QweakSimEPEventMessenger Class Reference

UI control for the event generator. More...

#include <QweakSimEPEventMessenger.hh>

Inherits G4UImessenger.

Collaboration diagram for QweakSimEPEventMessenger:

Public Member Functions
	QweakSimEPEventMessenger (QweakSimEPEvent *)
	~QweakSimEPEventMessenger ()
void	SetNewValue (G4UIcommand *, G4String)

Private Attributes
QweakSimEPEvent *	pQweakSimEPEvent
G4UIdirectory *	EventGenDir
G4UIcmdWithAnInteger *	verboseCmd
G4UIcmdWithAnInteger *	SelectReactionType_Cmd
G4UIcmdWithAnInteger *	SelectReactionRegion_Cmd
G4UIcmdWithAnInteger *	SelectOctant_Cmd
G4UIcmdWithAnInteger *	SelectIsotropy_Cmd
G4UIcmdWithADoubleAndUnit *	ThetaMinLimitCmd
G4UIcmdWithADoubleAndUnit *	ThetaMaxLimitCmd
G4UIcmdWithADoubleAndUnit *	PhiMinLimitCmd
G4UIcmdWithADoubleAndUnit *	PhiMaxLimitCmd
G4UIcmdWithADoubleAndUnit *	EPrimeMinLimitCmd
G4UIcmdWithADoubleAndUnit *	EPrimeMaxLimitCmd
G4UIcmdWithADoubleAndUnit *	SetBeamEnergyCmd
G4UIcmdWithADoubleAndUnit *	SetElasticPeakDeltaECmd
G4UIcmdWithADoubleAndUnit *	SetSchwingerDeltaECmd

Detailed Description

UI control for the event generator.

Definition at line 40 of file QweakSimEPEventMessenger.hh.

Constructor & Destructor Documentation

QweakSimEPEventMessenger::QweakSimEPEventMessenger

(

QweakSimEPEvent *

pEPEvent

)

Definition at line 24 of file QweakSimEPEventMessenger.cc.

References EPrimeMaxLimitCmd, EPrimeMinLimitCmd, EventGenDir, PhiMaxLimitCmd, PhiMinLimitCmd, SelectIsotropy_Cmd, SelectOctant_Cmd, SelectReactionRegion_Cmd, SelectReactionType_Cmd, SetBeamEnergyCmd, SetElasticPeakDeltaECmd, SetSchwingerDeltaECmd, ThetaMaxLimitCmd, ThetaMinLimitCmd, and verboseCmd.

:pQweakSimEPEvent(pEPEvent)
{
  G4cout << "###### Calling QweakSimEPEventMessenger::QweakSimEPEventMessenger() " << G4endl;

  EventGenDir = new G4UIdirectory("/EventGen/");
  EventGenDir->SetGuidance("Event generator control");

  verboseCmd = new G4UIcmdWithAnInteger("/EventGen/verbose",this);
  verboseCmd->SetGuidance("set verbose for event generator");
  verboseCmd->SetParameterName("verbose",true);
  verboseCmd->SetDefaultValue(1);
  verboseCmd->SetRange("verbose>=0");
  verboseCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  SelectOctant_Cmd = new G4UIcmdWithAnInteger("/EventGen/SelectOctant",this);
  SelectOctant_Cmd->SetGuidance("Select octant for primaries (=0: all octants, >8: two opposite octants)");
  SelectOctant_Cmd->SetParameterName("SelectOctant",true);
  SelectOctant_Cmd->SetDefaultValue(0);
  SelectOctant_Cmd->SetRange("SelectOctant>=0");
  SelectOctant_Cmd->AvailableForStates(G4State_PreInit,G4State_Idle);

// Isotropy:     0 - uniform phi angle and uniform theta angle, independent to each other
//               1 - uniform in any solid angle (i.e. uniform phi, but phi-denendent theta)
  SelectIsotropy_Cmd = new G4UIcmdWithAnInteger("/EventGen/SelectIsotropy",this);
  SelectIsotropy_Cmd->SetGuidance("Select isotropy for generator");
  SelectIsotropy_Cmd->SetParameterName("SelectIsotropy",true);
  SelectIsotropy_Cmd->SetDefaultValue(1);
  SelectIsotropy_Cmd->SetRange("SelectIsotropy>=0 && SelectIsotropy<=1");
  SelectIsotropy_Cmd->AvailableForStates(G4State_PreInit,G4State_Idle);

//    ReactionType:            1 - LH2 elastic
//                             2 - Al window elastic
//                             3 - Al window quasi-elastic proton
//                             4 - Al window quasi-elastic neutron
//
//    ReactionRegion:          1 - LH2 target
//                             2 - entrance window
//                             3 - exit window

  SelectReactionType_Cmd = new G4UIcmdWithAnInteger("/EventGen/SelectReactionType",this);
  SelectReactionType_Cmd->SetGuidance("Select reaction type");
  SelectReactionType_Cmd->SetGuidance("0 - Combination of all reactions");
  SelectReactionType_Cmd->SetGuidance("1 - LH2 elastic (default)");
  SelectReactionType_Cmd->SetGuidance("2 - Al elastic");
  SelectReactionType_Cmd->SetGuidance("3 - Al quasi-elastic (proton)");
  SelectReactionType_Cmd->SetGuidance("4 - Al quasi-elastic (neutron)");
  SelectReactionType_Cmd->SetGuidance("5 - LH2 inelastic (delta resonance)");
  SelectReactionType_Cmd->SetGuidance("6 - Moller scattering");
  SelectReactionType_Cmd->SetGuidance("7 - LH2 radiative lookup table (3.35 GeV)");
  SelectReactionType_Cmd->SetGuidance("8 - Al quasi-elastic (Bosted)");

  SelectReactionType_Cmd->SetGuidance("88 - LH2 pion photo-production (3.35 GeV)");
  SelectReactionType_Cmd->SetGuidance("89 - Al pion photo-production (3.35 GeV)");
  SelectReactionType_Cmd->SetGuidance("90 - C pion photo-production (3.35 GeV)");

  SelectReactionType_Cmd->SetGuidance("20 - C Elastic A (Harmonic Well)");
  SelectReactionType_Cmd->SetGuidance("21 - C Elastic B (FB empirical fit)");
  SelectReactionType_Cmd->SetGuidance("22 - C GDR");
  SelectReactionType_Cmd->SetGuidance("23 - C 4.4 MeV Excitation");
  SelectReactionType_Cmd->SetGuidance("24 - C 7.7 MeV Excitation");
  SelectReactionType_Cmd->SetGuidance("25 - C 9.6 MeV Excitation");

  SelectReactionType_Cmd->SetParameterName("SelectReactionType",true);
  SelectReactionType_Cmd->SetDefaultValue(1);
  SelectReactionType_Cmd->SetRange("SelectReactionType>=0");
  SelectReactionType_Cmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  SelectReactionRegion_Cmd = new G4UIcmdWithAnInteger("/EventGen/SelectReactionRegion",this);
  SelectReactionRegion_Cmd->SetGuidance("Select reaction region");
  SelectReactionRegion_Cmd->SetGuidance("1 - target (default)");
  SelectReactionRegion_Cmd->SetGuidance("2 - entrance target window");
  SelectReactionRegion_Cmd->SetGuidance("3 - exit target window");
  SelectReactionRegion_Cmd->SetParameterName("SelectReactionRegion",true);
  SelectReactionRegion_Cmd->SetDefaultValue(1);
  SelectReactionRegion_Cmd->SetRange("SelectReactionRegion>=1");
  SelectReactionRegion_Cmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  ThetaMinLimitCmd =  new G4UIcmdWithADoubleAndUnit("/EventGen/SetThetaMin",this);
  ThetaMinLimitCmd->SetGuidance("Set the minimum theta angle of event generator");
  ThetaMinLimitCmd->SetParameterName("ThetaMin",true);
  ThetaMinLimitCmd->SetUnitCategory("Angle");
  ThetaMinLimitCmd->SetDefaultUnit("degree");
  ThetaMinLimitCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  ThetaMaxLimitCmd =  new G4UIcmdWithADoubleAndUnit("/EventGen/SetThetaMax",this);
  ThetaMaxLimitCmd->SetGuidance("Set the maximum theta angle of event generator");
  ThetaMaxLimitCmd->SetParameterName("ThetaMax",true);
  ThetaMaxLimitCmd->SetUnitCategory("Angle");
  ThetaMaxLimitCmd->SetDefaultUnit("degree");
  ThetaMaxLimitCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  PhiMinLimitCmd =  new G4UIcmdWithADoubleAndUnit("/EventGen/SetPhiMin",this);
  PhiMinLimitCmd->SetGuidance("Set the minimum theta angle of event generator");
  PhiMinLimitCmd->SetParameterName("PhiMin",true);
  PhiMinLimitCmd->SetUnitCategory("Angle");
  PhiMinLimitCmd->SetDefaultUnit("degree");
  PhiMinLimitCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  PhiMaxLimitCmd =  new G4UIcmdWithADoubleAndUnit("/EventGen/SetPhiMax",this);
  PhiMaxLimitCmd->SetGuidance("Set the maximum theta angle of event generator");
  PhiMaxLimitCmd->SetParameterName("PhiMax",true);
  PhiMaxLimitCmd->SetUnitCategory("Angle");
  PhiMaxLimitCmd->SetDefaultUnit("degree");
  PhiMaxLimitCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  EPrimeMinLimitCmd =  new G4UIcmdWithADoubleAndUnit("/EventGen/SetEPrimeMin",this);
  EPrimeMinLimitCmd->SetGuidance("Set the minimum E\' of event generator");
  EPrimeMinLimitCmd->SetParameterName("EPrimeMin",true);
  EPrimeMinLimitCmd->SetUnitCategory("Energy");
  EPrimeMinLimitCmd->SetDefaultUnit("GeV");
  EPrimeMinLimitCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  EPrimeMaxLimitCmd =  new G4UIcmdWithADoubleAndUnit("/EventGen/SetEPrimeMax",this);
  EPrimeMaxLimitCmd->SetGuidance("Set the maximum E\' of event generator");
  EPrimeMaxLimitCmd->SetParameterName("EPrimeMax",true);
  EPrimeMaxLimitCmd->SetUnitCategory("Energy");
  EPrimeMaxLimitCmd->SetDefaultUnit("GeV");
  EPrimeMaxLimitCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  SetBeamEnergyCmd = new G4UIcmdWithADoubleAndUnit("/EventGen/SetBeamEnergy",this);
  SetBeamEnergyCmd->SetGuidance("Set beam energy.");
  SetBeamEnergyCmd->SetParameterName("E_beam",true);
  SetBeamEnergyCmd->SetUnitCategory("Energy");
  SetBeamEnergyCmd->SetDefaultValue(1.160*GeV);
  //SetBeamEnergyCmd->SetRange("BeamEnergy>0");
  SetBeamEnergyCmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  SetElasticPeakDeltaECmd = new G4UIcmdWithADoubleAndUnit("/EventGen/SetElasticPeakDeltaE",this);
  SetElasticPeakDeltaECmd->SetGuidance("Set elastic peak delta E range (Used in ReactionType 7).");
  SetElasticPeakDeltaECmd->SetParameterName("delta_E",true);
  SetElasticPeakDeltaECmd->SetUnitCategory("Energy");
  SetElasticPeakDeltaECmd->SetDefaultValue(15*MeV);
  SetElasticPeakDeltaECmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  SetSchwingerDeltaECmd = new G4UIcmdWithADoubleAndUnit("/EventGen/SetSchwingerDeltaE",this);
  SetSchwingerDeltaECmd->SetGuidance("Set elastic peak delta E range (Used in carbon generators).");
  SetSchwingerDeltaECmd->SetParameterName("Schwinger_delta_E",true);
  SetSchwingerDeltaECmd->SetUnitCategory("Energy");
  SetSchwingerDeltaECmd->SetDefaultValue(15*MeV);
  SetSchwingerDeltaECmd->AvailableForStates(G4State_PreInit,G4State_Idle);

  G4cout << "###### Leaving QweakSimEPEventMessenger::QweakSimEPEventMessenger() " << G4endl;
}

QweakSimEPEventMessenger::~QweakSimEPEventMessenger

(

)

Definition at line 171 of file QweakSimEPEventMessenger.cc.

References EPrimeMaxLimitCmd, EPrimeMinLimitCmd, EventGenDir, PhiMaxLimitCmd, PhiMinLimitCmd, SelectIsotropy_Cmd, SelectOctant_Cmd, SelectReactionRegion_Cmd, SelectReactionType_Cmd, SetBeamEnergyCmd, SetElasticPeakDeltaECmd, SetSchwingerDeltaECmd, ThetaMaxLimitCmd, ThetaMinLimitCmd, and verboseCmd.

{
  G4cout << "###### Calling QweakSimEPEventMessenger::~QweakSimEPEventMessenger() " << G4endl;

  delete SelectOctant_Cmd;
  delete SelectIsotropy_Cmd;
  delete SelectReactionType_Cmd;
  delete SelectReactionRegion_Cmd;
  delete verboseCmd;
  delete ThetaMinLimitCmd;
  delete ThetaMaxLimitCmd;
  delete PhiMinLimitCmd;
  delete PhiMaxLimitCmd;
  delete EPrimeMinLimitCmd;
  delete EPrimeMaxLimitCmd;
  delete SetBeamEnergyCmd;
  delete SetElasticPeakDeltaECmd;
  delete SetSchwingerDeltaECmd;
  delete EventGenDir;

  G4cout << "###### Leaving QweakSimEPEventMessenger::~QweakSimEPEventMessenger() " << G4endl;

}

Member Function Documentation

void QweakSimEPEventMessenger::SetNewValue	(	G4UIcommand *	command,
		G4String	newValue
	)

Definition at line 197 of file QweakSimEPEventMessenger.cc.

References QweakSimEPEvent::CreateLookupTable(), EPrimeMaxLimitCmd, EPrimeMinLimitCmd, PhiMaxLimitCmd, PhiMinLimitCmd, pQweakSimEPEvent, SelectIsotropy_Cmd, SelectOctant_Cmd, SelectReactionRegion_Cmd, SelectReactionType_Cmd, QweakSimEPEvent::SetActiveOctantNumber(), QweakSimEPEvent::SetBeamEnergy(), SetBeamEnergyCmd, QweakSimEPEvent::SetElasticPeakDeltaE(), SetElasticPeakDeltaECmd, QweakSimEPEvent::SetEPrime_Max(), QweakSimEPEvent::SetEPrime_Min(), QweakSimEPEvent::SetIsotropy(), QweakSimEPEvent::SetPhiAngle_Max(), QweakSimEPEvent::SetPhiAngle_Min(), QweakSimEPEvent::SetReactionRegion(), QweakSimEPEvent::SetReactionType(), QweakSimEPEvent::SetSchwingerDeltaE(), SetSchwingerDeltaECmd, QweakSimEPEvent::SetThetaAngle_Max(), QweakSimEPEvent::SetThetaAngle_Min(), ThetaMaxLimitCmd, and ThetaMinLimitCmd.

{

  if( command == SelectOctant_Cmd )
    {
      G4cout << "% % ===> Changing active octant number to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetActiveOctantNumber(SelectOctant_Cmd->GetNewIntValue(newValue));
    }
  if( command == SelectIsotropy_Cmd )
    {
      G4cout << "% % ===> Changing isotropy to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetIsotropy(SelectIsotropy_Cmd->GetNewIntValue(newValue));
    }
  if( command == SelectReactionType_Cmd )
    {
      G4cout << "% % ===> Changing reaction type to: "<<newValue<< G4endl;
      G4int type = SelectReactionType_Cmd->GetNewIntValue(newValue);
      pQweakSimEPEvent->SetReactionType(type);
      if (type == 7) pQweakSimEPEvent->CreateLookupTable();
    }

  if( command == SelectReactionRegion_Cmd )
    {
      G4cout << "% % ===> Changing reaction region to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetReactionRegion(SelectReactionRegion_Cmd->GetNewIntValue(newValue));
    }

  if( command == ThetaMinLimitCmd )
    {
      G4cout << "% % ===> Changing theta minimum to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetThetaAngle_Min(ThetaMinLimitCmd->GetNewDoubleValue(newValue));
    }

  if( command == ThetaMaxLimitCmd )
    {
      G4cout << "% % ===> Changing theta maximum to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetThetaAngle_Max(ThetaMaxLimitCmd->GetNewDoubleValue(newValue));
    }

  if( command == PhiMinLimitCmd )
    {
      G4cout << "% % ===> Changing phi minimum to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetPhiAngle_Min(PhiMinLimitCmd->GetNewDoubleValue(newValue));
    }

  if( command == PhiMaxLimitCmd )
    {
      G4cout << "% % ===> Changing phi maximum to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetPhiAngle_Max(PhiMaxLimitCmd->GetNewDoubleValue(newValue));
    }

  if( command == EPrimeMinLimitCmd )
    {
      G4cout << "% % ===> Changing E\' minimum to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetEPrime_Min(EPrimeMinLimitCmd->GetNewDoubleValue(newValue));
    }

  if( command == EPrimeMaxLimitCmd )
    {
      G4cout << "% % ===> Changing E\' maximum to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetEPrime_Max(EPrimeMaxLimitCmd->GetNewDoubleValue(newValue));
    }

  if( command == SetBeamEnergyCmd )
    {
      G4cout << "% % ===> Changing Beam Energy to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetBeamEnergy(SetBeamEnergyCmd->GetNewDoubleValue(newValue));
    }

  if( command == SetElasticPeakDeltaECmd )
    {
      G4cout << "% % ===> Changing Elastic Peak Energy Range to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetElasticPeakDeltaE(SetElasticPeakDeltaECmd->GetNewDoubleValue(newValue));
    }

  if( command == SetSchwingerDeltaECmd )
    {
      G4cout << "% % ===> Changing Schwinger Elastic Peak Energy Range to: "<<newValue<< G4endl;
      pQweakSimEPEvent->SetSchwingerDeltaE(SetSchwingerDeltaECmd->GetNewDoubleValue(newValue));
    }

}

Here is the call graph for this function:

Field Documentation

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::EPrimeMaxLimitCmd

private

Definition at line 64 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::EPrimeMinLimitCmd

private

Definition at line 63 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIdirectory* QweakSimEPEventMessenger::EventGenDir

private

Definition at line 52 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::PhiMaxLimitCmd

private

Definition at line 62 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::PhiMinLimitCmd

private

Definition at line 61 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

QweakSimEPEvent* QweakSimEPEventMessenger::pQweakSimEPEvent

private

Definition at line 50 of file QweakSimEPEventMessenger.hh.

Referenced by SetNewValue().

G4UIcmdWithAnInteger* QweakSimEPEventMessenger::SelectIsotropy_Cmd

private

Definition at line 57 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithAnInteger* QweakSimEPEventMessenger::SelectOctant_Cmd

private

Definition at line 56 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithAnInteger* QweakSimEPEventMessenger::SelectReactionRegion_Cmd

private

Definition at line 55 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithAnInteger* QweakSimEPEventMessenger::SelectReactionType_Cmd

private

Definition at line 54 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::SetBeamEnergyCmd

private

Definition at line 65 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::SetElasticPeakDeltaECmd

private

Definition at line 66 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::SetSchwingerDeltaECmd

private

Definition at line 67 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::ThetaMaxLimitCmd

private

Definition at line 60 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithADoubleAndUnit* QweakSimEPEventMessenger::ThetaMinLimitCmd

private

Definition at line 59 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), SetNewValue(), and ~QweakSimEPEventMessenger().

G4UIcmdWithAnInteger* QweakSimEPEventMessenger::verboseCmd

private

Definition at line 53 of file QweakSimEPEventMessenger.hh.

Referenced by QweakSimEPEventMessenger(), and ~QweakSimEPEventMessenger().

---

The documentation for this class was generated from the following files:

• QweakSimEPEventMessenger.hh
• QweakSimEPEventMessenger.cc
