QweakSimGeometry Class Reference

main class of QweakSim. All passive elements are are read from the GDML files. More...

#include <QweakSimGeometry.hh>

Collaboration diagram for QweakSimGeometry:

Public Member Functions
	QweakSimGeometry ()
	~QweakSimGeometry ()
void	SetWorldVolume (G4VPhysicalVolume *worldvolume)
void	SetReadFile (const G4String &file)
void	SetWriteFile (const G4String &file)
void	SetWriteModuleDepth (const G4int &depth)
void	SetWriteModuleUser (const G4bool &flag)
void	AddModule (G4VPhysicalVolume *physvol)
G4VPhysicalVolume *	Read ()
void	Write ()

Private Attributes
G4VPhysicalVolume *	fWorldVolume
G4int	fModuleDepth
G4bool	fModuleUser
G4bool	fStoreReferences
G4String	fReadFile
G4String	fWriteFile
QweakSimGeometryMessenger *	fGeometryMessenger

Detailed Description

main class of QweakSim. All passive elements are are read from the GDML files.

Definition at line 59 of file QweakSimGeometry.hh.

Constructor & Destructor Documentation

QweakSimGeometry::QweakSimGeometry

(

)

Definition at line 32 of file QweakSimGeometry.cc.

References fGeometryMessenger, fModuleDepth, fModuleUser, fReadFile, and fWriteFile.

: fStoreReferences(true)
{
  G4cout << G4endl << "###### Calling QweakSimGeometry::QweakSimGeometry() " << G4endl << G4endl;

  // Filenames
  fReadFile  = "GDML/qweak.gdml";
  fWriteFile = "GDML/qweak_out.gdml";

  // Modules
  fModuleDepth = -1;
  fModuleUser = false;

#ifdef G4LIB_USE_GDML
#else
  G4cout << "No support for GDML geometry!" << G4endl;
#endif

  fGeometryMessenger = new QweakSimGeometryMessenger(this);

  G4cout << G4endl << "###### Leaving QweakSimGeometry::QweakSimGeometry() " << G4endl << G4endl;
}

QweakSimGeometry::~QweakSimGeometry

(

)

Definition at line 57 of file QweakSimGeometry.cc.

References fGeometryMessenger.

{
  G4cout << G4endl << "###### Calling QweakSimGeometry::~QweakSimGeometry() " << G4endl << G4endl;

  if (fGeometryMessenger) delete fGeometryMessenger;

  G4cout << G4endl << "###### Leaving QweakSimGeometry::~QweakSimGeometry() " << G4endl << G4endl;
}

Member Function Documentation

void QweakSimGeometry::AddModule ( G4VPhysicalVolume *  physvol )

inline

Definition at line 81 of file QweakSimGeometry.hh.

References fModuleUser.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

                                               {
      if (fModuleUser) {
        if (physvol) {
          #ifdef G4LIB_USE_GDML
            fGDMLParser.AddModule(physvol);
          #endif
        }
      }
    }

Here is the caller graph for this function:

G4VPhysicalVolume * QweakSimGeometry::Read

(

)

Definition at line 87 of file QweakSimGeometry.cc.

References fReadFile.

{
  G4cout << G4endl << "###### Calling QweakSimGeometry::Read() " << G4endl << G4endl;

#ifdef G4LIB_USE_GDML
  fGDMLParser.SetOverlapCheck(true);
  fGDMLParser.Read(fReadFile);
  fGDMLParser.StripNamePointers();

  G4cout << *(G4Element::GetElementTable()) << G4endl;
  G4cout << *(G4Material::GetMaterialTable()) << G4endl;

  G4VPhysicalVolume* worldvolume = fGDMLParser.GetWorldVolume();
#else
  G4cout << "No support for GDML geometry!" << G4endl;
  G4VPhysicalVolume* worldvolume = NULL;
#endif

  G4cout << G4endl << "###### Leaving QweakSimGeometry::Read() " << G4endl << G4endl;

  return worldvolume;
}

void QweakSimGeometry::SetReadFile ( const G4String &  file )

inline

Definition at line 72 of file QweakSimGeometry.hh.

References fReadFile.

Referenced by QweakSimGeometryMessenger::SetNewValue().

{ fReadFile = file; };

Here is the caller graph for this function:

void QweakSimGeometry::SetWorldVolume ( G4VPhysicalVolume *  worldvolume )

inline

Definition at line 68 of file QweakSimGeometry.hh.

References fWorldVolume.

Referenced by QweakSimDetectorConstruction::ConstructQweak().

{ fWorldVolume = worldvolume; };

Here is the caller graph for this function:

void QweakSimGeometry::SetWriteFile ( const G4String &  file )

inline

Definition at line 73 of file QweakSimGeometry.hh.

References fWriteFile.

Referenced by QweakSimGeometryMessenger::SetNewValue().

{ fWriteFile = file; };

Here is the caller graph for this function:

void QweakSimGeometry::SetWriteModuleDepth ( const G4int &  depth )

inline

Definition at line 77 of file QweakSimGeometry.hh.

References fModuleDepth.

Referenced by QweakSimGeometryMessenger::SetNewValue().

{ fModuleDepth = depth; };

Here is the caller graph for this function:

void QweakSimGeometry::SetWriteModuleUser ( const G4bool &  flag )

inline

Definition at line 78 of file QweakSimGeometry.hh.

References fModuleUser.

Referenced by QweakSimGeometryMessenger::SetNewValue().

{ fModuleUser = flag; };

Here is the caller graph for this function:

void QweakSimGeometry::Write

(

)

Definition at line 68 of file QweakSimGeometry.cc.

References fModuleDepth, fStoreReferences, fWorldVolume, and fWriteFile.

Referenced by QweakSimGeometryMessenger::SetNewValue().

{
  G4cout << G4endl << "###### Calling QweakSimGeometry::Write() " << G4endl << G4endl;

#ifdef G4LIB_USE_GDML
  // If the module depth is non-negative, split according to this depth
  if (fModuleDepth >= 0)
    fGDMLParser.AddModule(fModuleDepth);
  // Write all geometry starting from the world volume
  fGDMLParser.Write(fWriteFile, fWorldVolume, fStoreReferences);
#else
  G4cout << "No support for GDML geometry!" << G4endl;
#endif

  G4cout << G4endl << "###### Leaving QweakSimGeometry::Write() " << G4endl << G4endl;
}

Here is the caller graph for this function:

Field Documentation

QweakSimGeometryMessenger* QweakSimGeometry::fGeometryMessenger

private

Definition at line 123 of file QweakSimGeometry.hh.

Referenced by QweakSimGeometry(), and ~QweakSimGeometry().

G4int QweakSimGeometry::fModuleDepth

private

Definition at line 104 of file QweakSimGeometry.hh.

Referenced by QweakSimGeometry(), SetWriteModuleDepth(), and Write().

G4bool QweakSimGeometry::fModuleUser

private

Definition at line 105 of file QweakSimGeometry.hh.

Referenced by AddModule(), QweakSimGeometry(), and SetWriteModuleUser().

G4String QweakSimGeometry::fReadFile

private

Definition at line 112 of file QweakSimGeometry.hh.

Referenced by QweakSimGeometry(), Read(), and SetReadFile().

G4bool QweakSimGeometry::fStoreReferences

private

Definition at line 108 of file QweakSimGeometry.hh.

Referenced by Write().

G4VPhysicalVolume* QweakSimGeometry::fWorldVolume

private

Definition at line 100 of file QweakSimGeometry.hh.

Referenced by SetWorldVolume(), and Write().

G4String QweakSimGeometry::fWriteFile

private

Definition at line 113 of file QweakSimGeometry.hh.

Referenced by QweakSimGeometry(), SetWriteFile(), and Write().

---

The documentation for this class was generated from the following files:

• QweakSimGeometry.hh
• QweakSimGeometry.cc
