Scans the input file for /Target/xyz commands. More...

#include <QweakSimTargetMessenger.hh>

Inherits G4UImessenger.

Collaboration diagram for QweakSimTargetMessenger:

Public Member Functions
	QweakSimTargetMessenger (QweakSimTarget *)

	~QweakSimTargetMessenger ()

void	SetNewValue (G4UIcommand *, G4String)

Private Attributes
QweakSimTarget *	myTarget

G4UIdirectory *	TargetDir

G4UIcmdWithAString *	TargCmd

G4UIcmdWithAString *	TargMatCmd

G4UIcmdWithAString *	TargCellMatCmd

G4UIcmdWithAString *	TargEntWinMatCmd

G4UIcmdWithAString *	TargExtWinMatCmd

G4UIcmdWithAString *	TargExtWinNipMatCmd

G4UIcmdWithADoubleAndUnit *	TargZPosCmd

G4UIcmdWithADoubleAndUnit *	TargLenCmd

Detailed Description

Scans the input file for /Target/xyz commands.

Placeholder for a long explaination

Definition at line 60 of file QweakSimTargetMessenger.hh.

Constructor & Destructor Documentation

QweakSimTargetMessenger::QweakSimTargetMessenger ( QweakSimTarget * myTar )

Definition at line 30 of file QweakSimTargetMessenger.cc.

References TargCellMatCmd, TargCmd, TargEntWinMatCmd, TargetDir, TargExtWinMatCmd, TargExtWinNipMatCmd, TargLenCmd, TargMatCmd, and TargZPosCmd.

 :myTarget(myTar)
 {
  // Target related
   TargetDir = new G4UIdirectory("/Target/");
   TargetDir -> SetGuidance("target control.");

   TargCmd = new G4UIcmdWithAString("/Target/SetTarget",this);
   TargCmd->SetGuidance("Select Target.");
   TargCmd->SetParameterName("choice",false);
   TargCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargZPosCmd =  new G4UIcmdWithADoubleAndUnit("/Target/SetCenterPositionInZ",this);
   TargZPosCmd->SetGuidance("Set the Z position of the target center");
   TargZPosCmd->SetParameterName("Size",true);
   //TargZPosCmd->SetRange("Size>=0.");
   TargZPosCmd->SetUnitCategory("Length");
   TargZPosCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargMatCmd = new G4UIcmdWithAString("/Target/SetTargetMaterial",this);
   TargMatCmd->SetGuidance("Select Material of the Target.");
   TargMatCmd->SetParameterName("choice",false);
   TargMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargCellMatCmd = new G4UIcmdWithAString("/Target/SetTargetCellMaterial",this);
   TargCellMatCmd->SetGuidance("Select Material of the Target Cell.");
   TargCellMatCmd->SetParameterName("choice",false);
   TargCellMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargEntWinMatCmd = new G4UIcmdWithAString("/Target/SetTargetEntranceWindowMaterial",this);
   TargEntWinMatCmd->SetGuidance("Select Material of the Target Entrance Window.");
   TargEntWinMatCmd->SetParameterName("choice",false);
   TargEntWinMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargExtWinMatCmd = new G4UIcmdWithAString("/Target/SetTargetExitWindowMaterial",this);
   TargExtWinMatCmd->SetGuidance("Select Material of the Target Exit Window.");
   TargExtWinMatCmd->SetParameterName("choice",false);
   TargExtWinMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargExtWinNipMatCmd = new G4UIcmdWithAString("/Target/SetTargetExitWindowNippleMaterial",this);
   TargExtWinNipMatCmd->SetGuidance("Select Material of the Target Exit Window.");
   TargExtWinNipMatCmd->SetParameterName("choice",false);
   TargExtWinNipMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

   TargLenCmd =  new G4UIcmdWithADoubleAndUnit("/Target/SetTargetLength",this);
   TargLenCmd->SetGuidance("Set the length of the target center");
   TargLenCmd->SetParameterName("Size",true);
   TargLenCmd->SetUnitCategory("Length");
   TargLenCmd->AvailableForStates(G4State_PreInit,G4State_Idle);
 }

QweakSimTargetMessenger::~QweakSimTargetMessenger ( )

Definition at line 83 of file QweakSimTargetMessenger.cc.

References TargCellMatCmd, TargCmd, TargEntWinMatCmd, TargetDir, TargExtWinMatCmd, TargExtWinNipMatCmd, TargLenCmd, TargMatCmd, and TargZPosCmd.

 {
   delete TargCmd;
   delete TargZPosCmd;
   delete TargMatCmd;
   delete TargCellMatCmd;
   delete TargEntWinMatCmd;
   delete TargExtWinMatCmd;
   delete TargExtWinNipMatCmd;
   delete TargetDir;
   delete TargLenCmd;
 }

Member Function Documentation

void QweakSimTargetMessenger::SetNewValue	(	G4UIcommand *	command,
		G4String	newValue
	)

Definition at line 98 of file QweakSimTargetMessenger.cc.

References myTarget, QweakSimTarget::SetTarget(), QweakSimTarget::SetTargetCellMaterial(), QweakSimTarget::SetTargetCenterPositionInZ(), QweakSimTarget::SetTargetEntranceWindowMaterial(), QweakSimTarget::SetTargetExitWindowMaterial(), QweakSimTarget::SetTargetExitWindowNippleMaterial(), QweakSimTarget::SetTargetLength(), QweakSimTarget::SetTargetMaterial(), TargCellMatCmd, TargCmd, TargEntWinMatCmd, TargExtWinMatCmd, TargExtWinNipMatCmd, TargLenCmd, TargMatCmd, and TargZPosCmd.

 {
   G4cout << "#### Calling QweakSimTargetMessenger::SetNewValue() " << newValue << G4endl;

   if( command == TargCmd )
   {
       G4cout << "#### Messenger: Setting Target to " << newValue << G4endl;

       myTarget->SetTarget(newValue);
   }

   if( command == TargZPosCmd )
    {
      G4cout << "#### Messenger: Setting Target Z position to " << newValue << G4endl;

      myTarget->SetTargetCenterPositionInZ(TargZPosCmd->GetNewDoubleValue(newValue));
    }

   if( command == TargMatCmd )
   {
       G4cout << "#### Messenger: Setting Target Material to " << newValue << G4endl;

       myTarget->SetTargetMaterial(newValue);
   }


   if( command == TargCellMatCmd )
   {
      G4cout << "#### Messenger: Setting Target Cell Material to " << newValue << G4endl;

      myTarget->SetTargetCellMaterial(newValue);
   }

   if( command == TargEntWinMatCmd )
   {
      G4cout << "#### Messenger: Setting Target Entrance Window Material to " << newValue << G4endl;

      myTarget->SetTargetEntranceWindowMaterial(newValue);
   }

   if( command == TargExtWinMatCmd )
   {
      G4cout << "#### Messenger: Setting Target Exit Window Material to " << newValue << G4endl;

      myTarget->SetTargetExitWindowMaterial(newValue);
   }

   if( command == TargExtWinNipMatCmd )
   {
      G4cout << "#### Messenger: Setting Target Exit Window Material to " << newValue << G4endl;

      myTarget->SetTargetExitWindowNippleMaterial(newValue);
   }

   if( command == TargLenCmd )
    {
      G4cout << "#### Messenger: Setting Target length to " << newValue << G4endl;

      myTarget->SetTargetLength(TargLenCmd->GetNewDoubleValue(newValue));
    }


   G4cout << "#### Leaving QweakSimTargetMessenger::SetNewValue() " << newValue << G4endl;
 }
