRange
G4double	rangeinit
G4double	currentRadLength
G4double	theta0max
G4double	rellossmax
G4double	third
G4int	currentMaterialIndex
G4double	y
G4double	Zold
G4double	Zeff
G4double	Z2
G4double	Z23
G4double	lnZ
G4double	coeffth1
G4double	coeffth2
G4double	coeffc1
G4double	coeffc2
G4double	coeffc3
G4double	coeffc4
G4bool	firstStep
G4bool	inside
G4bool	insideskin
G4bool	ePolarized
G4ThreeVector	polarization
G4double	eEnergy
G4bool	debugPrint

Detailed Description

Definition at line 70 of file QweakSimUrbanMscModel.hh.

Constructor & Destructor Documentation

QweakSimUrbanMscModel::QweakSimUrbanMscModel

(

const G4String &

nam = "UrbanMsc96"

)

Definition at line 77 of file QweakSimUrbanMscModel.cc.

References charge, ChargeSquare, coeffc1, coeffc2, coeffc3, coeffc4, coeffth1, coeffth2, couple, currentKinEnergy, currentMaterialIndex, currentRadLength, currentRange, currentTau, firstStep, fParticleChange, fr, geombig, geomlimit, geommin, inside, insideskin, lambda0, lambdaeff, lambdalimit, lnZ, mass, masslimite, par1, par2, par3, particle, presafety, rangeinit, rellossmax, skindepth, smallstep, stepmin, taubig, taulim, tausmall, tgeom, theManager, theta0max, third, tlimit, tlimitmin, tlimitminfix, tPathLength, y, Z2, Z23, Zeff, Zold, and zPathLength.

  : G4VMscModel(nam)
{
  masslimite    = 0.6*MeV;
  lambdalimit   = 1.*mm;
  fr            = 0.02;
  taubig        = 8.0;
  tausmall      = 1.e-16;
  taulim        = 1.e-6;
  currentTau    = taulim;
  tlimitminfix  = 1.e-6*mm;
  stepmin       = tlimitminfix;
  smallstep     = 1.e10;
  currentRange  = 0. ;
  rangeinit     = 0.;
  tlimit        = 1.e10*mm;
  tlimitmin     = 10.*tlimitminfix;
  tgeom         = 1.e50*mm;
  geombig       = 1.e50*mm;
  geommin       = 1.e-3*mm;
  geomlimit     = geombig;
  presafety     = 0.*mm;
  //facsafety     = 0.50 ;

  y             = 0.;

  Zold          = 0.;
  Zeff          = 1.;
  Z2            = 1.;
  Z23           = 1.;
  lnZ           = 0.;
  coeffth1      = 0.;
  coeffth2      = 0.;
  coeffc1       = 0.;
  coeffc2       = 0.;
  coeffc3       = 0.;
  coeffc4       = 0.;

  theta0max     = pi/6.;
  rellossmax    = 0.50;
  third         = 1./3.;
  particle      = 0;
  theManager    = G4LossTableManager::Instance();
  firstStep     = true;
  inside        = false;
  insideskin    = false;

  skindepth = skin*stepmin;

  mass = proton_mass_c2;
  charge = ChargeSquare = 1.0;
  currentKinEnergy = currentRadLength = lambda0 = lambdaeff = tPathLength
    = zPathLength = par1 = par2 = par3 = 0;

  currentMaterialIndex = -1;
  fParticleChange = 0;
  couple = 0;
  SetSampleZ(false);
}

QweakSimUrbanMscModel::~QweakSimUrbanMscModel ( )

virtual

Definition at line 139 of file QweakSimUrbanMscModel.cc.

{}

QweakSimUrbanMscModel::QweakSimUrbanMscModel ( const QweakSimUrbanMscModel &  )

private

Member Function Documentation

G4double QweakSimUrbanMscModel::ComputeCrossSectionPerAtom	(	const G4ParticleDefinition *	particle,
		G4double	KineticEnergy,
		G4double	AtomicNumber,
		G4double	AtomicWeight = 0.,
		G4double	cut = 0.,
		G4double	emax = DBL_MAX
	)

Definition at line 168 of file QweakSimUrbanMscModel.cc.

References charge, ChargeSquare, mass, SetParticle(), and Z23.

{
  static const G4double sigmafactor =
    twopi*classic_electr_radius*classic_electr_radius;
  static const G4double epsfactor = 2.*electron_mass_c2*electron_mass_c2*
                            Bohr_radius*Bohr_radius/(hbarc*hbarc);
  static const G4double epsmin = 1.e-4 , epsmax = 1.e10;

  static const G4double Zdat[15] = { 4.,  6., 13., 20., 26., 29., 32., 38., 47.,
             50., 56., 64., 74., 79., 82. };

  static const G4double Tdat[22] = { 100*eV,  200*eV,  400*eV,  700*eV,
             1*keV,   2*keV,   4*keV,   7*keV,
             10*keV,  20*keV,  40*keV,  70*keV,
             100*keV, 200*keV, 400*keV, 700*keV,
             1*MeV,   2*MeV,   4*MeV,   7*MeV,
             10*MeV,  20*MeV};

  // corr. factors for e-/e+ lambda for T <= Tlim
  static const G4double celectron[15][22] =
          {{1.125,1.072,1.051,1.047,1.047,1.050,1.052,1.054,
            1.054,1.057,1.062,1.069,1.075,1.090,1.105,1.111,
            1.112,1.108,1.100,1.093,1.089,1.087            },
           {1.408,1.246,1.143,1.096,1.077,1.059,1.053,1.051,
            1.052,1.053,1.058,1.065,1.072,1.087,1.101,1.108,
            1.109,1.105,1.097,1.090,1.086,1.082            },
           {2.833,2.268,1.861,1.612,1.486,1.309,1.204,1.156,
            1.136,1.114,1.106,1.106,1.109,1.119,1.129,1.132,
            1.131,1.124,1.113,1.104,1.099,1.098            },
           {3.879,3.016,2.380,2.007,1.818,1.535,1.340,1.236,
            1.190,1.133,1.107,1.099,1.098,1.103,1.110,1.113,
            1.112,1.105,1.096,1.089,1.085,1.098            },
           {6.937,4.330,2.886,2.256,1.987,1.628,1.395,1.265,
            1.203,1.122,1.080,1.065,1.061,1.063,1.070,1.073,
            1.073,1.070,1.064,1.059,1.056,1.056            },
           {9.616,5.708,3.424,2.551,2.204,1.762,1.485,1.330,
            1.256,1.155,1.099,1.077,1.070,1.068,1.072,1.074,
            1.074,1.070,1.063,1.059,1.056,1.052            },
           {11.72,6.364,3.811,2.806,2.401,1.884,1.564,1.386,
            1.300,1.180,1.112,1.082,1.073,1.066,1.068,1.069,
            1.068,1.064,1.059,1.054,1.051,1.050            },
           {18.08,8.601,4.569,3.183,2.662,2.025,1.646,1.439,
            1.339,1.195,1.108,1.068,1.053,1.040,1.039,1.039,
            1.039,1.037,1.034,1.031,1.030,1.036            },
           {18.22,10.48,5.333,3.713,3.115,2.367,1.898,1.631,
            1.498,1.301,1.171,1.105,1.077,1.048,1.036,1.033,
            1.031,1.028,1.024,1.022,1.021,1.024            },
           {14.14,10.65,5.710,3.929,3.266,2.453,1.951,1.669,
            1.528,1.319,1.178,1.106,1.075,1.040,1.027,1.022,
            1.020,1.017,1.015,1.013,1.013,1.020            },
           {14.11,11.73,6.312,4.240,3.478,2.566,2.022,1.720,
            1.569,1.342,1.186,1.102,1.065,1.022,1.003,0.997,
            0.995,0.993,0.993,0.993,0.993,1.011            },
           {22.76,20.01,8.835,5.287,4.144,2.901,2.219,1.855,
            1.677,1.410,1.224,1.121,1.073,1.014,0.986,0.976,
            0.974,0.972,0.973,0.974,0.975,0.987            },
           {50.77,40.85,14.13,7.184,5.284,3.435,2.520,2.059,
            1.837,1.512,1.283,1.153,1.091,1.010,0.969,0.954,
            0.950,0.947,0.949,0.952,0.954,0.963            },
           {65.87,59.06,15.87,7.570,5.567,3.650,2.682,2.182,
            1.939,1.579,1.325,1.178,1.108,1.014,0.965,0.947,
            0.941,0.938,0.940,0.944,0.946,0.954            },
           {55.60,47.34,15.92,7.810,5.755,3.767,2.760,2.239,
            1.985,1.609,1.343,1.188,1.113,1.013,0.960,0.939,
            0.933,0.930,0.933,0.936,0.939,0.949            }};

  static const G4double cpositron[15][22] = {
           {2.589,2.044,1.658,1.446,1.347,1.217,1.144,1.110,
            1.097,1.083,1.080,1.086,1.092,1.108,1.123,1.131,
            1.131,1.126,1.117,1.108,1.103,1.100            },
           {3.904,2.794,2.079,1.710,1.543,1.325,1.202,1.145,
            1.122,1.096,1.089,1.092,1.098,1.114,1.130,1.137,
            1.138,1.132,1.122,1.113,1.108,1.102            },
           {7.970,6.080,4.442,3.398,2.872,2.127,1.672,1.451,
            1.357,1.246,1.194,1.179,1.178,1.188,1.201,1.205,
            1.203,1.190,1.173,1.159,1.151,1.145            },
           {9.714,7.607,5.747,4.493,3.815,2.777,2.079,1.715,
            1.553,1.353,1.253,1.219,1.211,1.214,1.225,1.228,
            1.225,1.210,1.191,1.175,1.166,1.174            },
           {17.97,12.95,8.628,6.065,4.849,3.222,2.275,1.820,
            1.624,1.382,1.259,1.214,1.202,1.202,1.214,1.219,
            1.217,1.203,1.184,1.169,1.160,1.151            },
           {24.83,17.06,10.84,7.355,5.767,3.707,2.546,1.996,
            1.759,1.465,1.311,1.252,1.234,1.228,1.238,1.241,
            1.237,1.222,1.201,1.184,1.174,1.159            },
           {23.26,17.15,11.52,8.049,6.375,4.114,2.792,2.155,
            1.880,1.535,1.353,1.281,1.258,1.247,1.254,1.256,
            1.252,1.234,1.212,1.194,1.183,1.170            },
           {22.33,18.01,12.86,9.212,7.336,4.702,3.117,2.348,
            2.015,1.602,1.385,1.297,1.268,1.251,1.256,1.258,
            1.254,1.237,1.214,1.195,1.185,1.179            },
           {33.91,24.13,15.71,10.80,8.507,5.467,3.692,2.808,
            2.407,1.873,1.564,1.425,1.374,1.330,1.324,1.320,
            1.312,1.288,1.258,1.235,1.221,1.205            },
           {32.14,24.11,16.30,11.40,9.015,5.782,3.868,2.917,
            2.490,1.925,1.596,1.447,1.391,1.342,1.332,1.327,
            1.320,1.294,1.264,1.240,1.226,1.214            },
           {29.51,24.07,17.19,12.28,9.766,6.238,4.112,3.066,
            2.602,1.995,1.641,1.477,1.414,1.356,1.342,1.336,
            1.328,1.302,1.270,1.245,1.231,1.233            },
           {38.19,30.85,21.76,15.35,12.07,7.521,4.812,3.498,
            2.926,2.188,1.763,1.563,1.484,1.405,1.382,1.371,
            1.361,1.330,1.294,1.267,1.251,1.239            },
           {49.71,39.80,27.96,19.63,15.36,9.407,5.863,4.155,
            3.417,2.478,1.944,1.692,1.589,1.480,1.441,1.423,
            1.409,1.372,1.330,1.298,1.280,1.258            },
           {59.25,45.08,30.36,20.83,16.15,9.834,6.166,4.407,
            3.641,2.648,2.064,1.779,1.661,1.531,1.482,1.459,
            1.442,1.400,1.354,1.319,1.299,1.272            },
           {56.38,44.29,30.50,21.18,16.51,10.11,6.354,4.542,
            3.752,2.724,2.116,1.817,1.692,1.554,1.499,1.474,
            1.456,1.412,1.364,1.328,1.307,1.282            }};

  //data/corrections for T > Tlim
  static const G4double Tlim = 10.*MeV;
  static const G4double beta2lim = Tlim*(Tlim+2.*electron_mass_c2)/
                      ((Tlim+electron_mass_c2)*(Tlim+electron_mass_c2));
  static const G4double bg2lim   = Tlim*(Tlim+2.*electron_mass_c2)/
                      (electron_mass_c2*electron_mass_c2);

  static const G4double sig0[15] = {
                     0.2672*barn,  0.5922*barn, 2.653*barn,  6.235*barn,
                      11.69*barn  , 13.24*barn  , 16.12*barn, 23.00*barn ,
          35.13*barn  , 39.95*barn  , 50.85*barn, 67.19*barn ,
                      91.15*barn  , 104.4*barn  , 113.1*barn};

  static const G4double hecorr[15] = {
                         120.70, 117.50, 105.00, 92.92, 79.23,  74.510,  68.29,
                          57.39,  41.97,  36.14, 24.53, 10.21,  -7.855, -16.84,
       -22.30};

  G4double sigma;
  SetParticle(part);

  Z23 = G4Pow::GetInstance()->Z23(G4lrint(AtomicNumber));

  // correction if particle .ne. e-/e+
  // compute equivalent kinetic energy
  // lambda depends on p*beta ....

  G4double eKineticEnergy = KineticEnergy;

  if(mass > electron_mass_c2)
  {
     G4double TAU = KineticEnergy/mass ;
     G4double c = mass*TAU*(TAU+2.)/(electron_mass_c2*(TAU+1.)) ;
     G4double w = c-2. ;
     G4double tau = 0.5*(w+sqrt(w*w+4.*c)) ;
     eKineticEnergy = electron_mass_c2*tau ;
  }

  G4double eTotalEnergy = eKineticEnergy + electron_mass_c2 ;
  G4double beta2 = eKineticEnergy*(eTotalEnergy+electron_mass_c2)
                                 /(eTotalEnergy*eTotalEnergy);
  G4double bg2   = eKineticEnergy*(eTotalEnergy+electron_mass_c2)
                                 /(electron_mass_c2*electron_mass_c2);

  G4double eps = epsfactor*bg2/Z23;

  if     (eps<epsmin)  sigma = 2.*eps*eps;
  else if(eps<epsmax)  sigma = log(1.+2.*eps)-2.*eps/(1.+2.*eps);
  else                 sigma = log(2.*eps)-1.+1./eps;

  sigma *= ChargeSquare*AtomicNumber*AtomicNumber/(beta2*bg2);

  // interpolate in AtomicNumber and beta2
  G4double c1,c2,cc1,cc2,corr;

  // get bin number in Z
  G4int iZ = 14;
  while ((iZ>=0)&&(Zdat[iZ]>=AtomicNumber)) iZ -= 1;
  if (iZ==14)                               iZ = 13;
  if (iZ==-1)                               iZ = 0 ;

  G4double ZZ1 = Zdat[iZ];
  G4double ZZ2 = Zdat[iZ+1];
  G4double ratZ = (AtomicNumber-ZZ1)*(AtomicNumber+ZZ1)/
                  ((ZZ2-ZZ1)*(ZZ2+ZZ1));

  if(eKineticEnergy <= Tlim)
  {
    // get bin number in T (beta2)
    G4int iT = 21;
    while ((iT>=0)&&(Tdat[iT]>=eKineticEnergy)) iT -= 1;
    if(iT==21)                                  iT = 20;
    if(iT==-1)                                  iT = 0 ;

    //  calculate betasquare values
    G4double T = Tdat[iT],   E = T + electron_mass_c2;
    G4double b2small = T*(E+electron_mass_c2)/(E*E);

    T = Tdat[iT+1]; E = T + electron_mass_c2;
    G4double b2big = T*(E+electron_mass_c2)/(E*E);
    G4double ratb2 = (beta2-b2small)/(b2big-b2small);

    if (charge < 0.)
    {
       c1 = celectron[iZ][iT];
       c2 = celectron[iZ+1][iT];
       cc1 = c1+ratZ*(c2-c1);

       c1 = celectron[iZ][iT+1];
       c2 = celectron[iZ+1][iT+1];
       cc2 = c1+ratZ*(c2-c1);

       corr = cc1+ratb2*(cc2-cc1);

       sigma *= sigmafactor/corr;
    }
    else
    {
       c1 = cpositron[iZ][iT];
       c2 = cpositron[iZ+1][iT];
       cc1 = c1+ratZ*(c2-c1);

       c1 = cpositron[iZ][iT+1];
       c2 = cpositron[iZ+1][iT+1];
       cc2 = c1+ratZ*(c2-c1);

       corr = cc1+ratb2*(cc2-cc1);

       sigma *= sigmafactor/corr;
    }
  }
  else
  {
    c1 = bg2lim*sig0[iZ]*(1.+hecorr[iZ]*(beta2-beta2lim))/bg2;
    c2 = bg2lim*sig0[iZ+1]*(1.+hecorr[iZ+1]*(beta2-beta2lim))/bg2;
    if((AtomicNumber >= ZZ1) && (AtomicNumber <= ZZ2))
      sigma = c1+ratZ*(c2-c1) ;
    else if(AtomicNumber < ZZ1)
      sigma = AtomicNumber*AtomicNumber*c1/(ZZ1*ZZ1);
    else if(AtomicNumber > ZZ2)
      sigma = AtomicNumber*AtomicNumber*c2/(ZZ2*ZZ2);
  }
  return sigma;

}

Here is the call graph for this function:

G4double QweakSimUrbanMscModel::ComputeGeomPathLength

(

G4double

truePathLength

)

Definition at line 677 of file QweakSimUrbanMscModel.cc.

References couple, currentKinEnergy, currentRange, firstStep, insideskin, lambda0, lambdaeff, mass, par1, par2, par3, particle, stepmin, taulim, tausmall, third, tlimitminfix, tPathLength, and zPathLength.

{
  firstStep = false;
  lambdaeff = lambda0;
  par1 = -1. ;
  par2 = par3 = 0. ;

  //  do the true -> geom transformation
  zPathLength = tPathLength;

  // z = t for very small tPathLength
  if(tPathLength < tlimitminfix) return zPathLength;

  // this correction needed to run MSC with eIoni and eBrem inactivated
  // and makes no harm for a normal run
  // It is already checked
  // if(tPathLength > currentRange)
  //  tPathLength = currentRange ;

  G4double tau   = tPathLength/lambda0 ;

  if ((tau <= tausmall) || insideskin) {
    zPathLength  = tPathLength;
    if(zPathLength > lambda0) zPathLength = lambda0;
    return zPathLength;
  }

  G4double zmean = tPathLength;
  if (tPathLength < currentRange*dtrl) {
    if(tau < taulim) zmean = tPathLength*(1.-0.5*tau) ;
    else             zmean = lambda0*(1.-exp(-tau));
    zPathLength = zmean ;
    return zPathLength;

  } else if(currentKinEnergy < mass || tPathLength == currentRange)  {
    par1 = 1./currentRange ;
    par2 = 1./(par1*lambda0) ;
    par3 = 1.+par2 ;
    if(tPathLength < currentRange)
      zmean = (1.-exp(par3*log(1.-tPathLength/currentRange)))/(par1*par3) ;
    else {
      zmean = 1./(par1*par3) ;
    }
    zPathLength = zmean ;
    return zPathLength;

  } else {
    G4double T1 = GetEnergy(particle,currentRange-tPathLength,couple);
    G4double lambda1 = GetTransportMeanFreePath(particle,T1);

    par1 = (lambda0-lambda1)/(lambda0*tPathLength);
    par2 = 1./(par1*lambda0);
    par3 = 1.+par2 ;
    zmean = (1.-exp(par3*log(lambda1/lambda0)))/(par1*par3);
  }

  zPathLength = zmean;

  //  sample z
  if(samplez)
  {
    const G4double  ztmax = 0.999 ;
    G4double zt = zmean/tPathLength ;

    if (tPathLength > stepmin && zt < ztmax)
    {
      G4double u,cz1;
      if(zt >= third)
      {
        G4double cz = 0.5*(3.*zt-1.)/(1.-zt) ;
        cz1 = 1.+cz ;
        G4double u0 = cz/cz1 ;
        G4double grej ;
        do {
            u = exp(log(G4UniformRand())/cz1) ;
            grej = exp(cz*log(u/u0))*(1.-u)/(1.-u0) ;
           } while (grej < G4UniformRand()) ;
      }
      else
      {
        u = 2.*zt*G4UniformRand();
      }
      zPathLength = tPathLength*u ;
    }
  }

  if(zPathLength > lambda0) { zPathLength = lambda0; }
  //G4cout<< "zPathLength= "<< zPathLength<< " lambda1= " << lambda0 << G4endl;
  return zPathLength;
}

G4double QweakSimUrbanMscModel::ComputeTheta0	(	G4double	truePathLength,
		G4double	KineticEnergy
	)

Definition at line 810 of file QweakSimUrbanMscModel.cc.

References charge, coeffth1, coeffth2, currentKinEnergy, currentRadLength, mass, and y.

Referenced by SampleCosineTheta().

{
  // for all particles take the width of the central part
  //  from a  parametrization similar to the Highland formula
  // ( Highland formula: Particle Physics Booklet, July 2002, eq. 26.10)
  static const G4double c_highland = 13.6*MeV ;
  G4double betacp = sqrt(currentKinEnergy*(currentKinEnergy+2.*mass)*
                         KineticEnergy*(KineticEnergy+2.*mass)/
                      ((currentKinEnergy+mass)*(KineticEnergy+mass)));
  y = trueStepLength/currentRadLength;
  G4double theta0 = c_highland*std::abs(charge)*sqrt(y)/betacp;
  y = log(y);
  // correction factor from e- scattering data
  G4double corr = coeffth1+coeffth2*y;

  theta0 *= corr ;

  return theta0;
}

Here is the caller graph for this function:

G4double QweakSimUrbanMscModel::ComputeTruePathLengthLimit	(	const G4Track &	track,
		G4double &	currentMinimalStep
	)

Definition at line 426 of file QweakSimUrbanMscModel.cc.

References couple, currentKinEnergy, currentMaterialIndex, currentRange, debugPrint, eEnergy, ePolarized, firstStep, fr, geombig, geomlimit, geommin, inside, insideskin, lambda0, lambdalimit, mass, masslimite, particle, polarization, presafety, rangeinit, skindepth, smallstep, stepmin, tgeom, tlimit, tlimitmin, tlimitminfix, and tPathLength.

{
  tPathLength = currentMinimalStep;
  const G4DynamicParticle* dp = track.GetDynamicParticle();

  //FIXME
  ePolarized=false;
  debugPrint=false;
  if(strcmp(track.GetParticleDefinition()->GetParticleName().data() , "e-") == 0)
    if(strcmp(track.GetMaterial()->GetName(),"PBA") == 0){
      if(track.GetPolarization().getR() >= 0.1) debugPrint=true;
      if(sqrt(pow(track.GetPolarization().getX(),2)+pow(track.GetPolarization().getY(),2))>0.01){
  ePolarized=true;
  polarization=track.GetPolarization();
  eEnergy=track.GetTotalEnergy();
      }
    }
  debugPrint=false;
  //FIXME

  G4StepPoint* sp = track.GetStep()->GetPreStepPoint();
  G4StepStatus stepStatus = sp->GetStepStatus();
  couple = track.GetMaterialCutsCouple();
  SetCurrentCouple(couple);
  currentMaterialIndex = couple->GetIndex();
  currentKinEnergy = dp->GetKineticEnergy();
  currentRange = GetRange(particle,currentKinEnergy,couple);
  lambda0 = GetTransportMeanFreePath(particle,currentKinEnergy);
  if(tPathLength > currentRange) { tPathLength = currentRange; }

  // stop here if small range particle
  if(inside || tPathLength < tlimitminfix) {
    return ConvertTrueToGeom(tPathLength, currentMinimalStep);
  }

  presafety = sp->GetSafety();
  /*
  G4cout << "G4Urban96::StepLimit tPathLength= "
     <<tPathLength<<" safety= " << presafety
          << " range= " <<currentRange<< " lambda= "<<lambda0
     << " Alg: " << steppingAlgorithm <<G4endl;
  */
  // far from geometry boundary
  if(currentRange < presafety)
    {
      inside = true;
      return ConvertTrueToGeom(tPathLength, currentMinimalStep);
    }

  // standard  version
  //
  if (steppingAlgorithm == fUseDistanceToBoundary)
    {
      //compute geomlimit and presafety
      geomlimit = ComputeGeomLimit(track, presafety, currentRange);

      // is it far from boundary ?
      if(currentRange < presafety)
  {
    inside = true;
    return ConvertTrueToGeom(tPathLength, currentMinimalStep);
  }

      smallstep += 1.;
      insideskin = false;

      if(firstStep || (stepStatus == fGeomBoundary))
        {
          rangeinit = currentRange;
          if(firstStep) smallstep = 1.e10;
          else  smallstep = 1.;

          //define stepmin here (it depends on lambda!)
          //rough estimation of lambda_elastic/lambda_transport
          G4double rat = currentKinEnergy/MeV ;
          rat = 1.e-3/(rat*(10.+rat)) ;
          //stepmin ~ lambda_elastic
          stepmin = rat*lambda0;
          skindepth = skin*stepmin;
          //define tlimitmin
          tlimitmin = 10.*stepmin;
          if(tlimitmin < tlimitminfix) tlimitmin = tlimitminfix;
    //G4cout << "rangeinit= " << rangeinit << " stepmin= " << stepmin
    //   << " tlimitmin= " << tlimitmin << " geomlimit= " << geomlimit <<G4endl;
          // constraint from the geometry
          if((geomlimit < geombig) && (geomlimit > geommin))
            {
              // geomlimit is a geometrical step length
              // transform it to true path length (estimation)
              if((1.-geomlimit/lambda0) > 0.)
                geomlimit = -lambda0*log(1.-geomlimit/lambda0)+tlimitmin ;

              if(stepStatus == fGeomBoundary)
                tgeom = geomlimit/facgeom;
              else
                tgeom = 2.*geomlimit/facgeom;
            }
            else
              tgeom = geombig;
        }


      //step limit
      tlimit = facrange*rangeinit;

      //lower limit for tlimit
      if(tlimit < tlimitmin) tlimit = tlimitmin;

      if(tlimit > tgeom) tlimit = tgeom;

      //G4cout << "tgeom= " << tgeom << " geomlimit= " << geomlimit
      //      << " tlimit= " << tlimit << " presafety= " << presafety << G4endl;

      // shortcut
      if((tPathLength < tlimit) && (tPathLength < presafety) &&
         (smallstep > skin) && (tPathLength < geomlimit-0.999*skindepth))
  return ConvertTrueToGeom(tPathLength, currentMinimalStep);

      // step reduction near to boundary
      if(smallstep <= skin)
  {
    tlimit = stepmin;
    insideskin = true;
  }
      else if(geomlimit < geombig)
  {
    if(geomlimit > skindepth)
      {
        if(tlimit > geomlimit-0.999*skindepth)
    tlimit = geomlimit-0.999*skindepth;
      }
    else
      {
        insideskin = true;
        if(tlimit > stepmin) tlimit = stepmin;
      }
  }

      if(tlimit < stepmin) tlimit = stepmin;

      // randomize 1st step or 1st 'normal' step in volume
      if(firstStep || ((smallstep == skin+1) && !insideskin))
        {
          G4double temptlimit = tlimit;
          if(temptlimit > tlimitmin)
          {
            do {
              temptlimit = G4RandGauss::shoot(tlimit,0.3*tlimit);
               } while ((temptlimit < tlimitmin) ||
                        (temptlimit > 2.*tlimit-tlimitmin));
          }
          else
            temptlimit = tlimitmin;
          if(tPathLength > temptlimit) tPathLength = temptlimit;
        }
      else
        {
          if(tPathLength > tlimit) tPathLength = tlimit  ;
        }

    }
    // for 'normal' simulation with or without magnetic field
    //  there no small step/single scattering at boundaries
  else if(steppingAlgorithm == fUseSafety)
    {
      // compute presafety again if presafety <= 0 and no boundary
      // i.e. when it is needed for optimization purposes
      if((stepStatus != fGeomBoundary) && (presafety < tlimitminfix))
  presafety = ComputeSafety(sp->GetPosition(),tPathLength);
      /*
      G4cout << "presafety= " << presafety
       << " firstStep= " << firstStep
       << " stepStatus= " << stepStatus
       << G4endl;
      */
      // is far from boundary
      if(currentRange < presafety)
        {
          inside = true;
          return ConvertTrueToGeom(tPathLength, currentMinimalStep);
        }

      if(firstStep || stepStatus == fGeomBoundary)
      {
        rangeinit = currentRange;
        fr = facrange;
        // 9.1 like stepping for e+/e- only (not for muons,hadrons)
        if(mass < masslimite)
        {
          if(lambda0 > currentRange)
            rangeinit = lambda0;
          if(lambda0 > lambdalimit)
            fr *= 0.75+0.25*lambda0/lambdalimit;
        }

        //lower limit for tlimit
        G4double rat = currentKinEnergy/MeV ;
        rat = 1.e-3/(rat*(10.+rat)) ;
        stepmin = lambda0*rat;
        tlimitmin = 10.*stepmin;
        if(tlimitmin < tlimitminfix) tlimitmin = tlimitminfix;
      }
      //step limit
      tlimit = fr*rangeinit;

      if(tlimit < facsafety*presafety)
        tlimit = facsafety*presafety;

      //lower limit for tlimit
      if(tlimit < tlimitmin) tlimit = tlimitmin;

      if(firstStep || stepStatus == fGeomBoundary)
      {
        G4double temptlimit = tlimit;
        if(temptlimit > tlimitmin)
        {
          do {
            temptlimit = G4RandGauss::shoot(tlimit,0.3*tlimit);
             } while ((temptlimit < tlimitmin) ||
                      (temptlimit > 2.*tlimit-tlimitmin));
        }
        else
          temptlimit = tlimitmin;

        if(tPathLength > temptlimit) tPathLength = temptlimit;
      }
      else
        if(tPathLength > tlimit) tPathLength = tlimit;
    }

  // version similar to 7.1 (needed for some experiments)
  else
    {
      if (stepStatus == fGeomBoundary)
  {
    if (currentRange > lambda0) tlimit = facrange*currentRange;
    else                        tlimit = facrange*lambda0;

    if(tlimit < tlimitmin) tlimit = tlimitmin;
    if(tPathLength > tlimit) tPathLength = tlimit;
  }
    }
  //G4cout << "tPathLength= " << tPathLength
  //   << " currentMinimalStep= " << currentMinimalStep << G4endl;
  return ConvertTrueToGeom(tPathLength, currentMinimalStep);
}

G4double QweakSimUrbanMscModel::ComputeTrueStepLength

(

G4double

geomStepLength

)

Definition at line 770 of file QweakSimUrbanMscModel.cc.

References currentRange, insideskin, lambda0, par1, par3, tausmall, tlimitminfix, tPathLength, and zPathLength.

{
  // step defined other than transportation
  if(geomStepLength == zPathLength)
    { return tPathLength; }

  zPathLength = geomStepLength;

  // t = z for very small step
  if(geomStepLength < tlimitminfix) {
    tPathLength = geomStepLength;

  // recalculation
  } else {

    G4double tlength = geomStepLength;
    if((geomStepLength > lambda0*tausmall) && !insideskin) {

      if(par1 <  0.) {
  tlength = -lambda0*log(1.-geomStepLength/lambda0) ;
      } else {
  if(par1*par3*geomStepLength < 1.) {
    tlength = (1.-exp(log(1.-par1*par3*geomStepLength)/par3))/par1 ;
  } else {
    tlength = currentRange;
  }
      }
      if(tlength < geomStepLength)   { tlength = geomStepLength; }
      else if(tlength > tPathLength) { tlength = tPathLength; }
    }
    tPathLength = tlength;
  }
  //G4cout << "Urban96::ComputeTrueLength: tPathLength= " << tPathLength
  //   << " step= " << geomStepLength << G4endl;

  return tPathLength;
}

void QweakSimUrbanMscModel::Initialise	(	const G4ParticleDefinition *	p,
		const G4DataVector &
	)

Definition at line 144 of file QweakSimUrbanMscModel.cc.

References fParticleChange, SetParticle(), skindepth, and stepmin.

{
  skindepth = skin*stepmin;
  //  trackID = -1;

  // set values of some data members
  SetParticle(p);
  /*
  if(p->GetPDGMass() > MeV) {
    G4cout << "### WARNING: QweakSimUrbanMscModel model is used for "
     << p->GetParticleName() << " !!! " << G4endl;
    G4cout << "###          This model should be used only for e+-"
     << G4endl;
  }
  */
  fParticleChange = GetParticleChangeForMSC(p);

  //samplez = true;
  //G4cout << "### QweakSimUrbanMscModel::Initialise done!" << G4endl;
}

Here is the call graph for this function:

G4double QweakSimUrbanMscModel::LatCorrelation ( )

private

Definition at line 1162 of file QweakSimUrbanMscModel.cc.

References currentTau, insideskin, lambdaeff, taubig, taulim, and tausmall.

Referenced by SampleScattering().

{
  static const G4double kappa = 2.5;
  static const G4double kappami1 = kappa-1.;

  G4double latcorr = 0.;
  if((currentTau >= tausmall) && !insideskin)
  {
    if(currentTau < taulim)
      latcorr = lambdaeff*kappa*currentTau*currentTau*
                (1.-(kappa+1.)*currentTau/3.)/3.;
    else
    {
      G4double etau = 0.;
      if(currentTau < taubig) etau = exp(-currentTau);
      latcorr = -kappa*currentTau;
      latcorr = exp(latcorr)/kappami1;
      latcorr += 1.-kappa*etau/kappami1 ;
      latcorr *= 2.*lambdaeff/3. ;
    }
  }

  return latcorr;
}

Here is the caller graph for this function:

QweakSimUrbanMscModel& QweakSimUrbanMscModel::operator= ( const QweakSimUrbanMscModel &  right )

private

G4double QweakSimUrbanMscModel::SampleCosineTheta ( G4double  trueStepLength, G4double  KineticEnergy  )

private

Definition at line 955 of file QweakSimUrbanMscModel.cc.

References coeffc1, coeffc2, coeffc3, coeffc4, ComputeTheta0(), couple, currentKinEnergy, currentRadLength, currentTau, lambda0, lambdaeff, particle, rellossmax, SimpleScattering(), taubig, tausmall, theta0max, tlimitmin, UpdateCache(), Zeff, and Zold.

Referenced by SampleScattering().

{
  G4double cth = 1. ;
  G4double tau = trueStepLength/lambda0;
  currentTau   = tau;
  lambdaeff    = lambda0;

  Zeff = couple->GetMaterial()->GetTotNbOfElectPerVolume()/
         couple->GetMaterial()->GetTotNbOfAtomsPerVolume() ;

  if(Zold != Zeff)
    UpdateCache();

  G4double lambda1 = GetTransportMeanFreePath(particle,KineticEnergy);
  if(std::fabs(lambda1/lambda0 - 1) > 0.01 && lambda1 > 0.)
  {
    // mean tau value
    tau = trueStepLength*log(lambda0/lambda1)/(lambda0-lambda1);
  }

  currentTau = tau ;
  lambdaeff = trueStepLength/currentTau;
  currentRadLength = couple->GetMaterial()->GetRadlen();

  if (tau >= taubig) { cth = -1.+2.*G4UniformRand(); }
  else if (tau >= tausmall) {
    static const G4double numlim = 0.01;
    G4double xmeanth, x2meanth;
    if(tau < numlim) {
      xmeanth = 1.0 - tau*(1.0 - 0.5*tau);
      x2meanth= 1.0 - tau*(5.0 - 6.25*tau)/3.;
    } else {
      xmeanth = exp(-tau);
      x2meanth = (1.+2.*exp(-2.5*tau))/3.;
    }
    G4double relloss = 1.-KineticEnergy/currentKinEnergy;

    if(relloss > rellossmax)
      return SimpleScattering(xmeanth,x2meanth);

    // is step extreme small ?
    G4bool extremesmallstep = false ;
    G4double tsmall = tlimitmin ;
    G4double theta0 = 0.;
    if(trueStepLength > tsmall) {
       theta0 = ComputeTheta0(trueStepLength,KineticEnergy);
    } else {
      G4double rate = trueStepLength/tsmall ;
      if(G4UniformRand() < rate) {
  theta0 = ComputeTheta0(tsmall,KineticEnergy);
  extremesmallstep = true ;
      }
    }
    //G4cout << "Theta0= " << theta0 << " theta0max= " << theta0max
    //       << "  sqrt(tausmall)= " << sqrt(tausmall) << G4endl;

    // protection for very small angles
    G4double theta2 = theta0*theta0;

    if(theta2 < tausmall) { return cth; }

    if(theta0 > theta0max) {
      return SimpleScattering(xmeanth,x2meanth);
    }

    G4double x = theta2*(1.0 - theta2/12.);
    if(theta2 > numlim) {
      G4double sth = 2*sin(0.5*theta0);
      x = sth*sth;
    }

    // parameter for tail
    G4double ltau= log(tau);
    G4double u   = exp(ltau/6.);
    if(extremesmallstep)  u = exp(log(tsmall/lambda0)/6.);
    G4double xx  = log(lambdaeff/currentRadLength);
    G4double xsi = coeffc1+u*(coeffc2+coeffc3*u)+coeffc4*xx;

    // tail should not be too big
    if(xsi < 1.9) {
      /*
      if(KineticEnergy > 20*MeV && xsi < 1.6) {
  G4cout << "QweakSimUrbanMscModel::SampleCosineTheta: E(GeV)= "
         << KineticEnergy/GeV
         << " !!** c= " << xsi
         << " **!! length(mm)= " << trueStepLength << " Zeff= " << Zeff
         << " " << couple->GetMaterial()->GetName()
         << " tau= " << tau << G4endl;
      }
      */
      xsi = 1.9;
    }

    G4double c = xsi;

    if(fabs(c-3.) < 0.001)      { c = 3.001; }
    else if(fabs(c-2.) < 0.001) { c = 2.001; }

    G4double c1 = c-1.;

    G4double ea = exp(-xsi);
    G4double eaa = 1.-ea ;
    G4double xmean1 = 1.-(1.-(1.+xsi)*ea)*x/eaa;
    G4double x0 = 1. - xsi*x;

    // G4cout << " xmean1= " << xmean1 << "  xmeanth= " << xmeanth << G4endl;

    if(xmean1 <= 0.999*xmeanth) {
      return SimpleScattering(xmeanth,x2meanth);
    }
    //from continuity of derivatives
    G4double b = 1.+(c-xsi)*x;

    G4double b1 = b+1.;
    G4double bx = c*x;

    G4double eb1 = pow(b1,c1);
    G4double ebx = pow(bx,c1);
    G4double d = ebx/eb1;

    G4double xmean2 = (x0 + d - (bx - b1*d)/(c-2.))/(1. - d);

    G4double f1x0 = ea/eaa;
    G4double f2x0 = c1/(c*(1. - d));
    G4double prob = f2x0/(f1x0+f2x0);

    G4double qprob = xmeanth/(prob*xmean1+(1.-prob)*xmean2);

    // sampling of costheta
    //G4cout << "c= " << c << " qprob= " << qprob << " eb1= " << eb1
    // << " c1= " << c1 << " b1= " << b1 << " bx= " << bx << " eb1= " << eb1
    //       << G4endl;
    if(G4UniformRand() < qprob)
    {
      G4double var = 0;
      if(G4UniformRand() < prob) {
        cth = 1.+log(ea+G4UniformRand()*eaa)*x;
      } else {
        var = (1.0 - d)*G4UniformRand();
        if(var < numlim*d) {
          var /= (d*c1);
          cth = -1.0 + var*(1.0 - 0.5*var*c)*(2. + (c - xsi)*x);
        } else {
          cth = 1. + x*(c - xsi - c*pow(var + d, -1.0/c1));
          //b-b1*bx/exp(log(ebx+(eb1-ebx)*G4UniformRand())/c1) ;
        }
      }
      if(KineticEnergy > 5*GeV && cth < 0.9) {
        G4cout << "QweakSimUrbanMscModel::SampleCosineTheta: E(GeV)= "
               << KineticEnergy/GeV
         << " 1-cosT= " << 1 - cth
               << " length(mm)= " << trueStepLength << " Zeff= " << Zeff
               << " tau= " << tau
         << " prob= " << prob << " var= " << var << G4endl;
  G4cout << "  c= " << c << " qprob= " << qprob << " eb1= " << eb1
         << " ebx= " << ebx
               << " c1= " << c1 << " b= " << b << " b1= " << b1
               << " bx= " << bx << " d= " << d
               << " ea= " << ea << " eaa= " << eaa << G4endl;
      }
    }
    else {
      cth = -1.+2.*G4UniformRand();
      if(KineticEnergy > 5*GeV) {
        G4cout << "QweakSimUrbanMscModel::SampleCosineTheta: E(GeV)= "
               << KineticEnergy/GeV
               << " length(mm)= " << trueStepLength << " Zeff= " << Zeff
               << " qprob= " << qprob << G4endl;
      }
    }
  }
  return cth ;
}

Here is the call graph for this function:

Here is the caller graph for this function:

G4double QweakSimUrbanMscModel::SampleDisplacement ( )

private

Definition at line 1150 of file QweakSimUrbanMscModel.cc.

References currentTau, insideskin, tausmall, tPathLength, and zPathLength.

Referenced by SampleScattering().

{
  G4double r = 0.0;
  if ((currentTau >= tausmall) && !insideskin) {
    G4double rmax = sqrt((tPathLength-zPathLength)*(tPathLength+zPathLength));
    r = rmax*exp(log(G4UniformRand())/3.);
  }
  return r;
}

Here is the caller graph for this function:

G4ThreeVector & QweakSimUrbanMscModel::SampleScattering	(	const G4ThreeVector &	oldDirection,
		G4double	safety
	)

Definition at line 834 of file QweakSimUrbanMscModel.cc.

References couple, currentKinEnergy, currentRange, debugPrint, eEnergy, ePolarized, fParticleChange, lambda0, LatCorrelation(), particle, polarization, SampleCosineTheta(), SampleDisplacement(), tausmall, tlimitminfix, and tPathLength.

{
  fDisplacement.set(0.0,0.0,0.0);
  G4double kineticEnergy = currentKinEnergy;
  if (tPathLength > currentRange*dtrl) {
    kineticEnergy = GetEnergy(particle,currentRange-tPathLength,couple);
  } else {
    kineticEnergy -= tPathLength*GetDEDX(particle,currentKinEnergy,couple);
  }

  if((kineticEnergy <= eV) || (tPathLength <= tlimitminfix) ||
     (tPathLength/tausmall < lambda0)) { return fDisplacement; }

  G4double cth  = SampleCosineTheta(tPathLength,kineticEnergy);

  // protection against 'bad' cth values
  if(std::fabs(cth) > 1.) { return fDisplacement; }

  // extra protection agaist high energy particles backscattered
    //G4cout << "Warning: large scattering E(MeV)= " << kineticEnergy
    //     << " s(mm)= " << tPathLength/mm
    //     << " 1-cosTheta= " << 1.0 - cth << G4endl;
    // do Gaussian central scattering
  //  if(kineticEnergy > 5*GeV && cth < 0.9) {
  /*
  if(cth < 1.0 - 1000*tPathLength/lambda0
     && cth < 0.8 && kineticEnergy > 20*MeV) {
    G4ExceptionDescription ed;
    ed << particle->GetParticleName()
       << " E(MeV)= " << kineticEnergy/MeV
       << " Step(mm)= " << tPathLength/mm
       << " in " << CurrentCouple()->GetMaterial()->GetName()
       << " CosTheta= " << cth
       << " is too big";
    G4Exception("QweakSimUrbanMscModel::SampleScattering","em0004",
    JustWarning, ed,"");

    if(kineticEnergy > GeV && cth < 0.0) {
    do {
      cth = 1.0 + 2*log(G4UniformRand())*tPathLength/lambda0;
    } while(cth < -1.0);
  }
*/

  G4double sth  = sqrt((1.0 - cth)*(1.0 + cth));
  G4double phi  = twopi*G4UniformRand();
  if(ePolarized){//FIXME
    if(debugPrint) G4cout<<" Urban fix "<<G4endl;
    G4double _prob=G4UniformRand();
    G4double _amplitude=1.0/eEnergy * sth *
      sqrt(pow(polarization.getX(),2)+pow(polarization.getY(),2));//scale by transvers polarization
    if(_amplitude > 1 ) _amplitude=1;
    if( _prob < _amplitude * sin(phi-pi) )
      phi-=pi;
    phi+= polarization.getPhi() - oldDirection.getPhi();
    if(phi<0) phi+=twopi;
    else if(phi>twopi) phi=fmod(phi,twopi);
  }//FIXME

  G4double dirx = sth*cos(phi);
  G4double diry = sth*sin(phi);

  G4ThreeVector newDirection(dirx,diry,cth);
  newDirection.rotateUz(oldDirection);
  fParticleChange->ProposeMomentumDirection(newDirection);

  //FIXME
  if(debugPrint){
  G4cout<<" Urban96 cth, th, phi old.angle(new)" << cth << " " << acos(cth) << " " << phi << " " <<oldDirection.angle(newDirection) << G4endl;
  G4cout<<" Urban96: old dir: R th phi "<<oldDirection.getR()<<" "<<oldDirection.getTheta()<<" "<<oldDirection.getPhi()<<G4endl;
  G4cout<<" Urban96: new dir: R th phi "<<newDirection.getR()<<" "<<newDirection.getTheta()<<" "<<newDirection.getPhi()<<G4endl;
  }//FIXME
  /*
  G4cout << "QweakSimUrbanMscModel::SampleSecondaries: e(MeV)= " << kineticEnergy
   << " sinTheta= " << sth << " safety(mm)= " << safety
   << " trueStep(mm)= " << tPathLength
   << " geomStep(mm)= " << zPathLength
   << G4endl;
  */
  if (latDisplasment && safety > tlimitminfix) {

    G4double r = SampleDisplacement();
    /*
    G4cout << "QweakSimUrbanMscModel::SampleSecondaries: e(MeV)= " << kineticEnergy
     << " sinTheta= " << sth << " r(mm)= " << r
           << " trueStep(mm)= " << tPathLength
           << " geomStep(mm)= " << zPathLength
           << G4endl;
    */
    if(r > 0.)
      {
        G4double latcorr = LatCorrelation();
        if(latcorr > r) latcorr = r;

        // sample direction of lateral displacement
        // compute it from the lateral correlation
        G4double Phi = 0.;
        if(std::abs(r*sth) < latcorr)
          Phi  = twopi*G4UniformRand();
        else
        {
          G4double psi = std::acos(latcorr/(r*sth));
          if(G4UniformRand() < 0.5)
            Phi = phi+psi;
          else
            Phi = phi-psi;
        }

        dirx = std::cos(Phi);
        diry = std::sin(Phi);

        fDisplacement.set(r*dirx,r*diry,0.0);
        fDisplacement.rotateUz(oldDirection);
      }
  }
  return fDisplacement;
}

Here is the call graph for this function:

void QweakSimUrbanMscModel::SetParticle ( const G4ParticleDefinition *  p )

inlineprivate

Definition at line 186 of file QweakSimUrbanMscModel.hh.

References charge, ChargeSquare, mass, and particle.

Referenced by ComputeCrossSectionPerAtom(), Initialise(), and StartTracking().

{
  if (p != particle) {
    particle = p;
    mass = p->GetPDGMass();
    charge = p->GetPDGCharge()/CLHEP::eplus;
    ChargeSquare = charge*charge;
  }
}

Here is the caller graph for this function:

G4double QweakSimUrbanMscModel::SimpleScattering ( G4double  xmeanth, G4double  x2meanth  )

private

Definition at line 1132 of file QweakSimUrbanMscModel.cc.

Referenced by SampleCosineTheta().

{
  // 'large angle scattering'
  // 2 model functions with correct xmean and x2mean
  G4double a = (2.*xmeanth+9.*x2meanth-3.)/(2.*xmeanth-3.*x2meanth+1.);
  G4double prob = (a+2.)*xmeanth/a;

  // sampling
  G4double cth = 1.;
  if(G4UniformRand() < prob)
    cth = -1.+2.*exp(log(G4UniformRand())/(a+1.));
  else
    cth = -1.+2.*G4UniformRand();
  return cth;
}

Here is the caller graph for this function:

void QweakSimUrbanMscModel::StartTracking

(

G4Track *

track

)

Definition at line 413 of file QweakSimUrbanMscModel.cc.

References firstStep, geombig, inside, insideskin, SetParticle(), stepmin, tlimit, tlimitmin, and tlimitminfix.

{
  SetParticle(track->GetDynamicParticle()->GetDefinition());
  firstStep = true;
  inside = false;
  insideskin = false;
  tlimit = geombig;
  stepmin = tlimitminfix ;
  tlimitmin = 10.*stepmin ;
}

Here is the call graph for this function:

void QweakSimUrbanMscModel::UpdateCache ( )

inlineprivate

Definition at line 199 of file QweakSimUrbanMscModel.hh.

References coeffc1, coeffc2, coeffc3, coeffc4, coeffth1, coeffth2, lnZ, Z2, Z23, Zeff, and Zold.

Referenced by SampleCosineTheta().

{
    lnZ = std::log(Zeff);
    // correction in theta0 formula
    G4double facz = 0.74845+0.13354*exp(log(Zeff)/6.);
    coeffth1 = facz*(1. - 8.7780e-2/Zeff);
    coeffth2 = facz*(4.0780e-2 + 1.7315e-4*Zeff);

    // tail parameters
    G4double Z13 = std::exp(lnZ/3.);
    coeffc1  = 2.3785    - Z13*(4.1981e-1 - Z13*6.3100e-2);
    coeffc2  = 4.7526e-1 + Z13*(1.7694    - Z13*3.3885e-1);
    coeffc3  = 2.3683e-1 - Z13*(1.8111    - Z13*3.2774e-1);
    coeffc4  = 1.7888e-2 + Z13*(1.9659e-2 - Z13*2.6664e-3);

    Z2   = Zeff*Zeff;
    Z23  = Z13*Z13;

    Zold = Zeff;
}

Here is the caller graph for this function:

Field Documentation

G4double QweakSimUrbanMscModel::charge

private

Definition at line 127 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeCrossSectionPerAtom(), ComputeTheta0(), QweakSimUrbanMscModel(), and SetParticle().

G4double QweakSimUrbanMscModel::ChargeSquare

private

Definition at line 127 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeCrossSectionPerAtom(), QweakSimUrbanMscModel(), and SetParticle().

G4double QweakSimUrbanMscModel::coeffc1

private

Definition at line 169 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), SampleCosineTheta(), and UpdateCache().

G4double QweakSimUrbanMscModel::coeffc2

private

Definition at line 169 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), SampleCosineTheta(), and UpdateCache().

G4double QweakSimUrbanMscModel::coeffc3

private

Definition at line 169 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), SampleCosineTheta(), and UpdateCache().

G4double QweakSimUrbanMscModel::coeffc4

private

Definition at line 169 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), SampleCosineTheta(), and UpdateCache().

G4double QweakSimUrbanMscModel::coeffth1

private

Definition at line 168 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTheta0(), QweakSimUrbanMscModel(), and UpdateCache().

G4double QweakSimUrbanMscModel::coeffth2

private

Definition at line 168 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTheta0(), QweakSimUrbanMscModel(), and UpdateCache().

const G4MaterialCutsCouple* QweakSimUrbanMscModel::couple

private

Definition at line 123 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), SampleCosineTheta(), and SampleScattering().

G4double QweakSimUrbanMscModel::currentKinEnergy

private

Definition at line 155 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTheta0(), ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), SampleCosineTheta(), and SampleScattering().

G4int QweakSimUrbanMscModel::currentMaterialIndex

private

Definition at line 163 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::currentRadLength

private

Definition at line 158 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTheta0(), QweakSimUrbanMscModel(), and SampleCosineTheta().

G4double QweakSimUrbanMscModel::currentRange

private

Definition at line 156 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), ComputeTrueStepLength(), QweakSimUrbanMscModel(), and SampleScattering().

G4double QweakSimUrbanMscModel::currentTau

private

Definition at line 133 of file QweakSimUrbanMscModel.hh.

Referenced by LatCorrelation(), QweakSimUrbanMscModel(), SampleCosineTheta(), and SampleDisplacement().

G4bool QweakSimUrbanMscModel::debugPrint

private

Definition at line 178 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and SampleScattering().

G4double QweakSimUrbanMscModel::eEnergy

private

Definition at line 177 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and SampleScattering().

G4bool QweakSimUrbanMscModel::ePolarized

private

Definition at line 175 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and SampleScattering().

G4bool QweakSimUrbanMscModel::firstStep

private

Definition at line 171 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), and StartTracking().

G4ParticleChangeForMSC* QweakSimUrbanMscModel::fParticleChange

private

Definition at line 121 of file QweakSimUrbanMscModel.hh.

Referenced by Initialise(), QweakSimUrbanMscModel(), and SampleScattering().

G4double QweakSimUrbanMscModel::fr

private

Definition at line 128 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::geombig

private

Definition at line 139 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), and StartTracking().

G4double QweakSimUrbanMscModel::geomlimit

private

Definition at line 141 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::geommin

private

Definition at line 140 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4bool QweakSimUrbanMscModel::inside

private

Definition at line 172 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), and StartTracking().

G4bool QweakSimUrbanMscModel::insideskin

private

Definition at line 173 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), ComputeTrueStepLength(), LatCorrelation(), QweakSimUrbanMscModel(), SampleDisplacement(), and StartTracking().

G4double QweakSimUrbanMscModel::lambda0

private

Definition at line 147 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), ComputeTrueStepLength(), QweakSimUrbanMscModel(), SampleCosineTheta(), and SampleScattering().

G4double QweakSimUrbanMscModel::lambdaeff

private

Definition at line 148 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), LatCorrelation(), QweakSimUrbanMscModel(), and SampleCosineTheta().

G4double QweakSimUrbanMscModel::lambdalimit

private

Definition at line 128 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::lnZ

private

Definition at line 167 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), and UpdateCache().

G4double QweakSimUrbanMscModel::mass

private

Definition at line 126 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeCrossSectionPerAtom(), ComputeGeomPathLength(), ComputeTheta0(), ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), and SetParticle().

G4double QweakSimUrbanMscModel::masslimite

private

Definition at line 128 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::par1

private

Definition at line 151 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTrueStepLength(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::par2

private

Definition at line 151 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::par3

private

Definition at line 151 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTrueStepLength(), and QweakSimUrbanMscModel().

const G4ParticleDefinition* QweakSimUrbanMscModel::particle

private

Definition at line 120 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), SampleCosineTheta(), SampleScattering(), and SetParticle().

G4ThreeVector QweakSimUrbanMscModel::polarization

private

Definition at line 176 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and SampleScattering().

G4double QweakSimUrbanMscModel::presafety

private

Definition at line 145 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::rangeinit

private

Definition at line 157 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::rellossmax

private

Definition at line 160 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), and SampleCosineTheta().

G4double QweakSimUrbanMscModel::skindepth

private

Definition at line 142 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), Initialise(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::smallstep

private

Definition at line 143 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::stepmin

private

Definition at line 153 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), Initialise(), QweakSimUrbanMscModel(), and StartTracking().

G4double QweakSimUrbanMscModel::taubig

private

Definition at line 130 of file QweakSimUrbanMscModel.hh.

Referenced by LatCorrelation(), QweakSimUrbanMscModel(), and SampleCosineTheta().

G4double QweakSimUrbanMscModel::taulim

private

Definition at line 132 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), LatCorrelation(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::tausmall

private

Definition at line 131 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTrueStepLength(), LatCorrelation(), QweakSimUrbanMscModel(), SampleCosineTheta(), SampleDisplacement(), and SampleScattering().

G4double QweakSimUrbanMscModel::tgeom

private

Definition at line 137 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), and QweakSimUrbanMscModel().

G4LossTableManager* QweakSimUrbanMscModel::theManager

private

Definition at line 124 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::theta0max

private

Definition at line 160 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), and SampleCosineTheta().

G4double QweakSimUrbanMscModel::third

private

Definition at line 161 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::tlimit

private

Definition at line 134 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), and StartTracking().

G4double QweakSimUrbanMscModel::tlimitmin

private

Definition at line 135 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTruePathLengthLimit(), QweakSimUrbanMscModel(), SampleCosineTheta(), and StartTracking().

G4double QweakSimUrbanMscModel::tlimitminfix

private

Definition at line 136 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), ComputeTrueStepLength(), QweakSimUrbanMscModel(), SampleScattering(), and StartTracking().

G4double QweakSimUrbanMscModel::tPathLength

private

Definition at line 149 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTruePathLengthLimit(), ComputeTrueStepLength(), QweakSimUrbanMscModel(), SampleDisplacement(), and SampleScattering().

G4double QweakSimUrbanMscModel::y

private

Definition at line 165 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeTheta0(), and QweakSimUrbanMscModel().

G4double QweakSimUrbanMscModel::Z2

private

Definition at line 167 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), and UpdateCache().

G4double QweakSimUrbanMscModel::Z23

private

Definition at line 167 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeCrossSectionPerAtom(), QweakSimUrbanMscModel(), and UpdateCache().

G4double QweakSimUrbanMscModel::Zeff

private

Definition at line 167 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), SampleCosineTheta(), and UpdateCache().

G4double QweakSimUrbanMscModel::Zold

private

Definition at line 166 of file QweakSimUrbanMscModel.hh.

Referenced by QweakSimUrbanMscModel(), SampleCosineTheta(), and UpdateCache().

G4double QweakSimUrbanMscModel::zPathLength

private

Definition at line 150 of file QweakSimUrbanMscModel.hh.

Referenced by ComputeGeomPathLength(), ComputeTrueStepLength(), QweakSimUrbanMscModel(), and SampleDisplacement().

---

The documentation for this class was generated from the following files:

• QweakSimUrbanMscModel.hh
• QweakSimUrbanMscModel.cc
