wiser_pion.h File Reference

#include "TF1.h"

Include dependency graph for wiser_pion.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Macros
#define	pi_w   3.14159
#define	me_w   0.511E-3
#define	alpha_w   0.007299
#define	WISER_VERBOSE   0

Functions
G4double	wiser_all_fit (G4double *x, G4double *par)
G4double	wiser_sigma (G4double Ebeam, G4double pf, G4double thf, G4double rad_len, G4int type)

Macro Definition Documentation

#define alpha_w   0.007299

Definition at line 7 of file wiser_pion.h.

#define me_w   0.511E-3

Definition at line 6 of file wiser_pion.h.

#define pi_w   3.14159

Definition at line 5 of file wiser_pion.h.

#define WISER_VERBOSE   0

Definition at line 8 of file wiser_pion.h.

Referenced by wiser_sigma().

Function Documentation

G4double wiser_all_fit	(	G4double *	x,
		G4double *	par
	)

Definition at line 161 of file wiser_pion.h.

Referenced by wiser_sigma().

                                                  {
    // Primary variable x[0] is photon energy in [GeV]

    // Parameters are:
    // par[0]    Beam energy [GeV]
    //G4double Ebeam = par[0];
    // par[1]    Final particle momentum [GeV/c]
    G4double pf    = par[1];
    // par[2]    Final particle angle [rad]
    G4double thf   = par[2];
    // par[3]    Type (as defined in wiser_all_sig)
    G4int type  = (G4int) par[3];
    // par[4]    Minimum invariant mass of the residual system [GeV]
    G4double M_X   = par[4];


    const G4double mass_p  = 0.9383;
    const G4double mass_p2 = mass_p*mass_p;
    const G4double mass_pi = 0.13957;
    const G4double mass_K  = 0.4973;

    G4double mass[] = {mass_pi, mass_pi, mass_K, mass_K, mass_p, mass_p};

    G4double E_gamma = x[0];

    double s = mass_p2 + 2.0*E_gamma*mass_p;

    /*  Wiser's fit    pi+     pi-    k+     k-     p+       p-  */
    G4double A1[] =  {566.,  486.,   368., 18.2,  1.33E5,  1.63E3 };
    G4double A2[] =  {829.,  115.,   1.91, 307.,  5.69E4, -4.30E3};
    G4double A3[] =  {1.79,  1.77,   1.91, 0.98,  1.41,    1.79 };
    G4double A4[] =  {2.10,  2.18,   1.15, 1.83,   .72,    2.24 };
    G4double A6 =  1.90;
    G4double A7 = -.0117;


    // Boost to CoM
    double beta_cm = E_gamma/(E_gamma+mass_p);
    double gamma_cm = 1.0/sqrt(1.0 - beta_cm*beta_cm);

    double p_cm_z = -gamma_cm*beta_cm*sqrt(pf*pf+mass[type]*mass[type])
              +gamma_cm*pf*cos(thf);

    double pT   = pf*sin(thf);
    double p_cm = sqrt( pT*pT + p_cm_z*p_cm_z );
    double Ef = sqrt( p_cm*p_cm + mass[type]*mass[type] );

    double p_cm_max = sqrt(s +pow(M_X*M_X - mass[type]*mass[type],2.0)/s -
     2.0*(M_X*M_X + mass[type]*mass[type]) )/2.0;

    double X_R = p_cm/p_cm_max;

    if( X_R > 1.0 ){ return 0.0; } // Kinematically forbidden


    if( type != 4 ){ // Everything but proton
  return ( A1[type] + A2[type]/sqrt(s) )*
      pow(1.0 - X_R + A3[type]*A3[type]/s, A4[type])/E_gamma;
    } else {
  G4double U_MAN = fabs(2.0*mass_p2 - 2.0*mass_p*Ef);

  return ( A1[type] + A2[type]/sqrt(s) )*
      pow(1.0 - X_R + A3[type]*A3[type]/s, A4[type])/pow(1.0 + U_MAN,A6+A7*s)/E_gamma;
    }

    return 0.0;
}

Here is the caller graph for this function:

G4double wiser_sigma	(	G4double	Ebeam,
		G4double	pf,
		G4double	thf,
		G4double	rad_len,
		G4int	type
	)

Definition at line 12 of file wiser_pion.h.

References wiser_all_fit(), and WISER_VERBOSE.

Referenced by QweakSimEPEvent::Pion_PhotoProduction(), QweakSimEPEvent::Pion_PhotoProductionAl(), and QweakSimEPEvent::Pion_PhotoProductionCarbon().

                                                                                             {
    /*
        Adapted from the infamous Wiser code from Peter Bosted

  Seamus Riordan
  riordan@jlab.org
  September 4, 2012

      type = 0 pi+
         1 pi-
         2 K+
         3 K-
         4 p
         5 p-bar

  type defines the type of particle produced
        Ebeam and pf are the beam energy in GeV and final particle momentum
  in GeV/c respectively thf is the lab angle relative to the beam of
  the produced particle in radians

  rad_len is the *effective* *total* radiator. [not in percent, typically
  called bt in the literature]  This means put in the effective radiator for
  internal radiation BEFORE and AFTER the vertex (total 0.05 for JLab kinematics)
        on top of real radiation lengths from ext brem times 4/3

  Returns the cross section in units of nanobarns/GeV/str
     */

    const int ntype = 6;

    G4double A5[] = {-5.49,  -5.23, -5.91, -4.45, -6.77,  -6.53 };
    G4double A6[] = {-1.73,  -1.82, -1.74, -3.23,  1.90,  -2.45 };

    const G4double mass_p  = 0.9383;
    const G4double mass_p2 = mass_p*mass_p;
    const G4double mass_pi = 0.13957;
    const G4double mass_K  = 0.4973;
    const G4double mass_Lambda  = 1.116;

    G4double mass[] = {mass_pi, mass_pi, mass_K, mass_K, mass_p, mass_p};
    G4double *mass2 = new G4double[ntype];

    int i;
    for( i = 0; i < 6; i++ ){
  mass2[i] = mass[i]*mass[i];
    }

    // Calculate minimum photon energy required to produce such a system
    // with the particle of transverse momentum pf*sin(thf)
    // This is the case where in the CoM frame, the particle and the
    // residual system are going back to back, transverse to the incoming particles
    // and all components of the residual system are at rest relative to one another

    double M_X;// invariant mass of the minimum residual system

    switch( type ){
  // pi+ can just be N
  case 0:
      M_X = mass_p;
      break;
  // pi- needs a pi+ N
  case 1:
      M_X = mass_p + mass_pi;
      break;
  // K+ can be created with just a Lambda, final state
  // NOTE:  This is different from the original Wiser
  // code!  They had just proton mass, but you still have
  // to have an additional strange quark lying around
  // The lowest energy configuration you can have like this
  // is the Lambda
  case 2:
      M_X = mass_Lambda;
      break;
  // p/p-bar production is twice the mass of the proton
  case 4:
  case 5:
      M_X = 2.0*mass_p;
      break;
  default:
      fprintf(stderr, "%s: %s line %d - Forbidden type passed to Wiser parameterization\n",
        __PRETTY_FUNCTION__, __FILE__, __LINE__ );
      exit(1);
      break;
    }

    double MX2  = M_X*M_X;
    double Ef = sqrt(pf*pf + mass2[type]);

    G4double E_gamma_min = ( MX2 - mass2[type] - mass_p2 + 2.0*mass_p*Ef )/
             ( 2.0*( mass_p - Ef + pf*cos(thf) ) );

    // Parameterization parameters
    double pT = pf*sin(thf);
    double ML = sqrt(pT*pT + mass2[type]);

    double sigma, sig_e;
    double fitres;

    if(WISER_VERBOSE)
      G4cout <<"In wiser_pion.h: \n"<< Ebeam <<"\t" << pf << "\t" << thf <<"\t" << rad_len <<"\t" << type << G4endl;

    if(WISER_VERBOSE){
      G4cout << "E_gamma_min:: " << E_gamma_min << G4endl;
      G4cout << "Ebeam:: " << Ebeam << G4endl;
    }

    if( E_gamma_min > 0.0 && E_gamma_min < Ebeam ){

  TF1 *wiserfit = new TF1("wiserfit", wiser_all_fit, E_gamma_min, Ebeam, 5);
  wiserfit->SetParameter(0, Ebeam);
  wiserfit->SetParameter(1, pf);
  wiserfit->SetParameter(2, thf);
  wiserfit->SetParameter(3, (G4double) type);
  wiserfit->SetParameter(4, M_X);

  fitres = wiserfit->Integral(E_gamma_min, Ebeam);

  delete wiserfit;

  if( type != 4 ){
      sig_e = fitres*exp(A5[type]*ML)*exp(A6[type]*pT*pT/Ef);
  } else {
      sig_e = fitres*exp(A5[type]*ML);
  }

  // Factor of 1000 is required for units
  sigma = pf*pf*sig_e*rad_len*1000.0/Ef;

  if(WISER_VERBOSE)
    G4cout << "Pion crsec :: " << sigma << G4endl;

  delete mass2;
  return sigma;
    } else {
  // Kinematically forbidden
      if(WISER_VERBOSE)
  G4cout << "--** Creation of Pions kinematically Forbidden **--" << G4endl;
      delete mass2;
      return 0.0;
    }

    if(WISER_VERBOSE)
      G4cout << "--** No pions. E_gamma is outside the valid range **--" << G4endl;

    delete mass2;
    return 0.0;
}

Here is the call graph for this function:

Here is the caller graph for this function:
