QweakSimLeadGlass Class Reference

#include <QweakSimLeadGlass.hh>

Collaboration diagram for QweakSimLeadGlass:

Public Member Functions
	QweakSimLeadGlass ()
	~QweakSimLeadGlass ()
void	ConstructComponent (G4VPhysicalVolume *MotherVolume)
void	DestroyComponent ()
void	SetLeadGlass_Material (G4String)
void	SetLeadGlass_CenterPositionInX (G4double xPos)
void	SetLeadGlass_CenterPositionInY (G4double yPos)
void	SetLeadGlass_CenterPositionInZ (G4double zPos)
G4double	GetLeadGlass_CenterPositionInX ()
G4double	GetLeadGlass_CenterPositionInY ()
G4double	GetLeadGlass_CenterPositionInZ ()
void	SetLeadGlass_FullLengthInX (G4double dim)
void	SetLeadGlass_FullLengthInY (G4double dim)
void	SetLeadGlass_FullLengthInZ (G4double dim)
G4double	GetLeadGlass_FullLengthInX ()
G4double	GetLeadGlass_FullLengthInY ()
G4double	GetLeadGlass_FullLengthInZ ()
void	SetLeadGlass_TiltAngleInX (G4double xTiltAngle)
void	SetLeadGlass_TiltAngleInY (G4double yTiltAngle)
void	SetLeadGlass_TiltAngleInZ (G4double zTiltAngle)
G4double	GetLeadGlass_TiltAngleInX ()
G4double	GetLeadGlass_TiltAngleInY ()
G4double	GetLeadGlass_TiltAngleInZ ()
void	SetLeadGlass_Enabled ()
void	SetLeadGlass_Disabled ()
G4LogicalVolume *	GetLeadGlass_LogicalVolume ()
G4VPhysicalVolume *	GetLeadGlass_PhysicalVolume ()

Private Attributes
QweakSimLeadGlassMessenger *	LeadGlassMessenger
QweakSimMaterial *	pMaterial
G4Box *	LeadGlass_Solid
G4LogicalVolume *	LeadGlass_Logical
G4VPhysicalVolume *	LeadGlass_Physical
G4Material *	LeadGlass_Material
G4VisAttributes *	LeadGlass_VisAtt
G4double	LeadGlass_FullLength_X
G4double	LeadGlass_FullLength_Y
G4double	LeadGlass_FullLength_Z
G4double	MD7_CenterPosition_X
G4double	MD7_CenterPosition_Y
G4double	MD7_CenterPosition_Z
G4double	LeadGlass_CenterPosition_X
G4double	LeadGlass_CenterPosition_Y
G4double	LeadGlass_CenterPosition_Z
G4ThreeVector	LeadGlass_CenterPosition
G4double	LeadGlass_TiltAngle_X
G4double	LeadGlass_TiltAngle_Y
G4double	LeadGlass_TiltAngle_Z
G4RotationMatrix *	LeadGlass_RotationMatrix
G4VSensitiveDetector *	LeadGlassSD

Detailed Description

Definition at line 29 of file QweakSimLeadGlass.hh.

Constructor & Destructor Documentation

QweakSimLeadGlass::QweakSimLeadGlass

(

)

Definition at line 25 of file QweakSimLeadGlass.cc.

References QweakSimMaterial::GetInstance(), LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, LeadGlass_FullLength_X, LeadGlass_FullLength_Y, LeadGlass_FullLength_Z, LeadGlass_Logical, LeadGlass_Material, LeadGlass_Physical, LeadGlass_Solid, LeadGlass_TiltAngle_X, LeadGlass_VisAtt, LeadGlassMessenger, LeadGlassSD, MD7_CenterPosition_X, MD7_CenterPosition_Y, MD7_CenterPosition_Z, and pMaterial.

{
    //--- Initialize Pointers

    LeadGlassMessenger  = NULL;

    pMaterial           = NULL;

    LeadGlass_Solid     = NULL;
    LeadGlass_Logical   = NULL;
    LeadGlass_Physical  = NULL;

    LeadGlass_Material  = NULL;

    LeadGlassSD         = NULL;

    LeadGlass_VisAtt    = NULL;

    //--- Set Initialize Values

    LeadGlass_FullLength_X = 19.10*cm;
    LeadGlass_FullLength_Y = 19.10*cm;
    LeadGlass_FullLength_Z = 30.50*cm;

    MD7_CenterPosition_X =     0.0*cm;
    MD7_CenterPosition_Y = -335.17*cm;
    MD7_CenterPosition_Z =  577.88*cm;

    LeadGlass_CenterPosition_X = 0.0*cm;     //-150.00*cm;
    LeadGlass_CenterPosition_Y = -315.00*cm; //-300.00*cm;
    LeadGlass_CenterPosition_Z =  530.00*cm;

    LeadGlass_TiltAngle_X =  0.00*degree;
    LeadGlass_TiltAngle_X =  0.00*degree;
    LeadGlass_TiltAngle_X =  0.00*degree;

    LeadGlassMessenger = new QweakSimLeadGlassMessenger(this);

    pMaterial = QweakSimMaterial::GetInstance();
}

Here is the call graph for this function:

QweakSimLeadGlass::~QweakSimLeadGlass

(

)

Definition at line 70 of file QweakSimLeadGlass.cc.

References LeadGlass_Logical, LeadGlass_Material, LeadGlass_Physical, LeadGlass_Solid, LeadGlass_VisAtt, and LeadGlassMessenger.

{
    // --- Delete Pointers

    if (LeadGlass_VisAtt)          delete LeadGlass_VisAtt;

    //if (LeadGlassSD)               delete LeadGlassSD;

    if (LeadGlass_Material)        delete LeadGlass_Material;

    if (LeadGlass_Physical)        delete LeadGlass_Physical;
    if (LeadGlass_Logical)         delete LeadGlass_Logical;
    if (LeadGlass_Solid)           delete LeadGlass_Solid;

    if (LeadGlassMessenger)        delete LeadGlassMessenger;
}

Member Function Documentation

void QweakSimLeadGlass::ConstructComponent

(

G4VPhysicalVolume *

MotherVolume

)

Definition at line 91 of file QweakSimLeadGlass.cc.

References QweakSimMaterial::GetMaterial(), LeadGlass_CenterPosition, LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, LeadGlass_FullLength_X, LeadGlass_FullLength_Y, LeadGlass_FullLength_Z, LeadGlass_Logical, LeadGlass_Material, LeadGlass_Physical, LeadGlass_RotationMatrix, LeadGlass_Solid, LeadGlass_TiltAngle_X, LeadGlass_VisAtt, LeadGlassSD, pMaterial, and pSurfChk.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{

    //--- Material

    LeadGlass_Material = pMaterial->GetMaterial("LeadGlass");

    //--- Define LeadGlass Solid Volume

    LeadGlass_Solid = new G4Box("LeadGlass_Solid",
                                 0.5*LeadGlass_FullLength_X,     // X Length
                                 0.5*LeadGlass_FullLength_Y,     // Y Length
                                 0.5*LeadGlass_FullLength_Z);    // Z Length

    //--- Define LeadGlass Logical Volume

    LeadGlass_Logical = new G4LogicalVolume(LeadGlass_Solid,
                                            LeadGlass_Material,
                                            "LeadGlass_Logical",
                                            0,0,0);

    //--- Define LeadGlass Physical Volume

    LeadGlass_CenterPosition = G4ThreeVector(LeadGlass_CenterPosition_X,
                                             LeadGlass_CenterPosition_Y,
                                             LeadGlass_CenterPosition_Z);

    LeadGlass_RotationMatrix = new G4RotationMatrix();
    LeadGlass_RotationMatrix -> rotateX(LeadGlass_TiltAngle_X);

    LeadGlass_Physical = new G4PVPlacement(LeadGlass_RotationMatrix,
                                           LeadGlass_CenterPosition,
                                           "LeadGlass_Phyical",
                                           LeadGlass_Logical,
                                           MotherVolume,
                                           false,
                                           0,
                                           pSurfChk);

    //--- Define Sensitive Detectors to LeadGlass

    G4SDManager* SDman = G4SDManager::GetSDMpointer();

    LeadGlassSD = new QweakSimLeadGlass_DetectorSD("LeadGlassSD");
    SDman -> AddNewDetector(LeadGlassSD);
    LeadGlass_Logical -> SetSensitiveDetector(LeadGlassSD);

    //--- Define Visulization Attributes

    G4Colour blue (0/255., 0/255., 255/255.);
    LeadGlass_VisAtt = new G4VisAttributes(blue);
    LeadGlass_VisAtt -> SetVisibility(true);
    LeadGlass_Logical -> SetVisAttributes(LeadGlass_VisAtt);

}

Here is the call graph for this function:

Here is the caller graph for this function:

void QweakSimLeadGlass::DestroyComponent

(

)

Definition at line 151 of file QweakSimLeadGlass.cc.

{
}

G4double QweakSimLeadGlass::GetLeadGlass_CenterPositionInX ( )

inline

Definition at line 45 of file QweakSimLeadGlass.hh.

References LeadGlass_CenterPosition_X.

{return LeadGlass_CenterPosition_X;}

G4double QweakSimLeadGlass::GetLeadGlass_CenterPositionInY ( )

inline

Definition at line 46 of file QweakSimLeadGlass.hh.

References LeadGlass_CenterPosition_Y.

{return LeadGlass_CenterPosition_Y;}

G4double QweakSimLeadGlass::GetLeadGlass_CenterPositionInZ ( )

inline

Definition at line 47 of file QweakSimLeadGlass.hh.

References LeadGlass_CenterPosition_Z.

{return LeadGlass_CenterPosition_Z;}

G4double QweakSimLeadGlass::GetLeadGlass_FullLengthInX ( )

inline

Definition at line 52 of file QweakSimLeadGlass.hh.

References LeadGlass_FullLength_X.

{return LeadGlass_FullLength_X;}

G4double QweakSimLeadGlass::GetLeadGlass_FullLengthInY ( )

inline

Definition at line 53 of file QweakSimLeadGlass.hh.

References LeadGlass_FullLength_Y.

{return LeadGlass_FullLength_Y;}

G4double QweakSimLeadGlass::GetLeadGlass_FullLengthInZ ( )

inline

Definition at line 54 of file QweakSimLeadGlass.hh.

References LeadGlass_FullLength_Z.

{return LeadGlass_FullLength_Z;}

G4LogicalVolume* QweakSimLeadGlass::GetLeadGlass_LogicalVolume ( )

inline

Definition at line 66 of file QweakSimLeadGlass.hh.

References LeadGlass_Logical.

{return LeadGlass_Logical;}

G4VPhysicalVolume* QweakSimLeadGlass::GetLeadGlass_PhysicalVolume ( )

inline

Definition at line 67 of file QweakSimLeadGlass.hh.

References LeadGlass_Physical.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{return LeadGlass_Physical;}

Here is the caller graph for this function:

G4double QweakSimLeadGlass::GetLeadGlass_TiltAngleInX ( )

inline

Definition at line 59 of file QweakSimLeadGlass.hh.

References LeadGlass_TiltAngle_X.

{return LeadGlass_TiltAngle_X;}

G4double QweakSimLeadGlass::GetLeadGlass_TiltAngleInY ( )

inline

Definition at line 60 of file QweakSimLeadGlass.hh.

References LeadGlass_TiltAngle_Y.

{return LeadGlass_TiltAngle_Y;}

G4double QweakSimLeadGlass::GetLeadGlass_TiltAngleInZ ( )

inline

Definition at line 61 of file QweakSimLeadGlass.hh.

References LeadGlass_TiltAngle_Z.

{return LeadGlass_TiltAngle_Z;}

void QweakSimLeadGlass::SetLeadGlass_CenterPositionInX

(

G4double

xPos

)

Definition at line 180 of file QweakSimLeadGlass.cc.

References LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, and LeadGlass_Physical.

{
    //--- Set LeadGlass X Position

    G4cout << "=== Calling QweakSimLeadGlass::SetLeadGlass_CenterPositionInX() " << G4endl;
    LeadGlass_CenterPosition_X = xPos;
    LeadGlass_Physical->SetTranslation(G4ThreeVector(LeadGlass_CenterPosition_X,
                                                     LeadGlass_CenterPosition_Y,
                                                     LeadGlass_CenterPosition_Z));
    G4cout << "=== Leaving QweakSimLeadGlass::SetLeadGlass_CenterPositionInX() " << G4endl << G4endl;
}

void QweakSimLeadGlass::SetLeadGlass_CenterPositionInY

(

G4double

yPos

)

Definition at line 196 of file QweakSimLeadGlass.cc.

References LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, and LeadGlass_Physical.

{
    //--- Set LeadGlass Y Position

    G4cout << "=== Calling QweakSimLeadGlass::SetLeadGlass_CenterPositionInY() " << G4endl;
    LeadGlass_CenterPosition_Y = yPos;
    LeadGlass_Physical->SetTranslation(G4ThreeVector(LeadGlass_CenterPosition_X,
                                                     LeadGlass_CenterPosition_Y,
                                                     LeadGlass_CenterPosition_Z));
    G4cout << "=== Leaving QweakSimLeadGlass::SetLeadGlass_CenterPositionInY() " << G4endl << G4endl;
}

void QweakSimLeadGlass::SetLeadGlass_CenterPositionInZ

(

G4double

zPos

)

Definition at line 212 of file QweakSimLeadGlass.cc.

References LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, and LeadGlass_Physical.

{
    //--- Set LeadGlass Z Position

    G4cout << "=== Calling QweakSimLeadGlass::SetLeadGlass_CenterPositionInZ() " << G4endl;
    LeadGlass_CenterPosition_Z = zPos;
    LeadGlass_Physical->SetTranslation(G4ThreeVector(LeadGlass_CenterPosition_X,
                                                     LeadGlass_CenterPosition_Y,
                                                     LeadGlass_CenterPosition_Z));
    G4cout << "=== Leaving QweakSimLeadGlass::SetLeadGlass_CenterPositionInZ() " << G4endl << G4endl;
}

void QweakSimLeadGlass::SetLeadGlass_Disabled

(

)

Definition at line 318 of file QweakSimLeadGlass.cc.

References LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, LeadGlass_Physical, LeadGlass_VisAtt, and SetLeadGlass_Material().

{
    //--- Disable the LeadGlass

    G4cout << "=== Calling QweakSimLeadGlass::SetLeadGlass_Disabled() " << G4endl;
    LeadGlass_VisAtt -> SetVisibility(true);
    SetLeadGlass_Material("Air");
    LeadGlass_Physical->SetTranslation(G4ThreeVector(LeadGlass_CenterPosition_X,
                                                     LeadGlass_CenterPosition_Y,
                                                     LeadGlass_CenterPosition_Z + 400.00*cm));
    G4cout << "=== Leaving QweakSimLeadGlass::SetLeadGlass_Disabled() " << G4endl << G4endl;
}

Here is the call graph for this function:

void QweakSimLeadGlass::SetLeadGlass_Enabled

(

)

Definition at line 301 of file QweakSimLeadGlass.cc.

References LeadGlass_CenterPosition_X, LeadGlass_CenterPosition_Y, LeadGlass_CenterPosition_Z, LeadGlass_Material, LeadGlass_Physical, LeadGlass_VisAtt, and SetLeadGlass_Material().

{
    //--- Enable the LeadGlass

    G4cout << "=== Calling QweakSimLeadGlass::SetLeadGlass_Enabled() " << G4endl;
    LeadGlass_VisAtt -> SetVisibility(true);
    SetLeadGlass_Material(LeadGlass_Material -> GetName());
    LeadGlass_Physical->SetTranslation(G4ThreeVector(LeadGlass_CenterPosition_X,
                                                     LeadGlass_CenterPosition_Y,
                                                     LeadGlass_CenterPosition_Z));
    G4cout << "=== Leaving QweakSimLeadGlass::SetLeadGlass_Enabled() " << G4endl << G4endl;
}

Here is the call graph for this function:

void QweakSimLeadGlass::SetLeadGlass_FullLengthInX ( G4double  dim )

inline

Definition at line 49 of file QweakSimLeadGlass.hh.

References LeadGlass_FullLength_X.

{LeadGlass_FullLength_X = dim;}

void QweakSimLeadGlass::SetLeadGlass_FullLengthInY ( G4double  dim )

inline

Definition at line 50 of file QweakSimLeadGlass.hh.

References LeadGlass_FullLength_Y.

{LeadGlass_FullLength_Y = dim;}

void QweakSimLeadGlass::SetLeadGlass_FullLengthInZ ( G4double  dim )

inline

Definition at line 51 of file QweakSimLeadGlass.hh.

References LeadGlass_FullLength_Z.

{LeadGlass_FullLength_Z = dim;}

void QweakSimLeadGlass::SetLeadGlass_Material

(

G4String

materialName

)

Definition at line 159 of file QweakSimLeadGlass.cc.

References LeadGlass_Logical.

Referenced by SetLeadGlass_Disabled(), and SetLeadGlass_Enabled().

{
    //--- Set LeadGlass Material

    G4Material* pttoMaterial = G4Material::GetMaterial(materialName);

    if (pttoMaterial)
    {
        G4cout << "=== Changing LeadGlass material: Look up material " << G4endl;
        LeadGlass_Logical -> SetMaterial(pttoMaterial);
        G4cout << "=== Changing LeadGlass material: Now the material is " << materialName << G4endl;
    }
    else
        G4cerr << "=== Error: Changing LeadGlass material FAILED! " << G4endl << G4endl;

}

Here is the caller graph for this function:

void QweakSimLeadGlass::SetLeadGlass_TiltAngleInX

(

G4double

xTiltAngle

)

Definition at line 229 of file QweakSimLeadGlass.cc.

References LeadGlass_Physical, LeadGlass_RotationMatrix, and LeadGlass_TiltAngle_X.

{
    //--- Set LeadGlass New X Tilting Angle

    G4cout << G4endl << "=== Calling QweakSimLeadGlass::SetLeadGlass_TiltAngleInX() " << G4endl;

    //--- rotate back with old angle
    LeadGlass_RotationMatrix->rotateX(-1.0*LeadGlass_TiltAngle_X);
    LeadGlass_Physical->SetRotation(LeadGlass_RotationMatrix);

    //--- assign new tilting angle
    LeadGlass_TiltAngle_X = xTiltAngle;

    //--- rotate to new angle
    LeadGlass_RotationMatrix->rotateX(LeadGlass_TiltAngle_X);
    LeadGlass_Physical->SetRotation(LeadGlass_RotationMatrix);

    G4cout << G4endl << "=== Leaving QweakSimLeadGlass::SetLeadGlass_TiltAngleInX() " << G4endl << G4endl;
}

void QweakSimLeadGlass::SetLeadGlass_TiltAngleInY

(

G4double

yTiltAngle

)

Definition at line 253 of file QweakSimLeadGlass.cc.

References LeadGlass_Physical, LeadGlass_RotationMatrix, and LeadGlass_TiltAngle_Y.

{
    //--- Set LeadGlass New Y Tilting Angle

    G4cout << G4endl << "=== Calling QweakSimLeadGlass::SetLeadGlass_TiltAngleInY() " << G4endl;

    //--- rotate back with old angle
    LeadGlass_RotationMatrix->rotateY(-1.0*LeadGlass_TiltAngle_Y);
    LeadGlass_Physical->SetRotation(LeadGlass_RotationMatrix);

    //--- assign new tilting angle
    LeadGlass_TiltAngle_Y = yTiltAngle;

    //--- rotate to new angle
    LeadGlass_RotationMatrix->rotateY(LeadGlass_TiltAngle_Y);
    LeadGlass_Physical->SetRotation(LeadGlass_RotationMatrix);

    G4cout << G4endl << "=== Leaving QweakSimLeadGlass::SetLeadGlass_TiltAngleInY() " << G4endl << G4endl;
}

void QweakSimLeadGlass::SetLeadGlass_TiltAngleInZ

(

G4double

zTiltAngle

)

Definition at line 277 of file QweakSimLeadGlass.cc.

References LeadGlass_Physical, LeadGlass_RotationMatrix, and LeadGlass_TiltAngle_Z.

{
    //--- Set LeadGlass New Z Tilting Angle

    G4cout << G4endl << "=== Calling QweakSimLeadGlass::SetLeadGlass_TiltAngleInZ() " << G4endl;

    //--- rotate back with old angle
    LeadGlass_RotationMatrix->rotateZ(-1.0*LeadGlass_TiltAngle_Z);
    LeadGlass_Physical->SetRotation(LeadGlass_RotationMatrix);

    //--- assign new tilting angle
    LeadGlass_TiltAngle_Z = zTiltAngle;

    //--- rotate to new angle
    LeadGlass_RotationMatrix->rotateZ(LeadGlass_TiltAngle_Z);
    LeadGlass_Physical->SetRotation(LeadGlass_RotationMatrix);

    G4cout << G4endl << "=== Leaving QweakSimLeadGlass::SetLeadGlass_TiltAngleInZ() " << G4endl << G4endl;
}

Field Documentation

G4ThreeVector QweakSimLeadGlass::LeadGlass_CenterPosition

private

Definition at line 96 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent().

G4double QweakSimLeadGlass::LeadGlass_CenterPosition_X

private

Definition at line 93 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_CenterPositionInX(), QweakSimLeadGlass(), SetLeadGlass_CenterPositionInX(), SetLeadGlass_CenterPositionInY(), SetLeadGlass_CenterPositionInZ(), SetLeadGlass_Disabled(), and SetLeadGlass_Enabled().

G4double QweakSimLeadGlass::LeadGlass_CenterPosition_Y

private

Definition at line 94 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_CenterPositionInY(), QweakSimLeadGlass(), SetLeadGlass_CenterPositionInX(), SetLeadGlass_CenterPositionInY(), SetLeadGlass_CenterPositionInZ(), SetLeadGlass_Disabled(), and SetLeadGlass_Enabled().

G4double QweakSimLeadGlass::LeadGlass_CenterPosition_Z

private

Definition at line 95 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_CenterPositionInZ(), QweakSimLeadGlass(), SetLeadGlass_CenterPositionInX(), SetLeadGlass_CenterPositionInY(), SetLeadGlass_CenterPositionInZ(), SetLeadGlass_Disabled(), and SetLeadGlass_Enabled().

G4double QweakSimLeadGlass::LeadGlass_FullLength_X

private

Definition at line 84 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_FullLengthInX(), QweakSimLeadGlass(), and SetLeadGlass_FullLengthInX().

G4double QweakSimLeadGlass::LeadGlass_FullLength_Y

private

Definition at line 85 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_FullLengthInY(), QweakSimLeadGlass(), and SetLeadGlass_FullLengthInY().

G4double QweakSimLeadGlass::LeadGlass_FullLength_Z

private

Definition at line 86 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_FullLengthInZ(), QweakSimLeadGlass(), and SetLeadGlass_FullLengthInZ().

G4LogicalVolume* QweakSimLeadGlass::LeadGlass_Logical

private

Definition at line 76 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_LogicalVolume(), QweakSimLeadGlass(), SetLeadGlass_Material(), and ~QweakSimLeadGlass().

G4Material* QweakSimLeadGlass::LeadGlass_Material

private

Definition at line 79 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), QweakSimLeadGlass(), SetLeadGlass_Enabled(), and ~QweakSimLeadGlass().

G4VPhysicalVolume* QweakSimLeadGlass::LeadGlass_Physical

private

Definition at line 77 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_PhysicalVolume(), QweakSimLeadGlass(), SetLeadGlass_CenterPositionInX(), SetLeadGlass_CenterPositionInY(), SetLeadGlass_CenterPositionInZ(), SetLeadGlass_Disabled(), SetLeadGlass_Enabled(), SetLeadGlass_TiltAngleInX(), SetLeadGlass_TiltAngleInY(), SetLeadGlass_TiltAngleInZ(), and ~QweakSimLeadGlass().

G4RotationMatrix* QweakSimLeadGlass::LeadGlass_RotationMatrix

private

Definition at line 102 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), SetLeadGlass_TiltAngleInX(), SetLeadGlass_TiltAngleInY(), and SetLeadGlass_TiltAngleInZ().

G4Box* QweakSimLeadGlass::LeadGlass_Solid

private

Definition at line 75 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), QweakSimLeadGlass(), and ~QweakSimLeadGlass().

G4double QweakSimLeadGlass::LeadGlass_TiltAngle_X

private

Definition at line 99 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), GetLeadGlass_TiltAngleInX(), QweakSimLeadGlass(), and SetLeadGlass_TiltAngleInX().

G4double QweakSimLeadGlass::LeadGlass_TiltAngle_Y

private

Definition at line 100 of file QweakSimLeadGlass.hh.

Referenced by GetLeadGlass_TiltAngleInY(), and SetLeadGlass_TiltAngleInY().

G4double QweakSimLeadGlass::LeadGlass_TiltAngle_Z

private

Definition at line 101 of file QweakSimLeadGlass.hh.

Referenced by GetLeadGlass_TiltAngleInZ(), and SetLeadGlass_TiltAngleInZ().

G4VisAttributes* QweakSimLeadGlass::LeadGlass_VisAtt

private

Definition at line 81 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), QweakSimLeadGlass(), SetLeadGlass_Disabled(), SetLeadGlass_Enabled(), and ~QweakSimLeadGlass().

QweakSimLeadGlassMessenger* QweakSimLeadGlass::LeadGlassMessenger

private

Definition at line 71 of file QweakSimLeadGlass.hh.

Referenced by QweakSimLeadGlass(), and ~QweakSimLeadGlass().

G4VSensitiveDetector* QweakSimLeadGlass::LeadGlassSD

private

Definition at line 105 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), and QweakSimLeadGlass().

G4double QweakSimLeadGlass::MD7_CenterPosition_X

private

Definition at line 89 of file QweakSimLeadGlass.hh.

Referenced by QweakSimLeadGlass().

G4double QweakSimLeadGlass::MD7_CenterPosition_Y

private

Definition at line 90 of file QweakSimLeadGlass.hh.

Referenced by QweakSimLeadGlass().

G4double QweakSimLeadGlass::MD7_CenterPosition_Z

private

Definition at line 91 of file QweakSimLeadGlass.hh.

Referenced by QweakSimLeadGlass().

QweakSimMaterial* QweakSimLeadGlass::pMaterial

private

Definition at line 73 of file QweakSimLeadGlass.hh.

Referenced by ConstructComponent(), and QweakSimLeadGlass().

---

The documentation for this class was generated from the following files:

• QweakSimLeadGlass.hh
• QweakSimLeadGlass.cc
